Advanced Setup - Kraun Wireless Modem Router ADSL2/2+ User Manual

Figure 4-14
3) WPA-PSK
To configure WPA-PSK settings, select the WPA-PSK option
from the drop-down list. The menu will change to offer the
appropriate settings. WPA-PSK requires a shared key and does
not use a separate server for authentication. PSK keys can be
ASCII or Hex type.
Figure 4-15
- Encryption: Select the encryption you want to use: Automatic,
TKIP or AES (AES is an encryption method stronger than
TKIP).
• TKIP (Temporal Key Integrity Protocol) - a wireless
encryption protocol that provides dynamic encryption
keys for each packet transmitted.
• AES (Advanced Encryption Standard) - A security
method that uses symmetric 128-bit block data
encryption.
- Pre-Shared Key: Enter the key shared by the Router and
your other network devices. It must have 8-63 ASCII
characters or 64 Hexadecimal digits.
4) WPA2-PSK
To configure WPA2-PSK settings, select the WPA2-PSK option
from the drop-down list. The menu will change to offer the
appropriate settings. WPA2-PSK requires a shared key and
does not use a separate server for authentication. PSK keys can
be ASCII or Hex type.
Figure 4-16

4.4 Advanced Setup

Choose "Advanced Setup", you can see the next submenus:
Figure 4-17
Click any of them, and you will be able to configure the
corresponding function.
4.4.1 Firewall
Choose "Advanced Setup->Firewall" menu, and you will see the
next screen (shown in Figure 4-18).
Figure 4-18
- Firewall: Select this option can automatically detect and
block Denial of Service (DoS) attacks, such as Ping of
Death, SYN Flood, Port Scan and Land Attack.
- SPI: If you enable SPI, all traffics initiated from WAN
would be blocked, including DMZ, Virtual Server, and
ACL WAN side.
4.4.2 Routing
Choose "Advanced Setup->Routing" menu, and you will see
the routing information in the next screen (shown in Figure 4-
19).
Figure 4-19
Click ADD ROUTE button to add a new route in the next
screen (shown in Figure 4-20).
11
