Benchmark DAC2 Series Instruction Manual page 49

Audio Precision
-90
-92.5
-95
-97.5
d
-100
B
-102.5
-105
-107.5
-110
20 50
Graph Plot 10 - THD+N vs. FREQUENCY 80 kHz
The analog output stages on the DAC2 have high slew rates and are capable of maintaining low
THD levels at high frequencies even when driven to 0 dBFS. Note that there is almost no rise in
THD+N with frequency, even when operating at maximum output levels.
DAC2 Series Instruction Manual
DAC2 - THD+N VS FREQ AT 0 dBFS (w/80 kHz LPF
100 200 500
DAC2 - THD+N vs FREQUENCY 80kHZ.at27
unweighted)
Balanced Outputs
1k 2k
Hz
Rev C
5k 10k 20k
Page 49
