Summary of Contents for J.R. Clancy SC5300
- Page 1 SC5300 Console User Guide...
- Page 3 SceneControl ® 5000 HARDWARE SC5300 Console User Guide P/N: 5012-00 Version 1.00 June 2014 Copyright © 2001–2014 by J.R. C lanCy J.R. C lanCy 7041 Interstate Island Road Syracuse NY 13209 Domestic Toll Free: 800 836 1885 International: 001 315 451 3440...
- Page 4 SceneControl ® 5000 HARDWARE SceneControl ® 5000 HARDWARE...
- Page 5 The J.R. Clancy SC5300 Console also has the Operator’s E-stop, E-stop Reset, E-stop Reset Lockout controls and manual control joystick. The SC5300 macro buttons interface is all done right on the main touch screen. The SC5300 computer and monitor power is supplied from the SC5300 Power Distribution, described later in the manual.
- Page 6 SceneControl ® 5000 HARDWARE SC5300 Console List of Parts Review the diagrams below to familiarize yourself with the SC5300 Console operator buttons and physical features. SC5300 Console ISOMETRIC View Layout SC5300 Console Helm View Layout SceneControl ® 5000 HARDWARE...
- Page 7 Software. The lights will be RED when the system is in E-STOP and ORANGE when the system is in a standby state. 2 - Console Helm - Them main tactile buttons of the SC5300 Console are found here. Refer to the next several lines for detailed information on the buttons.
- Page 8 - Connect an extra monitor to this port (clone view) 5 – NET A FIELD MAIN 10 Base-T port - Connects the SC5300 Console to the Network Uplink. 6 - NET A FIELD Spare - Do not connect this unless the first link has stopped operating 7 –...
- Page 9 SceneControl ® 5000 HARDWARE SC5300 Console Left View Layout 1 – Light Power 3-PIN XLR - LittleLite +12VDC power source outlet 2 – USB - Plug any USB device into this, such as a memory card stick, external hard drive, or a mouse 3 –...
- Page 10 2 – Console Power Switch - Turns the on and off. The switch will stay depressed (latched). SC5300 Console HELM 3 – Light Power 3-PIN XLR - LittleLite +12VDC power source outlet NOTE: can be turned OFF and the E-Stop system will still function SC5300 Console properly.
- Page 11 SceneControl ® 5000 HARDWARE (This page is blank) SceneControl ® 5000 HARDWARE...
-
Page 12: Power Distribution
Power Distribution ® The SceneControl Power Distribution is the main source of power for the SC5300 Console. Familiarize yourself with the diagram below and follow safe operating procedures when connecting any cables to their inlets/outlets. Note: The diagram below may not be an exact representation of the PD, but all the items are identical and functionality remains the same. - Page 13 - Connect the Back-UPS unit to this port to provide the unit with AC Power. 9 - MONITOR POWER OUTLET - used to supply power to the monitors (NOT USED FOR SC5300). 10 - NET-1 - Network 1 pass through ports...
- Page 14 Press the Emergency Stop button. The Emergency Stop System should now be disabled. Turn on the power switch for the SC5300 Console Helm using the switch on the right hand side of the console. Your SC5300 Console will now perform a self-diagnostic test, lamp test and boot You are now ready to confirm communications and use your SC5300 Console.
- Page 15 SceneControl ® 5000 HARDWARE Console Startup & Shutdown Procedure Startup Turn Main Computer “ON” Wait for computer to boot up Start Raynok and Login Open the Show File needed for the venue. Setup Menu - “GO ONLINE” Reset E-Stop System - Turn the key switch to the right, hold and press “RESET”. Setup menu - “EXIT E-STOP RESET MODE”...
- Page 16 SceneControl ® 5000 HARDWARE RAYNOK Basic Procedures To Move Battens Reset E-Stop system Setup Menu - “EXIT E-STOP RESET MODE” Select batten Set target by using any of the following 1. Use “INTRIM” macro 2. Use “OUTTRIM” macro 3. Or use “ASK TARGETS” macro Reset Axis Press “GO”...
- Page 17 Test and Boot Up of the SC5300 Console After turning on the power to the SC5300 Console it will perform a lamp test to illustrate to you that all of the LED indicators are in proper working order. The LEDs will turn on and then off, chase from left to right, top to bottom and then turn on and off again.
- Page 18 SceneControl ® 5000 HARDWARE otes SceneControl ® 5000 HARDWARE...
- Page 19 SceneControl ® 5000 HARDWARE otes SceneControl ® 5000 HARDWARE...
