Product: TDP80DN /
11.10.2001
SERVICE MANUAL
BENEFON EXION
TDP80DN
Dp_80ngbTOC.fm
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EXION TDP80DN and is the answer not in the manual?

Questions and answers

Related Manuals for Benefon EXION TDP80DN

Summary of Contents for Benefon EXION TDP80DN

  • Page 1 Product: TDP80DN / 11.10.2001 SERVICE MANUAL BENEFON EXION TDP80DN Dp_80ngbTOC.fm...

  • Page 2: Table Of Contents

    Product: TDP80DN / 11.10.2001 CONTENTS 1.0 GENERAL ........1 - 1 1.1 TECHNICAL INFORMATION .
  • Page 3 Product: TDP80DN / 11.10.2001 3.2.7 Installation Material Bag ..... . 3 - 9 3.3 Operation and Testing after Installation ....3 - 9 4.0 BeneLoc .

  • Page 4: General

    Product: TDP80DN / General 9.2.2001 1.0 GENERAL General 1.1 TECHNICAL INFORMATION 1.1.1 Network standard NMT-450i Output power=1,2 W 1.1.2 Dimensions (with 900 mAh Lion) Size: 46 x 100 x 21 mm Weight: 109 g Volume: 81 cm³ 1.1.3 Display Full-graphics high-contrast screen Electro-luminescent lighting Resolution 100 x 48 pixels Up to 5 lines of text...

  • Page 5: Personal Organiser

    Product: TDP80DN / General 9.2.2001 1.1.5 Personal organiser Clock and date Alarm clock with snooze Calendar Calendar appointment manager with reminders Phone power on and off timers 1.1.6 Other phone features Autonomous Power Control Calculator and currency converter Several games for entertainment Personalised ringing melody groups External antenna connector Vibrating alert...

  • Page 6: Short Messages Service (Sms) (Operator Dependent Function)

    Product: TDP80DN / General 9.2.2001 Answered calls (10) list with time or date stamp and calling number or name identifi- cation Received DTMF-messages (10) with time and date stamp Unanswered calls (10) list with time or date stamp and calling number or name iden- tification Access phone book for sending SMS Pick SMS sender’s number for phone book...

  • Page 7: Battery Packs And Operating Times

    Product: TDP80DN / General 9.2.2001 1.1.12 Battery packs and operating times Initially two battery packs are available for Benefon Exion, namely Battery type Stand-by Talk time Charging time Charging time time Fast Normal Lithium ion 900 mAh 20 h -150 h...

  • Page 8: Benewin

    Edit and back up phone book memory Send and receive SMS messages by using a PC keyboard Compose and change ringing melodies with BeneWin Maestro Manage phone settings 1.1.16 Manufacturer BENEFON OYJ P.O. Box 84 (Meriniitynkatu 11) FIN 24101 SALO FINLAND...

  • Page 9: Product Family

    Product: TDP80DN / General 9.2.2001 1.2 PRODUCT FAMILY - BENEFON EXION HANDPORTABLE TDP80DN - MAINS CHARGER - CIGARETTE LIGHTER CHARGER - PORTABLE HANDS FREE (HF) KIT - DIGITAL, FULL DUPLEX, PLUG-IN HF CAR KIT - HANDS FREE CAR KIT WITH VOICE RECOGNITION AND...
  • Page 10 Product: TDP80DN / General 9.2.2001 Portable hands free (HF) kit Digital, full duplex, plug-in HF car kit Carbox Power Cable UBH75 fuse Hf Speaker System Cable Installation base Button Unit HF Holder KGS75 Microphone Hands free car kit with voice recognition and external antenna 2DP_80GB.fm...
  • Page 11 Product: TDP80DN / General 9.2.2001 Belt clip Car cradle BeneWin software & editor cable Line interface for data transmission 2DP_80GB.fm...

  • Page 12: Owner's Manual

    2.0 OWNER’S MANUAL 1user_gb.fm...

  • Page 13: Installation Instructions

    3.0 INSTALLATION INSTRUCTIONS Installation Instructions 3.1 Phone Programming You can program Benefon Exion by using either the keys on your phone, or the BeneLoc computer program and maintenance adapter. In either case, you will need a localbox. Programming Menu Commands: 3.1.1 To program Using the Phone Keys...
  • Page 14 Product: TDP80DN / Installation Instructions 11.10.2001 3.1.1.1 Sales Date 1. Select the Sales date sub-menu with n. Press CHANGE. 2. Press CHANGE. |XXXXXX will be replaced by the date [daydaymonthmonthyearyear]. Remember to check that the date is correct. If the date is correct, press OK.
  • Page 15 Product: TDP80DN / Installation Instructions 11.10.2001 3.1.1.4 Phone code 1. Select the Phone code sub-menu with n. Press CHANGE. 2. Enter the phone code (four digits), and save the code by pressing 3.1.1.5 Y1 Y3 ID (Additional operator indicator) Use this feature only in case the operator name is missing ie. RU1 works if Y3 is in use.
  • Page 16 Product: TDP80DN / Installation Instructions 11.10.2001 3.1.1.6 Sw version 3.1.1.7 Sak After ID is programmed SAK changes to normal mode. 3.1.1.8 Update localbox 3.1.1.9 Interleaving The Dealer activates or deactives them according to the operator's or the customer's likings. 6DP_80GB.fm...
  • Page 17 Product: TDP80DN / Installation Instructions 11.10.2001 3.1.1.10 Automatic roaming The Dealer activates or deactives them according to the operator's or the customer's likings. 3.1.1.11 Reset RAM Resets user settings and phone book. 3.1.1.12 Closing Instructions 1. Having programmed the necessary information press QUIT to return to stand-by mode.

  • Page 18: To Program Using The Beneloc Program

    Product: TDP80DN / Installation Instructions 11.10.2001 3.1.2 To program Using the BeneLoc Program p o w e r 5 V l o g g e n f l a s h 5 V l o g m e t e r Start the installed program by clicking the icon.
  • Page 19 Product: TDP80DN / Installation Instructions 11.10.2001 You can read the phone data by pressing the Read -key. You can change the miscellanous settings with the computer and transfer them to phone by pressing the Write -key. BeneLoc includes Help-program for further information. 6DP_80GB.fm...

  • Page 20: Car Kit

    Car Kit. Caution: The Car Kit should only be installed by a Benefon authorized installer. The end user should never attempt to install the Car Kit without professional assistance. Professional installers have the required tools and knowledge for installing the Car Kit properly and safely.

  • Page 21: Button Unit

    Product: TDP80DN / Installation Instructions 11.10.2001 3.2.4 Button Unit The button unit enables easy operation of the Car Kit. The unit consists of plastic base and buttons. Decide where to install the buttons unit. Possible locations are on the dashboard or on the handbrake lever. Mount the plastic base using supplied screws, bands or adhesive tape.
  • Page 22 Product: TDP80DN / Installation Instructions 11.10.2001 8. Make a cellular conversion to ensure that the Car Kit is installed correctly. Note: Whenever the car box is disconnected from the car's battery and then reconnected to the battery, make sure there is no phone connected in the hf holder.

  • Page 23: Beneloc

    BeneLoc program is designed to help service person on tuning and service purpose. With Flasher Program you can change the software to Benefon phones. Both, BeneLoc and Flasher program will need Power Supply and Localbox with ser- vice rights to work.

  • Page 24: To Start The Beneloc Program

    LOCAL mode. You can test this by pressing arrow button. There should be ***Benefon local*** on the display, if not, clean connectors and try again. When phone is in LOCAL mode you can start the BeneLoc Program.

  • Page 25: Using The Beneloc Program

    Product: TDP80DN / BeneLoc 9.2.2001 4.0.3 Using the BeneLoc program In the main window of the BeneLoc, you will find submenus and buttons. Clicking the buttons you can go to the submenus. Change For changing phone to another similar you do not need to do more than enter into main menu.
  • Page 26 Product: TDP80DN / BeneLoc 9.2.2001 Service You can control the audio lines (for example, switch Rx audio and compander on/off) in the Service main menu. It is also possible to control the phone to desired channel. There is also possible to change the power of transmitter. In the Ports submenu is you can see the status of different digital ports.
  • Page 27 Product: TDP80DN / BeneLoc 9.2.2001 System You select used mobile phone system from this submenu. File From settings submenu you can manually change settings of the communication port. 3dp_80gb.fm...

  • Page 28: Phone's Construction

    Product: TDP80DN / 11.10.2001 5.0 PHONE’S CONSTRUCTION 7dp_80gb.fm...

  • Page 29: General Description For The Baseband

    Product: TDP80DN / OC2720 Processor/Audio/RF 9.2.2001 LOGIC / AUDIO OC2720 Processor/Audio/RF 5.1 General description for the baseband The baseband is built with DSP asic (Digital Signal Processor) made by VLSI. All the functions are found within a single OC2700 board. The processor controls the RF parts, internal devices and external accessories.

  • Page 30: Pin Description Of The Dsp Baseband Asic

    Product: TDP80DN / OC2720 Processor/Audio/RF 9.2.2001 Analog interface: - 2 speech Analog-to-digital converters (ADC), for microphone and RX - 2 speech Digital-to-analog converters (DAC), for earphone and TX - 8-input 10-bit ADC - 6 10-bit DACs An interrupt controller An external bus interface A real-time clock Power on/off logic 5.2.1 Pin description of the DSP baseband asic...
  • Page 31 Product: TDP80DN / OC2720 Processor/Audio/RF 9.2.2001 AGND4 Analog ground AVDD0 Analog power supply AVDD1 Analog power supply PGND Earphone driver ground PVDD Earphone driver power supply RTCOSC1 Crystal oscillator output for real time clock OSC0 Crystal oscillator input (13 or 26 MHz) OSC1 Crystal oscillator output (13 or 26 MHz) XRESET...
  • Page 32 Product: TDP80DN / OC2720 Processor/Audio/RF 9.2.2001 Data IO of external memory bit 11 Data IO of external memory bit 12 Data IO of external memory bit 13 Data IO of external memory bit 14 Data IO of external memory bit 15 XCS0 Chip select 0 of an external memory XCS1...
  • Page 33 Product: TDP80DN / OC2720 Processor/Audio/RF 9.2.2001 KEYIN1 Keyboard interface input #1 KEYIN2 Keyboard interface input #2 KEYIN3 Keyboard interface input #3 KEYIN4 Keyboard interface input #4 KEYOUT0 Keyboard interface output #0 KEYOUT1 Keyboard interface output #1 KEYOUT2 Keyboard interface output #2 KEYOUT3 Keyboard interface output #3 KEYOUT4...

  • Page 34: Connectors

    Product: TDP80DN / OC2720 Processor/Audio/RF 9.2.2001 5.2.2 Connectors 5.2.2.1 The system connector NAME FUNCTION STATE IN/OUT AGND Analog Ground RS1CTS / RS1 Clear to Send / !2CINT I2C Interrupt (NMT) 2,7V 0V -1,5V pp EXTMIC External MIC line RS1RTS / RS1 Ready to Send / ACCPWR Accessory pwr control...
  • Page 35 Product: TDP80DN / OC2720 Processor/Audio/RF 9.2.2001 5.2.2.2 Battery connector, V50 3 – 5 V DC ground 5.2.2.3 Battery identification connector, V51 SBAT_ID0 Battery temperature, pulled at VCCS SBAT_ID1 Detect different battery packs, pulled at VCCS 5.2.2.4 Display connector, V80 VRAM 2.5 V VRAM 2.5 V...

  • Page 36: Functions

    Product: TDP80DN / OC2720 Processor/Audio/RF 9.2.2001 5.2.2.6 Circuit Diagram The processor, audio and RF circuit circuit diagrams are split into seven pages. Logic diagrams are found in first four pages. Pages: 1 of 7 Module connector pins 2 of 7 Power supply and on/off logic 3 of 7 Memory, DSP logic and SIS function...
  • Page 37 5.2.3.5 Sis SIM is performed by a BENEFON ASIC IG2048 manufactured by ATMEL. Integrated circuit IG2048 is E2 logic array. This type of array incorporates both electrically and programmable read only memory (EEPROM) and a gate array for SIM funcrtion.

  • Page 38: Rx Synthesizer

    Product: TDP80DN / OC2720 Processor/Audio/RF 9.2.2001 5.3 RX SYNTHESIZER 5.3.1 General The RX synthesizer generates an upper side injection frequency for the receiver. The injection frequency is fed to the receiver's first mixer. Operating voltage 3.0 VDC Current consumption 14 mA Output level to the receiver +1 dBm Frequency range...

  • Page 39: Tx-Synthesizer

    Product: TDP80DN / OC2720 Processor/Audio/RF 9.2.2001 5.4 TX-SYNTHESIZER 5.4.1 General The TX synthesizer generates the final modulated transmission frequency, which is fed to the transmitter. Operating voltage 3.0 VDC Current consumption <30 mA Output level to the transmitter +6 dBm Frequency range 452.500...457.475 MHz 5.4.2 Function Description...

  • Page 40: Control- And Output-Signals

    Product: TDP80DN / OC2720 Processor/Audio/RF 9.2.2001 5.4.3 Control- and Output-Signals VTXS TX synthesizer operating voltage (3.0 V) TXAUDIO Transmitter audio signal 13MHz 13.00 MHz signal to the receiver circuit. SCLK Clock signal for synthesizer control data SDATA Synthesizer control data ENABLE pulse to the synthesizer TXINJ TX synthesizer output to the transmitter (+6 dBm)

  • Page 41: Input- And Output-Signals

    Product: TDP80DN / OC2720 Processor/Audio/RF 9.2.2001 5.5.2 Input- and Output-Signals RF input from the duplex filter 462.500...467.475 MHz RXINJ RX injection signal to the balanced mixer 13.00 MHz signal to the multiplier for the 13MHz 2.mixer RX operating voltage 3.0V from the regulator 450 kHz Output from 2.

  • Page 42: Transmitter

    Product: TDP80DN / OC2720 Processor/Audio/RF 9.2.2001 5.6 TRANSMITTER 5.6.1 General Operating voltage 3.5 ... 4.5 v Current consumption mid power max. 1.1 A low power max. 0.45 A Input level from the synthesizer +6 dBm Output level to the duplex filter mid power 33 dBm (2.0W) low power 24.7 dBm (0.3W) Frequency range...

  • Page 43: Parts List

    Product: TDP80DN / OC2720_A1 11.10.2001 5.7 Module OC2720 (The Layout PC2700 A1) OC2720_A1 Parts list 5.7.1 CODE PART DESCRIPT. VALUE MANUF. TYPE AB0612 A101 Backup-battery 3V Manganese Lithium Panasonic ML612/F9D AM1840 A301 Electret Condenser micr. with rubber holder ????????? OBG-18S40-C33CEC AE0023 A321 Dynamic transducer...
  • Page 44 Product: TDP80DN / OC2720_A1 11.10.2001 CODE PART DESCRIPT. VALUE MANUF. TYPE CG0103 C222 SMD capasitor X7R 10nF Ò10% Murata CG0104 C241 SMD capasitor 100nF/10% 6,3V X5R Murata GRM36Y5V104Z216- CG0223 C242 SMD capasitor X7R 22nF 20% Murata CG0103 C243 SMD capasitor X7R 10nF Ò10% Murata CG0471...
  • Page 45 Product: TDP80DN / OC2720_A1 11.10.2001 CODE PART DESCRIPT. VALUE MANUF. TYPE CD0473 C450 SMD capasitor 47 nF 10% 50 V X7R Philips CD0105 C451 SMD capasitor 1uF/16V%10% X5R TaiyoYuden EMK212BJ105KG-T CD0103 C452 SMD capasitor 10 nF 10% 50 V X7R Philips CD0223 C453...
  • Page 46 Product: TDP80DN / OC2720_A1 11.10.2001 CODE PART DESCRIPT. VALUE MANUF. TYPE CG0103 C532 SMD capasitor X7R 10nF Ò10% Murata CG0103 C533 SMD capasitor X7R 10nF Ò10% Murata CG0102 C534 SMD capasitor X7R 1nF Ò10% Murata CG0103 C535 SMD capasitor X7R 10nF Ò10% Murata CG0150...
  • Page 47 Product: TDP80DN / OC2720_A1 11.10.2001 CODE PART DESCRIPT. VALUE MANUF. TYPE CG0102 C645 SMD capasitor X7R 1nF Ò10% Murata CF0105 C646 SMD capasitor 1uF 10% 6,3V X5R TaiyoYuden JKM107BJ105KA-T CG0101 C650 SMD capasitor X7R 100pF Ò5% Murata CG0101 C651 SMD capasitor X7R 100pF Ò5% Murata CG0101...
  • Page 48 Product: TDP80DN / OC2720_A1 11.10.2001 CODE PART DESCRIPT. VALUE MANUF. TYPE LC3333 L504 SMD inductor 33n -+2% Panasonic ELJRE33NGF2 LC3273 L510 SMD inductor 27nH -+2% Panasonic ELJRE27NGF2 LC3332 L513 SMD inductor 3n3 -+2% Panasonic ELJRE3N3ZF2 LC3334 L520 SMD inductor 330nH +-10% TaiyoYuden LK1608R33K-T LC3334...
  • Page 49 Product: TDP80DN / OC2720_A1 11.10.2001 CODE PART DESCRIPT. VALUE MANUF. TYPE RG0103 R132 SMD resistor 10k 5% 0.063W Kamaya RMC1/16S RG0331 R133 SMD resistor 330R 5% 0.063W Kamaya RMC1/16S RG0104 R134 SMD resistor 100k 5% 0.063W Kamaya RMC1/16S RG0102 R135 SMD resistor 1k0 5% 0.063W Kamaya...
  • Page 50 Product: TDP80DN / OC2720_A1 11.10.2001 CODE PART DESCRIPT. VALUE MANUF. TYPE RG0473 R331 SMD resistor 47k 5% 0.063W Kamaya RMC1/16S RG0472 R332 SMD resistor 4k7 5% 0.063W Kamaya RMC1/16S RG0000 R333 -RG9999 SMD resistor 0.063W Kamaya RMC 1/16S..RG0330 R334 SMD resistor 33R 5% 0.063W Kamaya...
  • Page 51 Product: TDP80DN / OC2720_A1 11.10.2001 CODE PART DESCRIPT. VALUE MANUF. TYPE RG0221 R484 SMD resistor 220R 5% 0.063W Kamaya RMC1/16S RG0473 R493 SMD resistor 47k 5% 0.063W Kamaya RMC1/16S RG0473 R497 SMD resistor 47k 5% 0.063W Kamaya RMC1/16S RG0101 SMD resistor 100R 5% 0.063W Kamaya RMC1/16S...
  • Page 52 Product: TDP80DN / OC2720_A1 11.10.2001 CODE PART DESCRIPT. VALUE MANUF. TYPE RG0222 R625 SMD resistor 2k2 5% 0.063W Kamaya RMC1/16S RG0100 R626 SMD resistor 10 R 5% 0.063W Kamaya RMC1/16S RG0103 SMD resistor 10k 5% 0.063W Kamaya RMC1/16S RG0103 R630 SMD resistor 10k 5% 0.063W Kamaya...

  • Page 53: Layouts

    Product: TDP80DN / OC2720_A1 11.10.2001 5.7.2 Layouts 4C2720_A1GB.fm...
  • Page 54 Product: TDP80DN / OC2720_A1 11.10.2001 CAUTION Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type rec- ommended by the equipment manufac- turer. Discard used batter- ies according to manu- facturer's instructions. 4C2720_A1GB.fm...

  • Page 55: Circuit Diagrams

    Product: TDP80DN / OC2720_A1 11.10.2001 5.7.3 Circuit Diagrams 4C2720_A1GB.fm...
  • Page 56 Product: TDP80DN / OC2720_A1 11.10.2001 4C2720_A1GB.fm...
  • Page 57 Product: TDP80DN / OC2720_A1 11.10.2001 4C2720_A1GB.fm...
  • Page 58 Product: TDP80DN / OC2720_A1 11.10.2001 4C2720_A1GB.fm...
  • Page 59 Product: TDP80DN / OC2720_A1 11.10.2001 4C2720_A1GB.fm...
  • Page 60 Product: TDP80DN / OC2720_A1 11.10.2001 4C2720_A1GB.fm...
  • Page 61 Product: TDP80DN / OC2720_A1 11.10.2001 4C2720_A1GB.fm...

  • Page 62: Keyboard

    Product:TDP80DN / OK2500 11.10.2001 5.8 Keyboard OK2500 4k2500gb.fm...
  • Page 63 Product:TDP80DN / OK2500 11.10.2001 4k2500gb.fm...
