Estate TEDL640AW0 Parts List

Estate tedl640aw0 electric dryer parts list

Advertisement

Quick Links

ELECTRIC DRYER

MODEL
TEDL640AW0
W−White, N−Almond
c
1992 WHIRLPOOL CORPORATION
11−92 Litho in U.S.A.
Part No. 4377008

Advertisement

loading
Need help?

Need help?

Do you have a question about the TEDL640AW0 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Estate TEDL640AW0

  • Page 1: Electric Dryer

    ELECTRIC DRYER MODEL TEDL640AW0 W−White, N−Almond 1992 WHIRLPOOL CORPORATION 11−92 Litho in U.S.A. Part No. 4377008...
  • Page 2 TOP AND CONSOLE PARTS For Model: TEDL640AW0 4377008...
  • Page 3 TOP AND CONSOLE PARTS For Model: TEDL640AW0 Illus. Part Illus. Part Illus. Part DESCRIPTION DESCRIPTION DESCRIPTION 1 3397545 Panel, Rear 339229 Hinge, R.H. 660936 Switch, Console 339230 Hinge, L.H. Push−To−Start 3 3390646 Screw, 688983 Screw, 8−18 x 5/8 692021 (Alt.) 8−18 x 5/16...
  • Page 4: Cabinet Parts

    CABINET PARTS For Model: TEDL640AW0 4377008...
  • Page 5 CABINET PARTS For Model: TEDL640AW0 Illus. Part Illus. Part Illus. Part DESCRIPTION DESCRIPTION DESCRIPTION 690363 Lock, Front 690236 Wire, Ground 690261 Block, Terminal Top (2) (Motor) 238088 Hinge, Top (2) Full Front 2 3393008 Screw, 10−16 x 1/2 691366 Idler & Pulley...
  • Page 6 BULKHEAD PARTS For Model: TEDL640AW0 Illus. Part Illus. Part Illus. Part DESCRIPTION DESCRIPTION DESCRIPTION 694283 Lint Chute Assembly 695547 Box, Heater 695239 Screw, 8−18 x 3/8 98460 Nut, Push−In (2) 15 3390291 Thermostat, 690997 Ring, Tri 686889 Pad, Cabinet High Limit 250 F 347364 Shaft, L.H.
