Options and accessories

7.8 Mathematical Operation Commands

The CALCulate:AVERage group of commands performs statistical
calculations on the current contents of the data logger memory.
A minimum of two readings must be stored otherwise an "execution
error" is generated i.e. bit (4) of the Standard Event Register is set.
This error is also generated if the log contains inconsistent entries i.e.
readings taken on different channels.

7.8.1 CALCulate:AVERage command summary

Command
CALCulate:AVERage:MINimum?
CALCulate:AVERage:MAXimum?
CALCulate :AVERage:AVERage?
CALCulate :AVERage:COUNt?
CALCulate :AVERage:PEAK?
CALCulate :AVERage:SDEV?

7.8.2 CALCulate:AVERage commands

CALCulate :AVERage:MINimum?
Return the minimum temperature value stored in the data log.
CALCulate :AVERage:MAXimum?
Return the maximum temperature value stored in the data log.
CALCulate :AVERage:AVERage?
Return the average of all temperature values stored in the data log.
CALCulate :AVERage:COUNt?
Return the number of readings stored in the data log.
CALCulate :AVERage:PEAK?
Return the peak-to-peak value of the temperature values stored in the
data log i.e. max - min.
CALCulate :AVERage:SDEV?
Return the standard deviation of the temperature values stored in the
data log. This is effectively a measure of RMS noise.
Description
Queries the minimum stored temperature.
Queries the maximum stored temperature
Queries the average stored temperature.
Queries the number of stored readings.
Queries the peak to peak value.
Queries the standard deviation value.
Page 7-22
