Description Fuse rating
26 SENSOR 2 15A
27 IG COIL 20A
28 SPARE 10A
29 SPARE 15A
30 SPARE 20A
31 SPARE 25A
32 SPARE 30A
Engine compartment (Diesel box)
Description
GLOW PLUG FUSIBLE LINK
FUEL FILTER HEATER
PTC HEATER #1
PTC HEATER #2
PTC HEATER #3
G4KE - PCM, Oxygen Sensor (Down) G6DC - PCM, Oxygen Sensor #1~#4 D4HB - Fuel Pressure
Regulating Valve, Oil Level Sensor EGR Cooling Bypass Solenoid, Electrical VGT Actuator
G4KE - Condenser, Ignition Coil #1~#4 G6DC - Condenser #1/2, Ignition Coil #1~#6 D4HB - ECM
Fuse rating
80A Glow relay unit
30A Fuel filter heater relay
40A PTC heater relay 1
40A PTC heater relay 2
40A PTC heater relay 3
Protected component
-
-
-
-
-
Protected component
Maintenance
9 53
