DLP Design DLP-USB245M-G User Manual

Usb to fifo parallel interface module

Advertisement

Quick Links

DLP-USB245M-G USB to FIFO Parallel Interface Module
The DLP-USB245M-G is the 2nd generation, lead free version of DLP Design's USB adapter. This device adds
extra functionality to it's DLP-USB1 predecessor with a reduced component count and a new low price.
DLP-USB245M FEATURES
Send / Receive Data over USB at up to 1 M Bytes /
sec
384 byte FIFO Transmit buffer / 128 byte FIFO
receive buffer for high data throughput
Simple interface to CPU or MCU bus
No in-depth knowledge of USB required as all USB
Protocol is handled automatically within the module
FTDI's Virtual COM port drivers eliminate the need
for USB driver development in most cases.
Integrated 3.3v Regulator – No External Regulator
Required
Integrated Power-On-Reset circuit
Integrated 6MHz – 48Mhz clock multiplier PLL
USB Bulk or Isocronous data transfer modes
4.4v - 5.25v Single Supply taken directly from the
USB port
UHCI / OHCI / EHCI host controller compatible
USB 1.1 and USB 2.0 compatible
USB VID, PID, Serial Number and Product
Description
Strings stored in on-board EEPROM.
EEPROM programmable on-board via USB
VIRTUAL COM PORT ( VCP ) DRIVERS for
-
Windows 98 and Windows 98 SE
-
Windows 2000 / ME / XP
-
Windows CE **
-
MAC OS-8 and OS-9
-
MAC OS-X
-
Linux 2.40 and greater
D2XX ( USB Direct Drivers + DLL S/W Interface )
-
Windows 98 and Windows 98 SE
-
Windows 2000 / ME / XP
[ ** = In planning or under development ]
Copyright © DLP Design 2002
DLP-USB245M User Manual
APPLICATION AREAS
Rapid Prototype Development
USB ISDN and ADSL Modems
High Speed USB PDA Interface
USB Interface for Digital Cameras
USB Interface for MP3 players
High Speed USB Instrumentation
USB Smart Card Readers
Set Top Box (S.T.B.) PC-USB interface
USB Hardware Modems
USB Wireless Modems
USB Bar Code Readers
Page 1 of 15
