Operating the TTI-7-R
Enter the new date as a sequence of six digits in the selected date
format. For example, to set the date to April 6th 1998 in the format
dd/mm/yy, enter [0] [6] [0] [4] [9] [8] and then press [OK]. The new
date is displayed on the screen; you can correct it if necessary by
pressing [Chg] again and repeating the process. USER/OPTN
deletes the entire data entry.

5.7.3 Configuring the communications interface

The TTI-7-R can be fitted with one of the following types of
communications interface card:
1. RS-232 serial communications interface
2. IEEE-488.2 parallel communications interface.
The optional communications interface lets you assign remote
control of the TTI-7-R to an external computer.
5.7.3.1 Configuring the RS232 communications interface
If an RS232 serial communications interface card is fitted, select the
[Rem I/F] option in the main configuration menu. If there is no
interface fitted, the TTI-7-R displays the message Option not
available.
The screen displays:
Switching on Talk Only Mode: You use the Talk only Mode to send
results directly to a serial printer, without the need for a PC. In this
mode, the TTI-7-R continuously outputs temperature data and
measurement results to the RS232 serial port. Output data format is
covered in Section 7.
When you select the [Talk Only] option, the screen displays:
Talk only mode is OFF?
Talk Baud
Only Rate
Quit OK
Chg Quit OK
Page 5-28
