Page 1: Command Reference
ZXR10 2900E Series Easy-maintenance Secure Switch Command Reference Version: 2.05.10 ZTE CORPORATION NO. 55, Hi-tech Road South, ShenZhen, P.R.China Postcode: 518057 Tel: +86-755-26771900 Fax: +86-755-26770801 URL: http://ensupport.zte.com.cn E-mail: support@zte.com.cn...
Page 2 ZTE CORPORATION is prohibited. Additionally, the contents of this document are protected by contractual confidentiality obligations. All company, brand and product names are trade or service marks, or registered trade or service marks, of ZTE CORPORATION or of their respective owners.
Page 3: Table Of Contents
Contents About This Manual ..................I Chapter 1 Safety Instruction..............1-1 1.1 Safety Instruction ....................1-1 1.2 Safety Signs ...................... 1-1 Chapter 2 Overview ..................2-1 2.1 Command Mode ....................2-1 2.1.1 User Mode....................2-1 2.1.2 Global Configuration Mode ............... 2-2 2.1.3 SNMP Configuration Mode ...............
Page 4 3.9 File Copy ......................3-8 3.10 Formatting flash ....................3-9 3.11 Updating bootrom ..................... 3-9 3.12 Automatically Downloading Software Versions ..........3-10 3.12.1 set dhcp download enable/disable ............3-10 3.13 Automatically Saving Configuration Files............3-10 3.13.1 set auto-saveconfig enable/disable ............3-10 3.13.2 set auto-saveconfig serverip..............3-11 3.13.3 set auto-saveconfig period ..............
Page 5 4.1.26 set user tacacs-plus admin-password ............ 4-15 4.1.27 set user multi-user ................4-15 4.1.28 cpu-threshold ..................4-16 4.1.29 mem-threshold ..................4-17 4.1.30 write ....................4-17 4.1.31 clear user..................... 4-18 4.1.32 clear reboot-time .................. 4-18 4.1.33 terminal monitor ................... 4-18 4.1.34 terminal log ..................4-19 4.1.35 terminal log toFile .................
Page 6 4.1.63 set fan speed ..................4-31 4.1.64 show Etag.................... 4-31 4.1.65 readconfig.................... 4-32 4.1.66 set temperature-alarm ................4-32 4.1.67 set date summer-time ................4-32 4.1.68 show summer-time ................4-33 4.1.69 clear summer-time................4-34 4.1.70 config mac-based-vlan................4-34 4.1.71 syscontact.................... 4-34 4.1.72 terminal record ..................
Page 7 4.3.1 set poe port enable/disable ..............4-52 4.3.2 set poe port pd-max-power ..............4-52 4.3.3 set poe port priority................. 4-53 4.3.4 set poe port forcepower ................4-54 4.3.5 set poe port extend-detection ..............4-55 4.3.6 set poe power maxvalue ................. 4-56 4.3.7 show poe device ..................
Page 8 4.6.3 set vlan voice-vlan qos-profile ..............4-74 4.6.4 set vlan voice-vlan qos-profile disable............4-74 4.6.5 clear vlan voice-vlan ................4-75 4.6.6 clear vlan voice-vlan port oui ..............4-75 4.6.7 clear vlan voice-vlan port oui-id ............... 4-76 4.6.8 show vlan voice-vlan ................4-76 4.6.9 show vlan voice-vlan port................
Page 9 4.7.27 show mac mix ..................4-95 4.7.28 show mac mac-address ................ 4-96 4.7.29 show mac unknown-filter............... 4-97 4.7.30 show mac aging-time................4-97 4.7.31 show mac filter ..................4-98 4.7.32 show mac logging-alarm ............... 4-98 4.7.33 set mac learning except session ............4-99 4.7.34 set mac learning except session unbind ..........
Page 10 4.10.1 set igmp snp enable/disable ..............4-115 4.10.2 set igmp snp add/delete vlan ..............4-115 4.10.3 set igmp snp add/delete maxnum vlan/port ........... 4-116 4.10.4 set igmp snp multicast -ring enable/disable ........... 4-117 4.10.5 set igm snp multicast-ring add/delete cascade port ........ 4-117 4.10.6 set igmp snp monitor-ring enable/disable ..........
Page 11 4.11.8 iptv channel name rename ..............4-140 4.11.9 iptv channel name/id-list cdr ..............4-141 4.11.10 iptv channel name/id-list viewfile-name/id ..........4-141 4.11.11 iptv sms-server ..................4-142 4.11.12 iptv sms-server-port ................4-143 4.11.13 iptv cdr enable/disable ...............4-143 4.11.14 iptv cdr report ..................4-144 4.11.15 iptv cdr create-period .................4-144 4.11.16 iptv cdr deny-right ................4-145 4.11.17 iptv cdr prv-right.................4-146 4.11.18 iptv cdr report-threshold ..............4-146...
Page 12 4.11.45 show iptv control................4-164 4.11.46 show iptv channel ................4-165 4.11.47 show iptv channel-group..............4-167 4.11.48 show iptv package ................4-169 4.11.49 show iptv prv ..................4-170 4.11.50 show iptv view-profile .................4-171 4.11.51 show iptv cdr ..................4-172 4.11.52 show iptv client ..................4-173 4.11.53 show iptv rule ..................4-174 4.11.54 show iptv duplicate ................4-175 4.12 STP Configuration ..................4-176 4.12.1 set stp enable/disable ................4-176...
Page 13 4.12.27 clear stp instance port/trunk cost ............4-192 4.12.28 clear stp name...................4-192 4.12.29 show stp ...................4-193 4.12.30 show stp instance ................4-193 4.12.31 show stp port..................4-194 4.12.32 show stp trunk ...................4-195 4.13 ACL Configuration ..................4-196 4.13.1 set port acl mode.................4-196 4.13.2 set port acl enable/disable..............4-196 4.13.3 set vlan acl enable/disable ..............4-197 4.13.4 set acl rule time-range enable/disable ...........4-198 4.13.5 create acl name...................4-198...
Page 14 4.13.31 ingress-acl hybrid rule type-any ............4-223 4.13.32 ingress-acl hybrid rule type-ipv6-ip-protocol.........4-224 4.13.33 ingress-acl hybrid rule type-ipv6-tcp............4-225 4.13.34 ingress-acl hybrid rule type-ipv6-udp...........4-226 4.13.35 ingress-acl hybrid rule type-ipv6-any ...........4-228 4.13.36 ingress-acl hybrid rule type-all ............4-229 4.13.37 clear ingress-acl hybrid ..............4-229 4.13.38 config ingress-acl global..............4-230 4.13.39 ingress-acl global rule type-ip-protocol ..........4-230 4.13.40 ingress-acl global rule type-ip .............4-232 4.13.41 ingress-acl global rule type-tcp ............4-233...
Page 15 4.13.68 egress-acl hybrid rule type-ipv6-any............4-261 4.13.69 egress-acl hybrid rule type-ipv6-ip-protocol .........4-262 4.13.70 egress-acl hybrid rule type-ipv6-tcp.............4-263 4.13.71 egress-acl hybrid rule type-ipv6-udp ...........4-265 4.13.72 egress-acl hybrid rule type-tcp............4-266 4.13.73 egress-acl hybrid rule type-udp............4-268 4.13.74 clear egress-acl hybrid ...............4-270 4.13.75 move after/before ................4-270 4.13.76 clear rule...................4-271 4.13.77 show vlan-range ................4-271 4.13.78 show acl blinding ................4-272...
Page 16 4.14.24 set qos traffic-shaping fe-port queue data-rate ........4-291 4.14.25 set qos traffic-shaping ge-port data-rate ..........4-292 4.14.26 set qos traffic-shaping ge-port queue data-rate ........4-293 4.14.27 set qos traffic-shaping xge-port data-rate ..........4-293 4.14.28 set qos traffic-shaping xge-port queue data-rate ........4-294 4.14.29 set anti-dos ..................4-295 4.14.30 show qos priority-mapping port ............4-295 4.14.31 show qos priority-mapping qos-profile ..........4-296 4.14.32 show qos queue-schedule mode ............4-298...
Page 17 4.14.61 clear qos policer ................4-315 4.14.62 show qos policer................4-316 4.14.63 show qos policy-counter..............4-317 4.14.64 show qos policer-counter ..............4-317 4.14.65 show policy ..................4-318 4.14.66 set icmp protect .................4-318 4.14.67 set qos traffic-limit ge-port|fe-port protect..........4-319 4.14.68 set qos traffic-limit ge-port|fe-port protect time ........4-320 4.14.69 show qos traffic-limit protect time ............4-320 4.15 PVLAN Configuration..................4-321 4.15.1 set vlan pvlan session................4-321...
Page 18 4.17.20 show hardware-iproute...............4-337 4.18 IPv6 Layer 3 Configuration................4-337 4.18.1 set ipv6port vlan ..................4-337 4.18.2 set ipv6port ipv6address ..............4-338 4.18.3 set ipv6port enable/disable..............4-339 4.18.4 ipv6route default..................4-339 4.18.5 clear ipv6port ..................4-340 4.18.6 clear ipv6route default .................4-340 4.18.7 show ipv6port..................4-340 4.18.8 show ipv6route ..................4-341 4.18.9 show ipv6port nd .................4-341 4.18.10 ping6 ....................4-342 4.19 DAI Configuration ..................4-343...
Page 19 4.20.19 aaa-control port dot1x ................4-357 4.20.20 aaa-control port port-mode ..............4-357 4.20.21 aaa-control port protocol ..............4-358 4.20.22 aaa-control port accounting ..............4-359 4.20.23 aaa-control port multiple-hosts............4-359 4.20.24 aaa-control port max-hosts..............4-360 4.20.25 aaa-control port keepalive ..............4-361 4.20.26 aaa-control port keepalive period ............4-361 4.20.27 aaa-control port keepalive antiproxy add/delete ........4-362 4.20.28 aaa-control port keepalive antidhcp.............4-363 4.20.29 aaa-control port keepalive client-ip............4-364 4.20.30 show aaa-control port ................4-364...
Page 20 4.22.2 set syslog level..................4-379 4.22.3 set syslog add server................4-380 4.22.4 set syslog delete server ...............4-380 4.22.5 set syslog enable/disable ..............4-381 4.22.6 show syslog status ................4-381 4.23 NTP Configuration ..................4-382 4.23.1 set ntp add authentication-key..............4-382 4.23.2 set ntp delete authentication-key ............4-383 4.23.3 set ntp add trusted-key ................4-383 4.23.4 set ntp authenticate ................4-384 4.23.5 set ntp server ..................4-384...
Page 21 4.25.11 set dhcp option82 mode port ..............4-402 4.25.12 clear dhcp snp-bind-entry mac............4-402 4.25.13 clear dhcp option82 sub-option device ani ...........4-403 4.25.14 show dhcp ..................4-403 4.25.15 show dhcp snooping ................4-404 4.25.16 show dhcp snooping binding ..............4-404 4.25.17 show dhcp ip-source-guard ..............4-405 4.25.18 show dhcp option82................4-406 4.25.19 show dhcp option82 port ..............4-406 4.25.20 show dhcp option82 device ..............4-407...
Page 22 4.26.11 set dhcpv6 option82 ani ..............4-423 4.26.12 set dhcpv6 option82 sub-option ............4-423 4.26.13 clear dhcpv6 snp-bind-entry mac ............4-424 4.26.14 clear dhcpv6 option82 ani ..............4-424 4.26.15 show dhcpv6 ..................4-425 4.26.16 show dhcpv6 snooping...............4-425 4.26.17 show dhcpv6 snooping binding............4-426 4.26.18 show dhcpv6 ip-source-guard.............4-427 4.26.19 show dhcpv6 option82 ...............4-427 4.26.20 show dhcpv6 option82 port..............4-428 4.26.21 show dhcpv6 option82 ani ..............4-428...
Page 23 4.29.12 set zesr linkhello-timer linkhello-failtimer..........4-443 4.29.13 set zesr linkhello enable/disable ............4-444 4.29.14 set zesr domain enable/disable ............4-444 4.29.15 set zesr domain major-level mode ............4-445 4.29.16 set zesr domain level segment mode ..........4-445 4.29.17 set zesr domain tcn................4-446 4.29.18 set zesr tcn-sending port ..............4-446 4.29.19 set zesr tcn-sending trunk ..............4-447 4.29.20 set zesr protocol-mac.................4-448 4.29.21 clear zesr domain ................4-448...
Page 24 4.32.3 clear vlan mapping session ..............4-466 4.32.4 clear vlan mapping user ...............4-467 4.32.5 clear vlan mapping user session............4-467 4.32.6 show vlan mapping................4-467 4.32.7 show vlan mapping session..............4-468 4.32.8 show vlan mapping user-table ..............4-468 4.32.9 show vlan mapping user-table session..........4-468 4.33 SFlow Configurations..................4-469 4.33.1 set sflow agent-address ...............4-469 4.33.2 set sflow collector-address ..............4-470 4.33.3 set sflow version..................4-470...
Page 25 4.35.2 lldp holdtime..................4-486 4.35.3 lldp max-neighbor................4-487 4.35.4 lldp port/trunk enable/disable..............4-488 4.35.5 lldp port/trunk txenable/txdisable ............4-488 4.35.6 lldp port/trunk rxenable/rxdisable ............4-489 4.35.7 lldp port med-tlv-select.................4-489 4.35.8 lldp port/trunk max-neighbor..............4-490 4.35.9 clear lldp neighbor ................4-490 4.35.10 clear lldp statistic ................4-491 4.35.11 show lldp config .................4-491 4.35.12 show lldp neighbor................4-492 4.35.13 show lldp entry ..................4-493 4.35.14 show lldp statistic ................4-494...
Page 26 4.38.3 set loopdetect port ................4-509 4.38.4 set loopdetect port vlan................4-510 4.38.5 set loopdetect port protect..............4-511 4.38.6 set loopdetect extend port ..............4-511 4.38.7 set loopdetect trunk ................4-512 4.38.8 set loopdetect trunk vlan ..............4-512 4.38.9 set loopdetect trunk protect ..............4-513 4.38.10 set loopdetect extend trunk ..............4-514 4.38.11 show loopdetect.................4-514 4.38.12 show loopdetect port................4-515...
Page 27 4.40.14 clear tacacs-plus accounting update ...........4-529 4.40.15 show tacacs-plus ................4-529 4.41 Time Range Configuration ................4-530 4.41.1 set time-range period................4-530 4.41.2 set time-range absolute ...............4-531 4.41.3 clear time-range ..................4-531 4.41.4 show time-range..................4-532 4.42 MAC BASED VLAN Configuration ..............4-533 4.42.1 mac based vlan rule ................4-533 4.42.2 clear mac based vlan rule ..............4-533 4.42.3 mac based vlan bind................4-534 4.42.4 show vlan mac based session ..............4-534...
Page 28 4.44.10 cfm mep state ...................4-549 4.44.11 cfm mep ccm-send state ..............4-550 4.44.12 cfm ccm-receive state ................4-551 4.44.13 cfm mep priority.................4-551 4.44.14 cfm mep alarm-lowest-priority.............4-552 4.44.15 cfm mep assign port/trunk ..............4-553 4.44.16 cfm mip assign port/trunk ..............4-554 4.44.17 clear cfm md ..................4-554 4.44.18 clear cfm ma ..................4-555 4.44.19 clear cfm mep ...................4-555 4.44.20 clear cfm mip..................4-556...
Page 29 5.1 REMOTE-ACCESS .................... 5-1 5.1.1 set remote-access any/specific..............5-1 5.1.2 set remote-access ipaddress permit/deny ..........5-2 5.1.3 clear remote-access all ................5-3 5.1.4 clear remote-access ipaddress..............5-3 5.1.5 show remote-access................. 5-4 5.2 PRIVILEGE......................5-4 5.2.1 privilege enable/disable ................5-4 5.2.2 privilege session ..................5-5 5.2.3 clear privilege...................
Page 30 5.4.22 show snmp ..................5-22 5.4.23 show snmp community/engineID/group/host/trap/user/view..... 5-24 5.5 RMON ......................5-26 5.5.1 set rmon enable/disable................5-26 5.5.2 set statistics ................... 5-27 5.5.3 set alarm ....................5-28 5.5.4 set event....................5-29 5.5.5 set history ....................5-30 5.5.6 show rmon..................... 5-32 5.5.7 show statistics..................
Page 31 5.6.24 set group delete member ..............5-50 5.6.25 set group handtime................5-50 5.6.26 set group holdtime ................5-51 5.6.27 set group name ..................5-51 5.6.28 set group mac-mode................5-52 5.6.29 set group syslogsvr................5-52 5.6.30 set group tftpsvr ................... 5-53 5.6.31 show group ..................
Page 33: About This Manual
About This Manual Purpose This manual is ZXR10 2900E (V2.05.10) Series Switch Command Reference. It is applicable to ZXR10 2900E (V2.05.10) series easy-maintenance secure switches (called ZXR10 2910E-PS/2918E-PS/2918E/2928E-PS/2928E/2952E and shortened as ZXR10 2900E series, and called "switches" in general description). It includes: ZXR10 2910E-PS easy-maintenance secure switch ZXR10 2918E-PS easy-maintenance secure switch ZXR10 2918E easy-maintenance secure switch...
Page 35: Safety Instruction
So take care to use debug commands. It is not recommended to use the debug commands when the user networks are in normal state. ZTE Corporation will assume no responsibility for consequences resulting from violation of general specifications for safety operations or of safety rules for design, production and use of the devices.
Page 36 ZXR10 2900E Series Command Reference Note: Indicates the description, hint, tip and so on for configuration operations. SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 37: Chapter 2 Overview
The prompt for user mode is the host name of the router followed with “>”, which is shown as below: zte> The default host name is zte, user can use hostname <name> (the length of name cannot exceed 200 characters) to change host name. SJ-20120409144109-003|2012-07-02(R1.0)
Page 38: Global Configuration Mode
ZXR10 2900E Series Command Reference At user mode, user can implement the exit command to exit the switch configuration and the show command to check the configuration information and running information of the system. Note: show can be used in all modes.
Page 39: File System Configuration Mode
2.1.8 Basic Ingress ACL Configuration Mode At global configuration mode, execute the config ingress-acl basic number <1-99> command to enter basic ingress ACL configuration mode, which is shown as below: zte(cfg)#config ingress-acl basic number 10 zte(ingress-basic-acl)# SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 40: Extended Ingress Acl Configuration Mode
ZXR10 2900E Series Command Reference At basic ingress ACL configuration mode, the basic ingress ACL rule with specified ACL number can be added, deleted and removed. To return to global configuration mode from ACL configuration mode, execute the exit command or press <Ctrl+Z>.
Page 41: Basic Egress Acl Configuration Mode
At global configuration mode, execute the config egress-acl basic number <400-499> command to enter basic egress ACL configuration mode, which is shown as below: zte(cfg)#config egress-acl basic number 400 zte(egress-basic-acl)# At basic egress ACL configuration mode, the basic egress ACL rule with specified ACL number can be added, deleted and removed.
Page 42: Hybrid Egress Acl Configuration Mode
ZXR10 2900E Series Command Reference 2.1.16 Hybrid Egress ACL Configuration Mode At global configuration mode, execute the config egress-acl hybrid number <700-799> command to enter hybrid egress ACL configuration mode, which is shown as below: zte(cfg)#config egress-acl hybrid number 700...
Page 43 Digits of the IP address and mask. “M” is an integer ranging from 1 to 32, for example, 10.40.47.254/24. <string> A character string without space. <mib-oid> Variable number in dotted decimal notation, for example, 1.3.6.2.19.2. <name> A character string without space. <sessionlist> Session list. SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 44 ZXR10 2900E Series Command Reference This page intentionally left blank. SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 45: Chapter 3 File System Configuration
3.1 Creating a Directory Purpose Creates a directory. Command Mode File system configuration mode Syntax md <directory name> Parameter Description Parameter Description <directory name> Directory name Example The following example describes how to create the temp directory. zte(cfg-tffs)#ls SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 46: Deleting A File Or A Directory
ZXR10 2900E Series Command Reference <DIR> <DIR> <DIR> <DIR> data <DIR> lost+found <DIR> 254,132,224 bytes free zte(cfg-tffs)#md temp Done ! zte(cfg-tffs)#ls <DIR> temp <DIR> <DIR> <DIR> data <DIR> lost+found <DIR> 254,132,224 bytes free 3.2 Deleting a File or a Directory Purpose Deletes a file or a directory.
Page 47: Changing The Name Of A File Or A Directory
Modifies the name of a file or a directory. Command Mode File system configuration mode Syntax rename <file-name><file-name> Parameter Description Parameter Description <file-name>(First) Source file name or directory name <file-name>(Second) Destination file name or directory name SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 48: Displaying Sub Directory And File
ZXR10 2900E Series Command Reference Example The following example describes how to change to_permmac.dat to permanent_mac .dat. zte(cfg-tffs)#ls /cfg <DIR> <DIR> to_permmac.dat 98,304 bytes 254,132,224 bytes free zte(cfg-tffs)#rename to_permmac.dat permanent_mac.dat Done ! zte(cfg-tffs)#ls /cfg <DIR> <DIR> permanent_mac.dat 98,304 bytes 254,132,224 bytes free zte(cfg-tffs)# 3.4 Displaying Sub Directory and File...
Page 49: Tftp Uploading And Downloading A File
<DIR> <DIR> <DIR> data <DIR> lost+found <DIR> 254,132,224 bytes free zte(cfg-tffs)#cd temp zte(cfg-tffs)#ls /temp <DIR> <DIR> 254,132,224 bytes free 3.6 TFTP Uploading and Downloading a File Purpose Uploads or downloads a file through TFTP server. SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 50 ZXR10 2900E Series Command Reference Command Mode File system configuration mode Syntax tftp <A.B.C.D> upload <local-file-name>[<remote-file-name>] tftp <A.B.C.D> download <remote-file-name>[<local-file-name>] Parameter Description Parameter Description <A.B.C.D> Server IP address. Downloads a file from the server to local Flash. download Uploads a local file to the server.
Page 51: Tftp Uploading And Downloading Files To Cluster Commander
3 interface support. 3.8 Uploading/Downloading Files Through FTP Purpose Uploads files to and downloads files from the FTP server. Command Mode File system configuration mode Syntax ftp <A.B.C.D><remote-file-name>{download|upload}<local-file-name> username <string> pa ssword <string> SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 52: File Copy
ZXR10 2900E Series Command Reference Parameter Description Parameter Description Downloads file from commander to the local flash download Uploads local file to commander upload See the same parameter in "TFTP Uploading and Downloading <local-file-name> a File". See the same parameter in "TFTP Uploading and Downloading <remote-file-name>...
Page 53: Formatting Flash
Be cautious to perform this operation. 3.11 Updating bootrom Purpose Updates Bootrom. Command Mode File system configuration mode Syntax update bootrom Usage Guidelines Before updating bootrom, back up important files to the back-end server. SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 54: Automatically Downloading Software Versions
ZXR10 2900E Series Command Reference 3.12 Automatically Downloading Software Versions 3.12.1 set dhcp download enable/disable Purpose Enables/Disables the automatic download function for DHCP client. Command Mode Global configuration mode Syntax set dhcp download{enable | disable} Parameters Parameter Description Enables the function.
Page 55: Set Auto-Saveconfig Serverip
0 again. Usage Guidelines Execute this command before executing the set auto-saveconfig enable command. Default The IP of a TFTP server is 0.0.0.0. 3-11 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 56: Set Auto-Saveconfig Period
ZXR10 2900E Series Command Reference 3.13.3 set auto-saveconfig period Purpose Configures the interval in days that the switch automatically uploads configuration files. Command Mode Global configuration mode Syntax set auto-saveconfig period <1-30> Parameter Parameter Description Period that the switch automatically uploads configuration files, <1-30>...
Page 57: Chapter 4 Service Configuration
DHCPv6 Configuration ...................4-416 VBAS Configuration ....................4-430 PPPoE-PLUS Configuration ...................4-432 ZESR Configuration ....................4-436 OAM Configuration....................4-450 SQinQ Configuration ....................4-463 VLAN Mapping Configuration .................4-465 SFlow Configurations .....................4-469 PP Configurations ....................4-476 LLDP Configurations ....................4-486 MLD Configuration ....................4-494 PoE Configuration ....................4-507 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 58: Management Configuration
ZXR10 2900E Series Command Reference Single-Port Loop Detection Configuration ...............4-508 UDLD Configuration ....................4-517 TACACS+ Configuration..................4-523 Time Range Configuration..................4-530 MAC BASED VLAN Configuration ................4-533 Y.1731 Configuration ....................4-535 802.1AG Configuration ...................4-543 DHCP relay Configuration ..................4-561 4.1 Management Configuration 4.1.1 config group Purpose Enters cluster management configuration mode.
Page 59: Config Tffs
4.1.5 config nas Purpose Enters the access service configuration mode. Command Mode Global configuration mode Syntax config nas 4.1.6 exit Purpose Exits from the current mode to the previous mode. Command Mode All Modes Syntax exit SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 60: Enable
ZXR10 2900E Series Command Reference Usage Guidelines At user mode (zte), execute the exit command to return to login interface. 4.1.7 enable Purpose Enters the global configuration mode from the user mode. Command Mode User mode Syntax enable Instructions After the enable command is executed, the system prompts the user to enter the management password.
Page 61: Line-Vty Timeout
Global configuration mode Syntax line-vty timeout <1-12> Parameter Parameter Description – <1 Timeout time. The unit is minute. 12> Defaults 10 minutes 4.1.11 set date Purpose Configures switch date and time. Command Mode Global configuration mode SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 62: Hostname
ZXR10 2900E Series Command Reference Syntax set date <yyyy-mm-dd> time <hh:mm:ss> Parameters Parameter Description <yyyy-mm-dd> Date (year/month/day). Year range: 2004~2037 Usage Guidelines After the switch is restarted, the date and time requires to be reconfigured. The switch automatic synchronization time function can be configured by NTP. For NTP configuration, refer to “NTP Configuration”.
Page 63: Syslocation
The following example describes how to configure the length of host name as 3. hello(cfg)# hello(cfg)#promptlen 3 hel(cfg)# 4.1.14 sysLocation Purpose Use this command to set the location information about the switch. Command Mode Global configuration mode Syntax sysLocation <string> Parameter Parameter Description <string> Location of the switch SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 64: Reboot
ZXR10 2900E Series Command Reference 4.1.15 reboot Purpose Use this command to restart the switch. Command Mode Global configuration mode Syntax reboot 4.1.16 reboot-time Purpose Configures the reboot of the switch at some time. Command Mode Global configuration mode Syntax reboot-time <hh:mm>...
Page 65: Create User
Usage Guidelines Four accounts can be created in total (includes admin default management account). Example The following example describes how to create a user with the name "userx" and guest authority. zte(cfg)#create user userx guest SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 66: Set Loginauth
ZXR10 2900E Series Command Reference 4.1.19 set loginauth Purpose Sets the login authentication mode. Command Mode Global configuration mode Syntax set loginauth {local | radius|local+radius|radius+local|tacacs-plus| local+tacacs-plus | tacacs- plus+local } Parameters Parameter Description Sets local authentication for the login user.
Page 67: Set Adminauth
Example The following example describes how to configure the login password of local user with the name “username” as ok. zte(cfg)#set user local username admin login-password ok 4.1.21 set adminauth Purpose Configures the management authentication mode.
Page 68: Set User Local Admin-Password
Example The following example describes how to set the management password of local user with name “username” as ok. zte(cfg)#set user local username admin admin-password ok 4.1.23 set user radius purview Purpose Sets RADIUS authentication user login authority.
Page 69: Set User Radius Admin-Password
(">"). Default admin Example The following example describes how to set RADIUS authentication user to has management authority. zte(cfg)#set user radius purview admin 4.1.24 set user radius admin-password Purpose Sets RADIUS authentication user management password. Command Mode Global configuration mode Syntax set user radius admin-password [<string>]...
Page 70: Set User Tacacs-Plus Purview
ZXR10 2900E Series Command Reference Usage Guidelines If admin-password is directly entered without any parameter, it indicates that the login password is set to null. Example The following example describes how to set RADIUS authentication user management password as ok.
Page 71: Set User Tacacs-Plus Admin-Password
If no parameter is specified after admin-password, it indicates that the management password is null. Example The following example describes how to set the management password of a TACACS+ user to "ok". zte(cfg)#set user tacacs-plus admin-password ok 4.1.27 set user multi-user Purpose Enables/Disables the multi-user login. Command Mode...
Page 72: Cpu-Threshold
ZXR10 2900E Series Command Reference Parameters Parameter Description Enables the multi-user login. enable Disables the multi-user login. disable Default Disables the multi-user login. Example The following example describes how to enable the multi-user login. zte(cfg)#set user radius admin-password ok 4.1.28 cpu-threshold Purpose Configures the alarm threshold of CPU utilization ratio.
Page 73: Mem-Threshold
The following example describes how to configure the alarm threshold of memory utilization ratio to 70%. zte(cfg)#mem-threshold 70 4.1.30 write Purpose Saves the current configuration information in flash. Command Mode Global configuration mode Syntax write 4-17 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 74: Clear User
ZXR10 2900E Series Command Reference 4.1.31 clear user Purpose Deletes one user. Command Mode Global configuration mode Syntax clear user <name> Parameter Parameter Description <name> User name Usage Guidelines Admin default user cannot be deleted. Example The following example describes how to delete the user with name “userx”.
Page 75: Terminal Log
Usage Guidelines Record the log information in RAM. If it requires to be saved to Flash, use the commands such as toFile/timer. 4.1.35 terminal log toFile Purpose Saves the log in RAM to Flash. 4-19 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 76: Terminal Log Timer
ZXR10 2900E Series Command Reference Command Mode Global configuration mode Syntax terminal log toFile Usage Guidelines The file saved in Flash is /data/terminal_log.dat. When the device is rebooted, ter minal_log.dat will be backed up to terminal_log_backup.dat automatically. The action will cover the terminal_log_backup.dat of last backup. Therefore modify term inal_log_backup.dat file name at bootManager interface automatically if necessary.
Page 77: Show Terminal Log Include
Parameter Description Key word included in the log to be searched. Spaces are not <string> supported. Example The following example describes how to view all port LinkUp event logs. zte(cfg)#show terminal log include linkup 4-21 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 78: Show Reset-Time
ZXR10 2900E Series Command Reference 4.1.39 show reset-time Purpose Shows switch console automatic logout time configuration. Command Mode All modes Syntax show reset-time 4.1.40 show line-vty Purpose Shows telnet user login timeout time configuration information. Command Mode All modes Syntax show line-vty 4.1.41 show loginauth...
Page 79: Show Terminal
Shows the terminal log information saved in RAM. Command Mode All modes Syntax show terminal log 4.1.45 clear terminal-log Purpose Clears terminal log information and the terminal_log.dat file in Flash memory. Command Mode Global configuration mode 4-23 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 80: Terminal Monitor Module
ZXR10 2900E Series Command Reference Syntax clear terminal-log Usage Guidelines When clearing terminal log information, you are prompted whether to delete the terminal_log.dat file. If you select "Yes", the file as well as the terminal log information in Flash memory are deleted. Otherwise, the system directly returns to global configuration mode.
Page 81: Terminal Log Module
Use this command to write logs in RAM. To save the logs in Flash memory, use the toFile/timer command. 4.1.48 show user Purpose Shows the user and current login user information configured on the switch. 4-25 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 82: Show Version
MAC address, PCB version and EPLD version. Example The following example describes how to show system information. zte(cfg)#show version ZXR10 Router Operating System Software, ZTE Corporation: ZXR10 2929E Version Number : 2900E Series V2.05.10.05 Copyright (c) 2001-2012 By ZTE Corporation...
Page 83: Show Running-Config
4.1.51 show start-config Purpose Displays all non-default configurations of the system saved at last time. Command Mode All modes Syntax show start-config 4.1.52 show date-time Purpose Shows the current date and time. Command Mode All modes 4-27 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 84: Show Reboot-Time
ZXR10 2900E Series Command Reference Syntax show date-time Usage Guidelines If the date and time are not configured, the time starts from 00:00 2004-07-01 by default. 4.1.53 show reboot-time Purpose Displays automatic reboot configuration. Command Mode All modes Syntax show reboot-time 4.1.54 show cpu...
Page 85: Show Fan
Purpose Displays the device power. Command Mode All modes Syntax show power 4.1.58 show bootpassword Purpose Displays the plain text of the password for entering boot mode. Command Mode All modes Syntax show bootpassword 4-29 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 86: Set Bootpassword
ZXR10 2900E Series Command Reference 4.1.59 set bootpassword Purpose Sets the password for entering boot mode. Command Mode Golbal configuration modes Syntax set bootpassword to <string> Usage Guidelines <string>The password must contain 8 characters. 4.1.60 set bootpassword clear Purpose Clears the password for entering boot mode.
Page 87: Set Fan Mode Manual
This command is valid for all 29E series switches except 2910E-PS and 2918E-PS. The parameter value is in the range of 0-3. 4.1.64 show Etag Purpose Displays the electric tag of a device. Command Mode All modes Syntax show Etag 4-31 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 88: Readconfig
ZXR10 2900E Series Command Reference 4.1.65 readconfig Purpose Reads local files of a switch as its configuration. Command Mode Golbal configuration modes Syntax readconfig <filename> 4.1.66 set temperature-alarm Purpose Sets the threshold of switch overheat alarms. The unit is centigrade. The default value is...
Page 89: Show Summer-Time
2. The following example describes how to set the DST period to 0:00 in the first Monday in June 2012 to 0:00 in the last Sunday in Octobor 2012. zte(cfg)#set date summer-time one-year week 1st monday 6 2012 00:00:00 last sunday 10 2012 4.1.68 show summer-time Purpose Display DST configuration.
Page 90: Clear Summer-Time
ZXR10 2900E Series Command Reference 4.1.69 clear summer-time Purpose Clears DST configuration. Command Mode Golbal configuration modes Syntax clear summer-time 4.1.70 config mac-based-vlan Purpose Enters MAC based VLAN configuration mode to configure a rule of a session. Command Mode Golbal configuration modes Syntax config mac-based-vlan session <1-64>...
Page 91: Port Configuration
: on terminal record status record time : Thu Jul 1 00:27:14 2004 record user : admin command line : terminal record on zte(cfg)# 4.2 Port Configuration 4.2.1 set port enable/disable Purpose Enables/Disables a port. 4-35 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 92: Set Port Work-Mode
ZXR10 2900E Series Command Reference Command Mode Global configuration mode Syntax set port <portlist>{enable | disable} Parameters Parameter Description <portlist> Port list enable Enables a port Disables a port disable Usage Guidelines By default, the port is enabled. It has nothing with combo port optical-electrical state.
Page 93: Set Port Speedadvertise
For example, the GE port is configured as speed100/fullduplex, port will negotiate with the peer port at speed100/fullduplex. When maxspeed is configured, for 100M port, it is 100M/fullduplex, for 1000M port, it is 1000M/fullduplex. 4-37 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 94: Set Port Duplex
ZXR10 2900E Series Command Reference Default By default, maxspeed is selected. 4.2.4 set port duplex Purpose Sets the working mode of a port to full duplex/half duplex. Command Mode Global configuration mode Syntax set port <portlist> duplex {full | half | auto}...
Page 95: Set Port Mdix
By default, the port rate is decided by negotiation. Example The following example describes how to set the rate of ports 1, 5, 6, 7 and 11 to 10 Mbps. zte(cfg)#set port 1,5-7,11 speed 10 4.2.6 set port mdix Purpose Configures line sequence identification function.
Page 96: Set Port Flowcontrol
ZXR10 2900E Series Command Reference Usage Guidelines Only copper mode port supports MDIX function. Default By default, auto is selected. 4.2.7 set port flowcontrol Purpose Enables/Disables port flow control function. Command Mode Global configuration mode Syntax set port <portlist> flowcontrol {enable | disable}...
Page 97: Set Port Accept-Frame
Usage Guidelines Port description information is no more than 200 characters. Example The following example describes how to set port 1 description. zte(cfg)#set port 1 description aaaa 4.2.9 set port accept-frame Purpose Configures the message type received by the port.
Page 98: Set Jumbo Port
ZXR10 2900E Series Command Reference Default By default, the message type is all. 4.2.10 set jumbo port Purpose Enables/Disables jumbo frame function. Command Mode Global configuration mode Syntax set jumbo port <portlist>{enable | disable } Parameters Parameter Description <geportlist> GE port...
Page 99: Set Port Statistics Mode
Affect counting statistics of some ports, such as 64 bytes message, 65~127 bytes message and have no influence on the statistics of receiving and sending messages. Default By default, ingress is selected.. 4.2.13 set sleep-mode Purpose Enables/Disables port sleep-mode. Command Mode Global configuration mode 4-43 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 100: Create Port Name
ZXR10 2900E Series Command Reference Syntax set sleep-mode {enable | disable} Parameters Parameter Description enable Enables port sleep-mode disable Disables port sleep-mode Default By default, port sleep-mode is disabled. 4.2.14 create port name Purpose Creates a port name. Command Mode...
Page 101: Clear Port
Clears the multicast filtering enable/disable flag and restores the default multicast-filter state. Example The following example describes how to clear names of ports 1, 5, 6, 7 and 11. zte(cfg)#clear port 1,5-7,11 name 4.2.16 show port Purpose Displays port configuration and the working status. Command Mode...
Page 102: Show Port Statistics
ZXR10 2900E Series Command Reference Usage Guidelines The port name and description are not displayed if they are not configured. In addition, commands without any parameter indicate that the configurations of all the ports are displayed. Example The following example describes how to display the configuration and working status of ports 1.
Page 103: Show Port Utilization
Parameter Description <portlist> Port list Usage Guidelines None Example The following example describes how to display the traffic statistics of port 1. zte(cfg)#set port 1 unit-statistics enable zte(cfg)#show port 1 utilization PortId: 1 PortName: Port rate : input 0Kbps,output: 0Kbps...
Page 104: Show Port Vlan
ZXR10 2900E Series Command Reference Command Mode All modes Syntax show port <portlist> brief Parameter Parameter Description <portlist> Port list Usage Guidelines One end is auto-negotiation port, another end is forced speed port. The interconnection result is as follows: Forced speed port...
Page 105: Show Jumbo
Parameters Parameter Description <portlist> Port list Example The following example describes how to show the VLAN to which port 2 belongs. zte(cfg)#show port 2 vlan PortId Tagged in vlan : 30 Untagged in vlan : 1-2,100 4.2.21 show jumbo Purpose Shows port jumbo configuration information.
Page 106: Show Cable-Diag
ZXR10 2900E Series Command Reference Parameter Parameter Description <portid> ID of a port Usage Guidelines Only copper mode port supports VCT detection. 4.2.23 show cable-diag Purpose Displays the port number, up/down state, and virtual line detection results of ports. Command Mode...
Page 107: Set Port Protect Time
Port list. <1-10> Port protection period, in minutes. Default 10 minutes Example The following example describes how to configure the port protection period for ports 1 and 5. zte(cfg)#set port 1,5 protect time 3 4-51 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 108: Poe Configuration
ZXR10 2900E Series Command Reference 4.3 POE Configuration 4.3.1 set poe port enable/disable Purpose Enables/Disables port POE function. Command Mode Global configuration mode Syntax set poe port <portlist>{enable | disable} Parameters Parameter Description <portlist> Port list Enables POE function enable...
Page 109: Set Poe Port Priority
The default value is standard power 15.4 W. Example The following example describes how to configure the maximum power of port 1, port 3 and port 5 as 30 W. zte(cfg)#set poe port 1/1,1/3,1/5 pd-max-power ext.30 4.3.3 set poe port priority Purpose Configures POE priority.
Page 110: Set Poe Port Forcepower
ZXR10 2900E Series Command Reference Parameter Description The highest priority critical high High priority Low priority Usage Guidelines The priority includes critical, high and low (from high to low). When the priority is same, the port with small port number has higher priority. The total power of the port whose priority is critical cannot exceed the total power of the device.
Page 111: Set Poe Port Extend-Detection
Default Forcepower function is disabled. Example The following example describes how to enable the forcepower function of port 1. zte(cfg)#set poe port 1/1 forcepower enable 4.3.5 set poe port extend-detection Purpose Enables/Disables port extend-detection function. Command Mode...
Page 112: Set Poe Power Maxvalue
Example The following example describes how to configure integrated equipment maximum output power as 100 W and protection threshold as 15 W. zte(cfg)#set poe power maxvalue 100 threshold 15 4.3.7 show poe device Purpose Shows device POE state information.
Page 113: Show Poe Status
Port list. The command without parameters will display all port <portlist> states. Example The following example describes how to show the POE state information of port 1 and port zte(cfg)#show poe status port 1/1-2 port: 1/1 power up : off power device...
Page 114: Show Poe Config
ZXR10 2900E Series Command Reference avgerage-power : 0 watt peak-power : 0 watt port: 1/2 power up : off power device : disabled power device type : open(no load) 802.3af classification : unknown current-power : 0 watt avgerage-power : 0 watt...
Page 115: Port Mirroring
Example The following example describes how to add the egress mirroring source ports 1, 5, 6, 7 and 12. zte(cfg)#set mirror add source-port 1,5-7,12 egress 4.4.2 set mirror session add dest-port Purpose Adds ingress/egress mirroring (destination) port according to session and enables RSPAN function on the mirroring port.
Page 116: Set Mirror Session Delete Source-Port
Example The following example describes how to configure ingress mirroring port 1. zte(cfg)#set mirror session 1 add dest-port 1 ingress 4.4.3 set mirror session delete source-port Purpose Deletes an ingress/egress mirroring port according to session. Command Mode...
Page 117: Set Mirror Session Delete Dest-Port
Chapter 4 Service Configuration zte(cfg)#set mirror session 1 delete source-port 1,5-7,12 ingress 4.4.4 set mirror session delete dest-port Purpose Deletes ingress/egress mirroring (destination) port according to session and disables RSPAN function on the mirroring port. Command Mode Global configuration mode Syntax set mirror session <1-3>...
Page 118: Set Mirror Statistical Sample-Interval
ZXR10 2900E Series Command Reference Syntax set mirror rspan-tag vlan-id <1-4094> priority <0-7>{ingress | egress} Parameters Parameter Description <1-4094> Vlan-id in RSPAN tag <0-7> Priority field in RSPAN tag Configures ingress monitoring port RSPAN ingress Configures egress monitoring port RSPAN...
Page 119: Clear Mirror Session
Parameter Description <1-3> Mirror function session number Usage Guidelines The content displayed includes RSPAN tag information of ingress and egress. Example The following example describes how to display the configuration of mirror session 1. 4-63 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 120: Show Mirror Rspan
ZXR10 2900E Series Command Reference zte(cfg)#show mirror session 1 Session 1: Ingress mirror information: --------------------------- Source port : none Destination port: 2 Rspan tag vlan : 2, priority: 7 Egress mirror information: --------------------------- Source port : 1,5-13 Destination port: 4...
Page 121: Vlan Configuration
Disables VLAN disable Usage Guidelines VLAN 1 cannot be disabled. Default By default, VLAN 1 is enabled, other VLANs are disabled. Example The following example describes how to enable Vlan 5-7,12. zte(cfg)#set vlan 5-7,12 enable 4-65 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 122: Set Vlan Add Port
Example The following example describes how to add tag port 2, 8 and 9, 10 and 18 to VLAN 1, 5, 6, 7 and 12. zte(cfg)#set vlan 1,5-7,12 add port 2,8-10,18 tag 4.5.3 set vlan delete port Purpose Deletes the designated port from VLAN.
Page 123: Set Vlan Add Trunk
Default The default trunk attribute is untag. Example The following example describes how to add trunk 1 with tag to VLAN 1, 5, 6,7 and 12. zte(cfg)#set vlan 1,5-7,12 add trunk 1 tag 4-67 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 124: Set Vlan Delete Trunk
ZXR10 2900E Series Command Reference 4.5.5 set vlan delete trunk Purpose Deletes the designated trunk from VLAN. Command Mode Global configuration mode Syntax set vlan <vlanlist> delete trunk <trunklist> Parameters Parameter Description <vlanlist> VLAN list <trunklist> trunk list Example The following example describes how to delete trunk 1 from VLAN 1, 5, 6, 7 and 12.
Page 125: Set Port Protocol-Vlan Enable/Disable
The following example describes how to add port 1 to VLAN, port 2 to VLAN 11, port 3 to VLAN 12..port 10 to VLAN 19 in untag mode. zte(cfg)#set port 1-10 vlan-attribute 10-19 untag 4.5.7 set port protocol-vlan enable/disable Purpose Enables/Disables protocol VLAN function on the port.
Page 126: Create Vlan Name
ZXR10 2900E Series Command Reference Command Mode Global configuration mode Syntax set vlan protocol-mapping session-no <1-8>{ethernet2 | llc | snap}<0xHHHH> vlan <1-4094> Parameters Parameter Description <1-8> Template number Matches ethernet2 type message ethernet2 Matches llc type message Matches snap type message snap <0xHHHH>...
Page 127: Clear Vlan Name
Description <vlanlist> VLAN list Example The following example describes how to clear the name of VLAN 1, 5, 6, 7 and 12. zte(cfg)#clear vlan 1,5-7,12 name 4.5.11 clear vlan protocol-mapping session-no Purpose Clears protocol VLAN template configuration. Command Mode Global configuration mode Syntax clear vlan protocol-mapping session-no <1-8>...
Page 128: Show Vlan
ZXR10 2900E Series Command Reference 4.5.12 show vlan Purpose Shows basic VLAN information. Command Mode All modes Syntax show vlan <vlanlist> Parameter Parameter Description <vlanlist> VLAN list Example The following example describes how to show all VLAN information. zte(cfg)#show vlan VlanType: 802.1q vlan...
Page 129: Voice Vlan Configuration
The port configurations cannot be modified or covered. If the modification is required, clear the original configurations first and then configure. 4.6.2 set vlan voice-vlan oui Purpose Adds one OUI to a port. Command Mode Global configuration mode 4-73 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 130: Set Vlan Voice-Vlan Qos-Profile
ZXR10 2900E Series Command Reference Syntax set vlan voice-vlan port <1-18> oui-id <1-32> mac-addr <HH.HH.HH.HH.HH.HH> mac-m ask <HH.HH.HH.HH.HH.HH> Parameters Parameter Description One port number. Different devices have different port number <1-18> ranges. Here, take the 2918E as an example. <1-32>...
Page 131: Clear Vlan Voice-Vlan
Here, take the 2918E as an example. Usage Guidelines The configured OUI cannot be cleared. 4.6.6 clear vlan voice-vlan port oui Purpose Clears all OUIs configured by the port. Command Mode Global configuration mode 4-75 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 132: Clear Vlan Voice-Vlan Port Oui-Id
ZXR10 2900E Series Command Reference Syntax clear vlan voice-vlan port <1-18> oui-id Parameters Parameter Description One port number. Different devices have different port number <1-18> ranges. Here, take the 2918E as an example. Usage Guidelines To clear all OUIs configured by the port, clear voice VLAN configurations on the port first.
Page 133: Show Vlan Voice-Vlan Port
Displays the default OUI of the device. Command Mode All configuration modes Syntax show vlan voice-vlan default-oui Usage Guidelines By default, the port configured voice VLAN is added the default OUI, and the default OUI cannot be deleted. 4-77 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 134: Show Vlan Voice-Vlan User-Table Port
ZXR10 2900E Series Command Reference 4.6.11 show vlan voice-vlan user-table port Purpose Displays the user-table of the port. Command Mode Global configuration mode Syntax show vlan voice-vlan user-table port <1-18> Parameters Parameter Description One port number. Different devices have different port number <1-18>...
Page 135: Mac Table Operation
By default, port security function is disabled. Example The following example describes how to enable the security function of port 1, 5, 6, 7 and zte(cfg)#set port 1,5-7,11 security enable 4.7.2 set port multicast-filter Purpose Enables/Disables port unregistered multicast filtering function.
Page 136: Set Trunk Multicast-Filter
ZXR10 2900E Series Command Reference Command Mode Global configuration mode Syntax set port <portlist> multicast-filter {enable | disable} Parameters Parameter Description <portlist> Port list Port unregistered multicast filtering function is enabled. Drop the enable unregistered multicast packet. Port unregistered multicast filtering function is disabled. Forward disable the unregistered multicast packet.
Page 137: Set Mac Add Static Port Vlan
Adds the MAC static entry based on trunk and VLAN. Command Mode Global configuration mode Syntax set mac add static <HH.HH.HH.HH.HH.HH> trunk <1-15> vlan <1-4094> Parameters Parameter Description MAC address, multicast address, broadcast address and all 0s <HH.HH.HH.HH.HH.HH> address cannot be added. 4-81 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 138: Set Mac Add Permanent Port Vlan
ZXR10 2900E Series Command Reference Parameter Description <1-15> Trunk ID <1-4094> VLAN ID Usage Guidelines Add static MAC entry. Mac address is not aging or floating. After the device is restarted, the MAC address will disappear. 4.7.6 set mac add permanent port vlan Purpose Adds the MAC permanent entry based on port and VLAN.
Page 139: Set Mac Delete
Some special MAC address entries, such as layer 3 interface address, cannot be deleted. These kinds of MAC addresses require specified method, such as deleting layer 3 interface. 4.7.9 set mac delete mac-address vlan Purpose Deletes one specified MAC address entry. Command Mode Global configuration mode 4-83 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 140: Set Mac Delete Port/Trunk/Vlan
ZXR10 2900E Series Command Reference Syntax set mac delete mac-address <HH.HH.HH.HH.HH.HH> vlan <1-4094> Parameters Parameter Description MAC address HH.HH.HH.HH.HH.HH <1-4094> VLAN ID Usage Guidelines Some special MAC address entries, such as layer 3 interface address, cannot be deleted. These kinds of MAC addresses require specified method, such as deleting layer 3 interface.
Page 141: Set Mac Delete Dynamic
Some special MAC address entries such as the Layer 3 interface address cannot be deleted. This kind of MAC address requires to be deleted in the special way, for example, delete the Layer 3 interface. 4-85 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 142: Set Mac Delete Static
ZXR10 2900E Series Command Reference 4.7.13 set mac delete static Purpose Deletes all static MAC address entries. Command Mode Global configuration mode Syntax set mac delete static Usage Guidelines Some special MAC address entries such as the Layer 3 interface address cannot be deleted.
Page 143: Set Mac Learning
Configures global MAC address learning mode global port Configures port MAC address learning mode One port number. Different devices have different port number <1-28> ranges. Here take 2928E as an example. trunk Configures trunk MAC address learning mode 4-87 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 144: Set Mac Limit
By default, automatic learning mode is enabled. Example The following example describes how to configure trunk 10 as cpu-controlled learning. zte(cfg)#set mac learning trunk 10 mode cpu-controlled 4.7.17 set mac limit Purpose Configures the limit of the number of MAC addresses based on global/port/trunk/VLAN.
Page 145: Set Mac Unknown-Filter
Configures the number of port MAC addresses One port number. Different devices have different port number <1-28> ranges. Here take 2928E as an example. trunk Configures the number of trunk MAC address <1-15> Trunk ID 4-89 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 146: Set Mac To Permanent
ZXR10 2900E Series Command Reference Parameter Description <0-16384> The number of MAC addresses Usage Guidelines If MAC address table capacity is exceeded, the message does not learn the MAC address and is dropped. Default By default, the unknown source message filtering function is disabled.
Page 147: Set Mac To Permanent Auto-Save-Time
By default, the auto save time is 360 minutes. 4.7.21 set mac to static Purpose Configures the function that MAC address turns from dynamic address to static address in batch. Command Mode Global configuration mode 4-91 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 148: Set Mac Logging-Alarm
ZXR10 2900E Series Command Reference Syntax set mac to static {port <1-28>| trunk <1-15>| vlan <1-4094>}{enable | disable} Parameters Parameter Description Configures the function that MAC address turns from dynamic port address to static address in batch on the port One port number.
Page 149: Set Mac Logging-Alarm Interval
<1-900> Parameters Parameter Description <0-256> Alarm interval, the unit is second Default By default, the alarm interval is 10 seconds. 4.7.24 show mac Purpose Shows MAC address entry content. Command Mode Global configuration mode 4-93 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 150: Show Mac Running-Config
ZXR10 2900E Series Command Reference Syntax show mac Usage Guidelines Shows all MAC addresses including dynamic, static, permanent, transformation in batch and the MAC address configured by other modes. Example zte(cfg)#show mac Total MAC Address : 5 Flags: Per - permanent, Stc - static, ToP - to_permanent, ToS - to_static,...
Page 151: Show Mac All-Type
Shows various MAC function configurations and MAC address entries based on global/port/trunk/VLAN. Command Mode Global configuration mode Syntax show mac {dynamic | learning | limit | permanent | static}[port <1-28>| trunk <1-15>| vlan <1-4094>] 4-95 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 152: Show Mac Mac-Address
ZXR10 2900E Series Command Reference Parameters Parameter Description dynamic Only shows dynamic MAC address Only shows permanent MAC address permanent Only shows static MAC address static Shows MAC learning mode configuration learning Shows the configuration of MAC learning quantity limitation...
Page 153: Show Mac Unknown-Filter
<1-15> trunk ID 4.7.30 show mac aging-time Purpose Shows device MAC address aging time. Command Mode Global configuration mode Syntax show mac aging-time Example zte(cfg)#show mac aging-time MAC global aging time : 360(s) 4-97 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 154: Show Mac Filter
ZXR10 2900E Series Command Reference 4.7.31 show mac filter Purpose Shows source MAC address/destination MAC address filtering configuration. Command Mode All modes Syntax show mac filter Example zte(cfg)#show mac filter MAC Filter Configuration : Flags: Per - permanent, Stc - static, ToP - to_permanent, ToS - to_static,...
Page 155: Set Mac Learning Except Session
After a session is bound with a port/trunk, the session does not learn matched MAC addresses, but forwards them. 4.7.34 set mac learning except session unbind Purpose Removes the binding relation between a port/trunk and all sessions. Command Mode All modes 4-99 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 156: Set Mac Learning Except Bind
ZXR10 2900E Series Command Reference Syntax set mac learning except {port <portlist>| trunk <trunklist>}session unbind Parameters Parameter Description Port bound with the session. port <portlist> Port list. Trunk bound with the session. trunk <portlist> Trunk list. Session in binding relation.
Page 157: Show Mac Learning Except Session
Purpose Displays sessions that do not learn specific source MAC addresses. Command Mode All modes Syntax show mac learning except session [<1-100>] Example zte(cfg)#show mac learning except session 1 Mac Learning Exception Session Status Session-Id Mac-Address MAC-Mask Vlan-ID --------------------------------------------------------------- 00.11.22.33.44.55 ff.ff.ff.00.00.00...
Page 158: Mac Authentication Configuration
ZXR10 2900E Series Command Reference 4.8 MAC Authentication Configuration 4.8.1 aaa-control mac-authentication Purpose Enables/Disables the MAC authentication function. Command Mode NAS configuration mode Syntax aaa-control mac-authentication {enable | disable } Parameters Parameter Description Enables MAC authentication. enable disable (Default) Disables MAC authentication.
Page 159: Clear Mac-Authentication Session
Example The following example describes how to configure the MAC address of session 1 to 00.1d.0f.22.57.0c, mask to ff.ff.ff.ff.00.00, that is, MAC addresses 00.1d.0f.22.**.** are to be authenticated. zte(cfg-nas)#aaa-control mac-authentication session 1 range 00.1d.0f.22.57.0c ff.ff.ff.ff.00.00 4.8.3 clear mac-authentication session Purpose Clears the rang of MAC addresses in unit of session.
Page 160: Clear Mac-Authentication Client Mac
ZXR10 2900E Series Command Reference Syntax clear mac-authentication client 4.8.5 clear mac-authentication client mac Purpose Clears the client authenticated by the specified MAC. Command Mode NAS configuration mode Syntax clear mac-authentication client mac <HH.HH.HH.HH.HH.HH> Parameter Parameter Description <HH.HH.HH.HH.HH.HH> Unicast MAC address.
Page 161: Show Aaa Mac-Authentication
All configuration modes Syntax show aaa mac-authentication client Example The following example describes how to view the states of clients authenticated by MAC addresses. zte(cfg-nas)#show aaa mac-authentication client MaxClients : 256 OnlineClients : 0 4-105 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 162: Lacp Configuration
ZXR10 2900E Series Command Reference 4.9 LACP Configuration 4.9.1 set trunk pvid Purpose Configures the default PVID of trunk. Command Mode Global configuration mode Syntax set trunk <trunklist> pvid <1-4094> Parameters Parameter Description <trunklist> Trunk lsit <1-4094> The default VLAN ID, any number from 1 to 4094 Example The following example describes how to configure the PVID of trunk 1, 2, 3 to 1000.
Page 163: Set Lacp Aggregator Port
Port list, at most 8 ports can be aggregated Example The following example describes how to add port 1, 5, 6 and 7 to aggregator 1. zte(cfg)#set lacp aggregator 1 add port 1,5-7 4.9.4 set lacp aggregator mode Purpose Sets the aggregation mode of aggregator.
Page 164: Set Lacp Port Mode
ZXR10 2900E Series Command Reference Parameters Parameter Description <1-15> Aggregator number Aggregation mode is static static Aggregation mode is dynamic dynamic Aggregation mode is dynamic mixed Default The default mode is dynamic mode. Example The following example describes how to set aggregation mode of aggregator 1 as dynamic.
Page 165: Set Lacp Port Timeout
To configure timeout, add the port to LACP aggregation group. Example The following example describes how to set port 1, 5, 6 and 7 as long timeout. zte(cfg)#set lacp port 1,5-7 timeout long 4.9.7 set lacp priority Purpose Sets LACP priority.
Page 166: Set Lacp Load-Balance
ZXR10 2900E Series Command Reference Default The default priority is 32768. 4.9.8 set lacp load-balance Purpose Configures LACP load-balance mode. Command Mode Global configuration mode Syntax set lacp load-balance {port | packet {L2 | L3 | L4}} Parameters Parameter Description The load balance is based on port.
Page 167: Show Trunk Vlan
Parameter Description <trunklist> Trunk list Example The following example describes how to show the VLAN to which trunk 1 belongs. zte(cfg)#show trunk 1 vlan TrunkId Tagged in vlan Untagged in vlan : 1 4.9.11 show lacp Purpose Shows LACP global configuration information.
Page 168: Show Lacp Aggregator
ZXR10 2900E Series Command Reference Command Mode All configuration modes Syntax show lacp Example The following example describes how to show LACP global configuration information. zte(cfg)#show lacp Lacp is enabled. Lacp priority is 1. Load-balance is based on L2 hash mode.
Page 169: Show Lacp Aggregator Aggid
Description <1-15> trunk ID 4.9.14 show lacp port Purpose Shows the aggregation state information of LACP member port. Command Mode All modes Syntax show lacp port <portlist > Parameter Parameter Description <portlist> Port list 4-113 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 170: Clear Trunk
ZXR10 2900E Series Command Reference Example The following example describes how to show the aggregation state information of LACP member port 2. zte(cfg)#show lacp port 2 PortID: 2 Port status: Select : Unselected Loop : False Aggnum PartnerId : Null...
Page 171: Igmp Snooping Configuration
Chapter 4 Service Configuration Example The following example describes how to clear the multicast filtering flag of trunks 1, 2, and zte(cfg)#clear trunk 1-3 multicast-filter 4.10 IGMP Snooping Configuration 4.10.1 set igmp snp enable/disable Purpose Enables/Disables multicast snooping. Command Mode...
Page 172: Set Igmp Snp Add/Delete Maxnum Vlan/Port
Port list Example The following example describes how to configure the maximum multicast number of VLAN 1-10 and port 1-10 to 100. zte(cfg)#set igmp snooping add maxnum 100 vlan 1-10 zte(cfg)#set igmp snooping add maxnum 100 port 1-10 4-116 SJ-20120409144109-003|2012-07-02(R1.0)
Page 173: Set Igmp Snp Multicast -Ring Enable/Disable
Disables the IGMP multicast ring network function. Example The following example describes how to enable the IGMP multicast ring network function. zte(cfg)#set igmp snooping multicast-ring enable 4.10.5 set igm snp multicast-ring add/delete cascade port Purpose Adds/Deletes a cascade port of a multicast ring network.
Page 174: Set Igmp Snp Monitor-Ring Enable/Disable
Example The following example describes how to add the cascade ports 51 and 52 of a multicast ring network. zte(cfg)#set igmp snooping multicast-ring add cascade port 51,52 4.10.6 set igmp snp monitor-ring enable/disable Purpose Enables/Disables the IGMP ring network monitoring function.
Page 175: Set Igmp Snp Vlan Add/Delete Group
The following example describes how to add static multicast group 230.40.44.167 to VLAN 1 and add port 1-10 to static group at the same time. zte(cfg)#set igmp snooping vlan 1 add group 230.40.44.167 port 1-10 4.10.8 set igmp snp vlan add/delete smr port/trunk Purpose Adds/Deletes route port/trunk port to the specified VLAN.
Page 176: Set Igmp Snp Private-Group
The trunk list as route port Example The following example describes how to add route port 9 and 10 to VLAN 1. zte(cfg)#set igmp snooping vlan 1 add smr port 9,10 4.10.9 set igmp snp private-group Purpose Adds private multicast group. Enables/Disables private multicast group function.
Page 177: Set Igmp Snp Timeout Route/Host
Example The following example describes how to configure the aging time of router as 400 seconds and that of host as 300 seconds. zte(cfg)#set igmp snooping timeout 4000 router zte(cfg)#set igmp snooping timeout 3000 host 4.10.11 set igmp snp query-interval Purpose Configures the interval that switch sends query message.
Page 178: Set Igmp Snp Response-Interval
ZXR10 2900E Series Command Reference Command Mode Global configuration mode Syntax set igmp snooping query-interval <10-2147483647> Parameter Parameter Description The interval that switch sends query message. The unit is 100 <10-2147483647> milliseconds. Default By default, the interval that switch sends query message is 125 seconds.
Page 179: Set Igmp Snp Last-Member-Query
Example The following example describes how to configure the waiting time that switch sends report message and waits for report message to 15 seconds. zte(cfg)#set igmp snooping response-interval 150 4.10.13 set igmp snp last-member-query Purpose Configures the querying circle of the last member.
Page 180: Set Igmp Snp Query Version
Disables query function. Example The following example describes how to enable the query function of VLAN 1–10. zte(cfg)#set igmp snooping query vlan 1-10 enable 4.10.15 set igmp snp query version Purpose Configures the IGMP version of query message sent by the switch.
Page 181: Set Igmp Snp Fastleave Enable/Disable
Disables fast leave. Default Disables fast leave. Example The following example describes how to enable fast leave. zte(cfg)#set igmp snooping fastleave enable 4.10.17 set igmp snp v3 enable/disable Purpose Enables/Disables IGMP V3 function. Command Mode Global configuration mode Syntax...
Page 182: Set Igmp Snp Proxy
ZXR10 2900E Series Command Reference Default Disables the multicast function of IGMP V3. Example The following example describes how to enable the multicast function of IGMP V3. zte(cfg)#set igmp snooping v3 enable 4.10.18 set igmp snp proxy Purpose Configures the version that the switch responses the query message send by the router.
Page 183: Set Igmp Filter Enable/Disable
Disables multicast filtering function. 4.10.21 set igmp filter add/delete groupip vlan Purpose Adds/Deletes the filtering of group in the specified VLAN. Command Mode Global configuration mode Syntax set igmp filter {add | delete} groupip <A.B.C.D.> vlan <vlanlist> 4-127 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 184: Set Igmp Filter Add/Delete Sourceip Vlan
VLAN list Example The following example describes how to filter the message of 231.0.0.100 in VLAN 1-10. zte(cfg)#set igmp filter add groupip 231.0.0.100 vlan 1-10 4.10.22 set igmp filter add/delete sourceip vlan Purpose Adds/Deletes the filtering of source in the specified VLAN.
Page 185: Show Igmp Snp Vlan
Shows the results of multicast snooping. Command Mode All modes Syntax show igmp snooping vlan [<1-4094>[host | route]] Parameters Parameter Description <1-4094> A VLAN ID or a VLAN name host Shows the snooping result of members. 4-129 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 186: Show Igmp Snp Port
ZXR10 2900E Series Command Reference Parameter Description router Shows the snooping result of routers. Usage Guidelines The command without VLAN ID will display the globl snooping result of the switch. The command with VLAN ID will display VLAN multicast group quantity limitation and snooping result.
Page 187: Show Igmp Snp V3 Port/Trunk
Parameter Description <portlist> Port list Example The following example describes how to show all ports multicast information. zte(cfg)#show igmp snooping port PortId: 1 Maximal group number: 100 Current group number: 0 PortId: 2 Maximal group number: 100 Current group number: 0...
Page 188: Show Igmp Filter
ZXR10 2900E Series Command Reference Parameters Parameter Description One port number. Different devices have different port ranges. <1-28> Here take 2928E as an example. <1-15> trunk ID Example The following example describes how to show multicast group information of v3 snooped at port 1.
Page 189: Set Igmp Filter Add/Delete Grouplist Mask Vlan
Description <1-4094> VLAN ID Example The following example describes how to show the multicast group filtering configuration of VLAN 1. zte(cfg)#show igm filter vlan 1 The filter address list of this vlan: Index FilterIpAddress FilterIpMask Vlan Type ----- ---------------- ---------------- ----- -------- 225.0.0.10...
Page 190: Iptv Configuration
The following example describes how to filter packets of the multicast group in vlan 1-10 whose IP address is 225.0.0.10 and mask is 255.255.255.0. That is, filter the multicast packets of IP addresses 225.0.0.0 to 225.0.0.255. zte(cfg)#set igm filter add grouplist 225.0.0.10 mask 255.255.255.0 vlan 1-10 4.11 IPTV Configuration 4.11.1 iptv control enable/disable Purpose Enables/Disables iptv control function.
Page 191: Iptv Channel-Group Mvlan Groupiplist Name
225.0.1.1, and the end IP address is 225.0.1.10. The channel group name is "lsj" and the channel group ID is "100". (If masks are configured, IP addresses are displayed as shown below.) zte(cfg-nas)#iptv channel-group mvlan 1 groupip-list 225.0.1.1 225.0.1.10 name lsj id 100 zte(cfg-nas)#show iptv channel-group MaxChannelGroupNum:256...
Page 192: Iptv Channel Mvlan Groupip Name
The following example describes how to create 224.0.1.1 on VLAN 1, create the name of 224.0.1.3 to cctv and channel number to 100. zte(cfg-nas)#iptv channel mvlan 1 groupip 224.0.1.1 zte(cfg-nas)#iptv channel mvlan 1 groupip 224.0.1.3 name cctv id 100 zte(cfg-nas)#show iptv channel MaxChannelNum:1032...
Page 193: Iptv Channel-Group Name Rename
Old channel group name. <new-name> New channel group name. Example The following example describes how to rename channel group "CCTV" as "CATV". zte(cfg-nas)#iptv channel-group name cctv rename catv 4.11.5 iptv channel-groupname/id-list cdr Purpose Enables/Disables the log function for a channel group. Command Mode...
Page 194: Iptv Channel-Groupname/Id-List Viewfile-Name/Id
ZXR10 2900E Series Command Reference Parameters Parameter Description <channel-group-name> Channel group name. <channel-group-list> Channel group list. Enables the log function. enable Disables the log function. By default, the function is disabled. disable Usage Guidelines The log function can be enabled/disabled by channel name or by channel group ID. The result is the same.
Page 195: Iptv Channel Mvlan Groupip Count
The following example describes how to create channel for VLAN 2 in batch. The group start address is 224.1.1.1, number is 10 and name prefix is cctv. zte(cfg-nas)#iptv channel mvlan 2 groupip 230.0.0.1 count 10 prename NET-TV zte(cfg-nas)#show iptv channel...
Page 196: Iptv Channel Name Rename
ZXR10 2900E Series Command Reference CurChannelNum:12 HisChannelNum:12 Name GroupIp MVlan ------ -------------------------------- --------------- ------ CHNAME0 224.0.1.1 NET-TV1 230.0.0.1 NET-TV2 230.0.0.2 NET-TV3 230.0.0.3 NET-TV4 230.0.0.4 NET-TV5 230.0.0.5 NET-TV6 230.0.0.6 NET-TV7 230.0.0.7 NET-TV8 230.0.0.8 NET-TV9 230.0.0.9 NET-TV10 230.0.0.10 CCTV 224.0.1.3 4.11.8 iptv channel name rename Purpose Renames channels.
Page 197: Iptv Channel Name/Id-List Cdr
Default Disables log function. Example The following example describes how to enable the log function of channel 0. zte(cfg-nas)#iptv channel id-list 0 cdr enable 4.11.10 iptv channel name/id-list viewfile-name/id Purpose Specifies the preview configuration file of the channel. Command Mode...
Page 198: Iptv Sms-Server
ZXR10 2900E Series Command Reference Syntax iptv channel {name <channel-name>| id-list <channel-list>}{viewfile-name <viewfile-name>| viewfile-id <0-1023>} Parameters Parameter Description Channel name, specifies the preview file according to channel <channel-name> name <channel-list> Channel list, specifies the preview file according to channel list <viewfile-name>...
Page 199: Iptv Sms-Server-Port
The following example describes how to configure the TCP port of SMS sever to 6000. zte(cfg-nas)#iptv sms-server-port 6000 4.11.13 iptv cdr enable/disable Purpose Enables/Disables CDR record function. Command Mode NAS configuration mode Syntax iptv cdr {enable | disable} 4-143 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 200: Iptv Cdr Report
ZXR10 2900E Series Command Reference Parameters Parameter Description enable Enables CDR record function. disable Disables CDR record function. Default CDR record function is disabled by default. Example The following example describes how to enable CDR record function. zte(cfg-nas)#iptv cdr enable 4.11.14 iptv cdr report...
Page 201: Iptv Cdr Deny-Right
CDR record circle is 3600 seconds by default. Example The following example describes how to configure CDR record circle to 7200 seconds. zte(cfg-nas)#iptv cdr create-period 7200 4.11.16 iptv cdr deny-right Purpose Enables/Disables cdr function when the access authority is denied.
Page 202: Iptv Cdr Prv-Right
ZXR10 2900E Series Command Reference 4.11.17 iptv cdr prv-right Purpose Enables/Disables cdr function of the preview access authority . Configuration Mode NAS configuration mode Syntax iptv cdr prv-right {enable | disable} Parameters Parameter Description Enables cdr function of the preview access authority...
Page 203: Iptv Cdr Report-Interval
By default, the number of CDR log records is 10. Example The following example describes how to configure the number of CDR log records in the message reported every time to 32. zte(cfg-nas)#iptv cdr report-threshold 32 4.11.19 iptv cdr report-interval Purpose Configures the time interval of CDR timing report.
Page 204: Iptv Cdr Warning-Threshold
ZXR10 2900E Series Command Reference Command Mode NAS configuration mode Syntax iptv cdr max-records <100-5000> Parameter Parameter Description <100-5000> The number of records Default By default, the number of records is 1000. Example The following example describes how to configure the maximum number of CDR log records in buffer to 2000.
Page 205: Iptv Package Name
Example The following example describes how to create a multicast package named as taocan. zte(cfg-nas)#iptv package name taocan id 0 4.11.23 iptv package name channel name/id-list Purpose Adds the channel into the package and configures the channel authority.
Page 206: Iptv Prv Enable/Disable
Add the authority of preview into the package Example The following example describes how to add the channel 100,103,104,107 to package. zte(cfg-nas)#iptv package name pkg1 channel id-list 100,103,104,107 order 4.11.24 iptv prv enable/disable Purpose Enables/Disables preview function. Command Mode...
Page 207: Iptv Prv Reset
Parameter Parameter Description Automatic reset preview function time, 24–hour notation : hour: <HH:MM:SS> minute: second Example The following example describes how to configure the reset preview function on 00:01:01 everyday. zte(cfg-nas)#iptv prv autoreset-time 00:01:01 4-151 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 208: Iptv Prv Recognition-Time
ZXR10 2900E Series Command Reference 4.11.27 iptv prv recognition-time Purpose Configures preview recognition time. If the preview occurs in a very short time, the time is ignored. Command Mode NAS configuration mode Syntax iptv prv recognition-time <1-65534> Parameter Parameter Description <1-65534>...
Page 209: Iptv View-Profile Name
Default CDR function is disabled by default. Example The following example describes how to enable the CDR function when the preview time is overcount. zte(cfg-nas)#iptv prv overcount-cdr enable 4.11.29 iptv view-profile name Purpose Creates preview configuration files. Command Mode NAS configuration mode Syntax iptv view-profile name <...
Page 210: Iptv View-Profile Name Count/Duration/Blackout
ZXR10 2900E Series Command Reference 4.11.30 iptv view-profile name count/duration/blackout Purpose Configures maximum preview count/maximum duration time of single preview/minimum preview interval. Command Mode NAS configuration mode Syntax iptv view-profile name <viewfile-name>{count | duration | blackout}<1-65535> Parameters Parameter Description <viewfile-name>...
Page 211: Iptv Port Service
<1-4094> A VLAN ID or a VLAN name Starts service. The service data takes effect. start Removes service to clear service data. remove Pauses service. The reserve data takes effect. pause Restores service. resume 4-155 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 212: Iptv Port Control-Mode
There are no services by default. Example The following example describes how to enable the service of port 1 in VLAN 1000. zte(cfg-nas)#iptv port 1 vlan 1000 service start 4.11.33 iptv port control-mode Purpose Configures multicast control mode for users.
Page 213: Iptv Port Package
To support the selection of package, package should be selected in control-mode first. Example The following example describes how to allocate package 0, 1 to port 1. zte(cfg-nas)#iptv port 1 package id-list 0,1 4.11.35 iptv port channel-group Purpose Assigns channel group access authority for a port user.
Page 214: Iptv Port Channel
Example The following example describes how to set the channel group access authority to "allow" for port 2. zte(cfg-nas)#iptv port 2 vlan 2 channel-group name chname0 order 4.11.36 iptv port channel Purpose Allocates channel access authority for user port.
Page 215: Iptv Port Cdr
Only channel is selected in control-mode, can it support the selection of channel. Example The following example describes how to configure the channel access authority at port 2 to order. zte(cfg-nas)#iptv port 2 vlan 2 channel name chname0 order 4.11.37 iptv port cdr Purpose Enables/Disables CDR function.
Page 216: Iptv Port Mac-Base
ZXR10 2900E Series Command Reference 4.11.38 iptv port mac-base Purpose Enables/Disables MAC-based management. Command Mode NAS configuration mode Syntax iptv port <portlist>[vlan <1-4094>] mac-base {enable | disable} Parameters Parameter Description <portlist> Port list vlan <1-4094> A VLAN ID or a VLAN name...
Page 217: Clear Iptv Channel
This command deletes IPTV users according to various rules. Without parameters it deletes all users. Example The following example describes how to clear channel group "catv". zte(cfg-nas)#clear iptv channel-group name catv 4.11.40 clear iptv channel Purpose Clears a channel. Command Mode...
Page 218: Clear Iptv View-Profile
ZXR10 2900E Series Command Reference Syntax clear iptv package {name <package-name>| id-list < package-idlist >| all} Parameters Parameter Description name <package-name> Package name id-list < package-idlist > Package list Deletes all packages Example The following example describes how to clear the package named as ccc.
Page 219: Clear Iptv Port Package
<package-idlist> Package id list Example The following example describes how to clear the package named as pkg1 allocated at port 3. zte(cfg-nas)#clear iptv port 3 package name pkg1 4.11.44 clear iptv client Purpose Clears IPTV users. Command Mode NAS configuration mode Syntax clear iptv client [index <0-255>| mac <HH.HH.HH.HH.HH.HH>| port <portlist>[vlan <1-40...
Page 220: Show Iptv Control
ZXR10 2900E Series Command Reference Parameters Parameter Description index <0-255> Deletes users according to indexes mac <HH.HH.HH.HH.HH.HH> Deletes users according to MAC addresses port <portlist> Deletes users according to ports vlan <1-4094> Deletes users according to port and VLAN Usage Guidelines This command deletes IPTV users according to various rules.
Page 221: Show Iptv Channel
1. The following example describes how to display all the channels. zte(cfg-nas)#show iptv channel MaxChannelNum:1032 CurChannelNum:11 HisChannelNum:12 Name GroupIp MVlan ------ -------------------------------- --------------- ----- CHNAME0 224.0.1.1 NET-TV1 230.0.0.1 NET-TV2 230.0.0.2 NET-TV3 230.0.0.3 NET-TV4 230.0.0.4 NET-TV5 230.0.0.5 NET-TV6 230.0.0.6 NET-TV7 230.0.0.7 4-165 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 222 ZXR10 2900E Series Command Reference NET-TV8 230.0.0.8 NET-TV9 230.0.0.9 NET-TV10 230.0.0.10 Filed Description MaxChannelNum The maximum channel number to be allocated CurChannelNum The number of current channels allocated HisChannelNum The number of history channels allocated Channel number Name Channel name...
Page 223: Show Iptv Channel-Group
1. The following example describes how to display information about all channel groups. zte(cfg-nas)#show iptv channel-group MaxChannelGroupNum:256 CurChannelGroupNum:1 HisChannelGroupNum:1 Name StartIp EndIp/Mask MVlan ----- ---------- ------------- ------------- ------ 225.0.1.1 225.0.1.10 4000 The information displayed is decribed as follows: 4-167 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 224 ZXR10 2900E Series Command Reference Parameter Description MaxChannelGroupNum Maximum number of channel groups that can be configured. CurChannelGroupNum Number of currently configured channel groups. HisChannelGroupNum Number of channel groups that were configured before. Channel group ID. Name Channel group name.
Page 225: Show Iptv Package
<0-127> Package ID Example 1. The following example describes how to display all packages. zte(cfg-nas)#show iptv package MaxPackageNum:128 CurPackageNum:2 HisPackageNum:4 Package Name ------------- TAOCAN ALLPRE The descriptions of the information are displayed below. 4-169 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 226: Show Iptv Prv
ZXR10 2900E Series Command Reference Filed Description MaxPackageNum The maximum number of packages to be allocated CurPackageNum The number of packages currently allocated HisPackageNum The number of packages configured Package ID Package Name Package name 2. The following example describes how to display channel list in the package.
Page 227: Show Iptv View-Profile
The command without parameters displays all configuration file names. Examples 1. The following example describes how to display the information of all the preview configuration files. zte(cfg-nas)#show iptv view-profile MaxViewfileNum:1024 CurViewfileNum:2 HisViewfileNum:2 4-171 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 228: Show Iptv Cdr
ZXR10 2900E Series Command Reference View Profie Name --------------- DEFVAL.PRF VTCC.PRF The descriptions of the information are displayed below. Filed Description MaxViewfileNum The maximum number of preview files to be allocated CurViewfileNum The number of preview files currently allocated HisViewfileNum...
Page 229: Show Iptv Client
The number of CDR records reported every time Warning-Threshold Warning threshold in CDR buffer pool Records in cache The number of CDR records in the buffer 4.11.52 show iptv client Purpose Shows the information about IPTV user. Command Mode All modes 4-173 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 230: Show Iptv Rule
ZXR10 2900E Series Command Reference Syntax show iptv client [{channel <0-1031>| index <0-255>| mac <HH.HH.HH.HH.HH.HH>| port <portid>| vlan <1-4094>}] Parameters Parameter Description channel <0-1031> Channel id index <0-255> User id mac <HH.HH.HH.HH.HH.HH> MAC addresses of users port <portid> Port number for user to log in vlan <1-4094>...
Page 231: Show Iptv Duplicate
The maximum number of rules to be configured CurRuleNum The number of current ports HisRuleNum The number of history ports 4.11.54 show iptv duplicate Purpose Displays duplicate rule configuration. Command Mode All configuration modes 4-175 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 232: Stp Configuration
ZXR10 2900E Series Command Reference Syntax show iptv duplicate Example The following example describes how to display duplicate rule configuration. zte(cfg-nas)#show iptv duplicate Index Port Mvlan Uvlan ----- ---- ----- ----- 4000 4.12 STP Configuration 4.12.1 set stp enable/disable Purpose Enables/Disables STP protocol.
Page 233: Set Stp Port Enable/Disable
STP force version is RSTP rstp STP force version is STP Example The following example describes how to set STP force version as RSTP. zte(cfg)#set stp forceversion rstp 4.12.3 set stp port enable/disable Purpose Enables/Disables STP on port. Command Mode...
Page 234: Set Stp Port Linktype
ZXR10 2900E Series Command Reference 4.12.4 set stp port linktype Purpose Configures port connection type. Command Mode Global configuration mode Syntax set stp port <portlist> linktype {point-point | shared} Parameters Parameter Description <portlist> Port list The port connection type is point-to-point...
Page 235: Set Stp Port Pcheck
RSTP, RSTP is selected. When RSTP is interconnected with STP, STP is selected. 4.12.7 set stp port bpdu-guard Purpose Enables/Disables BPDU protection on the port. Command Mode Global configuration mode Syntax set stp port <portlist> bpdu-guard {enable | disable} 4-179 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 236: Set Stp Bpdu-Interval
ZXR10 2900E Series Command Reference Parameters Parameter Description <portlist> Port list Enables BPDU protection on the port enable Disables BPDU protection on the port disable Usage Guidelines When the protection function is enabled, if the port receives BPDU message, the port will be linkdown.
Page 237: Set Stp Trunk Enable/Disable
Chapter 4 Service Configuration Example The following example describes how to configure BPDU recovery time to 1000. zte(cfg)#set stp bpdu-interval 1000 4.12.9 set stp trunk enable/disable Purpose Enables/Disables STP on trunk. Command Mode Global configuration mode Syntax set stp trunk <trunklist>{enable | disable}...
Page 238: Set Stp Trunk Packettype
ZXR10 2900E Series Command Reference Parameter Description Port connection type is point-to-point point-point shared Port connection type is shared Default By default, the port connection type is point-to-point. 4.12.11 set stp trunk packettype Purpose Sets packet type on trunk port.
Page 239: Set Stp Hmd5-Digest/Hmd5-Key
The edge port does not join STP calculation. Generally it is the port connected with the terminal. Example The following example describes how to set port 2 as STP edge port. zte(cfg)#set stp edge-port add port 2 4.12.13 set stp hmd5-digest/hmd5-key Purpose Configures the hmd5 parameters when the device interconnects with CISCO and HUAWEI devices.
Page 240: Set Stp Hellotime
ZXR10 2900E Series Command Reference Parameter Description 32 bits hexadecimal numeral, 0 means recovering default <0x00..0-0xff..f> configuration. 4.12.14 set stp hellotime Purpose Configures the interval that STP message is sent. Command Mode Global configuration mode Syntax set stp hellotime <1-10>...
Page 241: Set Stp Agemax
Default By default, the minimum switch time is 15 seconds. Example The following example describes how to set the minimum switch time to 10 seconds. zte(cfg)#set stp forwarddelay 10 4.12.16 set stp agemax Purpose Configures STP aging time. Command Mode...
Page 242: Set Stp Name
<name> Parameter Parameter Description <name> Domain name Example The following example describes how to set the MSTP area name as zte-test. zte(cfg)#set stp name zte-test 4.12.19 set stp revision Purpose Configures MST version number. 4-186 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 243: Set Stp Instance Add/Delete Vlan
Deletes the VLAN from the instance delete <vlanlist> VLAN list Usage Guidelines The corresponding relation between instance and VLAN is one of the reasons for domain classification. The devices in domain have the same corresponding relation. 4-187 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 244: Set Stp Instance Port/Trunk Priority
The default priority is 128. Example The following example describes how to set the priority of trunk 1 in instance 1 to 240. zte(cfg)#set stp instance 1 trunk 1 priority 240 4.12.22 set stp instance port/trunk cost Purpose Configures the path cost of port/trunk in an instance.
Page 245: Set Stp Instance Port/Trunk Root-Guard
Example The following example describes how to configure the path cost of port 1 in instance 1 to 20000. zte(cfg)#set stp instance 1 port 1 cost 20000 4.12.23 set stp instance port/trunk root-guard Purpose Enables/Disables root-guard function of port/trunk on an instance.
Page 246: Set Stp Instance Port/Trunk Loop-Guard
Usage Guidelines The port enabling loop-guard function cannot forward data. Example The following example describes how to enable loop-guard of port 1 on instance 1. zte(cfg)#set stp instance 1 port 1 loop-guard enable 4-190 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 247: Set Stp Instance Priority
4096, the system will automatically transform it to the value closest to the multiple of 4096. Example The following example describes how to set the priority of bridge as 4096 on instance 1. zte(cfg)#set stp instance 1 priority 4096 4.12.26 clear instance Purpose Deletes instances.
Page 248: Clear Stp Instance Port/Trunk Cost
ZXR10 2900E Series Command Reference Usage Guidelines Instance 0 can not be deleted. Example The following example describes how to delete instance 10. zte(cfg)#clear stp instance 10 4.12.27 clear stp instance port/trunk cost Purpose Configures the path cost of port/trunk in the stance as default value.
Page 249: Show Stp
Cisco digest: 0x00000000000000000000000000000000 Huawei key: 0x13ac06a62e47fd51f95d2ba243cd0346 Huawei digest: 0x00000000000000000000000000000000 Instance VlanMap -------- ------------------- 1-4094 4.12.30 show stp instance Purpose Shows the information of STP instance. Command Mode All modes Syntax show stp instance [<0-63>] 4-193 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 250: Show Stp Port
ZXR10 2900E Series Command Reference Parameter Parameter Description Instance ID. The command without parameters shows all instance <0-63> information. Example The following example describes how to show the information of instance 0. zte(cfg)#show stp instance 0 RootID: Priority : 49152 Address : 00.d0.d0.07.40.13...
Page 251: Show Stp Trunk
Chapter 4 Service Configuration Example The following example describes how to show the STP configuration information of port 1. zte(cfg)#show stp port 1 The following port(s) are active! PortId MSTI : 00 Priority : 96 Cost : Auto Status : Forward...
Page 252: Acl Configuration
ZXR10 2900E Series Command Reference 4.13 ACL Configuration 4.13.1 set port acl mode Purpose Configures the ACL binding mode of the port. Command Mode Global configuration mode Syntax set port <portlist> acl mode {port | vlan} Parameters Parameter Description <portlist>...
Page 253: Set Vlan Acl Enable/Disable
Example The following example describes how to bind ACL 1 to port 10. zte(cfg)#set port 10 acl 1 enable 4.13.3 set vlan acl enable/disable Purpose Configures the ACL instance bound with the VLAN.
Page 254: Set Acl Rule Time-Range Enable/Disable
ZXR10 2900E Series Command Reference Example The following example describes how to bind ACL 1 to VLAN 1-10. zte(cfg)#set vlan 1-10 acl 1 enable 4.13.4 set acl rule time-range enable/disable Purpose Configures to implement the ACL operation in the specified period.
Page 255: Clear Acl-Name
Description <1-800> ACL number 4.13.7 show port acl-mode Purpose Shows the ACL binding mode of the port. Command Mode Global configuration mode Syntax show port <portlist> acl-mode Parameter Parameter Description <portlist> acl-mode Port list 4-199 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 256: Config Ingress-Acl Basic
ZXR10 2900E Series Command Reference 4.13.8 config ingress-acl basic Purpose Creates the basic ingress ACL instance and configures it. Command Mode Global configuration mode Syntax config ingress-acl basic number <1-99> Parameter Parameter Description <1-99> Basic ingress ACL instance number 4.13.9 ingress-acl basic rule Purpose Configures the basic ingress ACL rule.
Page 257: Clear Ingress-Acl Basic
<1-99> Parameter Parameter Description <1-99> Basic ingress ACL instance number 4.13.11 config ingress-acl extend Purpose Creates extended ingress ACL instance and configures it. Command Mode Global configuration mode Syntax config ingress-acl extend number <100-199> 4-201 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 258: Ingress-Acl Extend Rule Type-Ip-Protocol
ZXR10 2900E Series Command Reference Parameter Parameter Description <100-199> Extended ingress ACL instance number 4.13.12 ingress-acl extend rule type-ip-protocol Purpose Configures the rule that the extended ingress ACL matches IPv4 specified protocol field. Command Mode Extended ingress ACL configuration mode Syntax rule <1-500>{permit | deny}<ip-protocol>{<source-ipaddr><sip-mask>| any}{<destination-ipad...
Page 259: Ingress-Acl Extend Rule Type-Icmp
Source mask and used for source. It is 32–bit IP address <sip-mask> expressed in dotted decimal notation. Uses keyword any as the abbreviation of source 0.0.0.0 and any (first) source mask 0.0.0.0 4-203 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 260: Ingress-Acl Extend Rule Type-Ip
ZXR10 2900E Series Command Reference Parameter Description The destination network or host address of the transmitted packet. <destination-ipaddr> It is 32–bit IP address expressed in dotted decimal notation. Destination mask and used for destination. It is 32–bit IP address <dip-mask>...
Page 261: Ingress-Acl Extend Rule Type-Tcp
IP addresses, any destination IP address, DSCP fields, or IP fragment fields. 4.13.15 ingress-acl extend rule type-tcp Purpose Configures the rule that the extended ingress ACL is used to match TCP message. Command Mode Extended ingress ACL configuration mode 4-205 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 262 ZXR10 2900E Series Command Reference Syntax rule <1-500>{permit | deny} tcp {<source-ipaddr><sip-mask>| any}[source-port <0-65535><s port-mask>]{<destination-ipaddr><dip-mask>| any}[dest-port <0-65535><dport-mask>][establ ishing | established][dscp <0-63>][fragment] Parameters Parameter Description <1-500> Rule number If the condition matches, permit to access permit If the condition matches, deny to access deny This rule only matches TCP message.
Page 263: Ingress-Acl Extend Rule Type-Udp
Source mask and used for source. It is 32–bit IP address <sip-mask> expressed in dotted decimal notation. Uses keyword any as the abbreviation of source 0.0.0.0 and any (first) source mask 0.0.0.0 4-207 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 264: Ingress-Acl Extend Rule Type-Arp
ZXR10 2900E Series Command Reference Parameter Description UDP source port number of transmitted packet source-port <0-65535> The parameters of source-port can resolve the some known port numbers. Also the port number and mask can be directly inputted. <sport-mask> Source port number mask The destination network or host address of the transmitted packet.
Page 265: Clear Ingress-Acl Extend
IP addresses, or any destination IP address. 4.13.18 clear ingress-acl extend Purpose Clears extended ingress ACL instance. Command Mode Global configuration mode Command Mode clear ingress-acl extend number <100-199> Parameter Parameter Description <100-199> Extended ingress ACL instance number 4-209 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 266: Config Ingress-Acl Link
ZXR10 2900E Series Command Reference 4.13.19 config ingress-acl link Purpose Creates layer 2 ingress ACL instance and configures it. Command Mode Global configuration mode Command Mode config ingress-acl link number <200-299> Parameter Parameter Description <200-299> Layer 2 ingress ACL instance number 4.13.20 ingress-acl link rule type-ip...
Page 267: Ingress-Acl Link Rule Type-Arp
Parameter Description <1-500> Rule number If the condition matches, permit to access permit deny If the condition matches, deny to access This rule is only valid for ARP packet. Non-ARP packet ignores this rule. 4-211 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 268: Ingress-Acl Link Rule Type-Other
ZXR10 2900E Series Command Reference Parameter Description This rule is only valid for the cos-specified message. Other cos <0-7> messages ignore this rule. The range of cos is 0~7. This rule is only valid for the message with specified VLAN ID.
Page 269: Ingress-Acl Link Rule Type-Any
4.13.23 ingress-acl link rule type-any Purpose Configures the rule that the layer 2 ingress ACL matches specified cos and VLAN ID. Command Mode Layer 2 ingress ACL configuration mode Syntax rule <1-500>{permit | deny} any [<vlan-id>[<vlan-mask>]][cos <0-7>] 4-213 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 270: Clear Ingress-Acl Link
ZXR10 2900E Series Command Reference Parameters Parameter Parameter <1-500> Rule number If the condition matches, permit to access permit If the condition matches, deny to access deny This rule can match any packet. This rule is only valid for the cos-specified message. Other cos <0-7>...
Page 271: Ingress-Acl Hybrid Rule Type-Ip-Protocol
Uses keyword any as the abbreviation of source 0.0.0.0 and any (first) source mask 0.0.0.0 The destination network or host address of the transmitted packet. <destination-ipaddr> It is 32–bit IP address expressed in dotted decimal notation. 4-215 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 272: Ingress-Acl Hybrid Rule Type-Ip
ZXR10 2900E Series Command Reference Parameter Description Destination mask and used for destination. It is 32–bit IP address <dip-mask> expressed in dotted decimal notation. Uses keyword any as the abbreviation of destination 0.0.0.0 and any (second) destination mask 0.0.0.0 This rule is only valid for the message with the specified DSCP dscp <0-63>...
Page 273 This rule is only valid for the message with specified VLAN ID. <vlan-id> Other messages ignore this rule. The rule of VLAN ID is 1~4094. <vlan-mask> Optional VLAN mask. The default value is 0xfff. <source-mac> Source MAC address of transmitted packet <smac-mask> Source MAC mask 4-217 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 274: Ingress-Acl Hybrid Rule Type-Tcp
ZXR10 2900E Series Command Reference Parameter Description Uses keyword any as the abbreviation of source MAC address any (third) 00.00.00.00.00.00 and mask 00.00.00.00.00.00 <dest-mac> Destination MAC address of transmitted packet <dmac-mask> Destination MAC address of transmitted packet Uses keyword any as the abbreviation of destination MAC address any (fourth) 00.00.00.00.00.00 and mask 00.00.00.00.00.00...
Page 275 00.00.00.00.00.00 and mask 00.00.00.00.00.00 <dest-mac> Destination MAC address of transmitted packet <dmac-mask> Destination MAC address of transmitted packet Uses keyword any as the abbreviation of destination MAC address any (fourth) 00.00.00.00.00.00 and mask 00.00.00.00.00.00 4-219 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 276: Ingress-Acl Hybrid Rule Type-Udp
ZXR10 2900E Series Command Reference Usage Guidelines TCP rule can match source-specified IP, any source IP, destination-specified IP, any destination IP, DSCP field, IP fragment field, cos field, VLAN field, source-specified MAC, any source MAC, destination-specified MAC and any destination MAC.
Page 277: Ingress-Acl Hybrid Rule Type-Arp
IP, any destination IP, DSCP field, IP fragment field, cos field, VLAN field, source-specified MAC, any source MAC, destination-specified MAC and any destination MAC. 4.13.30 ingress-acl hybrid rule type-arp Purpose Configures the rule that the hybrid ingress ACL matches the ARP packet. 4-221 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 278 ZXR10 2900E Series Command Reference Command Mode Hybrid ingress ACL configuration mode Syntax rule <1-500>{permit | deny} arp {<sender-ipaddr><sip-mask>| any}{<target-ipaddr><tip-mask >| any}[cos <0-7>][<vlan-id>[<vlan-mask>]][<source-mac><smac-mask>| any][<dest-mac><dm ac-mask>| any] Parameters Parameter Description <1-500> Rule number If the condition matches, permit to access permit...
Page 279: Ingress-Acl Hybrid Rule Type-Any
This rule is only valid for the message with specified VLAN ID. <vlan-id> Other messages ignore this rule. The rule of VLAN ID is 1~4094. <vlan-mask> Optional VLAN mask. The default value is 0xfff. <source-mac> Source MAC address of transmitted packet 4-223 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 280: Ingress-Acl Hybrid Rule Type-Ipv6-Ip-Protocol
ZXR10 2900E Series Command Reference Parameter Description <smac-mask> Source MAC mask Uses keyword any as the abbreviation of source MAC address any (third) 00.00.00.00.00.00 and mask 00.00.00.00.00.00 <dest-mac> Destination MAC address of transmitted packet <dmac-mask> Destination MAC mask Uses keyword any as the abbreviation of destination MAC address any (four) 00.00.00.00.00.00 and mask 00.00.00.00.00.00...
Page 281: Ingress-Acl Hybrid Rule Type-Ipv6-Tcp
Command Mode Hybrid ingress ACL configuration mode Syntax rule <1-500>{permit | deny} ipv6 tcp {<source-ipv6addr><sipv6-mask>| any}[source-port <0 -65535><sport-mask>]{<destination-ipv6addr><dipv6-mask>| any}[dest-port <0-65535><dpor t-mask>][<vlan-id>] Parameters Parameter Description <1-500> Rule number If the condition matches, permit to access permit 4-225 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 282: Ingress-Acl Hybrid Rule Type-Ipv6-Udp
ZXR10 2900E Series Command Reference Parameter Description If the condition matches, deny to access deny This rule is only valid for IPv6 TCP packet. Other packets ignore ipv6 tcp this rule. TCP source port number of transmitted packet source-port <0-65535>...
Page 283 <dport-mask> Destination port mask This rule is only valid for the message with specified VLAN ID. <vlan-id> Other messages ignore this rule. The rule of VLAN ID is 1~4094. 4-227 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 284: Ingress-Acl Hybrid Rule Type-Ipv6-Any
ZXR10 2900E Series Command Reference Usage Guidelines IPv6-UDP rule can match source-specified IPv6, any source IPv6, destination-specified IPv6, any destination IPv6, UDP source port number, UDP destination port number and VLAN field. 4.13.35 ingress-acl hybrid rule type-ipv6-any Purpose Configures the rule that the hybrid ingress ACL matches the IPv6 packet.
Page 285: Ingress-Acl Hybrid Rule Type-All
If the condition matches, permit to access deny Usage Guidelines All rules can match any packet. 4.13.37 clear ingress-acl hybrid Purpose Clears the hybrid ingress ACL instance. Command Mode Global configuration mode Syntax clear ingress-acl hybrid number <300-399> 4-229 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 286: Config Ingress-Acl Global
ZXR10 2900E Series Command Reference Parameter Parameter Description <300-399> Hybrid ingress ACL instance 4.13.38 config ingress-acl global Purpose Enters the global ingress ACL instance and configures. Command Mode Global configuration mode Syntax config ingress-acl global 4.13.39 ingress-acl global rule type-ip-protocol...
Page 287 Uses keyword any as the abbreviation of destination MAC address any (fifth) 00.00.00.00.00.00 and mask 00.00.00.00.00.00 Usage Guidelines Ip-protocol rule can match IPv4–specified protocol field, source-specified IP, any source IP, destination-specified IP, any destination IP, DSCP field, IP fragment fiedl, cos field, 4-231 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 288: Ingress-Acl Global Rule Type-Ip
ZXR10 2900E Series Command Reference VLAN field, source-specified MAC, any source MAC, destination-specified MAC and any destination MAC. The rule can be bound to one or all ports. 4.13.40 ingress-acl global rule type-ip Purpose Configures the rule that the global ingress ACL matches the IPv4 packet.
Page 289: Ingress-Acl Global Rule Type-Tcp
Configures the rule that the global ingress ACL matches the IPv4-TCP packet. Command Mode Global ingress ACL configuration mode Syntax rule <1-500>{permit | deny} port {<1-28>| any} tcp {<source-ipaddr><sip-mask>| any}[source- port <0-65535><sport-mask>]{<destination-ipaddr><dip-mask>| any}[dest-port <0-65535><d port-mask>][dscp <0-63>][fragment][cos <0-7>][<vlan-id>[<vlan-mask>]][<source-mac><sma c-mask>| any][<dest-mac><dmac-mask>| any] 4-233 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 290 ZXR10 2900E Series Command Reference Parameters Parameter Description <1-16> Global rule number If the condition matches, permit to access permit If the condition matches, deny to access deny One port number. Different devices have different port ranges. <1-28> Here take 2928E as an example. Bind global rule to one port.
Page 291: Ingress-Acl Global Rule Type-Udp
Syntax rule <1-500>{permit | deny} port {<1-28>| any} udp {<source-ipaddr><sip-mask>| any}[source-port <0-65535><sport-mask>]{<destination-ipaddr><dip-mask>| any}[dest-port <0-65535><dport-mask>][dscp <0-63>][fragment][cos <0-7>][<vlan-id>[<vlan-mask>]][<sour ce-mac><smac-mask>| any][<dest-mac><dmac-mask>| any] Parameters Parameter Description <1-16> Global rule number If the condition matches, permit to access permit 4-235 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 292 ZXR10 2900E Series Command Reference Parameter Description If the condition matches, deny to access deny One port number. Different devices have different port ranges. <1-28> Here take 2928E as an example. Bind global rule to one port. any (first) Binds the global rule to all ports This rule only matches UDP packet.
Page 293: Ingress-Acl Global Rule Type-Arp
If the condition matches, permit to access deny One port number. Different devices have different port ranges. <1-28> Here take 2928E as an example. Bind global rule to one port. any (first) Binds the global rule to all ports 4-237 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 294 ZXR10 2900E Series Command Reference Parameter Description This rule only matches ARP packet. The non-ARP packet ignores this rule. Sender network and host address of ARP packet. It is 32–bit IP <sender-ipaddr> address expressed in dotted decimal notation. Source mask and used for source. It is 32–bit IP address <sip-mask>...
Page 295: Ingress-Acl Global Rule Type-Any
Uses keyword any as the abbreviation of destination 0.0.0.0 and any (third) destination mask 0.0.0.0 <dest-mac> Destination MAC address of transmitted packet <dmac-mask> Destination MAC mask Uses keyword any as the abbreviation of source MAC address any (fourth) 00.00.00.00.00.00 and mask 00.00.00.00.00.00 4-239 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 296: Config Egress-Acl Basic
ZXR10 2900E Series Command Reference Usage Guidelines Any rule can match ether-type field, cos field, VLAN field, source-specified MAC, any source MAC, destination-specified MAC, any destination MAC. The rule can be bound to one or all ports. 4.13.45 config egress-acl basic Purpose Creates the basic ingress ACL instance and configures it.
Page 297: Clear Egress-Acl Basic
Global configuration mode Syntax clear egress-acl basic number <400-499> Parameter Parameter Description <400-499> Basic egress ACL instance number 4.13.48 config egress-acl extend Purpose Creates extended egress ACL instance and configures it. Command Mode Global configuration mode 4-241 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 298: Egress-Acl Extend Rule Type-Ip-Protocol
ZXR10 2900E Series Command Reference Syntax config egress-acl extend number <500-599> Parameter Parameter Description <500-599> Extended egress ACL instance number 4.13.49 egress-acl extend rule type-ip-protocol Purpose Configures the rule that the extended egress ACL matches IPv4 specified protocol field. Command Mode...
Page 299: Egress-Acl Extend Rule Type-Icmp
Source network or host of the transmitted package. It is 32–bit IP <source-ipaddr> address expressed in dotted decimal notation. Source mask and used for source. It is 32–bit IP address <sip-mask> expressed in dotted decimal notation. 4-243 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 300: Egress-Acl Extend Rule Type-Ip
ZXR10 2900E Series Command Reference Parameter Description Uses keyword any as the abbreviation of source 0.0.0.0 and any (first) source mask 0.0.0.0 The destination network or host address of the transmitted packet. <destination-ipaddr> It is 32–bit IP address expressed in dotted decimal notation.
Page 301: Egress-Acl Extend Rule Type-Tcp
IP addresses, any destination IP address, DSCP fields, or IP fragment fields. 4.13.52 egress-acl extend rule type-tcp Purpose Configures the rule that the extended egress ACL is used to match TCP message. Command Mode Extended egress ACL configuration mode 4-245 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 302 ZXR10 2900E Series Command Reference Syntax rule <1-500>{permit | deny} tcp {<source-ipaddr><sip-mask>| any}[source-port <0-65535><s port-mask>]{<destination-ipaddr><dip-mask>| any}[dest-port <0-65535><dport-mask>][establ ishing | established][dscp <0-63>][fragment] Parameters Parameter Description <1-500> Rule number If the condition matches, permit to access permit If the condition matches, deny to access deny This rule only matches TCP message.
Page 303: Egress-Acl Extend Rule Type-Udp
Source mask and used for source. It is 32–bit IP address <sip-mask> expressed in dotted decimal notation. Uses keyword any as the abbreviation of source 0.0.0.0 and any (first) source mask 0.0.0.0 4-247 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 304: Egress-Acl Extend Rule Type-Arp
ZXR10 2900E Series Command Reference Parameter Description UDP source port number of transmitted packet source-port <0-65535> The parameters of source-port can resolve the some known port numbers. Also the port number and mask can be directly inputted. <sport-mask> Source port number mask The destination network or host address of the transmitted packet.
Page 305: Clear Egress-Acl Extend
IP addresses, or any destination IP address. 4.13.55 clear egress-acl extend Purpose Clears extended egress ACL instance. Command Mode Global configuration mode Command Mode clear egress-acl extend number <500-599> Parameter Parameter Description <500-599> Extended egress ACL instance number 4-249 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 306: Config Egress-Acl Link
ZXR10 2900E Series Command Reference 4.13.56 config egress-acl link Purpose Creates layer 2 egress ACL instance and configures it. Command Mode Global configuration mode Command Mode config egress-acl link number <600-699> Parameter Parameter Description <600-699> Layer 2 egress ACL instance number 4.13.57 egress-acl link rule type-ip...
Page 307: Egress-Acl Link Rule Type-Arp
This rule is only valid for the message with specified VLAN ID. <vlan-id> Other messages ignore this rule. The rule of VLAN ID is 1~4094. <vlan-mask> Optional VLAN mask. The default value is 0xfff. <dest-mac> Destination MAC address of transmitted packet 4-251 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 308: Egress-Acl Link Rule Type-Other
ZXR10 2900E Series Command Reference Parameter Description <dmac-mask> Destination MAC mask Uses keyword any as the abbreviation of destination MAC address 00.00.00.00.00.00 and mask 00.00.00.00.00.00 Usage Guidelines ARP rule can match cos field, VLAN field, source-specified MAC, any source MAC, destination-specified MAC and any destination MAC.
Page 309: Egress-Acl Link Rule Type-Any
<1-500>{permit | deny} any [<vlan-id>[<vlan-mask>]][cos <0-7>][<dest-mac><dmac-mas k>| any] Parameters Parameter Parameter <1-500> Rule number If the condition matches, permit to access permit If the condition matches, deny to access deny This rule can match any packet. 4-253 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 310: Clear Egress-Acl Link
ZXR10 2900E Series Command Reference Parameter Parameter This rule is only valid for the cos-specified message. Other cos <0-7> messages ignore this rule. The range of cos is 0~7. This rule is only valid for the message with specified VLAN ID.
Page 311: Egress-Acl Hybrid Rule Type-All
If the condition matches, permit to access Usage Guidelines All rules can match any packet. 4.13.64 egress-acl hybrid rule type-any Purpose Configures the rule that the hybrid egress ACL matches non-IPv6 packet. Command Mode Hybrid egress ACL configuration mode 4-255 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 312: Egress-Acl Hybrid Rule Type-Arp
ZXR10 2900E Series Command Reference Syntax rule <1-500>{permit | deny} any {[ether-type <1501-65535>][cos <0-7>][<vlan-id>[<vlan-ma sk>]][<source-mac><smac-mask>| any][<dest-mac><dmac-mask>| any]} Parameters Parameter Description <1-500> Rule number If the condition matches, permit to access permit deny If the condition matches, deny to access This rule only matches non-IPv6 packet. IPv6 packet ignores this rule.
Page 313 <source-mac> Source MAC address of transmitted packet <smac-mask> Source MAC mask Uses keyword any as the abbreviation of source MAC address any (third) 00.00.00.00.00.00 and mask 00.00.00.00.00.00 <dest-mac> Destination MAC address of transmitted packet 4-257 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 314: Egress-Acl Hybrid Rule Type-Ip-Protocol
ZXR10 2900E Series Command Reference Parameter Description <dmac-mask> Destination MAC mask Uses keyword any as the abbreviation of destination MAC address any (four) 00.00.00.00.00.00 and mask 00.00.00.00.00.00 Usage Guidelines ARP rule can match sender-specified IP, any sender IP, target-specified IP, any target IP, cos field, VLAN field, source-specified MAC, any source MAC, destination-specified MAC and any destination MAC.
Page 315: Egress-Acl Hybrid Rule Type-Ip
IP, destination-specified IP, any destination IP, DSCP field, IP fragment fiedl, cos field, VLAN field, source-specified MAC, any source MAC, destination-specified MAC and any destination MAC. 4.13.67 egress-acl hybrid rule type-ip Purpose Configures the rule that the hybrid egress ACL matches the IPv4 packet. 4-259 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 316 ZXR10 2900E Series Command Reference Command Mode Hybrid egress ACL configuration mode Syntax rule <1-500>{permit | deny} ip {<source-ipaddr><sip-mask>| any}{<destination-ipaddr><dip-m ask>| any}[dscp <0-63>][fragment][cos <0-7>][<vlan-id>[<vlan-mask>]][<source-mac><smac -mask>| any][<dest-mac><dmac-mask>| any] Parameters Parameter Description <1-500> Rule number If the condition matches, permit to access...
Page 317: Egress-Acl Hybrid Rule Type-Ipv6-Any
<1-500> Rule number If the condition matches, permit to access permit deny If the condition matches, deny to access This rule is only valid for IPv6 packet. Other packets ignore this ipv6 any rule. 4-261 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 318: Egress-Acl Hybrid Rule Type-Ipv6-Ip-Protocol
ZXR10 2900E Series Command Reference Parameter Description IPv6 Source network or host of the transmitted package. The <source-ipv6addr> standard IPv6 address format is adopted, such as abcd:EF12::123 Source mask and used for source. It is expressed by an integer. <sipv6-mask>...
Page 319: Egress-Acl Hybrid Rule Type-Ipv6-Tcp
IPv6, destination-specified IPv6, any destination IPv6 and VLAN field. 4.13.70 egress-acl hybrid rule type-ipv6-tcp Purpose Configures the rule that the hybrid egress ACL matches the IPv6-TCP packet. Command Mode Hybrid egress ACL configuration mode 4-263 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 320 ZXR10 2900E Series Command Reference Syntax rule <1-500>{permit | deny} ipv6 tcp {<source-ipv6addr><sipv6-mask>| any}[source-port <0 -65535><sport-mask>]{<destination-ipv6addr><dipv6-mask>| any}[dest-port <0-65535><dpor t-mask>][<vlan-id>] Parameters Parameter Description <1-500> Rule number If the condition matches, permit to access permit If the condition matches, deny to access deny This rule is only valid for IPv6 TCP packet.
Page 321: Egress-Acl Hybrid Rule Type-Ipv6-Udp
Also the port number and mask can be inputted. <sport-mask> Source port mask The destination network or host address of the transmitted IPv6 <destination-ipv6addr> packet. The standard IPv6 address format is adopted, such as abcd:EF12::123 4 4-265 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 322: Egress-Acl Hybrid Rule Type-Tcp
ZXR10 2900E Series Command Reference Parameter Description Destination mask. It is used for destination and represented by <dipv6-mask> one integer. The value range is 1~128. Matches all destination IPv6 addresses. The destination and destination mask are all 0s. TCP destination port number of transmitted packet dest-port <0-65535>...
Page 323 <smac-mask> Source MAC mask Uses keyword any as the abbreviation of source MAC address any (third) 00.00.00.00.00.00 and mask 00.00.00.00.00.00 <dest-mac> Destination MAC address of transmitted packet <dmac-mask> Destination MAC address of transmitted packet 4-267 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 324: Egress-Acl Hybrid Rule Type-Udp
ZXR10 2900E Series Command Reference Parameter Description Uses keyword any as the abbreviation of destination MAC address any (fourth) 00.00.00.00.00.00 and mask 00.00.00.00.00.00 Usage Guidelines TCP rule can match source-specified IP, any source IP, destination-specified IP, any destination IP, DSCP field, IP fragment field, cos field, VLAN field, source-specified MAC, any source MAC, destination-specified MAC and any destination MAC.
Page 325 UDP rule can match source-specified IP, any source IP, UDP source port number, destination-specified IP, any destination IP, DSCP field, IP fragment field, cos field, VLAN field, source-specified MAC, any source MAC, destination-specified MAC and any destination MAC. 4-269 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 326: Clear Egress-Acl Hybrid
ZXR10 2900E Series Command Reference 4.13.74 clear egress-acl hybrid Purpose Clears the hybrid egress ACL instance. Command Mode Global configuration mode Syntax clear egress-acl hybrid number <700-799> Parameter Parameter Description <700-799> Hybrid egress ACL instance 4.13.75 move after/before Purpose Sorts the rule of ACL instance.
Page 327: Clear Rule
<vlan-range> Parameter Parameter Description <vlan-range> VLAN range Example The following example describes how to show the VLAN ID and the corresponding VLAN mask when VLAN 1–1000 is matched. zte(cfg)#show vlan-range 1-1000 index vlanId vlanMask 4-271 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 328: Show Acl Blinding
ZXR10 2900E Series Command Reference --------------------------- 0xffff 0xfffe 0xfffc 0xfff8 0xfff0 0xffe0 0xffc0 0xff80 0xff00 0xff00 0xff80 0xffc0 0xffe0 0xfff8 1000 0xffff 4.13.78 show acl blinding Purpose Shows the configuration information that ACL is bound to the interface. Command Mode...
Page 329: Show Acl Config
Used rule resource number : 4 AclNo AclName Direction AclType Rules BindPort BindVlan ----- -------------- --------- -------- ------ -------- -------- basic-1 ingress basic ingress extend ingress link ingress hybrid egress basic egress extend egress link egress hybrid ingress global 4-273 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 330: Show Acl Config Acl-Number/Acl-Name
ZXR10 2900E Series Command Reference 4.13.80 show acl config acl-number/acl-name Purpose Shows the detailed configuration of ACL instance. Command Mode Global configuration mode Syntax show acl config [<1-800>| name <word>][ active | command | deny | passive | permit | policy | rule <1-500>| snmp | time-range ]...
Page 331: Set Qos Priority-Mapping Port Trust-Mode
Selects profile according to the UP field of the message. The corresponding relation between UP and profile is decided by user-priority qos-profile configuration. The port default configuration is trust UP. 4-275 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 332: Set Qos Priority-Mapping Port Remark/Remapping
By default, trust user-priority. Example The following example describes how to configure port 20 to trust port-profile. zte(cfg)#set qos priority-mapping port 20 trust-mode port-profile 4.14.3 set qos priority-mapping port remark/remapping Purpose Configures message UP/DSCP remark/remapping based on port.
Page 333: Set Qos Priority-Mapping Port Port-To-Profile
One profile template number Usage Guidelines Bind the port to qos-profile. When trust-mode is configured as port-profile, select profile to implement QoS service according to binding relation. Default By default, port is bound to profile 0. 4-277 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 334: Set Qos Priority-Mapping Qos-Profile Dscp/Up-To-Profile
ZXR10 2900E Series Command Reference 4.14.6 set qos priority-mapping qos-profile dscp/up-to-profile Purpose Configures the corresponding relation between DSCP/UP to profile. Command Mode Global configuration mode Syntax set qos priority-mapping qos-profile {up-to-profile <0-7>| dscp-to-profile <0-63>} qos-pr ofile <0-127> Parameters Parameter Description Configures the binding relation between UP and profile.
Page 335 The following example describes how to configure QoS profile 100 drop priority to yellow, DSCP priority to 5, user priority to 2 and TC to 2. zte(cfg)#set qos priority-mapping qos 100 drop-priority yellow zte(cfg)#set qos priority-mapping qos 100 dscp-priority 5...
Page 336: Set Qos Priority-Mapping Qos-Profile Default
ZXR10 2900E Series Command Reference QoS Mapping Profile Table: Flags: QosIndex - Priority Mapping Profile TrafficClass - Local Traffic Class, DropPri - Local Drop Priority DSCPNew - New User Priority Value If Remark DSCP Priority Enable UsrPriNew - New User Priority Value If Remark User Priority Enable...
Page 337: Set Qos Queue-Schedule Enhance
Optimize internal resource allocation for a switch, so that queue scheduling is more accurate when congestion on the egress is not serious. 4.14.10 set qos queue-schedule mode Purpose Configures QoS queue scheduling unit. Command Mode Global configuration mode 4-281 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 338: Set Qos Queue-Schedule Port
ZXR10 2900E Series Command Reference Syntax set qos queue-schedule mode {byte | packet} Parameters Parameter Description Configures the scheduling mode based on the byte byte Configures the scheduling mode based on the packet packet Default By default, the scheduling is based on byte.
Page 339 Their scheduling priorities are as follows: cos7 > cos4 > [cos1, cos2, cos3, cos5, and cos6 are mixed into group WRR0. The priority is 1, and they are scheduled in the 1:2:3:1:2 proportion.] > cos0 4-283 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 340: Set Qos Traffic-Limit Mode
1:2, queue 4~5 is scheduled according to 2:4 and other queues are scheduled according to SP. zte(cfg)#set qos queue-schedule session 1 0 10 20 0 20 40 0 0 zte(cfg)#show qos queue-schedule session 1 Egress Queue Schedule Profile Table:...
Page 341: Set Qos Traffic-Limit Fe-Port Packet-Rate
Port number. The port number range varies with devices. Here, <1-24> takes 2928E as an example. <0-148810> Number of packets limited on the ingress port. <64-10240> Length of packets limited on the ingress port. disable Disables the port rate limit function. 4-285 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 342: Set Qos Traffic-Limit Fe-Port Packet-Type
ZXR10 2900E Series Command Reference Usage Guidelines Configures the ingress rate limit function according to this formula: ingress rate limit = number of packets * length of packets. The configuration is valid only in ingress rate limit global byte mode.
Page 343: Set Qos Traffic-Limit Ge-Port Packet-Rate
Port number. The port number range varies with devices. Here, <25-28> takes 2928E as an example. <0-148810> Number of packets limited on the ingress port. <64-10240> Length of packets limited on the ingress port. disable Disables the port rate limit function. 4-287 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 344: Set Qos Traffic-Limit Ge-Port Packet-Type
ZXR10 2900E Series Command Reference Usage Guidelines Configures the ingress rate limit function according to this formula: ingress rate limit = number of packets * length of packets. The configuration is valid only in ingress rate limit global byte mode.
Page 345: Set Qos Traffic-Limit Xge-Port Packet-Rate
10 GB port number. The port number range varies with devices. <2/1-2/4> Here, takes 2952E as an example. <0-148810> Number of packets limited on the ingress port. <64-10240> Length of packets limited on the ingress port. Disables the port rate limit function. disable 4-289 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 346: Set Qos Traffic-Limit Xge-Port Packet-Type
ZXR10 2900E Series Command Reference Usage Guidelines Configures the ingress rate limit function according to this formula: ingress rate limit = number of packets * length of packets. The configuration is valid only in ingress rate limit global byte mode.
Page 347: Set Qos Traffic-Shaping Fe-Port Data-Rate
4.14.24 set qos traffic-shaping fe-port queue data-rate Purpose Configures the egress shaping rate of 100M port based on queue. Command Mode Global configuration mode Syntax set qos traffic-shaping fe-port <1-24> queue <1-7>{data-rate <32-100000> burst-size <1-4 094>| disable} 4-291 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 348: Set Qos Traffic-Shaping Ge-Port Data-Rate
ZXR10 2900E Series Command Reference Parameters Parameter Description 100M port number. Different devices have different port number <1-24> ranges. Here take 2928E as an example. <1-7> Queue number data-rate Queue egress shaping rate <32-100000> Shaping rate value, the granularity is 32kbps.
Page 349: Set Qos Traffic-Shaping Ge-Port Queue Data-Rate
Disables queue egress shaping function. 4.14.27 set qos traffic-shaping xge-port data-rate Purpose Configures the egress traffic-shaping rate for a 10 GB port. Command Mode Global configuration mode Syntax set qos traffic-shaping xge-port <2/1-2/4>{data-rate <2-10000> burst-size <8-4094>| disabl 4-293 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 350: Set Qos Traffic-Shaping Xge-Port Queue Data-Rate
ZXR10 2900E Series Command Reference Parameters Parameter Description 10 GB port number. The port number range varies with devices. <2/1-2/4> Here, takes 2952E as an example. Egress traffic-shaping rate. data-rate <2-10000> Value of the traffic-shaping rate. The configuration granularity is 2 Mbps.
Page 351: Set Anti-Dos
When the anti-dos is enabled, filter Null Scan, SYN with sport<1024, Xmascan, SYSFIN attacking message. Default Disables anti-dos function. 4.14.30 show qos priority-mapping port Purpose Shows the priority mapping configuration based on port. Command Mode All configuration modes Syntax show qos priority-mapping port [<1-28>] 4-295 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 352: Show Qos Priority-Mapping Qos-Profile
ZXR10 2900E Series Command Reference Parameter Parameter Description One port number. Different devices have different port number <1-28> ranges. Here take 2928E as an example. Usage Guidelines The command without port number will display all port configurations. It can display default-up, remapping DSCP, remark DSCP/UP, port-to-profile and trust mode.
Page 353: Usage Guidelines
The command without parameters display all 128 profiles configuration information. Example 1. The following example describes how to display the configuration of profile 100. zte(cfg)#show qos priority-mapping qos-profile 100 QoS Mapping Profile Table: Flags: QosIndex - Priority Mapping Profile TrafficClass - Local Traffic Class, DropPri - Local Drop Priority...
Page 354: Show Qos Queue-Schedule Mode
ZXR10 2900E Series Command Reference TrafficClass - Local Traffic Class, DropPri - Local Drop Priority DSCPNew - New User Priority Value If Remark DSCP Priority Enable UsrPriNew - New User Priority Value If Remark User Priority Enable DSCPPri QosIndex TrafficClass...
Page 355: Show Qos Queue-Schedule Port
One port number. Different devices have different port number <1-28> ranges. Here take 2928E as an example. Example The following example describes how to show port 1 queue scheduling policy. zte(cfg)#show qos queue-schedule port 1 Port Egress Queue Schedule Table: Port ID : 1 Session Bind : Profile-SP...
Page 356: Show Qos Traffic-Limit
ZXR10 2900E Series Command Reference Parameter Parameter Description <1-7> Scheduling policy template number Example The following example describes how to show all queue scheduling policy template configuration. zte(cfg)#show qos queue-schedule session Egress Queue Schedule Profile Table: Session ID : Profile-1...
Page 357: Show Qos Traffic-Shaping
<1-28> ranges. Here take 2928E as an example. Example The following example describes how to show port 1 egress shaping configuration. zte(cfg)#show qos traffic-shaping port 1 Port Egress Traffic Shaping Table: Port ID : 1 Port Shaping Rate (Kbps) : No-Limit...
Page 358: Show Anti-Dos
ZXR10 2900E Series Command Reference 4.14.37 show anti-dos Purpose Shows anti-dos configuration. Command Mode All configuration mode Syntax show anti-dos 4.14.38 set qos policer mode Purpose Configures flow policer. Command Mode Global configuration mode Syntax set qos policer <0-383> mode {aware | blind} cir <32-1048576> cbs <20000-268435456>{ebs <20000-268435456>| pir <32-1048576>...
Page 359: Set Qos Policer Exceed-Action
The following example describes how to configure flow policer to color-sensitive mode, cir=64, cbs=20000, pir=128 and pbs=30000. zte(cfg)#set qos policer 0 mode aware cir 64 cbs 20000 pir 128 pbs 30000 policer 0:the real configured cir is 64Kbps,cbs is 20000Bytes,pir is 128Kbps, pbs is 30000Bytes 4.14.39 set qos policer exceed-action...
Page 360: Set Qos Policer Exceed-Action Remark Profile
ZXR10 2900E Series Command Reference 4.14.40 set qos policer exceed-action remark profile Purpose Configures the binding between flow policer and qos-profile and action mode. Command Mode Global configuration mode Syntax set qos policer <0-383> exceed-action remark profile <0-127> up {no-change | enable-mo...
Page 361: Set Qos Policer Counter
Disables counter. disable Usage Guidelines Multiple flow policers can be bound to the same counter. 4.14.43 set policy policing Purpose Enables flow policer and handles the specified flow by policer. Command Mode Global configuration mode 4-305 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 362: Set Policy Remark Ingress-Acl
10 user-priority 2 zte(cfg)#set qos priority-mapping qos-profile 10 drop-priority green zte(cfg)#set qos policer 10 mode aware cir 32 cbs 20000 ebs 40000 policer 10: the real configured cir is 32Kbps,cbs is 20000Bytes,ebs is 40000Bytes zte(cfg)#set qos policer 10 exceed-action red remark yellow remar...
Page 363: Set Policy Remark Egress-Acl
Egress ACL number. Egress ACL can directly modify the <400-799> UP/DSCP of the flow. <1-500> Rule number of egress ACL UP/DSCP is not modified. no-change <0-7> Modifies UP to this value <0-63> Modifies DSCP to this value 4-307 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 364: Set Mirror Analyze-Port Session
ZXR10 2900E Series Command Reference Usage Guidelines One of the ACL actions. 4.14.46 set mirror analyze-port session Purpose Configures the binding between flow mirroring monitor port and port mirroring session. Command Mode Global configuration mode Syntax set mirror analyze-port session <1-3>{enable | disable}...
Page 365: Set Policy Redirect
Rule number of ingress ACL Redirects the specified flow to CPU port <1-28> The destination port of flow redirection Usage Guidelines One of the ACL actions. 4.14.49 set policy statistics Purpose Configures flow count function. 4-309 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 366: Set Policy Vlan-Remark
ZXR10 2900E Series Command Reference Command Mode Global configuration mode Syntax set policy statistics in acl <1-800> rule <1-500> counter <0-1023> Parameters Parameter Description <1-800> ACL number <1-500> The rule number of ACL <0-1023> Flow counter Usage Guidelines One of the ACL actions.
Page 367: Set Policy Harddrop
One of the ACL actions. 4.14.52 clear policy remark Purpose Clears the configuration that qos-profile is used to modify UP/DSCP. Command Mode Global configuration mode Syntax clear policy remark in acl <1-800> rule <1-500> 4-311 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 368: Clear Policy Policing
ZXR10 2900E Series Command Reference Parameters Parameter Description <1-800> ACL number <1-500> The rule number of ACL 4.14.53 clear policy policing Purpose Clears the configuration that flow policer is used to handle the specified flow. Command Mode Global configuration mode Syntax clear policy in acl <1-800>...
Page 369: Clear Policy Statistics
Clears the configuration that the specified flow is redirected to the specified port. Command Mode Global configuration mode Syntax clear policy redirect in acl <1-399,800> rule <1-500> Parameters Parameter Description <1-399,800> Ingress ACL number <1-500> The rule number of ACL 4-313 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 370: Clear Policy Vlan-Remark
ZXR10 2900E Series Command Reference 4.14.57 clear policy vlan-remark Purpose Clears the configuration that the specified flow VLAN tag is modified. Command Mode Global configuration mode Syntax clear policy vlan-remark in acl <1-800> rule <1-500> Parameters Parameter Description <1-800> ACL number <1-500>...
Page 371: Clear Qos Policer-Counter
<counterlist> Parameter Parameter Description <counterlist> Flow policer counter list, in range of 0~383 4.14.61 clear qos policer Purpose Clears the configuration of flow policer. Command Mode Global configuration mode Syntax clear qos policer <0-383> 4-315 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 372: Show Qos Policer
ZXR10 2900E Series Command Reference Parameter Parameter Description <0-383> One flow policer ID 4.14.62 show qos policer Purpose Shows the configuration of flow policer. Command Mode All configuration modes Syntax show qos policer [<0-383>] Parameter Parameter Description <0-383> One flow policer ID Usage Guidelines The flow policer without configuration will have the corresponding prompt.
Page 373: Show Qos Policy-Counter
The command without parameter will display the counter of all specified flow counter. 4.14.64 show qos policer-counter Purpose Shows the flow policer counter. Command Mode All configuration modes Syntax show qos policer-counter [<0-383>] Parameter Parameter Description <0-383> Flow policer ID 4-317 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 374: Show Policy
ZXR10 2900E Series Command Reference 4.14.65 show policy Purpose Shows various binding configurations of the specified flow. Command Mode All the modes Syntax show policy [mirror | redirect | statistics | policing [<0-383>]| vlan-remark | remark | harddr Parameters Parameter...
Page 375: Set Qos Traffic-Limit Ge-Port|Fe-Port Protect
100M port number. Different devices have different port number <1-24> ranges. Here take 2928E as an example. Rate limit protection. protect Enables the 100M port egress rate limit function. enable Disables the 100M port egress rate limit function. disable 4-319 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 376: Set Qos Traffic-Limit Ge-Port|Fe-Port Protect Time
ZXR10 2900E Series Command Reference Default Disables the 100M port rate limit function. 4.14.68 set qos traffic-limit ge-port|fe-port protect time Purpose Configures the port shutdown time when the 100M port rate limit function is enabled. Command Mode Global configuration mode Syntax set qos traffic-limit {ge-port|fe-port}<1-24>protect time <1-10>...
Page 377: Pvlan Configuration
The communi-port can interwork with the promise-port, the communi-port in the same session, and normal ports, and cannot interwork with the isolate-port. 4.15.2 clear vlan pvlan session Purpose Clears PVLAN configuration. 4-321 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 378: Show Vlan Pvlan Session
ZXR10 2900E Series Command Reference Command Mode Global configuration mode Syntax clear vlan pvlan [session <1-4>] Parameter Parameter Description <1-4> PLVAN session number 4.15.3 show vlan pvlan session Purpose Shows PVLAN configuration. Command Mode Global configuration mode Syntax show vlan pvlan [session <1-4>]...
Page 379: L2Pt Configuration
Enables the transparent transmission function of layer-2 protocol Protocol message is dropped. disable Disables the transparent transmission function and recovers default configuration. Different protocols have different invalid configurations. 4.16.2 show l2pt Purpose Shows IEEE RESERVE MC message transparent transmission configuration. 4-323 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 380: Ipv4 Layer 3 Configuration
ZXR10 2900E Series Command Reference Command Mode All modes Syntax show l2pt Example zte(cfg)#show l2pt L2pt state: Enable : none Disable: none Invalid: 0x00, 0x02, 0x03, 0x04 0x05, 0x06, 0x07, 0x08 0x09, 0x0a, 0x0b, 0x0c 0x0d, 0x0e, 0x0f, 0x10 0x11,...
Page 381: Trace
Minimum TTL, that is, the number of hops allowed for the first <1-255> packet. The value of min-ttl must be smaller than or equal to that of max-ttl. <1-65535> Number of detection packets sent every time. 4-325 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 382: Set Ipport Enable/Disable
Usage Guidelines The ZXR10 2900E series layer 3 port is mainly used for switch management. It supports many application layer protocols including WEB, SSH, and TELNET. Before enabling the layer 3 port, you must configure the IP address, VLAN, and MAC address. The MAC address is optional, and the system MAC address is used by default.
Page 383: Set Ipport Ipaddress
4.17.5 set ipport mac Purpose Configures MAC address of layer 3 port. Command Mode Layer 3 configuration mode Syntax set ipport <0-63> mac <HH.HH.HH.HH.HH.HH> Parameters Parameters Description <0-63> Layer 3 interface number <HH.HH.HH.HH.HH.HH> MAC address 4-327 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 384: Set Ipport Vlan
ZXR10 2900E Series Command Reference Usage Guidelines MAC address range is from 00.d0.d0.f0.00.00 to 00.d0.d0.ff.ff.ff. If MAC address is not configured, use the MAC address of the switch to replace it. If MAC address of IP port is already configured, use this command to replace the old MAC address with a new one. To modify MAC parameters, disable the layer 3 interface first.
Page 385: Arp Add
Example The following example describes how to add static route to network 192.168.1.0/24, with gateway is 192.168.1.3 and metric is 3. zte(cfg-router)#iproute 192.168.1.0/24 192.168.1.255 3 zte(cfg-router)#iproute 192.168.1.0 255.255.255.0 192.168.1.3 3 4.17.8 arp add Purposes Adds static ARP entry. Command Mode...
Page 386: Arp Delete
ZXR10 2900E Series Command Reference Parameter Description <0-63> Layer 3 port number Usage Guidelines The IP address in the ARP entry must be within the IP subnet of the specified layer 3 interface. Example The following example describes how to add static ARP entry 192.168.1.167, MAC address 00.00.00.00.11.22, layer 3 port 1.
Page 387: Arp Gratuitous-Send
Example The following example describes how to configure the timeout of layer 3 port 1 to 100 minutes. zte(cfg-router)#arp ipport 1 timeout 100 4.17.11 arp gratuitous-send Purpose Enables the free ARP function and sets the free ARP packet sending interval.
Page 388: Clear Arp
ZXR10 2900E Series Command Reference Instructions After this function is enabled by the command, the device sends free ARP packets periodically to all layer-3 interfaces. If the device receives an ARP response, it indicates that there is a duplicate IP address on the corresponding layer-3 interface. In that case, the "layer3IpConflictTrap"...
Page 389: Clear Ipport
The following example describes how to delete all static entries. zte(cfg-router)#clear iproute The following example describes how to delete the static route to the network 192.168.1.0/24, gateway 192.168.1.12. zte(cfg-router)#clear iproute 192.168.1.0/24 192.168.1.12 4.17.14 clear ipport Purpose Deletes the configuration of ipport.
Page 390: Hardware-Iproute Enable/Disable
ZXR10 2900E Series Command Reference Command Mode Layer-3 configuration mode Syntax clear arp gratuitous-send 4.17.16 hardware-iproute enable/disable Purpose Enables/Disables the hardware routing function. Command Mode Layer 3 configuration mode Syntax hardware-iproute {enable | disable} Parameters Parameter Description Enables this function.
Page 391: Show Ipport
3. The following example describes how to display the static ARP information at layer 3 port 1. zte(cfg-router)#show arp ipport 1 static 4. The following example describes how to display the ARP information of IP address 192.168.1.167.
Page 392: Show Iproute
ZXR10 2900E Series Command Reference Usage Guidelines This command without parameters displays the summary information of all layer 3 ports. The command with parameters displays the detailed information of port. Examples 1. This command displays the summary information of all layer 3 ports.
Page 393: Show Hardware-Iproute
Hardware-iproute is enabled. 4.18 IPv6 Layer 3 Configuration 4.18.1 set ipv6port vlan Purpose Configures the VLAN bound to an IPv6 Layer 3 interface. Command Mode Layer 3 configuration mode Syntax set ipv6port <0> vlan <1-4094> 4-337 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 394: Set Ipv6Port Ipv6Address
ZXR10 2900E Series Command Reference Parameters Parameter Description <0> Number of an IPv6 Layer 3 interface. The current value is 0. <1-4094> VLAN ID. 4.18.2 set ipv6port ipv6address Purpose Configures the IPv6 address of an IPv6 Layer 3 interface and the prefix length of the address.
Page 395: Set Ipv6Port Enable/Disable
IPv6 address of the next hop. Usage Guidelines This command cannot be used for route forwarding on a route relay device but can be used for the default route function of a host . 4-339 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 396: Clear Ipv6Port
ZXR10 2900E Series Command Reference 4.18.5 clear ipv6port Purpose Clears configurations of an IPv6 Layer 3 interface. Command Mode Layer 3 configuration mode Syntax clear ipv6port <0>[ipv6address <ipv6Addr/M>] Parameters Parameter Description <0> Number of an IPv6 Layer 3 interface. The current value is 0.
Page 397: Show Ipv6Route
----------------- default 2001::10 Total: 1 4.18.9 show ipv6port nd Purpose Displays neighbor information of an IPv6 device. The function of this command is the same as that of the show arp command in IPv4. 4-341 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 398: Ping6
ZXR10 2900E Series Command Reference Command Mode All configuration modes Syntax show ipv6port <0> nd Parameters Parameter Description <0> Number of an IPv6 Layer 3 interface. The current value is 0. Examples The following example describes how to display neighbor information of an IPv6 device.
Page 399: Dai Configuration
Disables inspection disable Default By default, disables the inspection. Example The following example describes how to enable the legality inspection of the source IP address and the destination IP address. zte(cfg)#set arp-inspection validate ip enable 4-343 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 400: Set Arp-Inspection Vlan Enable/Disable
ZXR10 2900E Series Command Reference 4.19.2 set arp-inspection vlan enable/disable Purpose Enables/Disables DAI function based on VLAN. Command Mode Global configuration mode Syntax set arp-inspection vlan <vlanlist>{enable | disable} Parameters Parameter Description <vlanlist> VLAN list Enables DAI function enable disable...
Page 401: Set Arp-Inspection Port Limit
VLAN and the DAI function of the port are enabled, can the port support the DAI function. Default Configures trust port. Example The following example describes how to configure port 2 to untrust port. zte(cfg)#set arp-inspection port 2 untrust 4.19.4 set arp-inspection port limit Purpose Configures the maximum number of ARP messages. Command Mode...
Page 402: Show Arp-Inspection
ZXR10 2900E Series Command Reference Default By default, the number of ARP messages that the port processes every second is not limited. Example The following example describes how to configure the maximum number of ARP messages that port 8 processes every second to 20.
Page 403: Access Service Configuration
VLAN 1 by default. If the server distributes vlanjump information, take the server as a standard. If vlanjump function is disabled and server does not distribute vlanjump, the jump will not happen. 4-347 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 404: Dot1X Re-Authenticate Enable/Disable
The following example describes how to configure the users of port 1, 3, 5 and 7 to access VLAN 1000 when the authentication is passed. zte(cfg)#set vlan 1000 enable zte(cfg)#set port 1,3,5,6 vlanjump enable defaultauthvlan 1000 4.20.2 dot1x re-authenticate enable/disable Purpose Enables/Disables re-authentication mechanism.
Page 405: Dot1X Quiet-Period
Default By default, the interval of re-authentication is 3600 seconds. Example The following example describes how to configure the interval of re-authentication to 7200 seconds. zte(cfg-nas)#dot1x re-authenticate period 7200 4.20.4 dot1x quiet-period Purpose Configures authentication quiet time. Command Mode NAS configuration mode Syntax dot1x quiet-period <0-65535>...
Page 406: Dot1X Tx-Period
ZXR10 2900E Series Command Reference Example The following example describes how to configure the authentication quiet time to 120 seconds. zte(cfg-nas)#dot1x quiet-period 120 4.20.5 dot1x tx-period Purpose Configures the waiting time of retransmitted EAPOL data package when the authentication system can not receive the response from the client system.
Page 407: Dot1X Server-Timeout
The authentication sever system interval. the unit is second. Default The authentication sever system interval is 30 seconds. 4.20.8 dot1x max-request Purpose Configures the overtime retransmission times of challenge response received from the authentication system from client system. 4-351 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 408: Dot1X Add Vlan Mac
ZXR10 2900E Series Command Reference Command Mode NAS configuration mode Syntax dot1x max-request <1-10> Parameter Parameter Description <1-10> Overtime retransmission times Default The default overtime retransmission times is 2. Example The following example describes how to configure the overtime retransmission times to 5.
Page 409: Dot1X Delete Vlan
Example The following example describes how to configure users to use the special MAC address 01.d0.d0.00.00.01 when users are authenticated in VLAN 100. zte(cfg-nas)#dot1x add vlan 100 mac 01.d0.d0.00.00.01 4.20.10 dot1x delete vlan Purpose Deletes the special destination MAC address used for authentication in the specified VLAN.
Page 410: Clear Client Index
ZXR10 2900E Series Command Reference 4.20.12 clear client index Purpose Deletes the specified client end user. Command Mode NAS configuration mode Syntax clear client index <0-255> Parameter Parameter Description <0-255> User number 4.20.13 clear client port/vlan Purpose Deletes the client end user of the specified port/VLAN.
Page 411 The following example describes how to show access user status. zte(cfg-nas)#show client MaxClients : 256 HistoryAccessClientsTotal : 0 OnlineClients: 0 HistoryFailureClientsTotal: 0 4.20.16 show client index Purpose Shows the information of the specified access user. Command Mode All configuration modes 4-355 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 412: Show Client Index
ZXR10 2900E Series Command Reference Syntax show client index <0-255> Parameter Parameter Description <0-255> User number 4.20.17 show client mac Purpose Shows access information of the user in a certain MAC address. Command Mode All modes Syntax show client mac <HH.HH.HH.HH.HH.HH>...
Page 413: Aaa-Control Port Dot1X
Disables 802.1x access authentication function at the port. Example The following example describes how to enable 802.1x access authentication function at the port zte(cfg-nas)#aaa-control port 1 dot1x enable 4.20.20 aaa-control port port-mode Purpose Configures authentication control mode at the port.
Page 414: Aaa-Control Port Protocol
ZXR10 2900E Series Command Reference Parameters Parameter Description <portlist> Port list Enables 802.1x authentication. auto Forced authentication is not passed. force-unauthorized Forced authentication is passed. force-authorized Default By default, the auto is selected. 4.20.21 aaa-control port protocol Purpose Configures the authentication mode at the port.
Page 415: Aaa-Control Port Accounting
Default Disables port accounting function. Example The following example describes how to enable the accounting function of port 1, 3 and 5. zte(cfg-nas)#aaa-control port 1,3,5 accounting enable 4.20.23 aaa-control port multiple-hosts Purpose Enables/Disables multiple users access function at the port.
Page 416: Aaa-Control Port Max-Hosts
ZXR10 2900E Series Command Reference Parameter Description Enables multiple users access function at the port enable disable Disables multiple users access function at the port Default Disables multiple users access function at the port. Example The following example describes how to enable multiple users access function at the port 1, 3 and 5.
Page 417: Aaa-Control Port Keepalive
Chapter 4 Service Configuration zte(cfg-nas)#aaa-control port 1,3,5 max-hosts 5 4.20.25 aaa-control port keepalive Purpose Enables/Disables the abnormal offline detection at the port. Command Mode NAS configuration mode Syntax aaa-control port <portlist> keepalive {enable | disable} Parameters Parameter Description <portlist> Port list enable Enables the abnormal offline detection at the port.
Page 418: Aaa-Control Port Keepalive Antiproxy Add/Delete
ZXR10 2900E Series Command Reference Parameters Parameter Description <portlist> Port list <1-3600> Circle of abnormal offline detection at the port. The unit is second. Default The circle of abnormal offline detection at the port is 10 seconds. Example The following example describes how to configure the circle of abnormal offline detection at the port 1, 3 and 5 to 3600 seconds.
Page 419: Aaa-Control Port Keepalive Antidhcp
Limits the number of UDP ports Default Disables port anti-deception function. Example The following example describes how to limit the port 1, 3 and 5 to modify IP function. zte(cfg-nas)#aaa-control port 1,3,5 keepalive antiproxy add ip-modified 4.20.28 aaa-control port keepalive antidhcp Purpose Enables/Disables port anti-DHCP deception function.
Page 420: Aaa-Control Port Keepalive Client-Ip
ZXR10 2900E Series Command Reference 4.20.29 aaa-control port keepalive client-ip Purpose Enables/Disables the function of getting user IP address. Command Mode NAS configuration mode Syntax aaa-control port <portlist> keepalive client-ip {enable | disable} Parameters Parameter Description <portlist> Port list Enables the function of getting user IP address.
Page 421: Radius Isp
Description Port list. The command without parameters means displaying the <portlist> configuration of all ports. Example The following example describes how to show the aaa configuration of port 1. zte(cfg-nas)#show aaa-control port 1 PortId PortControl : auto Dot1x : enabled...
Page 422: Radius Isp Add/Delete Accounting
ZXR10 2900E Series Command Reference 4.20.32 radius isp add/delete accounting Purpose Adds/Deletes an accounting server in the ISP domain. Command Mode NAS configuration mode Syntax radius isp <ispname>{add | delete}accounting <A.B.C.D>[<0-65535>] Parameters Parameter Description <ispname> ISP name Adds an accounting server...
Page 423: Radius Isp Client
The default UDP port is 1812. Example The following example describes how to add authentication server 10.40.89.78 into test ISP domain. The default port number is used. zte(cfg-nas)#radius isp test add authentication10.40.89.78 4.20.34 radius isp client Purpose Configures the RADIUS client end address.
Page 424: Radius Isp Sharedsecret
ZXR10 2900E Series Command Reference Example The following example describes how to configure the client end address of RADIUS to 10.40.89.100. zte(cfg-nas)#radius isp test client 10.40.89.100 4.20.35 radius isp sharedsecret Purpose Configures the shared password of the filed. Command Mode...
Page 425: Radius Isp Defaultisp
Default Disables the full account in the filed. Example The following example describes how to enable the full account in the filed. zte(cfg-nas)#radius isp test fullaccount enable 4.20.37 radius isp defaultisp Purpose Configures/cancels the ISP domain as the default field.
Page 426: Radius Isp Description
ZXR10 2900E Series Command Reference 4.20.38 radius isp description Purpose Configures description information of ISP domain. Command Mode NAS configuration mode Syntax radius isp <ispname> description <string> Parameters Parameter Parameter <ispname> ISP name <string> Description information of ISP 4.20.39 radius nasname Purpose Configures NAS name.
Page 427: Radius Delimiter
<0-4294967295> Parameter Parameter Description The saving time of accounting package that fails to be sent. The <0-4294967295> unit is second. Default The saving time of accounting package that fails to be sent is 0. 4-371 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 428: Radius Timeout
ZXR10 2900E Series Command Reference 4.20.42 radius timeout Purpose Configures the retransmission interval of remote authentication request. Command Mode NAS configuration mode Syntax radius timeout <1-255> Parameter Parameter Description <1-255> Retransmission interval. The unit is second. Default The retransmission interval is 3 seconds.
Page 429: Clear Accounting-Stop
Command Mode All modes Syntax show radius [ispname <ispname>] Parameter Parameter Description ISP name. The command without parameters displays all ISP <ispname> configurations. Example The following example describes how to show all ISP configurations. 4-373 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 430: Show Radius Accounting-Stop
ZXR10 2900E Series Command Reference zte(cfg-nas)#show radius NAS name : name-of-nas Retransmit times Retransmit timeout: 3 Keep time : 3600 Isp Delimiter Default Isp : test Client : 0.0.0.0 IspName : test DefaultIsp : Yes Description : FullAccounts: Yes SharedSecret: radius-interactive...
Page 431: Qinq Configuration
Deletes customer port disable Example The following example describes how to configure port 1, 2, 3 and 4 to customer port. zte(cfg)#set vlan qinq customer port 1-4 enable 4.21.2 set vlan qinq uplink port Purpose Adds/Deletes the uplink port of QinQ.
Page 432: Set Vlan Egress-Tpid Session
<0xHHHH> egress-tpid value Example The following example describes how to configure the egress-tpid of template 7 to 0x8910. zte(cfg)#set vlan egress-tpid sesion 1 tpid-value 0x8910 4.21.4 set port egress-tpid Purpose Configures the port bound to the template. Command Mode...
Page 433: Show Vlan Egress-Tpid
The following example describes how to show the egress-tpid of all templates. zte(cfg)#show vlan egress-tpid EGRESS TPID PROFILE TABLE: SessionId TPID --------- -------- 0x8100 0xaaaa 0x0000 0x0000 0x0000 0x0000 0x0000 0x0000 4.21.6 show vlan qinq Purpose Shows the customer/uplink port of QinQ. 4-377 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 434: Syslog Configuration
ZXR10 2900E Series Command Reference Command Mode Global configuration mode Syntax show vlan qinq Example The following example describes how to show QinQ port. zte(cfg)#show vlan qinq Customer port : 1,5 Uplink port 4.22 syslog Configuration 4.22.1 set syslog module Purpose Enables/Disables the syslog function based on module.
Page 435: Set Syslog Level
Enables syslog function. enable disable Disables syslog function. Example This example shows how to enable the syslog function of all modules. zte(cfg)#set syslog module all enable 4.22.2 set syslog level Purpose Configures the level of Syslog information. Command Mode Global configuration mode...
Page 436: Set Syslog Add Server
ZXR10 2900E Series Command Reference Default The default configuration is level 7. Example The following example describes how to configure the level of syslog alarm to 7 (normal information). zte(cfg)#set syslog level informational 4.22.3 set syslog add server Purpose Configures the syslog server.
Page 437: Set Syslog Enable/Disable
Parameter Description <1-5> Syslog server ID, in the range of 1-5 Example The following example describes how to delete syslog server 1. zte(cfg)#set syslog delete server 1 4.22.5 set syslog enable/disable Purpose Enables/disables syslog function. Command Mode Global configuration mode...
Page 438: Ntp Configuration
Authentication id, in the range of 1-255 <string> md5 authentication code, in the range of 1~16 characters Example The following example describes how to configure the NTP authentication key to zte. zte(cfg)#set ntp add authentication-key 1 md5 zte 4-382 SJ-20120409144109-003|2012-07-02(R1.0)
Page 439: Set Ntp Delete Authentication-Key
Adds trusted authentication key delete Deletes trusted authentication key <1-255> Authentication number, in range of 1~255 Example The following example describes how to configure the trusted authentication key of NTP to 1. zte(cfg)#set ntp add trusted-key 1 4-383 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 440: Set Ntp Authenticate
ZXR10 2900E Series Command Reference 4.23.4 set ntp authenticate Purpose Enables/Disables NTP authentication function. Command Mode Global configuration mode Syntax set ntp authenticate {enable | disable} Parameters Parameter Description Enables NTP authentication function enable Disables NTP authentication function disable Default Disables NTP authentication function.
Page 441: Set Ntp Source
Example The following example describes how to configure the IP address of NTP server to 202.10.10.10, the protocol version number to 2. zte(cfg)#set ntp server 202.10.10.10 version 2 4.23.6 set ntp source Purpose Configures the source IP address that the switch transmits NTP data package.
Page 442: Set Ntp Timezone
ZXR10 2900E Series Command Reference Syntax set ntp clock-period <5-2147483647> Parameter Parameter Description <5-2147483647> Synchronization clock circle. The unit is second. Default The synchronization clock circle is 10 seconds. 4.23.8 set ntp timezone Purpose Configures the timezone to which NTP belongs.
Page 443: Set Ntp Src-Udp-Port
The source UDP port of the sent NTP packets is 123. The source UDP port of the sent NTP packets is 1000. 1000 Defaults By default, the udp_port is 1000. 4.23.11 show ntp Purpose Shows the NTP configuration. Command Mode All modes 4-387 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 444: Garp/Gvrp Configuration
ZXR10 2900E Series Command Reference Syntax show ntp Example The following example describes how to display the NTP configuration. zte(cfg)#show ntp ntp protocol is enabled ntp server address : 10.40.89.78 ntp source address : None ntp source udp port : 1000...
Page 445: Set Garp Enable/Disable
The following example describes how to configure VLAN 2, 4 to permit dynamically adding port 2 and 4, VLAN 3, 5 to forbid dynamically adding port 3 and 5. zte(cfg)#set vlan 2,4 permit port 2,4 zte(cfg)#set vlan 3,5 forbid port 3,5 zte(cfg)#show vlan VlanType: 802.1q vlan...
Page 446: Set Garp Timer
ZXR10 2900E Series Command Reference Command Mode Global configuration mode Syntax set garp {enable | disable} Parameter Parameter Description enable Enables GARP function disable Disables GARP function Default By default, GARP function is disabled. 4.24.3 set garp timer Purpose Configures GARP timer.
Page 447: Show Garp
GARP is enabled! GARP Timers: Hold Timeout 100 milliseconds Join Timeout 200 milliseconds Leave Timeout 600 milliseconds LeaveAll Timeout : 10000 milliseconds 4.24.5 set gvrp enable/disable Purpose Enables/Disables GVRP function. Command Mode Global configuration mode 4-391 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 448: Set Gvrp Port/Trunk Enable/Disable
ZXR10 2900E Series Command Reference Syntax set gvrp {enable | disable} Parameter Parameter Description enable Enables GVRP function disable Disables GVRP function Default By default, GVRP function is disabled. 4.24.6 set gvrp port/trunk enable/disable Purpose Enables/Disables GVRP function based on port/trunk.
Page 449: Set Gvrp Port/Trunk Registration
Default Port/trunk can be added to dynamic VLAN. 4.24.8 show gvrp Purpose Shows GVRP configuration. Command Mode All modes Syntax show gvrp Example The following example describes how to show GVRP configuration. 4-393 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 450: Dhcp Configuration
ZXR10 2900E Series Command Reference zte(cfg)#show gvrp GVRP is enabled! PortId Status Registration LastPduOrigin ------ -------- ------------ ----------------- Disabled Normal 00.00.00.00.00.00 Disabled Normal 00.00.00.00.00.00 4.25 DHCP Configuration 4.25.1 set dhcp snooping-and-option82 enable/disable Purpose Enables/Disables DHCP snooping and Option82. Command Mode...
Page 451: Set Dhcp Port Server/Cascade/Client
Disables DHCP Snooping function at port. Example The following example describes how to enable DHCP snooping function on port 10. zte(cfg)#set dhcp snooping add port 10 DHCP snooping-and-option82 is disabled (0x40000cf0) zte(cfg)#set dhcp snooping-and-option82 enable zte(cfg)#set dhcp snooping add port 10 4.25.3 set dhcp port server/cascade/client...
Page 452: Set Dhcp Trunk Server/Default
ZXR10 2900E Series Command Reference Parameter Description Configures the port connecting with DHCP Sever. It is the trust server port. Configures the port to be cascaded. It is the untrust port. cascade Configures the port to be directly connected with DHCP Client. It client is the untrust port.
Page 453: Set Dhcp Ip-Source-Guard Add/Delete
DHCP snooping function should be enabled first. Example The following example describes how to enable the ip-source-guard function of port 9~10. zte(cfg)#set dhcp ip-source-guard add port 9-10 Fail to enable ip source guard on port 9. DHCP snooping is disabled on this port (0x40000cea)
Page 454: Set Dhcp Snooping Bind-Entry Mac Ip Vlan Port
ZXR10 2900E Series Command Reference 4.25.6 set dhcp snooping bind-entry mac ip vlan port Purpose Adds the static user information binding entry. Command Mode Global configuration mode Syntax set dhcp snooping bind-entry mac <HH.HH.HH.HH.HH.HH> ip <A.B.C.D> vlan <1-4094> port <1-28>...
Page 455: Set Dhcp Option82 Add/Delete
4.25.8 set dhcp option82 add/delete Purpose Enables/Disables port DHCP Option82 function. Command Mode Global configuration mode Syntax set dhcp option82 {add | delete}{port <portlist>| trunk <trunklist>} Parameters Parameter Description Enables option82 function Disables option82 function delete 4-399 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 456: Set Dhcp Option82 Sub-Option Device
The configuration is in character string format. Usage Guidelines Device identification information can locate the specified switch in user location procedure. Example The following example describes how to configure option82 ani to zte-test. zte(cfg)#set dhcp option82 sub-option device ani zte-test 4.25.10 set dhcp option82 sub-option Purpose Configures the sub-option of DHCP Option82.
Page 457 Tag of the sub option. <1-255> ID of the tag. It cannot be 1, 2, or 6. value Value of the sub option. <string> The contents are in character string format. Disables the sub option. 4-401 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 458: Set Dhcp Option82 Mode Port
ZXR10 2900E Series Command Reference 4.25.11 set dhcp option82 mode port Purpose Configures the binding mode of the dynamic user information binding option of a port. Command Mode Global configuration mode Syntax set dhcp option82 mode port <1-52>{default | drop | modify | append}...
Page 459: Clear Dhcp Option82 Sub-Option Device Ani
DHCP download flag is disabled, config file is found. DHCP download will not startup, when system reboot. DHCP config file(option-67) *.dat will be translated to ZXR10_2928E.dat. DHCP snooping-and-option82 is enableDHCP snooping-and-option82 is enabled. PortId PortType Snooping Option82 ------ -------- -------- -------- 4-403 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 460: Show Dhcp Snooping
ZXR10 2900E Series Command Reference Client Disabled Disabled Client Disabled Disabled Client Disabled Disabled Client Disabled Disabled Client Disabled Disabled Client Disabled Disabled Client Disabled Disabled Client Disabled Disabled Client Enabled Disabled Cascade Enabled Enabled /*Omitted*/ Server Disabled Enabled DHCP client is disabled.
Page 461: Show Dhcp Ip-Source-Guard
Example The following example describes how to show all DHCP snooping entry information. zte(cfg)#show dhcp snooping binding DHCP snooping binding table: used = 1, capacity = 256 Hold mode is configured on the following port(s): 10...
Page 462: Show Dhcp Option82
ZXR10 2900E Series Command Reference 4.25.18 show dhcp option82 Purpose Shows the configuration information of DHCP option82. Command Mode All configuration modes Syntax show dhcp option82 Example The following example describes how to show the configuration information of DHCP option82.
Page 463: Show Dhcp Option82 Device
Chapter 4 Service Configuration zte(cfg)#show dhcp option82 port 10 DHCP option82 sub-option information on port 10: Circuit-ID: Disabled Remote-ID: Enabled Format: Cisco Subscriber-ID: Disabled Reserve: Disabled DHCP option82 mode information on port 10: Default 4.25.20 show dhcp option82 device Purpose Displays device information, including ANI and remote-ID.
Page 464: Set Dhcp Client Broadcast-Flag Enable/Disable
ZXR10 2900E Series Command Reference Parameters Parameter Description Enables DHCP client function. The layer 3 interface can enable automatically apply IP address. Disables DHCP client function. disable Default Disables DHCP client function. 4.25.22 set dhcp client broadcast-flag enable/disable Purpose Configures if DHCP server reply message takes broadcast procedure.
Page 465: Set Ipport Ipaddress Dhcp
DHCP client can only get IP address. Other parameters such as MAC and VLAN requires manual configuration. 4.25.25 set ipport ipaddress dhcp release/renew Purpose Releases/renews layer 3 interface IP address. Command Mode Layer 3 configuration mode Syntax set ipport <0-63> ipaddress dhcp {release | renew} 4-409 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 466: Set Ipport Dhcp Client Class-Id/Client-Id/Hostname/Lease
ZXR10 2900E Series Command Reference Parameters Parameter Description <0-63> Layer 3 interface number Releases layer 3 interface address release Renews layer 3 interface address renew Usage Guidelines The command belongs to trigger-mode command. The command cannot be saved. 4.25.26 set ipport dhcp client class-id/client-id/hostname/lease Purpose Configures the optional information when DHCP client interacts with server.
Page 467: Set Ipport Dhcp Client Request
4.25.28 clear ipport dhcp client class-id/client-id/hostname/lease Purpose Clears DHCP client optional information configuration. Command Mode Layer 3 configuration mode Syntax clear ipport < 0-63> dhcp client { class-id | client-id | hostname | lease } 4-411 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 468: Clear Ipport Dhcp Client Request
ZXR10 2900E Series Command Reference Parameters Parameter Parameter <0-63> Layer 3 interface port Clears class-id configuration class-id Clears client-id configuration client-id Clears hostname configuration hostname lease Clears lease configuration 4.25.29 clear ipport dhcp client request Purpose Clears the configuration of requesting DHCP server to return various information...
Page 469: Set Dhcp Snooping Bind-Entry Database Read
4.25.31 set dhcp snooping bind-entry database recovery Purpose Restores the binding table from the Flash memory after the device is restarted. Command Mode Golbal configuration mode Syntax set dhcp snooping bind-entry database recovery{ disable | enable } 4-413 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 470: Set Dhcp Snooping Bind-Entry Database Time-Write
ZXR10 2900E Series Command Reference Parameters Parameter Description Disables the function of reading data from dhcpbase.dat after the disable device is started. Enables the function of reading data from dhcpbase.dat after the enable device is started. 4.25.32 set dhcp snooping bind-entry database time-write Purpose Writes the DHCP binding table into the Flash memory at a scheduled time.
Page 471: Show Dhcp Snooping Database
4.25.34 show dhcp snooping database Purpose Displays DHCP database related configuration. Command Mode Golbal configuration mode Syntax show dhcp snooping database Example zte(cfg)#show dhcp snooping database DHCP snooping database recovery: enable DHCP snooping database timer enable 5000 4.25.35 set dhcp special udp-light-check enable/disable Purpose Enables/Disables the DHCP UDP checking function globally.
Page 472: Set Dhcp Snooping Vlan Enable/Disable
ZXR10 2900E Series Command Reference Default Enable 4.25.36 set dhcp snooping vlan enable/disable Purpose Enables/Disables the DHCP snooping function for a VLAN globally. Command Mode Golbal configuration mode Syntax set dhcp snooping vlan <vlanlist>{ disable | enable } Parameters Parameter Description <vlanlist>...
Page 473: Set Dhcpv6 Snooping Add/Delete
To make the Snooping function effective on a port, enable the Snooping function in global mode and on the port. Defaults The default is set to disable. Examples The following example describes how to configure the DHCPv6 Snooping function on port 4-417 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 474: Set Dhcpv6 Port Server/Cascade/Client
ZXR10 2900E Series Command Reference zte(cfg)#set dhcpv6 snooping add port 1 DHCP v6 snooping is disabled (0x40000927) zte(cfg)#set dhcpv6 sn zte(cfg)#set dhcpv6 snooping en zte(cfg)#set dhcpv6 snooping add port 1 4.26.3 set dhcpv6 port server/cascade/client Purpose Configure the attribute in the DHCPv6 Snooping function for a port.
Page 475: Set Dhcpv6 Option18 Enable/Disable
DHCPv6 Snooping function on the port first. Examples The following example describes how to enable the ip-source-guard function on port 9-10. zte(cfg)#set dhcpv6 ip-source-guard add port 9-10 Fail to enable ip v6 source guard on port 9. DHCP v6 snooping is disabled on this port (0x4000092a)
Page 476: Set Dhcpv6 Option18 Add/Delete
ZXR10 2900E Series Command Reference Parameters Parameter Description enable Enables this function. Disables this function. disable Usage Guidelines To enable the DHCPv6 option18 function on a port, enable this function in global mode first. Defaults The default is set to disable.
Page 477: Set Dhcpv6 Option37 Add/Delete
| delete} port <portlist> Parameters Parameter Description Enables this function. Disables this function. delete port <portlist> Port list. 4.26.9 set dhcpv6 option82 enable/disable Purpose Enables/Disables the DHCPv6 option82 fucntion in global mode. 4-421 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 478: Set Dhcpv6 Option82 Add/Delete
ZXR10 2900E Series Command Reference Command Mode Global configuration mode Syntax set dhcpv6 option82 {enable | disable} Parameters Parameter Description Enables this function. enable Disables this function. disable Usage Guidelines To enable the DHCPv6 option82 function on a port, enable the function in global mode first.
Page 479: Set Dhcpv6 Option82 Ani
Device identification information can be used to locate the specified switch during the user’s location procedure. Examples The following example describes how to configure the option82 ani to zte-lsj. zte(cfg)#set dhcpv6 option82 ani zte-lsj 4.26.12 set dhcpv6 option82 sub-option Purpose Configures the option82 sub-option.
Page 480: Clear Dhcpv6 Snp-Bind-Entry Mac
ZXR10 2900E Series Command Reference Parameter Description Adds the circuit-ID sub-option. circuit-ID Enables sub-option. Disables sub-option Enables the circuit-ID sub-option to the cisco format. cisco Enables the circuit-ID sub-option to the china-tel format. china-tel Enables the circuit-ID sub-option to the dsl-forum format.
Page 481: Show Dhcpv6
Disabled Disabled Disabled Client Enabled Enabled Disabled Disabled Disabled Client Disabled Disabled Disabled Disabled Disabled Client Disabled Disabled Disabled Disabled Disabled /*Omitted*/ 4.26.16 show dhcpv6 snooping Purpose Displays global configuration information of DHCPv6 Snooping. 4-425 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 482: Show Dhcpv6 Snooping Binding
ZXR10 2900E Series Command Reference Command Mode All configuration mode Syntax show dhcpv6 snooping Example The following example shows how to display global configuration information of DHCPv6 Snooping. zte(cfg)#show dhcpv6 snooping DHCP v6 snooping is enabled on the following port(s):...
Page 483: Show Dhcpv6 Ip-Source-Guard
Syntax show dhcpv6 option82 Example The following example shows how to display configuration information of DHCPv6 option82. zte(cfg)#show dhcpv6 option82 DHCP v6 option82 is enabled on the following port(s): PortId PortType ------ -------- Client 4-427 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 484: Show Dhcpv6 Option82 Port
ZXR10 2900E Series Command Reference 4.26.20 show dhcpv6 option82 port Purpose Displays configuration information of DHCPv6 option82 on a port. Command Mode All configuration mode Syntax show dhcpv6 option82 [port <1-28>] Parameters Parameter Description Port number. Different devices have different port number ranges.
Page 485: Show Dhcpv6 Option18
Chapter 4 Service Configuration Example The following example describes how to display identification information of the current device. zte(cfg)#show dhcpv6 option82 ani AccessNodeIdentifier: lsj 4.26.22 show dhcpv6 option18 Purpose Displays configuration information of DHCPv6 option18. Command Mode All configuration mode...
Page 486: Vbas Configuration
ZXR10 2900E Series Command Reference DHCP v6 option37 is enabled on the following port(s): PortId PortType ------ -------- Client 4.27 VBAS Configuration 4.27.1 set vbas trust-port enable/disable Purpose Adds/Deletes the VBAS trust port. Command Mode Global configuration mode Syntax set vbas trust-port <portlist>{enable | disable}...
Page 487: Set Vbas Enable/Disable
Only VBAS message can be normally forwarded. Default Deletes cascade port. Example The following example describes how to add port 8 to VBAS cascade port. zte(cfg)#set vbas cascade-port 8 enable 4.27.3 set vbas enable/disable Purpose Enables/Disables the VBAS function. Command Mode...
Page 488: Show Vbas
ZXR10 2900E Series Command Reference Default Disables VBAS function. 4.27.4 show vbas Purpose Shows VBAS configuration. Command Mode Global configuration mode Syntax show vbas Example The following example describes how to show VBAS configuration. zte(cfg)#show vbas vbas: disabled trust port cascade port : 6 4.28 PPPoE-PLUS Configuration...
Page 489: Set Pppoe-Plus Tag-Format
< string > stands '\' Example The following example describes how to set the PPPoE+ tag format of port 1 to "cisco". zte(cfg)#set pppoe-plus tag-format port 1 cisco 4.28.3 set pppoe-plus rid Purpose Adds/Deletes the rid information of the port.
Page 490: Show Pppoe-Plus
ZXR10 2900E Series Command Reference Command Mode Global configuration mode Syntax set pppoe-plus rid <1-28>[<string>] Parameters Parameter Description One port number. Different devices have different port number <1-28> ranges. Here take 2928E as an example. Rid character string <string> Example...
Page 491: Set Pppoe-Plus Mode Port
<1-28> ranges. Example The following example describes how to show the port character string of port 2 to port 2. zte(cfg)#show pppoe-plus port 2 PPPoE VST remote ID on port 2: port2 4.28.6 set pppoe-plus mode port Purpose Configures the mode of handling dynamic user information on a port.
Page 492: Zesr Configuration
VLAN ID, in range of 1~4094 <vlanId> Example The following example describes how to add control VLAN 1 of ZESR domain 1. zte(cfg)#set zesr domain 1 add control-vlan 1 4.29.2 set zesr add/delete protect-instance Purpose Adds/Deletes the MSTP instance protected by ZESR.
Page 493: Set Zesr Add/Delete Primary/Secondary-Port/Trunk
Instance number, the range is 1~15, instance 0 cannot be added <1-15> Example The following example describes how to add the MSTP instance 1 protected by ZESR. zte(cfg)#set zesr domain 1 add protect-instance 1 4.29.3 set zesr add/delete primary/secondary-port/trunk Purpose Adds/Deletes primary/secondary-port/trunk of each node of ring.
Page 494: Set Zesr Add/Delete Access-Port/Access-Trunk
ZXR10 2900E Series Command Reference zte(cfg)#set zesr domain 1 delete primary-port 1 4.29.4 set zesr add/delete access-port/access-trunk Purpose Adds/Deletes the SMART-LINK access port/trunk on ZESR ring. Command Mode Global configuration mode Syntax set zesr domain <1-4>{add | delete}{access-port <1-28>| access-trunk <1-15>}...
Page 495: Set Zesr Major-Level Mode
Example The following example describes how to configure the current device to the master ring master node of ZESR domain 1. zte(cfg)#set zesr domain 1 major-level mode master 4.29.7 set zesr major-level preforward-timer Purpose Configures the preforward-timer, preup-timer and linkdown-failtimer on the primary ring.
Page 496: Set Zesr Level Segment Mode
Example The following example describes how to configure the preforward as 11 seconds, preup as 0 second and linkdown-failtimer as nine seconds. zte(cfg)#set zesr domain 1 major-level preforward-timer 11 preup-timer 0 linkdown-failtimer 9 4.29.8 set zesr level segment mode Purpose Configures the node attribute on the secondary ring.
Page 497: Set Zesr Level Segment Add/Delete Edge-Port/Trunk
Adds edge port Deletes edge port delete Edge port number. Different devices have different port number edge-port <1-28> ranges. Here take 2928E as an example. edge-trunk <1-15> Edge trunk number, trunk ID notmaster Non-master node 4-441 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 498: Set Zesr Level Segment Preforward-Timer
ZXR10 2900E Series Command Reference 4.29.10 set zesr level segment preforward-timer Purpose Configures the preforward-timer, preup-timer and linkdown-failtimer on the secondary ring. Command Mode Global configuration mode Syntax set zesr domain <1-4> level <1-2> segment <1-4> preforward-timer <3-600> preup-timer <0-500> linkdown-failtimer <8-500>...
Page 499: Set Zesr Linkhello-Timer Linkhello-Failtimer
<3-9> Usage Guidelines linkhello-timer and inkhello-failtime must meet the following condition: linkhello-failtimer >= 3*linkhello-timer. Default Sending interval of linkhello message is 1 second. linkhello mechanism timeout time is five seconds. 4-443 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 500: Set Zesr Linkhello Enable/Disable
ZXR10 2900E Series Command Reference 4.29.13 set zesr linkhello enable/disable Purpose Enables/Disables linkhello mechanism. Command Mode Global configuration mode Syntax set zesr domain <1-4> linkhello {enable | disable} Parameters Parameter Description <1-4> ZESR domain ID, the range is 1~4 Enables linkhello mechanism.
Page 501: Set Zesr Domain Major-Level Mode
Configures the node feature of the level ring of the cross-device smart-link. Command Mode Global configuration mode Syntax set zesr domain <domainId> level <levelId> segment <segId> mode {zess-master|zess-transit| zess-edge-master|zess-edge-transit} Parameters Parameter Description <domainId> ZESR domain ID, in range of 1~4. 4-445 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 502: Set Zesr Domain Tcn
ZXR10 2900E Series Command Reference Parameter Description <levelId> Level Id, in range of 1~2. <segId> Segment link Id, in range of 1~4. Node mode: main node of the cross-device smart-link. zess-master Node mode: transmission node of the cross-device smart-link. zess-transit...
Page 503: Set Zesr Tcn-Sending Trunk
<trunklist>{enable|disable} Parameters Parameter Description <trunklist> Trunk port list. Enables trunk ports to send tcn messages. enable disable Disables trunk ports to send tcn messages. Defaults Disables trunk ports to send tcn messages. 4-447 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 504: Set Zesr Protocol-Mac
Sets the protocol MAC mode of ZESR to the special mode. When this mode is set, the MAC address of all messages of ZESR uses special the private MAC address of ZTE. Default setting. Defaults The default is set to special.
Page 505: Show Zesr Domain
Chapter 4 Service Configuration Example The following example describes how to delete ZESR domain 1. zte(cfg)#clear zesr domain 1 4.29.22 show zesr domain Purpose Shows ZESR configuration. Command Mode Global configuration mode Syntax show zesr domain [<1-4>] Parameter Parameter Description ZESR domain ID, the range is 1~4 <1-4>...
Page 506: Oam Configuration
ZXR10 2900E Series Command Reference Edge Port : Yes Linkdown Failtime ZESR D omain Tcn option : Yes ZESR Domain Control Vlan : 100 ZESR Domain Protected Instance : 1 ZESR Domain LinkHello Time Interval: ZESR Domain LinkHello FailTime Interval: ZESR protocol mac mode: special 4.30 OAM Configuration...
Page 507: Set Ethernet-Oam Port Period Timeout Mode
Disables OAM function on port. Example The following example describes how to enable the OAM function of port 1. zte(cfg)#set ethernet-oam port 1 enable 4.30.3 set ethernet-oam port period timeout mode Purpose Configures OAM discovery period, timeout time and mode on port.
Page 508: Set Ethernet-Oam Remote-Loopback Timeout
The following example describes how to configure the sending period of oampdu to 10 milliseconds, timeout time to five seconds and active discovery mode. zte(cfg)#set ethernet-oam port 1 period 1 timeout 5 mode active 4.30.4 set ethernet-oam remote-loopback timeout Purpose Configures the timeout time of port remote loopback function.
Page 509: Set Ethernet-Oam Remote-Loopback
OAM discovery process succeeds. Example The following example describes how to enable remote loopback function on port 8. zte(cfg)#set ethernet-oam remote-loopback port 8 start zte(cfg)# Thu Jul 1 05:06:48 2004 ETH-OAM starts remote loopback successfully on port 8.
Page 510: Set Ethernet-Oam Org-Specific
Description oui <XX-XX-XX> Organization code time-stamp <1-10> Time stamp, the unit is 100 milliseconds. Default Organization code is 00-15-EB, that is, zte. Time stamp is 10. 4.30.7 set ethernet-oam port link-monitor enable/disable Purpose Enables/Disables link monitor function. Command Mode Global configuration mode Syntax set ethernet-oam port <portlist>...
Page 511: Set Ethernet-Oam Port Link-Monitor Symbol-Period
Default Disables link monitor function. Example The following example describes how to enable link monitor function on port 1. zte(cfg)#set ethernet-oam port 1 link-monitor enable 4.30.8 set ethernet-oam port link-monitor symbol-period Purpose Configures the symbol period event of link monitor.
Page 512: Set Ethernet-Oam Port Link-Monitor Frame
This example shows how to set the number of the incorrect symbols collected in a unit time to 1, and the symbol period to 30. zte(cfg)#set ethernet-oam port1 link-monitor symbol-period threshold 1 window 30 4.30.9 set ethernet-oam port link-monitor frame Purpose Configures the incorrect frame on the port.
Page 513: Set Ethernet-Oam Port Link-Monitor Frame-Period
Chapter 4 Service Configuration zte(cfg)#set ethernet-oam port 1 link-monitor frame threshold 2 window 20 4.30.10 set ethernet-oam port link-monitor frame-period Purpose Configures the incorrect frame period. Command Mode Global configuration mode Syntax set ethernet-oam port <portlist> link-monitor frame-period threshold <1-65535> window <1-600000>...
Page 514: Set Ethernet-Oam Port Link-Monitor Frame-Seconds
Example The following example describes how to set the cumulative time of incorrect frames as 10 seconds and the time period as 100 seconds. zte(cfg)#set ethernet-oam port 1 link-monitor frame-seconds threshold 10 window 100 4.30.12 show ethernet-oam Purpose Shows OAM global configuration information.
Page 515: Show Ethernet-Oam Port
The following example describes how to show the summary information of ethernet-oam port. zte(cfg)#show ethernet-oam Ethernet Oam : enabled Link Monitor : support Mib Retrieval : nonsupport Remote LoopBack : support Event Time Stamp : 10*100(ms) Remote LoopBack Timeout : 3(s) Local OUI : 00-15-EB 4-459 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 516: Show Ethernet-Oam Port Discovery
ZXR10 2900E Series Command Reference 4.30.14 show ethernet-oam port discovery Purpose Shows the summary information of OAM port. Command Mode Global configuration mode Syntax show ethernet-oam port <portlist> discovery Parameter Parameter Desription Port list <portlist> Example The following example describes how to show the ethernet oam discovery state of port 8.
Page 517: Show Ethernet-Oam Port Statistics
Parameter Description Port list <portlist> Example The following example describes how to show the statistics of ethernet-oam on port 8. zte(cfg)#show ethernet-oam port 8 statistics OAMPDU Counters of Port: 8 TransmitInformation : 7971 ReceiveInformation : 7812 TransmitLoopbackControl : 2 ReceiveLoopbackControl...
Page 518: Show Ethernet-Oam Port Link-Monitor
ZXR10 2900E Series Command Reference ReceiveZTESpecific TransmitUnsupported : 0 ReceiveUnsupported Remote loopback Packet Counters TransmitPacketsIntotal : 1530 ReceivePacketsIntotal 4.30.16 show ethernet-oam port link-monitor Purpose Shows the configuration and state of port OAM link event. Command Mode Global configuration mode Syntax show ethernet-oam port <portlist>...
Page 519: Sqinq Configuration
<1-400> customer-port <port-id> customer-vlan <vlan-list> uplink -vlan <vlan-id> Parameters Parameter Description <1-400> SQinQ session number <port-id> The port number of user side <vlan-list> VLAN list of CVLAN. One session supports eight vlan-ranges <vlan-id> SPVLAN 4-463 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 520: Clear Vlan Sqinq
ZXR10 2900E Series Command Reference Usage Guidelines When SQinQ is enabled, the uplink traffic is forwarded in SPVLAN. The downlink traffic is forwarded in SPVLAN. Because the use side port belongs to SPVLAN based on untag mode, when messages are forwarded through the user side port, the tag will be separated.
Page 521: Show Vlan Sqinq Session
Configures the VLAN Mapping function. Command Mode Global configuration mode Syntax set vlan mapping session <1-400> customer-port <<port-id> customer-vlan <vlan-list> up link-vlan <vlan-id> Parameters Parameter Description <1-400> VLAN Mapping session number <port-id> User side port number 4-465 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 522: Clear Vlan Mapping
ZXR10 2900E Series Command Reference Parameter Description <vlan-list> VLAN list of CVLAN. One session supports eight vlan-ranges <vlan-id> SPVLAN Usage Guidelines When VLAN Mapping is enabled, the uplink traffic is forwarded in SPVLAN. The downlink traffic is forwarded in SPVLAN. When reaching the user port, it will be changed to the corresponding CVLAN tag.
Page 523: Clear Vlan Mapping User
Global configuration mode Syntax clear vlan mapping user session <1-400> Parameter Parameter Description <1-400> VLAN Mapping session number 4.32.6 show vlan mapping Purpose Shows all VLAN Mapping sessions. Command Mode All modes Syntax show vlan mapping 4-467 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 524: Show Vlan Mapping Session
ZXR10 2900E Series Command Reference 4.32.7 show vlan mapping session Purpose Shows the specified VLAN Mapping session. Command Mode All modes Syntax show vlan mapping session <1-400> Parameter Parameter Description <1-400> VLAN Mapping session number 4.32.8 show vlan mapping user-table Purpose Shows the user information of all VLAN Mapping sessions.
Page 525: Sflow Configurations
The number of the UDP port used to send sFlow sampling messages is 6343. Example The following example describes how to set the IP address of the sFlow agent to 10.40.89.50. zte(cfg)#set sflow agent-address 10.40.89.50 4-469 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 526: Set Sflow Collector-Address
ZXR10 2900E Series Command Reference 4.33.2 set sflow collector-address Purpose Configures the IP address of a sFlow collector. Command Mode Global configuration mode Syntax set sflow collector-address <A.B.C.D>[udp-port <1-65535>] Parameters Parameter Description <A.B.C.D> IP address of the sFlow agent. Number of the UDP port used to send sFlow sampling messages.
Page 527: Set Sflow Ingress/Egress Enable/Disable
Disables the sFlow function. disable Defaults The sampling is disabled. Example The following example shows how to enable the ingress sFlow function and disable the egress sFlow function. zte(cfg)#set sflow ingress enable zte(cfg)#set sflow egress disable 4-471 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 528: Set Sflow Ingress/Egress Reload-Mode Continue/Cpu
ZXR10 2900E Series Command Reference 4.33.5 set sflow ingress/egress reload-mode continue/cpu Purpose Configures the sFlow ingress/egress reloading mode. Command Mode Global configuration mode Syntax set sflow {ingress | egress} reload-mode { continue | cpu} Parameters Parameter Description ingress Configures the ingress sFlow.
Page 529: Set Sflow Ingress/Egress Packet-Sample Off
<portlist> Port list. Usage Guidelines The port-based sampling is disabled. Example The following example describes how to disable the ingress samplings on port 2 and port zte(cfg)#set sflow ingress port 2,3 packet-sample off 4-473 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 530: Set Sflow Ingress/Egress Packet-Sample On
3 to 3000 and bind the sampling to the time-range named abc. zte(cfg)#set sflow ingress port 2 packet-sample on frequency 2000 zte(cfg)#set sflow egress port 3 packet-sample on frequency 3000 time-range abc 4-474 SJ-20120409144109-003|2012-07-02(R1.0)
Page 531: Clear Sflow Config
4.33.10 clear sflow statistic Purpose Clears the counter information of the port. Command Mode Global configuration mode Syntax clear sflow statistic 4.33.11 show sFlow Purpose Shows all sFlow configurations. 4-475 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 532: Pp Configurations
ZXR10 2900E Series Command Reference Command Mode All configuration modes Syntax show sflow Example The following example shows how to view all sFlow configurations. zte(cfg)#show sflow Agent address :10.40.89.100 udp port: 6343 Collector address:10.40.89.78 udp port: 6343 Version: 5 Ingress:...
Page 533: Set Protocol-Protect Alarm Enable/Disable
HH> mask <HH.HH.HH.HH.HH.HH> Mask. Example The following example describes how to create a MAC drop rule. zte(cfg)# create protocol-protect mac-drop rule 1 src-mac 00.11.22.33.44.55 mask ff.ff.ff.ff.ff.ff 4.34.2 set protocol-protect alarm enable/disable Purpose Enables/Disables the port-based PP alarm function. Command Mode...
Page 534: Set Protocol-Protect Alarm Threshold
Example The following example describes how to set the alarm threshold of the STP protocol protection on port 1 to 3000. zte(cfg)#set protocol-protect alarm port 1 stp 3000 4.34.4 set protocol-protect limit Purpose Configures the rate limit value of the protocol packet sent to the CPU that PP allows per second.
Page 535: Set Protocol-Protect Priority
<0-800> Protocol rate limit value. Example The following example describes how to set the rate limit of the ZESR protocol per second to 100. zte(cfg)#set protocol-protect limit zesr 100 4.34.5 set protocol-protect priority Purpose Configures the PP priority. Command Mode...
Page 536: Set Protocol-Protect Mac-Drop Enable/Disable
ZXR10 2900E Series Command Reference 4.34.6 set protocol-protect mac-drop enable/disable Purpose Enables/Disables the MAC drop function. Command Mode Global configuration mode Syntax set protocol-protect mac-drop {disable|enable} Parameters Parameter Description enable Enables the MAC drop function. Disables the MAC drop function. By default, the function is disable disabled.
Page 537: Clear Protocol-Protect Mac-Drop Counter
Chapter 4 Service Configuration Example The following example describes how to bind rule 1 with port 2. zte(cfg)#set protocol-protect mac-drop rule 1 bind port 2 4.34.8 clear protocol-protect mac-drop counter Purpose Clears the counter of packets dropped by the MAC drop function.
Page 538: Clear Protocol-Protect Mac-Drop Rule
ZXR10 2900E Series Command Reference Example The following example describes how to clear rule 2 on port 1. zte(cfg)#clear protocol-protect mac-drop port 1 rule 2 4.34.10 clear protocol-protect mac-drop rule Purpose Clears a MAC drop rule. Command Mode Global configuration mode Syntax clear protocol-protect mac-drop rule [<1-128>]...
Page 539: Show Protocol-Protect Limit
Chapter 4 Service Configuration Example The following example describes how to view the protocol alarm statistics on port 1. zte(cfg)#show protocol-protect statistic port 1 Port 1 protocol protect alarm: Enable ProtocolName CurTotalRcvCnt Last30sRcvCnt 30s'Limit ---------------------------------------------------------------- 1200 lacp 1200 1200 arp-request...
Page 540: Show Protocol-Protect Priority
ZXR10 2900E Series Command Reference Example The following example describes how to view the rate limit value of the protocol packet sent to the CPU. zte(cfg)#show protocol-protect limit ProtocolGroup 1s'limit ProtocolGroup 1s'limit ---------------------------- ---------------------------- ieee-reserved1 zesr loopdetect arp-reply ieee-reserved2 802.1x...
Page 541: Show Protocol-Protect Mac-Drop Port
Parameter Description <portlist> Port list. Example The following example describes how to display rules bound wtih port 1. zte(cfg)#show protocol-protect mac-drop port 1 4.34.15 show protocol-protect mac-drop rule Purpose Displays a MAC drop rule. Command Mode Global configuration mode Syntax show protocol-protect mac-drop rule [<1-128>]...
Page 542: Lldp Configurations
ZXR10 2900E Series Command Reference zte(cfg)#show protocol-protect mac-drop rule 1 4.35 LLDP Configurations 4.35.1 lldp hellotime Purpose Configures the time interval that LLDP neighbor discovery packets are sent. Command Mode Global configuration mode Syntax lldp hellotime <5-32768> Parameters Parameter Description Time interval that neighbor discovery packets are sent, in unit <5-32768>...
Page 543: Lldp Max-Neighbor
Global maximum number of neighbors. Defaults The global maximum number of neighbors is 31. Example The following example shows how to set the maximum number of neighbors that LLDP can globally discover to 10. zte(cfg)#lldp max-neighbor 10 4-487 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 544: Lldp Port/Trunk Enable/Disable
ZXR10 2900E Series Command Reference 4.35.4 lldp port/trunk enable/disable Purpose Enables/Disables all LLDP functions on specified ports. Command Mode Global configuration mode Syntax lldp {port <portlist>| trunk <trunklist>}{enable | disable} Parameters Parameter Description <portlist> Port list. <trunklist> Trunk port list.
Page 545: Lldp Port/Trunk Rxenable/Rxdisable
Chapter 4 Service Configuration zte(cfg)#lldp port 1 txenable 4.35.6 lldp port/trunk rxenable/rxdisable Purpose Enables/Disables the LLDP receiving function on specified ports. Command Mode Global configuration mode Syntax lldp {port <portlist>| trunk <trunklist>}{rxenable | rxdisable} Parameters Parameter Description <portlist> Port list.
Page 546: Lldp Port/Trunk Max-Neighbor
ZXR10 2900E Series Command Reference Example The following example shows how to enable the notification function of LLDP-MED network policy on port 1. zte(cfg)#lldp port 1 med-tlv-select network-policy-tlv enable 4.35.8 lldp port/trunk max-neighbor Purpose Configures the maximum number of neighbors that the LLDP port can discover.
Page 547: Clear Lldp Statistic
Port list. <trunklist> Trunk port list. Example The following example shows how to clear LLDP global statistics information. zte(cfg)#clear lldp statistic 4.35.11 show lldp config Purpose Shows LLDP configuration information. Command Mode All configuration modes 4-491 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 548: Show Lldp Neighbor
ZXR10 2900E Series Command Reference Syntax show lldp config [{port <portlist>| trunk <trunklist>}] Parameters Parameter Description <portlist> Port list. <trunklist> Trunk port list. Example The following example shows how to view LLDP global configurations and configurations on port 1. zte(cfg)#show lldp config...
Page 549: Show Lldp Entry
:114 (Time to live) Port Description :port-32 status is up,media-type is 100BaseT,pvid is 1. System Name :zte System Description:ZXR10 2952E Version V2.05.10B10 System Capability :Bridge Switch Management Address:IPv4 - 10.40.89.106, ifIndex - 0, OID – Null 4-493 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 550: Show Lldp Statistic
ZXR10 2900E Series Command Reference 4.35.14 show lldp statistic Purpose Shows LLDP statistics information. Command Mode All configuration modes Syntax show lldp statistic [{port <portlist>| trunk <trunklist>}] Parameters Parameter Description <portlist> Port list. <trunklist> Trunk port list. Example The following example shows how to view LLDP statistics information.
Page 551: Set Mld Snp Add/Delete Vlan
Deletes multicast snooping VLANs. delete <vlanlist> VLAN list. Usage Guidelines All legal VLANs can be snooped. Example The following example shows how to configure MLD snooping VLANs 1–10. zte(cfg)#set mld snooping add vlan 1-10 4-495 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 552: Set Mld Snp Add Maxnum Vlan
Example The following example shows how to set the maximum number of multicast groups of VLANs 1–10 to 100. zte(cfg)#set mld snooping add maxnum 100 vlan 1-10 4.36.4 set mld snp vlan add group Purpose Adds a static group into the specified VLAN and adds ports into the statistic group.
Page 553: Set Mld Snp Vlan Delete Group
The following example shows how to add the statistic multicast group ff1e::22 to VLAN 1 and add ports 1–10 into the static group. zte(cfg)#set mld sn vlan 1 add group ff1e::11 port 1-10 4.36.5 set mld snp vlan delete group Purpose Clears the static group on the specified VLAN and the port list in the static group.
Page 554: Set Mld Snp Host-Time-Out/Mrouter-Time-Out
Here, the 2928E is used as an example. Example The following example shows how to add port 9 into VLAN 1 as a mrouter port. zte(cfg)#set mld sn vlan 1 add mrouter port 9 4.36.7 set mld snp host-time-out/mrouter-time-out Purpose Configures the timeout time of the mrouter/host port.
Page 555: Set Mld Snp Query-Interval
The following example shows how to set the aging time of the mrouter port to 400 s and the aging time of the host port to 300 s. zte(cfg)#set mld snooping mrouter-time-out 400 zte(cfg)#set mld snooping host-time-out 300 4.36.8 set mld snp query-interval Purpose Configures the time interval that the switch sends query messages.
Page 556: Set Mld Snp Last-Member-Query
ZXR10 2900E Series Command Reference Command Mode Global configuration mode Syntax set mld snooping query-response-interval <1000-25000> Parameters Parameter Description <1000-25000> Waiting time, in unit of milliseconds. Usage Guidelines When the switch receives query messages, it waits for a period and then sends report messages, which avoids the instant attack to the router due to the centralized replies.
Page 557: Set Mld Snp Query Vlan Enable/Disable
The query function is disabled. Example The following example shows how to enable the query function on VLANs 1–10. zte(cfg)#set mld snooping query vlan 1-10 enable 4.36.12 set mld snp query version Purpose Configures the MLD version of the query message sent by the switch.
Page 558: Set Mld Snp Fastleave Enable/Disable
ZXR10 2900E Series Command Reference Syntax set mld snooping query version {v1 | v2} Parameters Parameter Description Sends the query message with version 1. Sends the query message with version 2. Defaults The query message with version 2 is sent.
Page 559: Show Mld Snp
: disabled HostTimeout : 260s Working Mode : proxy Querier : disable Query Interval : 125s Robustness Last Member Query Interval : 1s Query Response Interval : 10000ms Total Group Number Have Host Group Number 4-503 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 560: Show Mld Snp Vlan
ZXR10 2900E Series Command Reference 4.36.16 show mld snp vlan Purpose Shows results of MLD snooping. Command Mode All configuration modes Syntax show mld snooping vlan <1-4094>[group <ipv6-address>| port-info | group-source-filter | ho st-source-filter ] Parameters Parameter Description <1-4094> VLAN id group <ipv6-address>...
Page 561 ----- ---- --------------------------------------- ------- ---------- -------- ff1e::22 0:00:14:05 S:1-10 ff1e::11 0:00:04:52 S:9 The following example describes how to view information based on group ffe::22 in VLAN zte(cfg)#show mld sn vlan 1 group ff1e::22 Vlan ID Group Address : ff1e::22 Host Number : 10 Max Host Number : not limit The following example describes how to view snooping states about host ports in VLAN 1.
Page 562: Show Mld Snp Mr-Port-Info
ZXR10 2900E Series Command Reference Vlan Port : 10 Group ID : ff1e::22 Filter Mode : Exclude Source List : Index Vlan Port Group ID : ff1e::22 Filter Mode : Exclude Source List : Index Vlan Port Group ID : ff1e::22...
Page 563: Poe Configuration
4.37.2 show poe config Purpose Shows PoE configurations. Command Mode All configuration modes Syntax show poe config [port <port list>] Parameters Parameter Description <port list> Port number. 4-507 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 564: Single-Port Loop Detection Configuration
ZXR10 2900E Series Command Reference Example The following example shows how to view summary configurations about all ports. zte(cfg)#show poe config port | enable | max-power | priority | extend-detection | force-power disable 15.4w disable disable disable 15.4w disable disable disable 15.4w...
Page 565: Set Loopdetect Blockdelay
The default period that loopdetect blocks the loop port is 5 minutes. 4.38.3 set loopdetect port Purpose Enables/Disables the loop detection on the port. Command Mode Global configuration mode Syntax set loopdetect port <portlist>{enable|disable} Parameters Parameter Description <portlist> Port list. 4-509 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 566: Set Loopdetect Port Vlan
ZXR10 2900E Series Command Reference Parameter Description Enables the PVID loop detection on the port. enable disable Disables the loop detection on all VLANs for the port. Usage Guidelines The set loopdetect port command with enable is used to enable the loop detection on the port, that is, detect whether there is a loop on the PVID for the port.
Page 567: Set Loopdetect Port Protect
Enables/Disables the cross-device loop detection on the port. Command Mode Global configuration mode Syntax set loopdetect extend port <portlist>{enable | disable} Parameters Parameter Description <portlist> Port list. Enables the cross-device loop detection on the port. enable 4-511 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 568: Set Loopdetect Trunk
ZXR10 2900E Series Command Reference Parameter Description Disables the cross-device loop detection on the port. disable Defaults Disables the cross-device loop detection on the port. 4.38.7 set loopdetect trunk Purpose Enables/Disables the loop detection on the aggregation port. Command Mode...
Page 569: Set Loopdetect Trunk Protect
Parameter Description <trunklist> Trunk port list. Blocks a trunk port when loopback is detected on the port. enable Displays an alarm when loopback is detected on a trunk port, disable without blocking the port. 4-513 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 570: Set Loopdetect Extend Trunk
ZXR10 2900E Series Command Reference Usage Guidelines This command enables/disables trunk port protection when trunk port loopback occurs. If trunk port protection is enabled, the trunk port is blocked when loopback is detected on the port. If trunk port protection is disabled, only an alarm is displayed when loopback is detected on the trunk port, and the port is not blocked.
Page 571: Show Loopdetect Port
Global configuration mode Syntax show loopdetect port [<portlist>] Parameters Parameter Description <portlist> Port list. Examples The following example describes how to display the port detection status. zte(cfg)#show loopdetect port 23 PortId : 23 VlanId isLoop isBlock ------ ------ ------- 4-515 SJ-20120409144109-003|2012-07-02(R1.0)
Page 572: Show Loopdetect Trunk
ZXR10 2900E Series Command Reference For each port, three parameters are displayed: VlanId: VLAN ID. isLoop: indicates whether the port encounters loopback in the VLAN. isBlock: indicates whether the port is blocked in the VLAN. 4.38.13 show loopdetect trunk Purpose Displays trunk information in loop detection.
Page 573: Udld Configuration
Disables the port-based UDLD protocol. disable Defaults Disables the port-based UDLD protocol. 4.39.2 udld port mode Purpose Configures UDLD mode on specified ports. Command Mode Global configuration mode Syntax udld port <portlist> mode {aggressive | normal} 4-517 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 574: Udld Port Message Timer
ZXR10 2900E Series Command Reference Parameters Parameter Description <portlist> Port list. Aggressive mode. aggressive Normal mode. normal Defaults The default is set to normal mode. Example The following example shows how to set port 10 to aggressive mode. zte(cfg)#udld port 10 mode aggressive 4.39.3 udld port message timer...
Page 575: Udld Port Recovery Enable/Disable
UDLD detects link problems and disables fault ports. You do not need to execute the reset command. Defaults Disables the UDLD automatic recovery function. 4.39.5 udld port recovery timer Purpose Configures the automatic recovery period. Command Mode Global configuration mode Syntax udld port <portlist> recovery timer <10-600> 4-519 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 576: Udld Port Reset
ZXR10 2900E Series Command Reference Parameters Parameter Description <portlist> Port list. recovery timer <10-600> Link automatic recovery period, in unit of seconds. Usage Guidelines When UDLD disables the port, the function that the port creates the link will be automatically recovered after the configured recovery period.
Page 577: Show Udld
Enable Bidirection Enable Aggr Enable Bidirection Enable Disable Bidirection Disable Disable Disable 4.39.8 show udld port Purpose Displays port configurations and neighbor detailed information. Command Mode All configuration modes Syntax show udld port [<portlist>] 4-521 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 578: Udld Port Force-Check Enable/Disable
ZXR10 2900E Series Command Reference Parameters Parameter Description <portlist> Port list. Usage Guidelines This command is used to display information about all ports or specified ports. 4.39.9 udld port force-check enable/disable Purpose Enables/Disables the forced UDLD monologue detection function. Command Mode...
Page 579: Tacacs-Plus Group Enable/Disable
By default, the forced UDLD monologue detection timer is 30 seconds. Example The following example describes how to set the forced UDLD monologue detection timer to 60 seconds for ports 9 and 10. zte(cfg)#udld port 9-10 force-check timer 60 4.40 TACACS+ Configuration 4.40.1 tacacs-plus group enable/disable Purpose Enables/Disables a sever group.
Page 580: Tacacs-Plus Group Add/Delete Host
ZXR10 2900E Series Command Reference Parameters Parameter Description <group-name> Name of the TACACS+ server, in range of 1–31 characters. Enables the server group. enable Disables the server group. disable Usage Guidelines The system can enable up to five server groups.
Page 581: Tacacs-Plus Loginauthen Default Group
Syntax tacacs-plus loginauthor default group <group-name> Parameters Parameter Description <group-name> Name of the TACACS+ server group, in range of 1–31 characters. Usage Guidelines The group should be enabled and has at least one member. 4-525 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 582: Tacacs-Plus Adminauthen Default Group
ZXR10 2900E Series Command Reference 4.40.5 tacacs-plus adminauthen default group Purpose Configures the default server group of TACACS+ management authentication. Command Mode NAS configuration mode Syntax tacacs-plus adminauthen default group <group-name> Parameters Parameter Description <group-name> Name of the TACACS+ server, in range of 1–31 characters.
Page 583: Tacacs-Plus Accounting Exec Default Group
NAS configuration mode Syntax tacacs-plus accounting update period <1-2147483647> Parameters Parameter Description <1-2147483647> Update period of TACACS+ accounting users, in minutes. 4.40.9 clear tacacs-plus loginauthen default Purpose Clears the default server group of TACACS+ login authentication. 4-527 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 584: Clear Tacacs-Plus Loginauthor Default
ZXR10 2900E Series Command Reference Command Mode NAS configuration mode Syntax clear tacacs-plus loginauthen default 4.40.10 clear tacacs-plus loginauthor default Purpose Clears the default server group authorized by the TACACS+ login. Command Mode NAS configuration mode Syntax clear tacacs-plus loginauthor default 4.40.11 clear tacacs-plus adminauthen default...
Page 585: Clear Tacacs-Plus Accounting Exec Default
Shows TACACS+ configuration information. Command Mode All configuration modes Syntax show tacacs-plus Example The following example describes how to view TACACS+ configuration information. zte(cfg)#show tacacs-plus Loginauthen defaut group: zte Loginauthor defaut group: zte Adminauthen defaut group: zte 4-529 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 586: Time Range Configuration
ZXR10 2900E Series Command Reference Accounting commands defaut group: test Accounting exec defaut group: test Accounting update period: test GroupName: zte IpAddress Port Timeout --------------- ----- ------- -------------------- 10.20.1.23 10.20.1.20 zxr10 GroupName: test IpAddress Port Timeout --------------- ----- ------- -------------------- 10.40.89.78...
Page 587: Set Time-Range Absolute
Time when the operation is end <yyyy-mm-dd> (second) Date when the operation is end. Usage Guidelines Perform the operation when the configured time and date reach. 4.41.3 clear time-range Purpose Clear time-range configurations. Command Mode Global configuration mode 4-531 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 588: Show Time-Range
ZXR10 2900E Series Command Reference Syntax clear time-range <word> Parameters Parameter Description <word> Name of the time-range, up to 16 characters. Usage Guidelines The time-range bound to some functions cannot be deleted. To delete this kind of time-range, release the binding first.
Page 589: Mac Based Vlan Configuration
After the MAC based VLAN function is enabled, a VLAN is assigned to untag packets whose MAC address matches the configured MAC address. 4.42.2 clear mac based vlan rule Purpose Clears the rule configured for a MAC based VLAN. 4-533 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 590: Mac Based Vlan Bind
ZXR10 2900E Series Command Reference Command Mode MAC based VLAN configuration mode Syntax clear rule <1-1024> 4.42.3 mac based vlan bind Purpose Configures the binding relation between a MAC based VLAN session and a port or all ports. Command Mode...
Page 591: Show Vlan Mac Based Session Bind
MD index. <1-32> MA index. <1-8191> MEP ID, unique within an MA. Disables the one-LM function for the MEP. By default, the function disable is disabled. Enables the one-LM function for the MEP. enable 4-535 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 592: Cfm Two-Lm Enable/Disable
ZXR10 2900E Series Command Reference Example The following example describes how to enable the one-LM function. zte(cfg)#cfm md-session 1 ma-session 1 mep-id 1 one-lm enable 4.43.2 cfm two-lm enable/disable Purpose Enables/Disables the two-LM function. Command Mode Global configuration mode Syntax cfm md-session <1-16>...
Page 593: Cfm Ais Enable/Disable
Enables the bidirectional DM function for the MEP. enable Example The following example describes how to enable the bidirectional DM function. zte(cfg)#cfm md-session 1 ma-session 1 mep-id 1 two-dm enable 4.43.4 cfm ais enable/disable Purpose Enables/Disables the AIS function. Command Mode...
Page 594: Cfm Lck Enable/Disable
Enables the LCK function for the MEP. enable Example The following example describes how to enable the LCK function for an MEP. zte(cfg)#cfm md-session 1 ma-session 1 mep-id 1 lck enable 4.43.6 cfm client-level Purpose Configures the client level for which AIS/LCK packets are sent.
Page 595: Cfm Relate-To Rmep
Remote MEP ID, unique within an MA. Example The following example describes how to associate local MEP 1 with remote MEP 2. zte(cfg)#cfm md-session 1 ma-session 1 mep-id 1 relate-to rmep-id 2 4.43.8 cfm one-lm send-packet Purpose Starts one-LM detection.
Page 596: Cfm One-Lm Send-Packet Stop
<1-60> is 1 s. Example The following example describes how to start one-LM detection at the default detection intervals. zte(cfg)#cfm md-session 1 ma-session 1 mep-id 1 one-lm send-packet 4.43.9 cfm one-lm send-packet stop Purpose Stops one-LM detection. Command Mode Global configuration mode Syntax cfm md-session <1-16>...
Page 597: Cfm Two-Dm Send-Packet
Chapter 4 Service Configuration Example The following example describes how to stop an ongoing one-LM detection. zte(cfg)#cfm md-session 1 ma-session 1 mep-id 1 one-lm send-packet stop 4.43.10 cfm two-dm send-packet Purpose Starts bidirectional DM detection. Command Mode Global configuration mode Syntax cfm md-session <1-16>...
Page 598: Clear Cfm Lm/Dm
MEP ID, unique within an MA. Example The following example describes how to stop an ongoing bidirectional DM detection. zte(cfg)#cfm md-session 1 ma-session 1 mep-id 1 two-dm send-packet stop 4.43.12 clear cfm lm/dm Purpose Clears one-LM, two-LM, and bidirectional DM measurement results.
Page 599: Clear Cfm Relate-Rmep
<1-8191> MEP ID, unique within an MA. Example The following example describes how to clear an associated remote MEP. zte(cfg)#clear cfm md-session 1 ma-session 1 mep-id 1 relate-rmep 4.44 802.1AG Configuration 4.44.1 cfm enable/disable Purpose Enables/Disables the CFM function globally.
Page 600: Create Cfm Md
MD level Example The following example describes how to create cfm md-session 1. The MD level is 1 and the name is zte_1. zte(cfg)#create cfm md-session 1 name zte_1 level 6 4.44.3 create cfm ma Purpose Creates a CFM MA.
Page 601: Create Cfm Local-Mep
Example The following example describes how to create cfm ma session 1. The name is zte_zte_1. The MA belongs to md session 1. zte(cfg)#create cfm md-session 1 ma-session 1 name zte_zte_1 4.44.4 create cfm local-mep Purpose Creates a CFM local MEP.
Page 602: Create Cfm Mip
The following example describes how to create a CFM MEP. The session id is 1; the mep-id is 1000; the MEP belongs to md 1 ma 1; the direction of the MEP is "down". zte(cfg)#create cfm md-session 1 ma-session 1 mep-session 1 mep-id 1000 direction down 4.44.5 create cfm mip Purpose Creates a CFM MIP.
Page 603: Cfm Primary-Vlan
The following example describes how to create a remote CFM MEP. The session id is 2. The rmep-id is 2000. The MEP belongs to md 1 ma 1. zte(cfg)#create cfm md-session 1 ma-session 1 rmep-session 2 rmep-id 2000 remote-mac 00.50.43.3c.3b.5d 4.44.7 cfm primary-vlan...
Page 604: Cfm Ccm-Interval
ZXR10 2900E Series Command Reference Example The following example describes how to set the primary VLAN of md-session 1 ma-session 1 to "vlan 100". zte(cfg)#cfm md-session 1 ma-session 1 primary-vlan 100 4.44.8 cfm ccm-interval Purpose Configures the CCM packet sending interval of CFM MEP.
Page 605: Cfm Mep State
Example The following example describes how to set the MEG ID padding mode in md-session 1 ma-session 1 to "absent". zte(cfg)#cfm md-session 1 ma-session 1 ccm md-name absent 4.44.10 cfm mep state Purpose Enables/Disables the CFM function for an MEP.
Page 606: Cfm Mep Ccm-Send State
Example The following example describes how to enable the CFM function for mep 1000 in md-session 1 ma-session 1. zte(cfg)#cfm md-session 1 ma-session 1 mep-id 1000 state enable 4.44.11 cfm mep ccm-send state Purpose Enables/Disables the CCM packet sending function for CFM MEP.
Page 607: Cfm Ccm-Receive State
Example The following example describes how to enable the CCM packet sending function for mep 1000 in md-session 1 ma-session 1. zte(cfg)#cfm md-session 1 ma-session 1 mep-id 1000 ccm-send enable 4.44.12 cfm ccm-receive state Purpose Configures the CCM packet receiving function for CFM MEP.
Page 608: Cfm Mep Alarm-Lowest-Priority
Example The following example describes how to set the packet sending priority of mep 1000 in md-session 1 ma-session 1 to "5". zte(cfg)#cfm md-session 1 ma-session 1 mep-id 1000 priority 5 4.44.14 cfm mep alarm-lowest-priority Purpose Configures the lowest alarm priority of a CFM MEP.
Page 609: Cfm Mep Assign Port/Trunk
Example The following example describes how to set the lowest alarm priority of mep 1000 in md-session 1 ma-session 1 to "3". zte(cfg)#cfm md-session 1 ma-session 1 mep-id 1000 alarm-lowest-priority 3 4.44.15 cfm mep assign port/trunk Purpose Assigns a port or trunk for an MEP.
Page 610: Cfm Mip Assign Port/Trunk
ZXR10 2900E Series Command Reference zte(cfg)#cfm md-session 1 ma-session 1 mep-id 1000 assign port 15 4.44.16 cfm mip assign port/trunk Purpose Assigns a port or trunk for an MIP. Command Mode Global configuration modes Syntax cfm md-session <1-16> ma-session <1-32> mip-session <1-64> assign {delete | port <por tid>| trunk <trunkid>}...
Page 611: Clear Cfm Ma
MD index. <1-32> MA index. Example The following example describes how to clear configuration of all MAs in md-session 1. zte(cfg)#clear cfm md-session 1 ma-session 4.44.19 clear cfm mep Purpose Clears all configuration of CFM MEP. Command Mode Global configuration modes 4-555 SJ-20120409144109-003|2012-07-02(R1.0)
Page 612: Clear Cfm Mip
MEP ID, unique within an MA. Example The following example describes how to clear all configuration of mep 1000 in md-session 1 ma-session 1. zte(cfg)#clear cfm md-session 1 ma-session 1 mep-id 1000 4.44.20 clear cfm mip Purpose Clears all configuration of CFM MIP.
Page 613: Show Cfm Md
Global configuration modes Syntax show cfm md-session <1-16> ma-session [<1-32>] Parameters Parameter Description <1-16> MD index. <1-32> MA index. 4.44.23 show cfm mp Purpose Displays all configuration of CFM MP, including MEP and MIP configuration. 4-557 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 614: Send Cfm Lbm
ZXR10 2900E Series Command Reference Command Mode Global configuration modes Syntax show cfm md-session <1-16> ma-session <1-32> mp-session [<1-64>] Parameters Parameter Description <1-16> MD index. <1-32> MA index. <1-64> MP session ID, including MEP and MIP, unique within a switch 4.44.24 show cfm...
Page 615: Send Cfm Ltm
The following example describes how to initiate an LBM detection in md session 1 ma session 1. The source MEP ID is 1000, and the destination MEP ID is 2000. zte(cfg)#cfm lbm md-session 1 ma-session 1 smep-id 1000 dmep-id 2000 4.44.26 send cfm ltm Purpose Initiates a linktrace detection.
Page 616: Read Ltm Trans-Id
The following example describes how to initiate an LTM detection in md session 1 ma session 1. The source MEP ID is 1000, and the destination MEP ID is 2000. zte(cfg)#cfm ltm md-session 1 ma-session 1 smep-id 1000 dmep-id 2000 4.44.27 read ltm trans-id Purpose Displays the path tree of an LTM response.
Page 617: Dhcp Relay Configuration
Enables/Disables the DHCP relay option82 function globally. Command Mode Global configuration modes Syntax set dhcp relay option82{enable | disable} Parameters Parameter Description Enables the DHCP relay option82 function. enable Disables the DHCP relay option82 function. disable 4-561 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 618: Set Dhcp Relay Option82 Sub-Option Device
The device ID information can be used to locate a specific switch during user location process. Example The following example describes how to set relay option82 ani to "zte-test". zte(cfg)#set dhcp relay option82 sub-option device ani zte-test 4.45.4 set dhcp relay option82 sub-option Purpose Configures the Relay option82 sub option.
Page 619: Set Dhcp Relay Option82 Mode Port
4.45.5 set dhcp relay option82 mode port Purpose Configures the mode of binding dynamic user information on a port. Command Mode Global configuration modes Syntax set dhcp relay option82 mode port <1-52>{default | drop | modify | append} 4-563 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 620: Set Dhcp Relay Server Mode
ZXR10 2900E Series Command Reference Parameters Parameter Description <1-52> Port number. The port number range varies with devices. Here, takes 2952E as an example. default Default mode, in which the option82 attribute in a packet is kept unchanged. Drop mode, in which the packet carrying the option82 attribute is drop discarded.
Page 621: Set Dhcp Relay Server Retry
Specifies that the domain name is in hexadecimal number format. < hex-string> Domain name in hexadecimal number format. <A.B.C.D> IP address bound with the domain. One domain can be configured with up to five server addresses. 4-565 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 622: Clear Dhcp Relay Vclass-Id
ZXR10 2900E Series Command Reference 4.45.9 clear dhcp relay vclass-id Purpose Clears a configured DHCP relay vclass-id. Command Mode Global configuration modes Syntax clear dhcp relay vclass-id {characters <string>{ server A.B.C.D}| hex-numbers <hex-string >{ server A.B.C.D}} Parameters Parameter Description characters Deletes the vclass-id in character string format.
Page 623: Show Dhcp Relay
Displays DHCP relay option60 configuration. Command Mode All configuration modes Syntax show dhcp vclass-id Example The following example describes how to display DHCP relay vclass-id configuration. zte(cfg)#show dhcp relay vclass-id Index Vclass_ID IpAddress ----- -------------------------------------------------- --------------- ztelsj 1.1.1.1 4-567 SJ-20120409144109-003|2012-07-02(R1.0)
Page 624: Show Dhcp Relay Binding
ZXR10 2900E Series Command Reference 4.45.13 show dhcp relay binding Purpose Displays DHCP relay binding table information. Command Mode All configuration modes Syntax show dhcp relay binding [port <1-28>| trunk <1-15>] Parameters Parameter Description port <1-28> Port number corresponding to a relay table entry.
Page 625: Show Dhcp Relay Option82 Device
All configuration modes Syntax show dhcp relay option82 device Example The following example describes how to display device information. zte(cfg)#show dhcp relay option82 device DHCP relay option82 sub-option information on device: Access-Node-Identifier: - Remote-ID: Cisco 4.45.16 set ipport dhcp relay Purpose Configures DHCP relay information on an IP port.
Page 626: Clear Ipport Dhcp Relay
ZXR10 2900E Series Command Reference Parameter Description server Server IP address. <A.B.C.D> DHCP server address. 4.45.17 clear ipport dhcp relay Purpose Clears the DHCP relay configuration on an IP port. Command Mode Layer-3 configuration mode Syntax clear ipport <0-63> dhcp relay {agent | server <A.B.C.D>}...
Page 627: Chapter 5 Management Configuration
Only specific IP address can log in to the switch. The filtering specific function is enabled. Usage Guidelines any/specific is the global switch. When the any is configured, the deny configuration based on the protocol will not be valid. SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 628: Set Remote-Access Ipaddress Permit/Deny
ZXR10 2900E Series Command Reference Default By default, any IP address can log in to the switch. Example The following example describes how to configure any IP address to log in to the switch. zte(cfg)#set remote-access any 5.1.2 set remote-access ipaddress permit/deny...
Page 629: Clear Remote-Access All
The following example describes how to allow the IP address 192.168.0.1 to log in to the switch by ssh and deny the access by telnet. zte(cfg)#set remote-access specific zte(cfg)#set remote-access ipaddress 192.168.0.1 255.255.255.0 zte(cfg)#set remote-access ipaddress 192.168.0.1 255.255.255.0 ssh permit zte(cfg)#set remote-access ipaddress 192.168.0.1 255.255.255.0 telnet deny 5.1.3 clear remote-access all Purpose Deletes the configuration of all IP addresses.
Page 630: Show Remote-Access
ZXR10 2900E Series Command Reference Parameters Parameter Description <A.B.C.D> (first) IP address <A.B.C.D> (second) Mask 5.1.5 show remote-access Purpose Shows the information of remote-access. Command Mode All modes Syntax show remote-access Example The following example describes how to show the information of remote-access.
Page 631: Privilege Session
Command mode. Currently, the following modes are supported: user, cfg, router, snmp, tffs, nas, group, ingress-basic-acl, <mode> ingress-extend-acl, ingress-link-acl, ingress-hybrid-acl, ingress-global-acl, egress-basic-acl, egress-extend-acl, egress-link-acl, and egress-hybrid-acl,mac-based-vlan. Rule keyword. At least 1 keyword and up to 10 keywords can <key1-string>[...<key10-string> be configured. SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 632: Clear Privilege
1 commands; other commands are grade 10 commands. Example The following example describes how to create a rule of authority grade 12. zte(cfg)# privilege 12 session 1 part cfg set 5.2.3 clear privilege Purpose Clears a command authority rule.
Page 633: Ssh
Description <0-15> Command grade. <1-1024> Rule index. Example The following example describes how to view configuration of rule 1. zte(cfg)#show privilege session 1 Session: 1 Level: 12 Type : part Mode: cfg Rule : set 5.3 SSH 5.3.1 set ssh enable/disable Purpose Enables/Disables the SSH function.
Page 634: Set Ssh Regenerate
ZXR10 2900E Series Command Reference 5.3.2 set ssh regenerate Purpose Generates a new SSH public key. Command Mode Golbal configuration mode Syntax set ssh regenerate 5.3.3 show ssh Purpose Shows the configuration and state of SSH. Command Mode All modes...
Page 635: Set Recvpacket
The following example describes how to configure the number of SNMP messages that SNMP protocol stack can process every second to 80. zte(cfg-snmp)#set recvpacket 80 5.4.3 create community public/private Purpose Creates community name and allocates authority. SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 636: Create View
ZXR10 2900E Series Command Reference Command Mode SNMP configuration mode Syntax create community <string>{public | private}[ingress-acl-basic-number <1-99>] Parameters Parameter Description Community name <string> The attribute of community name is read-only. public The attribute of community name is read/write. private <1-99>...
Page 637: Set Community Acl-Rule-Id
Ingress ACL basic group ID bound to the community name Example The following example describes how to set the ACL rule ID bound to the community "beijing" to 12. zte(cfg-snmp)#set community beijing ingress-acl-basic-number 12 5.4.6 clear community acl-rule-id Purpose Deletes the ACL rule ID for a name-specified community.
Page 638: Set Community View
ZXR10 2900E Series Command Reference Example The following example describes how to delete the ACL rule ID for the community "beijing". zte(cfg-snmp)#clear community beijing ingress-acl-basic-number 5.4.7 set community view Purpose Configures the view contains the specified community name. Command Mode...
Page 639: Set Host Trap
Example The following example describes how to set the IP address, version, and community name of a trap host respectivley to "10.40.44.167", "v2", and "beijing". zte(cfg-snmp)#set host 10.40.44.167 trap v2c beijing 5.4.10 set host inform Purpose Configures the host IP address, community names and user names, versions and security levels of inform.
Page 640: Set Trap Enable/Disable
Example The following example describes how to set the inform host IP address as 10.40.44.167, version to v3, username to uname and security level to auth. zte(cfg-snmp)#set host 10.40.44.167 inform v3 uname auth 5.4.11 set trap enable/disable Purpose Enables/Disables traps, such as link up/down, authentication failure, coldstart/warmstart, cluster topology changing and cluster member up/down, loopdetect, and so on.
Page 641 Abnormal power status. powerstatus protocolprotect Too many packets are received by the CPU in unit time. OAM discovery event remotediscovery OAM remote link fault event. remotelinkstatus STP bridge role change. stpBridgeRoleChange STP port state change. stpPortStateChange 5-15 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 642: Set Group V3
ZXR10 2900E Series Command Reference Parameter Description Temperature alarm. temperature topologychange Topology change found by ZTP. Trunk loopback detection. trunkloopdetect UDLD event, such as monologue, incorrect connection, and udldunidirectional neighbor aging. Warm start (restarting with the reboot command). warmstart Ping test/test failure alarm or test completion notification.
Page 643: Set User V3
The command without read/write/notify indicates that group operates zteView. Example The following example describes how to set user name as zte, group name as BN , authentication mode as md5–auth and password as abc for V3. zte(cfg-snmp)#set user zte BN v3 md5-auth abc 5.4.14 set trap macnotification enable/disable...
Page 644: Set Trap Macnotification History-Size/Interval
Example The following example describes how to enable the function of the MAC address change notification trap on port 3, port 5, and port 8. zte (cfg-snmp)#set trap macnotification port 3,5,8 enable 5.4.15 set trap macnotification history-size/interval Purpose Configures the maximum number of entries in the MAC notification history table and the threshold of the interval that MAC change notification traps are sent.
Page 645: Clear Host Trap/Inform
The following example shows how to set the maximum number of entries in the MAC notification history table to 200, and the threshold of the interval that MAC change notification traps are sent to 1 s. zte(cfg-snmp)#set trap macnotification history-size 200 zte(cfg-snmp)#set trap macnotification interval 1 5.4.16 clear host trap/inform Purpose Deletes host configuration.
Page 646: Clear Community
Syntax clear community <string> Parameter Parameter Description Community name <string> Example The following example describes how to delete community name zte. zte(cfg-snmp)#clear community zte 5.4.18 clear view Purpose Deletes view name. Command Mode SNMP configuration mode Syntax clear view <string>...
Page 647: Clear Group V3
Neither authentication nor encryption noauth Authentication and encryption priv Example The following example describes how to delete group name gname whose security level is auth. zte(cfg-snmp)#clear group gname v3 auth 5.4.20 clear user v3 Purpose Delete user. Command Mode SNMP configuration mode 5-21 SJ-20120409144109-003|2012-07-02(R1.0)
Page 648: Clear Engineid
ZXR10 2900E Series Command Reference Syntax clear user <string> v3 Parameter Parameter Description <string> User name Example The following example describes how to delete user uname. zte(cfg-snmp)#clear user uname v3 5.4.21 clear engineID Purpose Clears SNMP engine ID and restores the default value.
Page 649: Chapter 5 Management Configuration
HostIpAddress Comm/User Version Type SecurityLevel ---------------- ------------ ------- ------ ------------- 10.40.89.78 beijing Ver.2c Trap All snmp community information: CommunityName Level ViewName ---------------------------------- ------- --------------- --- beijing private All snmp view information: ViewName Exc/Inc MibFamily 5-23 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 650: Show Snmp Community/Engineid/Group/Host/Trap/User/View
ZXR10 2900E Series Command Reference ------------ -------- ------------------------ test Include 1.3.6.1 zteView Include 1.3.6.1 5.4.23 show snmp community/engineID/group/host/trap/user/view Purpose Shows the information of SNMP V1, V2C and V3. Command Mode All modes Syntax show snmp {community | engineID | group | host | trap | user | view}...
Page 651: Zte Proprietary And Confidential
: disabled udldUnidirectionalTrap : disabled protocolProtectTrap : disabled stpPortStateChangeTrap : disabled stpBridgeRoleChangeTrap : disabled arpOverloadTrap : disabled macOverloadTrap : disabled fileTransferTrap : disabled poeTrap : disabled fanSpeedTrap : disabled temperatureTrap : disabled ipConflictTrap : disabled 5-25 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 652: Rmon
ZXR10 2900E Series Command Reference bootfileLostTrap : disabled cfmFaultAlarmTrap : disabled adminPasswordNoChangeTrap: disabled dismanPingNotifications : disabled macNotificationTrap : disabled The following example describes how to show the configuration of V3 user. zte(cfg-snmp)#show snmp user UserName : shanghai GroupName : BN(v3)
Page 653: Set Statistics
The following example describes how to set the data source of the statistics instance whose index is 10 as port 1. zte(cfg-snmp)#set statistics 10 datasource 1 The following example describes how to set the data source of the statistics instance whose index is 10 as tom.
Page 654: Set Alarm
ZXR10 2900E Series Command Reference The following example describes how to set the status of the statistics instance whose index is 10 as invalid. zte(cfg-snmp)#set statistics 10 status invalid 5.5.3 set alarm Purpose Configures alarm group. Command Mode SNMP configuration mode Syntax set alarm <1-65535>{interval <1-65535>| variable <mib-oid>| sampletype {absolute | delta}|...
Page 655: Set Event
The following example describes how to set that the alarm whose index is 10 triggers the alarm whose index is 100 when data rises to 30000. zte(cfg-snmp)#set alarm 10 threshold 30000 eventindex 100 rising The following example describes how to set the owner of the alarm whose index is 10 as user1.
Page 656: Set History
ZXR10 2900E Series Command Reference Parameters Parameter Description event <1-65535> Index of event group Description information <string> The type of event group is non-operation. none The type of event group is log. The type of event group is trace. snmptrap logandtrap The type of event group is trace and log.
Page 657 The following example describes how to set the data source of the history instance whose index is 10 as port 1. zte(cfg-snmp)#set history 10 datasource 1 The following example describes how to set the data source of the history instance whose index is 10 as userx.
Page 658: Show Rmon
ZXR10 2900E Series Command Reference The following example describes how to set the status of history instance whose index is 10 as invalid. zte(cfg-snmp)#set history 10 status invalid 5.5.6 show rmon Purpose Shows the RMON global configuration. Command Mode All modes...
Page 659: Show Alarm
Startup : risingOrFallingAlarm Threshold(F) : 0 Status : underCreation EventIndex(R): 0 Variable EventIndex(F): 0 Owner AlarmIndex SampleType: absolute Interval : 1800 Value Threshold(R) : 0 Startup : risingOrFallingAlarm Threshold(F) : 0 Status : underCreation 5-33 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 660: Show Event
ZXR10 2900E Series Command Reference EventIndex(R): 0 Variable EventIndex(F): 0 Owner 5.5.9 show event Purpose Shows the configuration information of event group. Command Mode All modes Syntax show event [<1-65535>] Parameter Parameter Description Index of event group <1-65535> Example The following example describes how to show the RMON information of all event instances.
Page 661: Zgmp
5.6.1 set zdp enable/disable Purpose Enables/Disables protocol. Command Mode Cluster management configuration mode Syntax set zdp {enable | disable} Parameters Parameter Description Enables ZDP protocol enable Disables ZDP protocol disable Default Enables ZDP protocol. 5-35 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 662: Set Zdp Port/Trunk Enable/Disable
ZXR10 2900E Series Command Reference 5.6.2 set zdp port/trunk enable/disable Purpose Enables/Disables the ZDP function based on a port/trunk. Command Mode Cluster management configuration mode Syntax set zdp {port <portlist>| trunk <trunklist>}{enable | disable} Parameters Parameter Description port <portlist> Port list trunk <trunklist>...
Page 663: Set Zdp Holdtime
Default The default time is 30 seconds. Example The following example describes how to set the time interval for sending ZDP packets as five seconds. zte(cfg-group)#set zdp timer 5 5.6.4 set zdp holdtime Purpose Configures ZDP holdtime. Command Mode Cluster management configuration mode Syntax set zdp holdtime <10-255>...
Page 664: Show Zdp
ZXR10 2900E Series Command Reference 5.6.5 show zdp Purpose Shows ZDP global configuration. Command Mode All modes Syntax show zdp Example The following example describes how to show the ZDP global configuration. zte(cfg-group)#show zdp Global ZDP : enabled ZDP timer...
Page 665: Show Zdp Neighbour Detail
Hold-Time : 176 Platform : ZXR10 2952E Hostname : zte Version : ZTE ZXR10 2952E Software. Version number : V2.05.10B10 Version make date: Aug 13 2010 May 23 2012 Version make time: 21:05:42 11:25:34 5.6.8 set ztp enable/disable Purpose Enables/Disables ZTP protocol.
Page 666: Set Ztp Port/Trunk Enable/Disable
ZXR10 2900E Series Command Reference Parameter Description Disables ZTP protocol disable Default Enables ZTP protocol. 5.6.9 set ztp port/trunk enable/disable Purpose Enables/Disables the ZTP function based on a port/trunk. Command Mode Cluster management configuration mode Syntax set ztp {port <portlist>| trunk <trunklist>}{enable | disable}...
Page 667: Set Ztp Hop
Default The topology collection is performed in VLAN 1. Example The following example describes how to specify VLAN 100 to perform topology collection. zte(cfg-group)#set ztp vlan 100 5.6.11 set ztp hop Purpose Configures the range of topology collection (hop count).
Page 668: Set Ztp Timer
ZXR10 2900E Series Command Reference 5.6.12 set ztp timer Purpose Configures the time interval for starting auto topology collection. Command Mode Cluster management configuration mode Syntax set ztp timer Parameter Parameter Description The time interval, the unit is minute <0-60>...
Page 669: Set Ztp Hopdelay
Example The following example describes how to set the ZTP message port forwarding waiting time to 40 milliseconds. zte(cfg-group)#set ztp portdelay 40 5.6.14 set ztp hopdelay Purpose Configures the delay time for waiting the collected device forward the topology collection packets.
Page 670: Ztp Start
ZXR10 2900E Series Command Reference zte(cfg-group)#set ztp hopdelay 400 5.6.15 ztp start Purpose Manually triggers topology information collection. Command Mode Cluster management configuration mode Syntax ztp start 5.6.16 show ztp Purpose Shows the global configuration of ZTP. Command Mode All modes...
Page 671 Device-Id Device-Hop : 2 Platform : ZXR10 2928-SI 2918E Hostname : zte Version : ZTE ZXR10 2918E Software. Version number : V2.05.10B10 Version make date: Apr 27 2010 May 23 2012 Version make time: 14:57:57 11:25:34 SwitchRole : CANDIDATE_SWITCH 5-45 SJ-20120409144109-003|2012-07-02(R1.0)
Page 672: Show Ztp Topology
ZXR10 2900E Series Command Reference IpAddress Peer-Device Local-Port Peer-Port Status ------------------ ------------- ------------- ------- 00.11.22.33.44.55 Port22 Port10 Forward 5.6.18 show ztp topology Purpose Shows the network topology with the simple figure. Command Mode All modes Syntax show ztp topology Example The following example describes how to show the network topology.
Page 673: Set Group Commander Ipport
Device-Id Device-Hop : 2 Platform : ZXR10 2918E Hostname : zte Version : ZTE ZXR10 2918E Software. Version number : V2.05.10B10 Version make date: Apr 27 2010 May 23 2012 Version make time: 14:57:57 11:25:34 SwitchRole : CANDIDATE_SWITCH IpAddress Peer-Device...
Page 674: Set Group Candidate
Example The following example describes how to set a commander switch, specify L3 port to ipport 63, and specify IP address pool as 10.40.89.100/24. zte(cfg-group)#set group commander ipport 63 ip-pool 10.40.89.100/24 5.6.21 set group candidate Purpose Configures the role of switch as candidate.
Page 675: Set Group Add
The following example describes how to add a member machine. Cmdr.zte(cfg-group)#show group candidate MacAddress Hop HostName Platform --- ----------------- --- -------------------------------- ------------- 00.19.c6.32.f1.9c 2 ZXR10 2918E Cmdr.zte(cfg-group)#set group add device 2 Adding device id : 2 succeeded to add member! 5-49 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 676: Set Group Delete Member
ZXR10 2900E Series Command Reference 5.6.24 set group delete member Purpose Deletes a member machine. Command Mode Cluster management configuration mode Syntax set group delete member <idlist> Parameter Parameter Description Member ID <idlist> 5.6.25 set group handtime Purpose Configures the time interval for member switch to perform handshake with commander switch.
Page 677: Set Group Holdtime
Chapter 5 Management Configuration Cmdr.zte(cfg-group)#set group handtime 1 5.6.26 set group holdtime Purpose Configures the hold time for saving the information of member switch. Command Mode Cluster management configuration mode Syntax set group holdtime <1-300> Parameter Parameter Description The hold time for saving the information of member switch. The <1-300>...
Page 678: Set Group Mac-Mode
ZXR10 2900E Series Command Reference 5.6.28 set group mac-mode Purpose Configures the protocol multicast address of cluster management. Command Mode Cluster management configuration mode Syntax set group mac-mode {standard | extend [mac <HH.HH.HH.HH.HH.HH>]} Parameters Parameter Description Uses the standard 01.80.c2.00.00.09 standard Uses the extended address.
Page 679: Set Group Tftpsvr
IP address <A.B.C.D> Example The following example describes how to set the IP address of cluster SYSLOG server as 192.168.200.1. Cmdr.zte(cfg-group)#set group syslogsvr 192.168.200.1 5.6.30 set group tftpsvr Purpose Configures the IP address of cluster tftp server. Command Mode Cluster management configuration mode Syntax set group tftpsvr <A.B.C.D>...
Page 680: Show Group Candidate
ZXR10 2900E Series Command Reference Cmdr.zte(cfg-group)#show group SwitchRole : COMMANDER_SWITCH GroupName : ZXR10-ECARRIER HandTime : 8 s HoldTime : 80 s TotalMember: 2 (exclude itself) TftpSvr : none SyslogSvr : 192.168.200.1 Ip-pool : 192.168.1.1/24 Ipport-num : 63 ManageVlan : 1 Mac-mode : extend(01.80.c2.00.00.13)
Page 681: Save Member
ID list of member switch <idlist> All member switches save configuration information 5.6.35 erase member Purpose Deletes the configuration of cluster member switch. Command Mode Cluster management configuration mode Syntax erase member {<idlist>| all} 5-55 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 682: Reboot Member
ZXR10 2900E Series Command Reference Parameters Parameter Description ID list of member switch <idlist> All member switches delete the configuration file 5.6.36 reboot member Purpose Restarts the member switch. Command Mode Cluster management configuration mode Syntax reboot member {<idlist>| all}...
Page 683: Sflow
Parameter Parameter Description Sflow agent IP address <A.B.C.D> Usage Guidelines In SFLOW application, the switch takes as SFLOW agent role and agent-address is generally configured as the layer 3 interface address of the switch. 5-57 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 684: Set Sflow Collector-Address
ZXR10 2900E Series Command Reference Example The following example describes how to configure the SFLOW agent IP address to 10.40.89.50. zte(cfg)#set sflow agent-address 10.40.89.50 5.7.2 set sflow collector-address Purpose Configures the IP address of SFLOW collector. Command Mode Global configuration mode Syntax set sflow collector-address <A.B.C.D>...
Page 685: Set Sflow Ingress/Egress Reload-Mode
The port packet-sample sampling frequency is only valid at the continue mode. Example The following example describes how to set the sampling mode of ingress to the specified interval sampling. zte(cfg)#set sflow ingress reload-mode continue 5-59 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 686: Set Sflow Ingress/Egress Packet-Sample
Disables the port sampling. Example The following example describes how to configure the egress/ingress sampling frequency of port 2 to 2000. zte(cfg)#set sflow ingress port 2 packet-sample on frequency 2000 zte(cfg)#set sflow egress port 2 packet-sample on frequency 2000 5-60 SJ-20120409144109-003|2012-07-02(R1.0)
Page 687: Clear Sflow Config
Shows the SFLOW configuration information. Command Mode Global configuration mode Syntax show sflow Example The following example describes how to show the SFLOW configuration information. zte(cfg)#show sflow Agent address :10.40.89.100 Collector address:10.40.89.78 Version: 4 5-61 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 688: Telnet
ZXR10 2900E Series Command Reference Ingress: Enable State: Yes Reload Mode: Continuous Sample Mode: Forward PortId Port Freq CPU Freq Counter ------ ---------- ---------- --------- None 2000 None Egress: Enable State: Yes Reload Mode: Continuous PortId Port Freq CPU Freq...
Page 689: Show Telnet
5.8.2 show telnet Purpose Displays Telnet configuration and status. Command Mode All configuration mode Syntax show telnet Example The following example describes how to display Telnet configuration and status. zte(cfg)#show telnet Telnet server is enable 5-63 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 690 ZXR10 2900E Series Command Reference This page intentionally left blank. 5-64 SJ-20120409144109-003|2012-07-02(R1.0) ZTE Proprietary and Confidential...
Page 691: Glossary
Glossary - Access Control List - Address Resolution Protocol - Cyclic Redundancy Check DHCP - Dynamic Host Configuration Protocol DSCP - Differentiated Services Code Point - File Transfer Protocol ICMP - Internet Control Message Protocol - Internet Protocol IPv4 - Internet Protocol version 4 IPv6 - Internet Protocol Version 6 - Internet Service Provider...
Page 692 ZXR10 2900E Series Command Reference - Quality of Service RADIUS - Remote Authentication Dial In User Service RMON - Remote Monitoring RSTP - Rapid Spanning Tree Protocol SNMP - Simple Network Management Protocol - Strict Priority TACACS+ - Terminal Access Controller Access-Control System Plus...
