Page 1 A000A01A-AAT This Owner's Manual should be considered a part of the car and remain with it when it is sold for the use of the next owner. OWNER'S I.D. ORIGINAL OWNER ADDRESS CITY STATE ZIP CODE DELIVERY DATE (Date Sold to Original Retail purchaser) DEALER NAME DEALER NO.
Page 2: Specifications
Specifications A030A01O-A All information in this Owner's Manual is current at the time of publication. However, Hyundai reserves the right to make changes at any time so that our policy of continual product improvement may be carried out. This manual applies to all Hyundai models and includes descriptions and explanations of optional as well as standard equipment.
Page 3 A020A01A-AAT RESPONSIBILITY FOR MAINTENANCE The maintenance requirements for your new Hyundai are found in Section 5. As the owner, it is your responsibility to see that all maintenance operations specified by the manufacturer are carried out at the appropriate intervals.
Page 4 Your Owner's Manual will introduce you to the features and operation of your new Hyundai. It is suggested that you read it carefully because the information it contains can contribute greatly to the satisfaction you receive from your new car.
Page 5 Your Hyundai should not be modified in any way. Such modifications may adversely affect the performance, safety or durability of your Hyundai and may, in addition, violate conditions of the limited warranties covering the vehicle. Certain modifications may also be in violation of regulations established by the U.S. Department of Transportation and other federal or state agencies.
Page 6 A090A01A-AAT SAFETY AND VEHICLE DAMAGE WARNING This manual includes information titled as WARNING, CAUTION and NOTE. These titles indicate the following: WARNING: This indicates that a condition may result in harm, serious injury or death to you or other persons if the warning is not heeded.
Page 7 Hyundai Genuine Parts are the same parts Hyundai Genuine Parts? used by Hyundai Motor Company to manu- facture vehicles. They are designed and Look for the Hyundai Genuine Parts Logo on tested for the optimum safety, performance, the package (see below). and reliability to our customers.
Page 8 TABLE OF CONTENTS FEATURES OF YOUR HYUNDAI DRIVING YOUR HYUNDAI WHAT TO DO IN AN EMERGENCY CORROSION PREVENTION & APPEARANCE CARE VEHICLE MAINTENANCE REQUIREMENTS SECTION DO-IT-YOURSELF MAINTENANCE EMISSION CONTROL SYSTEMS CONSUMER INFORMATION, REPORTING SAFETY DEFECTS & BINDING ARBITRATION OF WARRANTY CLAIMS...
Page 9: Instruments And Controls
INSTRUMENTS AND CONTROLS B250A04O-AAT B250A01O-A smhma-0.p65 9/24/04, 9:04 AM...
Page 10 1. Multi-Function Light Switch 13.Front Fog Light Switch (If installed) 2. Instrument Cluster 14.Hood Release Lever 3. Horn and Driver's Airbag 15.Panel Brightness Control Knob (Rheostat Switch) 4. Trip Switch / Trip Computer Switch (If installed) 16.Traction Control System Switch (If installed) 5.
Page 11 YOUR VEHICLE AT A GLANCE B255A03O-AAT INDICATOR SYMBOLS ON THE INSTRUMENT CLUSTER Door Ajar Warning Light and Chime SRS (Airbag) Service Reminder Indicator (SRI) Low Fuel Level Warning Light Turn Signal Indicator Lights Seat Belt Reminder Light and Chime Malfunction Indicator Light High Beam Indicator Light ABS Service Reminder Indicator (If installed) Front Fog Indicator Light (If installed)
Page 12: Table Of Contents
FEATURES OF YOUR HYUNDAI Fuel Recommendations ..........1-2 Breaking in Your New Hyundai ........1-3 Keys ................1-3 Door Locks ..............1-4 Theft-Alarm System ............1-8 Power Windows ............1-11 Seats ................1-12 Seat Belts..............1-19 Child Restraint System ..........1-26 Advanced Supplemental Restraint (AIRBAG) System (SRS) ............
Page 13: Features Of Your Hyundai
Gasohol (a mixture of 90% unleaded gasoline Fuels containing methanol (wood alcohol) should and 10% ethanol or grain alcohol) may be used not be used in your Hyundai. This type of fuel UNLEADED in your Hyundai. However, if your engine devel-...
Page 14: Breaking In Your New Hyundai
2,000 Operation in Foreign Countries rpm and 4,000 rpm. o Use moderate acceleration. Don't start If you are going to drive your Hyundai in another B030A01HR quickly or depress the accelerator pedal country, be sure to: For greater convenience, the same key oper- fully.
Page 15: Door Locks
A code number is stamped on the number plate B030C01E-1 o In case of accident, the door is unlocked that came with the keys to your Hyundai. This Whenever either front door is opened, the igni- automatically (If installed). key number plate should not be left with the keys tion switch will be illuminated for your conve- but kept in a safe place, not in the vehicle.
Page 16 FEATURES OF YOUR HYUNDAI NOTE: B040B01O-AAT B040C02O-AAT Locking, unlocking front doors with a Locking From the Outside o When pushing the lock switch of the (Driver's side-without key) driver's door to the "LOCK" position, only the driver's door can be locked.
Page 17 FEATURES OF YOUR HYUNDAI NOTE: B040D01O-AAT B045C02O-AAT Locking From the Inside Locking From the Outside o When pushing the lock switch of the (Driver's side) (Passenger's side-without key) passenger's door to the "LOCK" posi- tion, all doors can be locked.
Page 18 UNLOCK HSM170-1 B040G01O-A The central door locking switch is located on the Your Hyundai is equipped with left and right side HSM362-D "child-protector" rear door locks. When the lock driver's arm rest. It is operated by depressing To lock the door from the inside, simply close the mechanism is engaged, the rear door cannot be either the "LOCK"...
Page 19: Theft-Alarm System
FEATURES OF YOUR HYUNDAI THEFT-ALARM SYSTEM B070F01O-AAT B070A01A-AAT B075B01O-AAT KEYLESS ENTRY SYSTEM (If installed) (If installed) Armed Stage Locking doors This system is designed to provide protection from unauthorized entry into the car. This sys- 1. Close all doors. tem is operated in three stages : the first is the 2.
Page 20 FEATURES OF YOUR HYUNDAI NOTE: B075C01JM-AAT B075D01JM-AAT Alarm Stage Disarmed Stage o If any door, the tail gate or engine hood remains open, the system will not be The alarm will be activated if any of the following The system will be disarmed by using the armed.
Page 21 FEATURES OF YOUR HYUNDAI B075E01O-AAT B070E02HP-AAT Case Panic Warning Replacing the battery When the transmitter's battery begins to get weak, it may take several pushes on the button to lock or unlock the doors, and the LED will not light. Replace the battery as soon as possible.
Page 22: Power Windows
FEATURES OF YOUR HYUNDAI POWER WINDOWS B060A03Y-AAT Close Close Open Open HSM050 HSM441-A HSM048 In order to prevent operation of the passenger The power windows operate when the ignition front and rear windows, a window lock switch(2) key is in the "ON" position. The main switches is provided on the armrest of the driver's door.
Page 23: Seats
FEATURES OF YOUR HYUNDAI SEATS B080A01A-AAT B080B02A-AAT B080C02A-AAT ADJUSTABLE FRONT SEATS Adjusting Seat Forward and Rearward Adjusting Seatback Angle WARNING: Never attempt to adjust the seat while the vehicle is moving. This could result in loss of control or an accident which may cause death, serious injury, or property damage.
Page 24 FEATURES OF YOUR HYUNDAI B080D02JM-AAT Adjustable Headrests WARNING: WARNING: To minimize risk of severe injury in the event of a collision or a sudden stop, both the driver and passenger seatbacks should always be in an upright position while the vehicle is in motion.
Page 25 FEATURES OF YOUR HYUNDAI B080E01O-AAT B080F01A-AAT B090A01Y-AAT Lumbar Support Control Seat Cushion Height Adjustment POWER DRIVER'S SEAT (If installed) (Driver's seat only) (If installed) (Driver's Seat Only) (If Installed) The driver's seat can be adjusted appropriately by using the control knobs on the left side of the seat.
Page 26 FEATURES OF YOUR HYUNDAI B090B01Y-AAT B090C01Y-AAT B090D02Y-AAT Adjusting Seat Forward and Rearward Seat Cushion Height Adjustment Adjusting Seatback Angle B090D01O B090B01O B090C01O Pull the control knob forward or backward to Move the front portion of the control knob up or...
Page 27 FEATURES OF YOUR HYUNDAI B080G01FC-AAT B100A01JM-AAT UNDER TRAY (If installed) SEAT WARMER (If Installed) WARNING: To minimize the risk of personal injury in the event of a collision or a sudden stop, both the driver's and passenger's seatback should remain in an upright position while the car is in motion.
Page 28 FEATURES OF YOUR HYUNDAI B085A01O-BAT B085B02O-AAT REAR SEAT Folding Rear Seatback and Seat Adjusting Seatback Angle Cushion WARNING: It is recommended that the seat heater not For convenience, the seatbacks and seat cush- be used when elderly people or people who ions may be folded down and up.
Page 29 FEATURES OF YOUR HYUNDAI Hanger WARNING: Buckle clips o When folding down or returning the seatback, always hold the seatback. Otherwise, the seatback could move suddenly and result in unexpected in- jury. Securing loop o The purpose of the fold-up rear seat...
Page 30: Seat Belts
FEATURES OF YOUR HYUNDAI SEAT BELTS B150A01S-AAT SEAT BELT PRECAUTIONS WARNING: o When you return the rear seatback to its B140A01B-AAT REAR SEAT WARNING upright position after being folded down, WARNING: be careful not to damage the seatbelt All occupants of the vehicle must wear their webbing or buckle.
Page 31 FEATURES OF YOUR HYUNDAI B150C02A-AAT B150E01A-AAT Larger Children Injured Person WARNING: Children who are too large for child restraint A seat belt should be used when an injured Every person in your vehicle needs to be systems should always occupy the rear seat person is being transported.
Page 32 For proper protection when the vehicle is in tions concerning seat belt operation should be B160B01A-AAT motion, have the seatback upright. directed to your Hyundai Dealer. Periodic Inspection Then sit back in the seat and wear your seat belt properly. See page 1-22.
Page 33 FEATURES OF YOUR HYUNDAI B170A04Y-AAT Release the button to lock the anchor into To fasten your seat belt, pull it out of the retractor HEIGHT ADJUSTABLE FRONT SEAT position. Try sliding the height adjuster to make and insert the metal tab into the buckle. There sure that it has locked into the position.
Page 34 Although a combination retractor is also installed to the emergency locking operation mode, hardware is damaged, replace it. in the front passenger seat position, Hyundai allow the unbuckled seat belt to fully re- strongly recommends that children always be tract.
Page 35 FEATURES OF YOUR HYUNDAI B200A01A-AAT B210A01A-AAT B220D02O-AAT Adjusting Your Seat Belt To Release the Seat Belt SEAT BELTS - Rear Seat Center 3-Point System With Combination Locking Re- tractor B210A01L B200A01L The seat belt is released by pressing the re- lease button in the locking buckle.
Page 36 FEATURES OF YOUR HYUNDAI WARNING: o When using the rear seat center belt, you must lock all metal tabs and buckles. If any metal tab or buckle is not locked, it will increase the chance of injury in the event of collision.
Page 37: Child Restraint System
FEATURES OF YOUR HYUNDAI CHILD RESTRAINT SYSTEM B220C02A-GAT B230A03O-AAT To Release the Seat Belt Children riding in the car should sit in the rear seat and must always be properly restrained to WARNING: minimize the risk of injury in an accident, sudden stop or sudden maneuver.
Page 38 If the seat belt will not properly fit the can become very hot if it is left in a closed child, Hyundai recommends the use of vehicle on a sunny day, even if the out- an approved booster seat in the rear seat side temperature does not feel hot.
Page 39 FEATURES OF YOUR HYUNDAI B230B01E-AAT B230C05O-AAT To install the child restraint seat tether Using a Child Restraint System Installing a Child Restraint Seat with the "Tether Anchorage" System For small children and babies, the use of a child seat or infant seat is required. This child seat or...
Page 40 FEATURES OF YOUR HYUNDAI For vehicles with adjustable headrests, route B230D03E-AAT Rear luggage compartment floor Securing the Child Restraint Seat with the tether strap under the headrest and between the headrest posts, otherwise route the "ISOFIX" system the tether strap over the top of the seatback.
Page 41 FEATURES OF YOUR HYUNDAI Follow the child seat manufacturer's instruc- tions to properly install safety seats with ISOFIX or ISOFIX-compatible attachments. WARNING: ISOFIX Anchor o Do not install a child restraint seat at the Position Indicator Once you have installed the ISOFIX child re-...
Page 42 If the seat belt does not operate as de- scribed, have the system checked imme- B230G01L diately by your authorized Hyundai dealer. To install a child restraint system in the outboard B235G01O-A rear seats, extend the shoulder/lap belt entirely Use the center seat belt for the rear seat to from its retractor until a "click"...
Page 43 WARNING: Your Hyundai vehicle is equipped with driver's inside the pre-tensioner will release some of the To obtain maximum benefit from a pre- and front passenger's pre-tensioner seat belts.
Page 44 "ON" posi- pre-tensioner seat belts yourself. This tion, and then it should turn off. must be done by an authorized Hyundai o If the pre-tensioner seat belt is not work- dealer. ing properly, this warning light will illu-...
Page 45: Advanced Supplemental Restraint (Airbag) System (Srs)
ADVANCED SUPPLEMENTAL RESTRAINT (AIRBAG) SYSTEM (SRS) B240A01O-AAT The SRS uses sensors to gather information Additionally, your Hyundai is equipped with an about the driver's and front passenger's seat occupant classification system in the front Driver's Airbag position, the driver's and front passenger's seat passenger's seat.
Page 46 If you are considering modification of airbags will only deploy once. Seat belts your vehicle due to a disability, please must be worn at all times. contact the Hyundai Customer Assis- tance Center at 1-800-633-5151. smhma-1a.p65 7/29/04, 1:53 PM...
Page 47 If the airbags deploy, they must be re- ing the driver should always wear their placed by an authorized Hyundai dealer. o Do not tamper with or disconnect SRS seat belts whether or not an airbag is...
Page 48 FEATURES OF YOUR HYUNDAI The SRSCM continually monitors all elements while the ignition is "ON" to determine if a frontal or near-frontal impact is severe enough to require airbag deployment or pre-tensioner seat belt deployment. The SRS service reminder indicator (SRI) on...
Page 49 "ON" position, or after the engine is started, comes on while driving, the SRS is not working properly. If this occurs, have your vehicle immedi- ately inspected by your Hyundai dealer. o Before you replace a fuse or disconnect B240B01O B240B05L a battery terminal, turn the ignition key to the "LOCK"...
Page 50 FEATURES OF YOUR HYUNDAI B990A01O-AAT the floor), the "PASSENGER AIR BAG OFF" *2) Do not allow children to ride in the front OCCUPANT CLASSIFICATION SYSTEM indicator will be turned off and the front passenger seat. When a larger child who...
Page 51 FEATURES OF YOUR HYUNDAI Normal position B990A07O B990A03O B990A01O o Excessively recline the front passenger When an adult is seated in the front passenger - Lean on on the center console. seatback. seat, if the "PASSENGER AIR BAG OFF" indi- - Sit on one side of the front passenger seat.
Page 52 "ON" abling the passenger airbags. position, or if it illuminates while the vehicle is being driven, have an authorized Hyundai dealer inspect the occupant classification system and the SRS airbag system as soon as possible.
Page 53 This condition can result in an B990B02Y adult potentially being misclassified and Your Hyundai is equipped with a side impact WARNING: illumination of the "PASSENGER AIR airbag in each front seat. The purpose of the o The side impact airbag is supplemental BAG OFF"...
Page 54 Hyundai technician. by an airbag deployment in case of an o Do not place any objects (an umbrella, Improper handling of the airbag system may accident.
Page 55 Doing so could result in injury o Do not replace the bumper or the bumper reduce the protection provided by the seat guard with the one other than the Hyundai due to accidental deployment of the belt and increase the chance of serious genuine parts.
Page 56 FEATURES OF YOUR HYUNDAI o Keep occupants away from the airbag covers. All occupants should sit upright, fully back in their seats with their seat belts on and WARNING: their feet on the floor. If occupants are too o Sitting improperly or out of position can...
Page 57: Instrument Cluster And Indicator Lights
FEATURES OF YOUR HYUNDAI INSTRUMENT CLUSTER AND INDICATOR LIGHTS B260A01O-AAT B260A01O-A smhma-1a.p65 7/29/04, 1:53 PM...
Page 58 FEATURES OF YOUR HYUNDAI 1. 4WD System Warning Light (If installed) 14.Charging System Warning Light 2. ABS Service Reminder Indicator (If installed) 15.Door Ajar Warning Light 3. Tachometer 16.Parking Brake/Low Brake Fluid Level Warning Light 4. Turn Signal Indicator Lights 17.Seat Belt Warning Light...
Page 59: Warning And Indicator Lights
If the arrow comes on but does not blink, the front fog lamp switches are on. engine should be checked by a Hyundai blinks more rapidly than normal, or does not dealer before the car is driven again.
Page 60 If the light stays on fully driven to a Hyundai dealer for inspection. WARNING: while the engine is running, there is a malfunc-...
Page 61 "ON" position, the key is in the "LOCK" position and a door take your car to your nearest authorized Hyundai is open. The warning chime only sounds dealer and have the system checked.
Page 62 See indicator stays on, take your car to your autho- again or the cruise control "CANCEL" switch is your Hyundai dealer immediately. rized Hyundai dealer and have the system pushed. checked. See section 2 for more information about the TCS.
Page 63 If you suspect cooling system trouble, have your cool- ing system checked by a Hyundai dealer as soon as possible. B280A01O The needle on the gauge indicates the approxi- B290A01O mate fuel level in the fuel tank.
Page 64 (Without Trip Computer) B330A01O B300A01O-A The tachometer registers the speed of your Your Hyundai's speedometer is calibrated in HSM2079 engine in revolutions per minute (rpm). miles per hour (on the outer scale) and kilome- Pushing in the trip switch for less than 1 second ters per hour (on the inner scale).
Page 65 FEATURES OF YOUR HYUNDAI NOTE: B310C01O-AAT ODOMETER/TRIP ODOMETER Federal law forbids alteration of the odom- eter of any vehicle with the intent to change (With Trip Computer) the number of the odometer. The alteration may void your warranty coverage. Trip Odometer 2, 3.
Page 66: Trip Computer
FEATURES OF YOUR HYUNDAI TRIP COMPUTER B400B01O-GAT 2. Trip Odometer Trip Computer Switch (If installed) o This mode indicates the drive distance trav- o The trip computer switch is used to zero the elled since the last drive time reset.
Page 67 FEATURES OF YOUR HYUNDAI NOTE: 1. Distance to Empty 2. Average Fuel Consumption o If the distance to empty is less than 30 Distance to empty symbol Average fuel consumption symbol miles (50km),the symbol "RANGE" will blink and the distance to empty "----"...
Page 68: Multi-Function Light Switch
This mode indicates the average speed from o This mode indicates the total distance trav- out fuse or bulb or see your Hyundai dealer. elled since the last tripmeter reset. Total the starting of the vehicle to the ignition key distance is also reset to zero if the battery is "OFF".
Page 69 FEATURES OF YOUR HYUNDAI B340B01A-AAT B340C03A-AAT B340D01A-AAT Lane Change Signal Headlight Switch High-beam Switch B340B01O B340C01O B340D01O To indicate a lane change, move the lever up or To operate the headlights, turn the barrel on the To turn on the headlight high beams, push the down to a point where it begins flashing.
Page 70 FEATURES OF YOUR HYUNDAI B340E01A-AAT B340G01LZ-GAT Headlight Flasher Auto Light (If installed) Auto light sensor HSM2095 NOTE: HSM2094 B340E01O o Never place anything over sensor lo- To flash the headlights, pull the switch lever To operate the automatic light feature, turn the cated on the instrument panel, this will barrel on the end of the multi-function switch.
Page 71: Windshield Wiper/Washer Switch
FEATURES OF YOUR HYUNDAI WINDSHIELD WIPER AND WASHER SWITCH B350A01A-AAT B350B01O-GAT Mist Wiper Operation Windshield Washer Operation B350A01O-A B350B02O-A The windshield wiper switch has three posi- B350B01O-A If a single wipe is desired in mist, push the tions: To use the windshield washer, pull the wiper/ windshield wiper and washer control lever up- washer lever toward the steering wheel.
Page 72 FEATURES OF YOUR HYUNDAI NOTE: B350C01O-AAT B390A01JM-AAT Adjustable Intermittent Wiper Operation Rear Window Wiper And Washer Do not operate the washer continuously for (If installed) more than 15 seconds or when the fluid reservoir is empty; this could damage the system.
Page 73 FEATURES OF YOUR HYUNDAI FRONT FOG LIGHT SWITCH HAZARD WARNING SYSTEM REAR WINDOW DEFROSTER SWITCH B360A04A-AAT B370A01A-AAT B380A01HP-AAT (If installed) B370A01O-A B380A01O-A The hazard warning system should be used The rear window defroster switch also acti- B360A01O-A whenever you find it necessary to stop the car vates the outside rear view mirror heaters.
Page 74 FEATURES OF YOUR HYUNDAI DIGITAL CLOCK ELECTRIC AZIMUTH COMPASS B400A01A-AAT B990C01O-AAT (With sunroof) (If installed) CAUTION: Do not clean the inner side of the rear window glass with an abrasive type of glass cleaner or use a scraper to remove foreign...
Page 75 FEATURES OF YOUR HYUNDAI 3. When the rotation is finished, the azimuth Correcting Azimuth Indicator The azimuth compass indicator correc- compass indicator will stop blinking and the tion will be cancelled: It is needed to correct the error between a error correction is completed.
Page 76 FEATURES OF YOUR HYUNDAI INSTRUMENT PANEL LIGHT CONTROL (RHEOSTAT) For the correct terrestrial deviation angle B410A01A-AAT The Counter Line Map for Terrestrial value for your location, refer to the contour Deviation Angle Correction line map included. If your place is located in between the terres-...
Page 77 Do not hold the cigarette lighter pressed in. This can damage the heating element and create a fire hazard. If it is necessary to replace the cigarette lighter, use only a genuine Hyundai replacement or its approved equivalent. smhma-1a.p65 7/29/04, 1:54 PM...
Page 78 FEATURES OF YOUR HYUNDAI DRINK HOLDER ASHTRAY B430A01O-AAT B440A01O-AAT B450A01JM-AAT Front Ashtray Rear Ashtray Front Drink Holder HSM2165 HSM2164 B450A01O The front ashtray may be opened by pulling it out The rear ashtray may be opened by pulling it out The front drink holder is located on the main by its grip.
Page 79 FEATURES OF YOUR HYUNDAI B450B02O-AAT B450B01JM-AAT Rear Drink Holder Rear Drink Holder CAUTION: Place the drink holder in its closed position when not in use. WARNING: Do not place objects other than cups or cans in the drink holder. The objects can be...
Page 80: Sunroof
B460A01O with the ignition key in the "ON" position. The o Periodically remove any dirt that may Your HYUNDAI is equipped with a sliding sun- sunroof is moved to its two-third open position have accumulated on the guide rails. shade which you can manually adjust to let in by pushing the "...
Page 81 FEATURES OF YOUR HYUNDAI B460C01O-AAT B460D01O-GAT Tilting the Sunroof Manual Operation of Sunroof If the sunroof does not electrically operate: B460D02O 2. Turn the hexagonal bolts counterclockwise HSM2023 to remove the overhead console with a The sunroof is moved to its fully tilt up position socket wrench.
Page 82 FEATURES OF YOUR HYUNDAI INTERIOR LIGHT B480B01JM-AAT B490A03Y-AAT Map Light Interior Light With Sunroof Without Sunroof B460D03O 3. Insert the hexagonal head wrench provided HSM2112 with the vehicle into the socket. This wrench B490A01O can be found in the vehicle's glove box.
Page 83 FEATURES OF YOUR HYUNDAI SPECTACLE CASE GLOVE BOX B491A03O-GAT B500A01S-AAT o ON In the "ON" position, the light stays on at all With Sunroof Without Sunroof times. LOCK UNLOCK CAUTION Do not leave this button pressed for an extended period of time when the vehicle is not running.
Page 84 FEATURES OF YOUR HYUNDAI OUTSIDE REARVIEW MIRROR CENTER CONSOLE BOX B500B01O-AAT B505A01O-GAT B510A01A-AAT Illuminated Glove Box Manual Type Opening the glove box will automatically turn on the light when the multi-function switch is turned to the first/second position. HSM2167 The center console box is used for storing B510A01O cassette tape or small articles.
Page 85 FEATURES OF YOUR HYUNDAI B510B01Y-AAT To adjust the position of either mirror: Electric Type (If installed) 1. Move the selecting switch to the right or left CAUTION: to activate the adjustable mechanism for the If the mirror control is jammed with ice, do corresponding door mirror.
Page 86 FEATURES OF YOUR HYUNDAI B510D01HP-AAT B510C02A-AAT OUTSIDE REARVIEW MIRROR HEATER FOLDING THE OUTSIDE REARVIEW (If installed) MIRRORS CAUTION: o Do not operate the switch continuously for an unnecessary length of time. o Scraping ice from the mirror face could cause permanent damage. To remove any ice, use a sponge, soft cloth or approved de-icer.
Page 87: Mirror
Homelink buttons B520B01O B520A01O B520C01L Your Hyundai is equipped with a day/night inside Your new vehicle may be equipped with an The electric type day/night inside rearview mir- rearview mirror. The "night" position is selected automatic night vision mirror. During nighttime...
Page 88 FEATURES OF YOUR HYUNDAI NOTE: Automatic-Dimming Function HOMELINK PROGRAMMING If programming a garage door opener or gate, it is advised to unplug the device during the "cycling" process to prevent CAUTION: possible motor burnout. o Make sure people and/or objects are out...
Page 89 FEATURES OF YOUR HYUNDAI 1. When programming the buttons for the first 3. If the garage door opener or other device you 3. Return to the vehicle and firmly press and time, press and hold the two outside wish to program is rolling-code equipped, release the programmed HomeLink button.
Page 90 FEATURES OF YOUR HYUNDAI Erasing Programmed Buttons Reprogramming a Single HomeLink Gate Operator Programming & Cana- Button dian Programming To program a device to HomeLink using a During programming, your handheld transmit- Flashing HomeLink button previously trained, follow these ter may automatically stop transmitting.
Page 91 FEATURES OF YOUR HYUNDAI PARKING BRAKE TAIL GATE B530A01A-AAT B540A01FC-AAT WARNING: The tail gate should always be kept com- pletely closed while the vehicle is in motion. If it is left open or ajar, poisonous exhaust gases may enter the car resulting in serious illness or death to the occupants.
Page 92 FEATURES OF YOUR HYUNDAI LUGGAGE COMPARTMENT B540B02O-AAT B540C01HP-GAT B640A01S-AAT Tail gate Window LUGGAGE COMPARTMENT LIGHT CARGO SECURITY SCREEN (If installed) HSM2113 HSM2012 o When you push the tail gate window release Luggage compartment light has a 3-position B640A01O button to open the tail gate window, it will switch.
Page 93 FEATURES OF YOUR HYUNDAI B540D02O-AAT LUGGAGE NET (If installed) CAUTION: To prevent damage to the goods or the B650A01S-AAT Stowage Precautions vehicle, care should be taken when carrying fragile or bulky objects in the luggage com- 1. Do not place objects on the cargo security partment.
Page 94 HSM2173 B550A01O you are driving, check frequently to make If your Hyundai has a roof rack, you can load In addition to the lower-mounted rear stoplights sure the luggage carrier and cargo are things on top of your vehicle. Crossrails and on either side of the car, the high mounted rear still securely fastened.
Page 95 Do the filler area. If you need to replace the not pry on the lid. If necessary, spray around filler cap, use a genuine Hyundai re- WARNING: the lid with an approved de-icer fluid (do placement part.
Page 96: Hood Release
FEATURES OF YOUR HYUNDAI HOOD RELEASE B570A01L-GAT WARNING: WARNING: o If you open the fuel filler cap during high o When using a portable fuel container be ambient temperatures, a slight "pres- sure to place the container on the ground sure sound"...
Page 97 Ticket holder Vanity mirror B570A01JM-A B580A01O Your Hyundai is equipped with sun visors to give When using a floor mat on the front floor carpet, the driver and front passenger either frontal or B570A03O make sure it attaches to the floor mat anchor in sideward shade.
Page 98 FEATURES OF YOUR HYUNDAI STEERING WHEEL TILT LEVER B580C01JM-AAT B600A02Y-AAT SUN VISOR EXTENDER WARNING: Do not place the sun visor in such a manner that it obscures visibility of the roadway, traffic or other objects. B580B01O-AAT Illuminated Vanity Mirror (If installed)
Page 99 FEATURES OF YOUR HYUNDAI FRONT DOOR EDGE WARNING HORN REAR SEAT ARM REST LIGHT B620A01S-AAT B610A01L-GAT B611A01Y-AAT B610A01O HSM2049 B620A01O A red light comes on when the front door is Press the pad on the steering wheel to sound the This arm rest is located in the center of the rear opened.
Page 100: Cruise Control
FEATURES OF YOUR HYUNDAI CRUISE CONTROL B660A01S-AAT 1. Push the cruise control ON´OFF button. 5. To momently increase speed, temporarily (If installed) The "CRUISE" indicator light in the instru- depress the accelerator pedal enough for ment cluster will illuminate. This turns the the vehicle to exceed the preset speed.
Page 101 FEATURES OF YOUR HYUNDAI B660C03O-AAT B660D01O-AAT B660F04O-AAT To cancel the cruise speed To Resume the Preset Speed To Reset at a Slower Speed B660C01O B660B01O B660D01O The vehicle will automatically resume the speed To disengage the cruise control system, push 1.
Page 102 FEATURES OF YOUR HYUNDAI WARNING: o Keep the main switch off when not using the cruise control. o Use the cruise control system only when traveling on open highways in good weather. o Do not use the cruise control when it...
Page 103: Heating And Cooling Control
FEATURES OF YOUR HYUNDAI HEATING AND COOLING CONTROL B710A01O-GAT B710B02O-AAT (If installed) Center Ventilator The center ventilators are located in the middle of the instrument panel. To change the direction of the air flow, move the knob in the center of the vent up-and-down and side-to-side.
Page 104 FEATURES OF YOUR HYUNDAI HEATING AND VENTILATION B670A03O-AAT B670B02O-AAT B670C02O-AAT (If installed) Fan Speed Control (Blower Control) Air Intake Control Switch B690A01O-1 B670B01O-1 B670C02O There are three controls and two switches for This is used to select the blower fan speed.
Page 105 FEATURES OF YOUR HYUNDAI With the " " mode selected, air enters the B670D04O-AAT Air Flow Control vehicle from outside and is heated or cooled according to the other functions selected. With the " " mode selected, air from within...
Page 106 FEATURES OF YOUR HYUNDAI HSM2123 HSM2125 HSM2124 Bi-Level Floor-Defrost Level Floor-Level Air is discharged through the face vents and the Air is discharged through the windshield de- Air is discharged through the floor vents, wind- floor vents. This makes it possible to have...
Page 107 FEATURES OF YOUR HYUNDAI NOTE: light does not turn on. The A/C will not off until the air flow control is set to the another o The air intake control switch will change mode except the floor-defrost mode and to "...
Page 108 FEATURES OF YOUR HYUNDAI HEATING CONTROLS B670E02A-AAT B690A01O-AAT Temperature Control B670D07O Cool Warm B690A01O-1 For normal heating operation, set the air flow B670E01O Off-Level control to the floor ( ) position. (The "Fresh" This control is used to adjust the degree of mode will be activated.)
Page 109 B740A01S-AAT (If installed) Air Conditioning Switch B700A01O-1 B710A01O-1 Your Hyundai is equipped with bi-level heating To operate the ventilation system: controls. This makes it possible to have cooler B740A01O air from the dashboard vents and warmer air o Set the air intake control switch to the fresh The air conditioning is turned on or off by from the floor outlets at the same time.
Page 110 FEATURES OF YOUR HYUNDAI B740B03O-AAT o Set the temperature control to "Cool". ("Cool" B740C02O-AAT Air Conditioning Operation De-Humidified Heating provides maximum cooling. The tempera- ture may be moderated by moving the con- Cooling trol toward "Warm".) o Adjust the fan control to the desired speed.
Page 111 FEATURES OF YOUR HYUNDAI B730A01L-AAT Operation Tips o To keep dust or unpleasant fumes from entering the car through the ventilation sys- tem, temporarily set the air intake control switch to the position. Be sure to return the control switch to position when the irritation has passed to keep fresh air in the vehicle.
Page 112 FEATURES OF YOUR HYUNDAI B720A02E-AAT DEFROSTING/DEFOGGING Manual A/C Full automatic A/C Manual A/C Full automatic A/C B720A02O-1 B720B02O-1 Use the heating/ventilation system to defrost or defog the To remove frost or exterior fog on the windshield; windshield: o Set the air flow control to the defrost ( ) position.
Page 113 AUTOMATIC HEATING AND COOLING CONTROL SYSTEM B970A01Y-AAT B970B01O-AAT (If installed) Heating and Cooling Controls Your Hyundai is equipped with an automatic heating and cooling control system controlled by simply setting the desired temperature. B970B01O 1. Temperature Control Button 6. OFF Switch 2.
Page 114 FEATURES OF YOUR HYUNDAI NOTE: B970C01O-AAT Automatic Operation o If the battery has been discharged or disconnected, the temperature mode will reset to Fahrenheit degree. This is a normal condition and you can adjust the temperature mode from Fahr- enheit to Centigrade as follows;...
Page 115 FEATURES OF YOUR HYUNDAI B995A01O-GAT B980B01Y-AAT B670C02S-AAT AMBIENT TEMPERATURE SWITCH Fan Speed Control Air Intake Control Switch B995A01O B980B01O B670C01O Pressing the "AMB" button displays the ambient The fan speed can be set to the desired speed This is used to select fresh outside air or temperature on display window.
Page 116 FEATURES OF YOUR HYUNDAI With the "Fresh" mode selected, air enters the B980D01Y-AAT B980E01O-AAT Heating and Cooling System Off Air Flow Control vehicle from the outside and is heated or cooled according to the function selected. With the "Recirculation" mode selected, air from...
Page 117 FEATURES OF YOUR HYUNDAI HSM2124 HSM2123 HSM2122 Bi-Level Floor-Level Face-Level When selecting the "Face-Level", the indicator When selecting the "Bi-Level", the indicator light When selecting the "Floor-Level", the indicator light will come on, causing air to be discharged will come on and the air will be discharged light will come on and the air will be discharged through the face level vents.
Page 118 FEATURES OF YOUR HYUNDAI B980F02O-AAT B740D01Y-AAT Defrost Switch Operation Tips o If the interior of the car is hot when you first get in, open the windows for a few minutes to expel the hot air. o When you are using the air conditioning system, keep all windows closed to keep hot air out.
Page 119: Stereo Sound System
FEATURES OF YOUR HYUNDAI STEREO SOUND SYSTEM B750A02A-AAT AM reception FM radio station How Car Audio Works Ionosphere FM reception Mountains Unobstructed Ionosphere area Buildings Iron bridges Obstructed area B750A02L B750A03L AM broadcasts can be received at greater FM broadcasts are transmitted at high frequen- distances than FM broadcasts.
Page 120 FEATURES OF YOUR HYUNDAI B750B03Y-AAT Using a cellular phone or a two-way radio When a cellular phone is used inside the vehicle, noise may be produced from the audio equip- ment. This does not mean that something is wrong with the audio equipment. In such a case, use the cellular phone at a place as far as possible from the audio equipment.
Page 121: Audio System
FEATURES OF YOUR HYUNDAI AUDIO SYSTEM H260A01O-AAT STEREO RADIO OPERATION (H260) (If installed) 3. BASS/TREBLE Control Knob 4. SCAN Button 6. BAND Selector 7. PRESET Button 5. TUNE/SEEK Select Button 1. POWER ON-OFF/VOLUME/BALANCE Control Knob 2. FADER Control Knob H260A01O smhma-1b.p65...
Page 122 FEATURES OF YOUR HYUNDAI H260B04O-AAT 3. BASS Control Knob SEEK Operation 1. POWER ON-OFF Control Knob (Automatic Channel Selection) Press to pop the knob out and turn to the left or The radio unit may be operated when the ignition right for the desired bass tone.
Page 123 FEATURES OF YOUR HYUNDAI HOW TO PRESET STATIONS Six AM and twelve FM stations may be pro- CAUTION: grammed into the memory of the radio. Then, by o Do not place beverages close to the simply pressing the band select button and/or audio system.
Page 124 FEATURES OF YOUR HYUNDAI H260B01O-AAT COMPACT DISC PLAYER OPERATION (H260) (If installed) 4. SCAN Button 1. Playing CD 3. TRACK UP/DOWN 6. EJECT Button 2. FF/REW Button 5. REPEAT Button H260A01O smhma-1b.p65 7/28/04, 5:10 PM...
Page 125 FEATURES OF YOUR HYUNDAI NOTE: B260D04O-AAT 4. SCAN Button 1. Playing CD o If the CD does not operate properly or if o Press the SCAN button to playback the first the ER2 fault code is displayed, use one o Insert the CD with the label facing upward.
Page 126 FEATURES OF YOUR HYUNDAI o This equipment is designed to be used only in a 12 volt DC battery system with negative ground. CAUTION: o This unit is made of precision parts. Do o Do not insert warped or poor quality...
Page 127 AUDIO FAULT CODE If you see any error indication in the display while using the system CD mode, find the cause in the chart below. If you cannot clear the error indication, take the car to your Hyundai dealer. INDICATION...
Page 128 FEATURES OF YOUR HYUNDAI D285A01O-AAT STEREO RADIO OPERATION (D-285) (If installed) 6. AUDIO Knob (Bass/Treble/Balance/Fade) 1. POWER ON•OFF, VOLUME Control Knob 5. PRESET STATION Select Button 4. SEEK/SCAN Button 3. RADIO STATION Control Knob 7. AUTO EQUALIZER 2. BAND Select Button HSM324 smhma-1b.p65...
Page 129 FEATURES OF YOUR HYUNDAI D285B02O-AAT 5. Press and hold one of the six numbered SCAN 1. POWER ON•OFF Control Knob pushbuttons. The radio will produce one Press and hold one of the arrows for more than beep. Whenever you press that numbered Press this knob to turn the system on and off.
Page 130 FEATURES OF YOUR HYUNDAI Adjusting the Speakers (Balance/Fade) 7. AUTO EQUALIZER To adjust the balance between the right and left This feature allows you to choose bass and CAUTION: speakers, push and release the AUDIO knob treble equalization settings designed for coun- o Do not place beverages close to the until BAL appears on the display.
Page 131 FEATURES OF YOUR HYUNDAI D285C01O-AAT CASSETTE TAPE PLAYER OPERATION (D-285) (If installed) 2. REVERSE Button 3. FORWARD Button 5. DOLBY Button 4. SIDE Button 1. SEEK Button 8. TAPE EJECT Button 7. TAPE/CD Select Button 6. BAND Select Button HSM324 smhma-1b.p65...
Page 132 FEATURES OF YOUR HYUNDAI D285D02O-AAT SEEK 3. FORWARD Button Playing a Cassette Tape Press this pushbutton to go to the previous Press this pushbutton to advance quickly to Your tape player is built to work best with tapes selection on the tape if the selection has been another part of the tape.
Page 133 FEATURES OF YOUR HYUNDAI o The tape is broken. Try a new tape. Your tape player should be cleaned regularly 7. TAPE/CD Select Button o The tape is wrapped around the tape head. after every 59 hours of use. Your radio may Press this button to play a tape when listening Attempt to get the cassette out.
Page 134 FEATURES OF YOUR HYUNDAI 3. Press and hold the TAPE/CD select button for five seconds. READY will appear on the display and a cassette symbol will flash for CAUTION: five second. o Do not insert anything like coins into the 4.
Page 135 FEATURES OF YOUR HYUNDAI D285E01O-AAT COMPACT DISC PLAYER OPERATION (D-285) (If installed) 2. REVERSE Button 4. RANDOM Button 3. FORWARD Button 7. CD EJECT Button 1. SEEK/SCAN Button 6. TAPE/CD Select Button 5. BAND Select Button HSM324 smhma-1b.p65 7/28/04, 5:10 PM...
Page 136 FEATURES OF YOUR HYUNDAI D285F02O-AAT SCAN 4. RANDOM Button Playing a Compact Disc Press and hold either SEEK SCAN arrow for Press this pushbutton to hear the tracks in Insert a disc partway into the slot. Label side up. more than two seconds until SCAN appears on random, rather than sequential, order.
Page 137 FEATURES OF YOUR HYUNDAI To disable the feature, use the following steps: 8. Care of Your Compact Discs Handle disc careful. Store them in their original 1. Turn the radio off. CAUTION: cases or other protective cases away from 2. Press and hold the TAPE CD Button. The o Do not insert warped or poor quality direct sunlight and dust.
Page 138 FEATURES OF YOUR HYUNDAI D295A01O-AAT STEREO RADIO OPERATION (D-295) (If installed) 1. POWER ON•OFF, VOLUME Control Knob 6. AUDIO Knob (BASS/MID/TREB) 4. SEEK/SCAN Button 3. RADIO STATION Control Knob 7. AUTO EQUALIZER 5. PRESET STATION Select Button 2. BAND Select Button HSM325 smhma-1b.p65...
Page 139 FEATURES OF YOUR HYUNDAI D295B02O-AAT SCAN PRESET SCAN 1. POWER ON•OFF Control Knob Press and hold either SEEK/SCAN arrow for Press and hold either SEEK/SCAN arrow for Press this knob to turn the system on and off. two seconds until SCAN appears on the display more than four seconds, PRESET SCAN will and you hear a beep.
Page 140 FEATURES OF YOUR HYUNDAI To set the balance and fade to the middle 7. AUTO EQUALIZER Button position, select balance or fade and press and Press the AUDIO knob until MID appears on the This feature allows you to choose preset bass, hold the AUDIO knob.
Page 141 FEATURES OF YOUR HYUNDAI D295C01O-AAT COMPACT DISC PLAYER OPERATION (D-295) (If installed) 5. REPEAT Button 11. Song List Mode 6. RANDOM Button 1. LOAD Button 4. FORWARD Button 2. CD EJECT Button 3. REVERSE Button 8. SEEK/SCAN Button 7. AUTO EQUALIZER 9.
Page 142 FEATURES OF YOUR HYUNDAI D295D03O-AAT 3. Once the light stops flashing and turns green. A small bar will appear under the CD number that 1. LOAD Button Load a disc. Insert a disc partway into the is playing, it could be due to one of the following slot, label side up.
Page 143 FEATURES OF YOUR HYUNDAI When the eject button is pressed, the receiver o Press and release the RDM button to play 4. FORWARD Button will eject the disc and REMOVE CD will be the tracks on all of the discs that are loaded, Press and hold this button to advance quickly displayed.
Page 144 FEATURES OF YOUR HYUNDAI To play the song list, press LIST. One beep will SCAN 10. Using Song List Mode be heard and SLIST will appear on the display. Press and hold either SEEK SCAN arrow for The integrated 6-disc CD changer has a feature...
Page 145 FEATURES OF YOUR HYUNDAI CAUTION: o Do not insert warped or poor quality discs into the CD player as damage to the unit may occur. o Do not insert anything like coins into the player slot as damage to the unit may occur.
Page 146 FEATURES OF YOUR HYUNDAI CARE OF DISCS CARE OF CASSETTE TAPES B850A02F-AAT B860A01A-AAT Storage Proper Handling When not in use, place your discs in their individual case and store them in a cool place away from the sun, heat, and dust.
Page 147 FEATURES OF YOUR HYUNDAI o Never leave a cassette inserted in the player o Store cassettes in a cool, dry place with the o The playback head, capstan and pinch roll- when not being played. This could damage open side facing down to prevent dust from ers will develop a coating of tape residue that the tape player unit and the cassette tape.
Page 148: Antenna
FEATURES OF YOUR HYUNDAI ANTENNA B870C01A-GAT B885A01O-AAT MANUAL ANTENNA (If installed) MICRO ANTENNA (If installed) Your car uses the micro antenna to receive both AM and FM broadcast signals. This antenna is folding and removable type. CAUTION: B860A03L NOTE: B870C01O Look at a tape before you insert it.
Page 149 FEATURES OF YOUR HYUNDAI B885B01O 2. Before entering an automatic car wash, remove by turning the antenna counter- clockwise to prevent damage to the mi- cro antenna. To install the antenna, turn the antenna clockwise. smhma-1b.p65 7/28/04, 5:10 PM...
Page 150: Driving Your Hyundai
DRIVING YOUR HYUNDAI Engine Exhaust Can Be Dangerous! ......2-2 Risk of Rollover ............2-3 Before Starting the Engine ..........2-3 Key Positions ..............2-4 Starting ................2-5 Automatic Transaxle ..........2-6, 2-9 Anti-Lock Brake System (ABS) ........2-12 Brake Traction Control System (BTCS) ..... 2-13 Full Traction Control System (FTCS) ......
Page 151: Engine Exhaust Can Be Dangerous
Hyundai dealer. o Do not run the engine in an enclosed area.
Page 152: Risk Of Rollover
1. Look around the vehicle to be sure there are o Sports utility vehicles have higher o The 2WD Santa Fe is not designed for no flat tires, puddles of oil, water or other ground clearance and a narrower track off-road use.
Page 153: Key Positions
To CAUTION: Hyundai for off-road driving, you should remove the key, always confirm that the The engine should not be turned off or the not use these tires for highway driving.
Page 154: Starting
DRIVING YOUR HYUNDAI STARTING NOTE: C070C01A-AAT C050A01A-AAT To remove the ignition key Do not hold the key in the "START" position for more than 15 seconds. o "ON" LOCK When the key is in the "ON" position, the ignition is on and all accessories may be turned on. If the engine is not running, the key should not be left in the "ON"...
Page 155: Automatic Transaxle
HSM3022 The starter should not be operated for more The highly efficient Hyundai automatic transaxle than 15 seconds at a time. Wait 15-30 sec- has four forward speeds and one reverse onds between starting attempts to protect speed.
Page 156 DRIVING YOUR HYUNDAI NOTE: C090C01A-AAT C090F01JM-GAT o R(Reverse): Sports Mode Depress the brake pedal and push the button when shifting. Use for backing up the vehicle. Bring the car to a complete stop before shifting the selector Push the button when shifting.
Page 157 DRIVING YOUR HYUNDAI o To maintain the required levels of ve- C090I02L-GAT hicle performance and safety, the sys- tem may not execute certain gearshifts CAUTION: when the selector lever is operated. CAUTION: o In sports mode, The driver must execute...
Page 158 C090B01A-AAT The function of each position is as fol- HSM3022 lows: The highly efficient Hyundai automatic transaxle has five forward speeds and one reverse speed. o P (Park): The individual speeds are selected automati- HSM3022-1 cally, depending on the position of the speed Use to hold the vehicle in place when parked or selector lever.
Page 159 DRIVING YOUR HYUNDAI C090C01A-AAT C095F01O-GAT o R(Reverse): Sports Mode CAUTION: Use for backing up the vehicle. Bring the car to o In sports mode the driver must execute a complete stop before shifting the selector shifts in accordance with prevailing road lever to "R"...
Page 160 DRIVING YOUR HYUNDAI NOTE: C090H01L-GAT C090I02L-GAT NOTE: o In sports mode, only the five forward o For smooth and safe operation, depress gears can be selected. To select reverse the brake pedal when shifting from "Neu- or park, move the selector lever to the CAUTION: tral"...
Page 161: Anti-Lock Brake System (Abs)
DRIVING YOUR HYUNDAI ANTI-LOCK BRAKE SYSTEM (ABS) C090N03O-AAT C120A02A-AAT Good Driving Practices (If installed) WARNING: o Never move the gear selector lever from "P" The Anti-Lock Brake System (ABS) is designed o Avoid high cornering speeds. or "N" to any other position with the accelera-...
Page 162: Brake Traction Control System (Btcs)
DRIVING YOUR HYUNDAI BRAKE TRACTION CONTROL SYS- TEM (BTCS) C300A02O-AAT (If installed) WARNING: CAUTION: On slippery road surfaces, the traction control ABS will not prevent accidents due to im- When the TCS indicator blinks, SLIP func- system (TCS) limits the drive wheels from proper or dangerous driving maneuvers.
Page 163: Full Traction Control System (Ftcs)
DRIVING YOUR HYUNDAI FULL TRACTION CONTROL SYS- TEM (FTCS) C300B01O-AAT C300D02O-AAT C310A01O-AAT TCS ON Mode Indicator and Warning (If installed) When the TCS is operating, the TCS indicator The TCS indicator should illuminate when the in the instrument cluster will blink.
Page 164 DRIVING YOUR HYUNDAI C310B02O-AAT C310D01JM-AAT SLIP Control TCS ON/OFF Mode Indicators and Warning Limits the drive wheels from spinning exces- When the TCS is operating, the TCS indicator The indicators should illuminate when the igni- sively during starting or while making acceler- in the instrument cluster will blink.
Page 165: Full-Time 4Wd Operation
DRIVING YOUR HYUNDAI FULL-TIME 4WD OPERATION C350A03O-AAT (5) Do not drive the vehicle through water. (i.e. (If installed) streams, rivers, lakes, etc.) (6) The stopping distance of the full-time 4WD WARNING: Engine power can be delivered to all wheels. vehicle differs very little from that of the 2WD...
Page 166 (9)For a speedometer test or inspection/main- 1. The ignition switch is in "ACC" or carrying capacity. If you nevertheless de- tenance (I/M) program of a SANTA FE 4WD "ON". cide to equip your vehicle with any tire/ vehicle, use a four wheel chassis dynamom- 2.
Page 167 DRIVING YOUR HYUNDAI o In rare cases when it's unavoidable that a 4WD vehicle is to be inspected on a 2WD roll tester, strictly follow the proce- WARNING: CAUTION: dures. o Avoid high cornering speeds. o While the full-time 4WD vehicle is being 1.
Page 168: Limited-Slip Differential
See page 9-5 for the recommended oil is no curb or if it is required by other condi- Hyundai dealer for assistance. descriptions. tions to keep the car from rolling, block the wheels.
Page 169: Driving For Economy
Keep your car clean. For maximum service, sary braking. This also reduces brake wear. your Hyundai should be kept clean and free o Drive at a moderate speed. The faster you of corrosive materials. It is especially impor- drive, the more fuel your car uses.
Page 170: Winter Driving
DRIVING YOUR HYUNDAI SMOOTH CORNERING WINTER DRIVING o Remember, your Hyundai does not require C150A01A-AAT C160A01A-AAT extended warm-up. As soon as the engine The more severe weather conditions of winter Avoid braking or gear changing in corners, is running smoothly, you can drive away. In result in greater wear and other problems.
Page 171 If a lock is covered with ice, squirt it with only. If your vehicle is equippied with the in your battery can be checked by your Hyundai an approved de-icing fluid to remove the ice. If 4WD (four wheels drive), be sure to in- dealer or a service station.
Page 172 DRIVING YOUR HYUNDAI HIGHER SPEED MOTORING C160I01L-AAT C160K01A-AAT C170A01A-AAT Don't Let Your Parking Brake Freeze Carry Emergency Equipment Pre-Trip Inspections Under some conditions your parking brake can Depending on the severity of the weather where 1. Tires: freeze in the engaged position. This is most...
Page 173 Ask your chassis. Hyundai dealer for further details before towing. The hitch should be bolted securely to the car and installed by a qualified technician. DO NOT USE A HITCH DESIGNED FOR TEMPORARY...
Page 174 DRIVING YOUR HYUNDAI NOTE: C190E03O-AAT Trailer Weight Limit 1. Never load the trailer with more weight in the back than in the front. About 60% of CAUTION: the trailer load should be in the front half o Never connect a trailer brake system on the trailer and the remaining 40% in directly to the vehicle brake system.
Page 175: Trailer Or Vehicle Towing
DRIVING YOUR HYUNDAI Lbs. (kg) C190F02O-AAT Trailer or Vehicle Towing Tips Maximum Towable Weight Engine WARNING: Trailer Tongue 1. Before towing, check hitch and safety chain o Improperly loading your vehicle and Type A 1700(771) 170(77.1) connections as well as proper operation of 2.4(2WD)
Page 176: Vehicle Load Limit
DRIVING YOUR HYUNDAI VEHICLE LOAD LIMIT 8. If the trailer has electric brakes, start your C190F01JM-AAT Tire and Loading Information Label vehicle and trailer moving, and then apply the trailer brake controller by hand to be sure the CAUTION: brakes are working. This lets you check If overheating should occur when towing, your electrical connection at the same time.
Page 177 DRIVING YOUR HYUNDAI Steps for Determining Correct Load (5)Determine the combined weight of Example 1 Limit luggage and cargo being loaded on (1)Locate the statement "The combined the vehicle. That weight may not weight of occupants and cargo should safely exceed the available cargo...
Page 178 DRIVING YOUR HYUNDAI Refer to your vehicle's tire and loading Example 2 Example 3 information label for specific informa- tion about your vehicle's capacity weight and seating positions. The combined weight of the driver, passengers and cargo should never exceed your vehicle's capacity weight.
Page 179 DRIVING YOUR HYUNDAI C190G01JM-AAT This label also tells you the maximum NOTE: Compliance Label weights that can be supported by the o Overloading your vehicle may front and rear axles, called Gross Axle cause damage. Repairs would not Weight Rating (GAWR). To find out the be covered by your warranty.
Page 180 DRIVING YOUR HYUNDAI WARNING: Items you carry inside your vehicle can strike and injure people in a sudden stop or turn, or in a crash. o Put things in the cargo area of your vehicle. Try to spread the weight evenly.
Page 181: What To Do In An Emergency
WHAT TO DO IN AN EMERGENCY If the Engine will not Start ..........3-2 Jump Starting ..............3-3 If the Engine Overheats ..........3-4 Spare Tire ..............3-5 If You Have a Flat Tire ..........3-6 Changing a Flat Tire ............3-6 If Your Vehicle Must be Towed ........
Page 182: If The Engine Will Not Start
3. Check the fuel line in the engine compart- create a fire hazard. ment. 4. If the engine still does not start, call a Hyundai dealer or seek other qualified assistance. D010D01A-AAT If Engine Stalls While Driving D010B01O 1.
Page 183: Jump Starting
When jump starting, wear pro- positive (+) post or cable of the discharged your Hyundai dealer. tective glasses and be careful not to get battery. acid on yourself, your clothing or on the car.
Page 184: If The Engine Overheats
Do not remove the radiator cap when the be checked as soon as possible by a Hyundai engine running and check to be sure the engine is hot. This can allow coolant to be dealer.
Page 185: Spare Tire
WHAT TO DO IN AN EMERGENCY SPARE TIRE D040A01O-GAT D040B02B-GAT Handling the Spare Tire The following instructions for the FULL SIZE spare tire should be observed: Check inflation pressure as soon as practical after installing the spare tire, and adjust to the specified pressure. The tire pressure should be periodically checked and maintained at the speci- fied pressure while the tire is stored.
Page 186: If You Have A Flat Tire
WHAT TO DO IN AN EMERGENCY IF YOU HAVE A FLAT TIRE CHANGING A FLAT TIRE D050A01L-AAT D060A02O-AAT If a tire goes flat while you are driving: 1. Take your foot off the accelerator pedal and let the car slow down while driving straight ahead.
Page 187 The spare tire is located underneath your vehicle with any tire/wheel com- the car. bination not recommended by Hyundai for off-road driving, you should not use these tires for high- way driving. smhma-3.p65 7/28/04, 5:13 PM...
Page 188 WHAT TO DO IN AN EMERGENCY D060D01A-AAT D060E01A-AAT D060F02E-AAT 3. Loosen Wheel Nuts 4. Put the Jack in Place 5. Raising the Car Wrench bar Wheel nut wrench HSM4018 HFC4022 D060E01O The wheel nuts should be loosened The base of the jack should be placed After inserting a wrench bar into the slightly before raising the car.
Page 189 WHAT TO DO IN AN EMERGENCY Raise the car high enough so that the D060G02Y-AAT 6. Changing Wheels fully inflated spare tire can be installed. To do this, you will need more ground clearance than is required to remove the flat tire. WARNING: Do not get under the car when it is supported by the jack! This is very...
Page 190 WHAT TO DO IN AN EMERGENCY D060H02O-AAT D060I01E-AAT 7. Reinstall Wheel Nuts 8. Lower Vehicle and Tighten Nuts WARNING: If there is, remove it. If there is not good contact on the mounting sur- face between the wheel and hub, the wheel nuts could come loose and cause the loss of a wheel.
Page 191 WHAT TO DO IN AN EMERGENCY Wheel nut tightening torque: it is correct. Always reinstall the valve Steel wheel & aluminium alloy wheel: cap after checking or adjusting tire 65-80 lb.ft (900-1,100 kg.cm) pressure. If the cap is not replaced, air may leak from the tire.
Page 192: If Your Vehicle Must Be Towed
D080B02O-AAT If your vehicle has to be towed, it should be done Towing the 2 Wheel Drive Vehicle by your Hyundai dealer or a commercial tow CAUTION: truck service. This will help assure that your o When towing the vehicle, take care not to vehicle is not damaged in towing.
Page 193 WHAT TO DO IN AN EMERGENCY 1) If the vehicle is being towed with the rear D080B02O-AAT Towing the 4 Wheel Drive Vehicle wheels on the ground, be sure the parking brake is released. CAUTION: NOTE: Before towing, check the level of the auto- matic transaxle fluid.
Page 194: Emergency Towing
WHAT TO DO IN AN EMERGENCY D080D02O-AAT For emergency towing when no commercial EMERGENCY TOWING tow vehicle is available, attach a tow cable, chain or strap to one of the towing hooks under CAUTION: <Front> the front/rear of your car. Be very careful when o The 4WD vehicle should never be towed attempting this procedure when the vehicle is on with the wheels on the ground.
Page 195: If You Lose Your Keys
WHAT TO DO IN AN EMERGENCY IF YOU LOSE YOUR KEYS D120A01A-AAT If you lose your keys, many Hyundai dealers CAUTION: can make you a new key if you have your key If the car is being towed with all four wheels number.
Page 196 CORROSION PREVENTION & APPEARANCE CARE Corrosion Protection ............. 4-2 To Help Prevent Corrosion ........... 4-2 Washing and Waxing ............ 4-3 Cleaning the Interior ............4-5 smhma-4.p65 7/28/04, 5:14 PM...
Page 197: Corrosion Protection
Some of the struction practices to combat corrosion, common causes of accelerated corrosion are Hyundai produces cars of the highest quality. road salts, dust control chemicals, ocean air However, this is only part of the job. To achieve E020B01A-AAT and industrial pollution.
Page 198: Washing And Waxing
These should be carried only in proper contain- These are available at your Hyundai dealer or ers and any spills or leaks should be cleaned up, auto parts outlet. Don't use strong household flushed with clear water and thoroughly dried.
Page 199 To protect the paintwork of the car Always wash and dry the car before polishing To clean plastic wheel covers, use a clean against corrosion, you must clean your Hyundai or waxing or using a combination cleaner and sponge or soft cloth and water.
Page 200: Cleaning The Interior
Then apply In the normal course of use, leather upholstered Hyundai. They are: a solution of mild soap or detergent and water surfaces will, like any material, pick-up dust and using a clean sponge or soft cloth.
Page 201 Cleaning the Carpets Cleaning the Windows If you have any questions about the care of your car, consult your Hyundai dealer. Use a foam-type carpet cleaner. Cleaners of You may use any household window cleaner on this type are available in aerosol cans in liquid the windows.
Page 202: Vehicle Maintenance Requirements
VEHICLE MAINTENANCE REQUIREMENTS Maintenance Intervals ........... 5-2 Scheduled Maintenance ..........5-4 Maintenance under Severe Usage Conditions ..... 5-6 Explanation of Scheduled Maintenance Items ....5-7 smhma-5.p65 7/30/04, 9:46 AM...
Page 203: Maintenance Intervals
To ensure that you receive the greatest number The maintenance required for your Hyundai These are the procedures such as inspections, of miles of satisfying operation from your Hyundai, can be divided into three main areas: adjustments and replacements that are listed in certain maintenance procedures must be per- the maintenance charts starting on page 5-4.
Page 204: Scheduled Maintenance
These are the regular checks you should per- o Whenever you have your Hyundai serviced, form when you drive your Hyundai or you fill the keep copies of the service records in your o Inspection should be performed any time a fuel tank.
Page 205 VEHICLE MAINTENANCE REQUIREMENTS SCHEDULED MAINTENANCE F030A01A-AAT The following maintenance services must be performed to ensure good emission control and performance. Keep receipts for all vehicle emission services to protect your warranty. Where both mileage and time are shown, the frequency of service is determined by whichever occurs first. F030B01O-AAT R :Replace I : Inspect and, after Inspection, clean, adjust, repair or replace if necessary.
Page 206 VEHICLE MAINTENANCE REQUIREMENTS F030C06O-AAT R : Replace I : Inspect and, after inspection, clean, adjust, repair or replace if necessary MILES X 1000 22.5 37.5 52.5 67.5 82.5 97.5 112.5 127.5 142.5 DESCRIPTION KILOMETERS X 1000 MONTHS GENERAL ITEMS DRIVE BELT 2.7 V6 (ALT, P/STR'G, A/CON) 3.5 V6 (ALT, P/STR'G, A/CON) COOLANT...
Page 207: Maintenance Under Severe Usage Conditions
VEHICLE MAINTENANCE REQUIREMENTS MAINTENANCE UNDER SEVERE USAGE CONDITIONS F040A04O-AAT The following items must be serviced more frequently on cars normally used under severe driving conditions. Refer to the chart below for the appropriate maintenance intervals. R : Replace I : Inspect and, after inspection, clean, adjust, repair or replace if necessary MAINTENANCE MAINTENANCE DRIVING...
Page 208: Explanation Of Scheduled Maintenance Items
VEHICLE MAINTENANCE REQUIREMENTS EXPLANATION OF SCHEDULED MAINTENANCE ITEMS F060A01A-AAT F060B01A-AAT F060F01O-AAT o Drive Belts o Vacuum Hoses F060M01A-AAT Inspect all drive belts for evidence of cuts, Inspect the surface of hoses for evidence of o Engine Oil and Filter cracks, excessive wear or oil saturation and heat and/or mechanical damage.
Page 209 GENUINE ATF SP III, DIAMOND ATF SP III, SK Make sure to install new spark plugs of the Inspect the hose routing to assure that the hose ATF SP III or other brands approved by Hyundai correct heat range. does not come in contact with any heat source, Motor Co., when adding or changing fluid.
Page 210 VEHICLE MAINTENANCE REQUIREMENTS F070G02A-AAT F070K01A-AAT F070N01A-AAT o Brake Fluid o Exhaust Pipe and Muffler o Power Steering Pump, Belt and Hoses Check brake fluid level in the brake fluid reser- Visually inspect the exhaust pipes, muffler and Check the power steering pump and hoses for voir.
Page 211 DO-IT-YOURSELF MAINTENANCE Engine Compartment ............ 6-2 General Checks ............6-4 Checking the Engine Oil ..........6-5 Changing the Oil and Filter ..........6-6 Checking and Changing the Engine Coolant ....6-8 Spark Plugs ..............6-10 Changing the Air Cleaner Filter ........6-11 Checking the Transaxle Fluid (Automatic) ....
Page 212: Do-It-Yourself Maintenance
DO-IT-YOURSELF MAINTENANCE G010B01O-AAT (2.7 V6) CAUTION: When inspecting or servicing the engine, you should handle tools and other heavy objects carefully so that the plastic cover of the engine is not damaged. G010B01O 1. Coolant reservoir cap 5. Windshield washer fluid reservoir 9.
Page 213 DO-IT-YOURSELF MAINTENANCE G010C01O-AAT (3.5 V6) CAUTION: When inspecting or servicing the engine, you should handle tools and other heavy objects carefully so that the plastic cover of the engine is not damaged. HSM424 1. Coolant reservoir cap 5. Fuse and Relay box 9.
Page 214: Engine Compartment
Seat belt condition and operation o Sunvisor operation If you notice anything that does not operate correctly or appears to be functioning correctly, inspect it carefully and seek assistance from your Hyundai dealer if service is needed. smhma-6.p65 7/28/04, 5:55 PM...
Page 215: Checking The Engine Oil
DO-IT-YOURSELF MAINTENANCE CHECKING THE ENGINE OIL NOTE: G030A01A-AAT 3.5 V6 o For good fuel economy, SAE 5W-20 (5W- Engine oil is essential to the performance and 30), ILSAC GF-3 engine oil is preferred service of the engine. It is suggested that you regardless of regional option and en- check the oil level at least once a week in normal gine variation.
Page 216: Changing The Oil And Filter
DO-IT-YOURSELF MAINTENANCE CHANGING THE OIL AND FILTER G030D01O-AAT G040A03A-GAT Adding Oil 1. Remove the oil filler cap by turning it counter- 2.7 V6 clockwise. 2.7 V6 2. Add oil, then check the level again. Do not overfill. 3. Replace the cap by turning it clockwise. The distance between the "F"...
Page 217 DO-IT-YOURSELF MAINTENANCE The engine oil and filter should be changed at 4. When the oil has stopped draining, replace those intervals specified in the maintenance the drain plug using a new washer and schedule in Section 5. If the car is being driven retighten by turning it clockwise.
Page 218: Checking And Changing The Engine Coolant
DO-IT-YOURSELF MAINTENANCE CHECKING AND CHANGING THE ENGINE COOLANT G050A01A-AAT G050B01A-AAT Recommended Engine Coolant PROPOSITION 65 WARNING: Use a high quality ethylene-glycol coolant in a Used engine oil may cause irritation or 50/50 mix with water. The engine coolant should WARNING: cancer of the skin if left in contact with the be compatible with aluminum engine parts.
Page 219 "L" and "F". If the level is low, inspect for coolant leaks and recheck the fluid level frequently. If the level drops again, visit your Hyundai dealer for an inspection and diagnosis of the reason. G050D01O smhma-6.p65...
Page 220: Spark Plugs
(1.0~1.1 mm) of fuel economy, poor acceleration, etc. When spark plugs are replaced, always use spark plugs recommended by Hyundai. The use of other spark plugs can result in loss of perfor- mance, radio interference or engine damage. G050D02O...
Page 221: Changing The Air Cleaner Filter
If the wipers continue to streak or smear the HHR5048 glass, replace them with genuine Hyundai re- 1. Push down the wiper blade with the locking placement parts or their equivalent.
Page 222 DO-IT-YOURSELF MAINTENANCE FILLING THE WASHER RESERVOIR 1. Put a new wiper blade onto the wiper arm and G090A01O-AAT lower the wiper blade at the level of the wiper arm as shown in the drawing. HHR5049 G090A01O 2. Raise the wiper blade lightly and pull up it. The washer fluid reservoir supplies fluid to the windshield washer system.
Page 223: Checking The Transaxle Fluid (Automatic)
Only section 5. use HYUNDAI GENUINE ATF SP III, DIA- MOND ATF SP III, SK ATF SP III or other brands approved by Hyundai Motor Co., If you are having your vehicle serviced at a facility other than a Hyundai dealer, verify ATF is used for your vehicle.
Page 224 DO-IT-YOURSELF MAINTENANCE G110C01O-AAT G110D02O-AAT Transaxle Fluid Capacity To Check the Transaxle Fluid Level The fluid capacity of the automatic transaxle is Park the car on level ground with the parking 8.98 U.S. quarts (8.5 liters). brake engaged. When the transaxle fluid level is checked, the transaxle fluid should be at normal operating temperature and the engine idling.
Page 225: Checking The Brakes
Follow the instructions printed on the operation of the car, it is suggested that container. they be checked and inspected by your Hyundai dealer. The brakes should be G120D01A-AAT checked and inspected for wear at those To Check the Fluid Level intervals specified in the vehicle mainte- nance schedule in Section 5.
Page 226: Air Conditioning Care
2. If the air coming out of the in-dash vents is voir and tighten. not cold, have the air conditioning system inspected by your Hyundai dealer. CAUTION: Running the air conditioning system for extended periods of time with a low refrig- erant level may damage the compressor.
Page 227 Pressing with your finger, you should not be able to deflect this belt anymore than 1/3 of an inch. If the belt is too loose, have it adjusted by your Hyundai dealer. comp. 1.18 in. (30 mm)
Page 228: Checking Drive Belts
If the brake pedal clearance is not within the fied in the illustration above. If it is not, have it limits specified in the illustration, have it in- inspected by your Hyundai dealer and adjusted spected by your Hyundai dealer and adjusted or repaired if necessary.
Page 229: Checking And Replacing Fuses
If this ever happens, have a Hyundai dealer determine the cause, repair the system and replace the fusible link. The fusible links are located in a relay box in the engine compartment for easy inspection.
Page 230 If it is not, have the fuse (a small "fuse puller" tool is contained in the clip repaired or replaced by a Hyundai dealer. fuse box to simplify this operation). If you do not have a spare fuse, you may be 3.
Page 231: Checking The Battery
Hyundai dealer for cloth saturated with water. diagnosis and repair. Never replace a fuse...
Page 232: Power Steering Fluid Level
DO-IT-YOURSELF MAINTENANCE CHECKING ELECTRIC COOLING POWER STEERING FLUID LEVEL FANS G210B03A-AAT G220A01A-AAT G230A03A-AAT Checking the Battery Keep the battery clean. Any evidence of corro- WARNING: sion around the battery posts or terminals The cooling fan is controlled by engine should be removed using a solution of house- coolant temperature and may sometimes hold baking soda and warm water.
Page 233 Hyundai, you may steering oil reservoir is empty. the front bumper & rear bumper down sev- purchase a factory Shop Manual at your Hyundai eral times. dealer's parts department. This is the same Place vehicle at a distance of 118 in. (3m) manual used by dealership technicians and from the test wall.
Page 234 Horizontal aiming should be adjusted by Ground line 118 in. (3,000 mm). an authorized Hyundai dealer. G290A03O If the vehicle has had front body repair and the headlight assembly has been replaced, the headlight aiming should be checked using an aiming chart as shown in the illustration.
Page 235: Replacement Of Light Bulbs
DO-IT-YOURSELF MAINTENANCE REPLACEMENT OF LIGHT BULBS G260A02A-AAT G270A02O-AAT Headlight and Front Turn Signal Light Before attempting to replace a light bulb, be sure the switch is turned to the "OFF" position. 1. Allow the bulb to cool. Wear eye protection. The next paragraph shows how to reach the 2.
Page 236 DO-IT-YOURSELF MAINTENANCE 6. Turn the plastic cover counterclockwise and remove it. HSM331 HSM330 8. Push the bulb spring to remove the headlight 9. Remove the protective cap from the re- bulb. placement bulb and install the new bulb by HSM329 matching the plastic base with the headlight 7.
Page 237 DO-IT-YOURSELF MAINTENANCE G270B02O-GAT Rear Combination Light HSM332 G270A03O 12.To replace the front turn signal light bulb, remove from the bulb holder and install the G270B01O new bulb. Do not touch the glass of the new WARNING: bulb. This halogen bulb contains gas under pres- sure and if impacted could shatter, result- ing in flying fragments.
Page 238 DO-IT-YOURSELF MAINTENANCE 1. Open the tail gate. G270C01O-AAT Luggage Compartment Light 2. Remove the mounting screws of the rear combination light as shown with a phillips screwdriver. HSM342 3. Replace with a new bulb. HSM341 1. Open the tail gate. G270B03O 2.
Page 239 DO-IT-YOURSELF MAINTENANCE G270E01O-AAT G270G01O-AAT Front Side Marker Light Interior Light HSM335 2. Disconnect the connector. HSM334 HSM343 1. Remove the cover with a phillips screw- 1. Remove the cover with a flat-head screw- driver. driver. HSM336 3. Replace with a new bulb. smhma-6.p65 7/28/04, 5:56 PM...
Page 240 DO-IT-YOURSELF MAINTENANCE G270H01O-AAT Glove Box Illuminated Light HSM344 G270E02L 2. Replace with a new bulb. 3. Disconnect the connector. HSM366 1. Open the glove box. 2. Remove the cover with a flat-head screw- driver. HTB284 4. Replace with a new bulb. smhma-6.p65 7/28/04, 5:56 PM...
Page 241: Bulb Wattage
DO-IT-YOURSELF MAINTENANCE BULB WATTAGE G280A02O-AAT G280A01O-A Part Name Wattage Wattage Part Name Head Light (Low/High) 55/60 Luggage Compartment Light Turn Signal Light/Front Position Light 28/8 High Mounted Rear Stop Light (If installed) With sunroof Rear Combination Light Map Light Without sunroof Turn Signal Light Interior Light Stop/Tail Light (Side Mrker Light)
Page 242: Fuse Panel Description
DO-IT-YOURSELF MAINTENANCE FUSE PANEL DESCRIPTION G200C02O-AAT FUSE Engine Compartment PROTECTED COMPONENTS DESCRIPTION RATING 140A Generator Tail lamp relay, Fuse 11~17, Power connector Start relay, Ignition switch A/C Fuse, Blower relay FUSIBLE ABS.1 ABS control module, Air bleeding connector LINK ABS.2 ABS control module, Air bleeding connector Engine contorl relay Power window relay, Fuse 26...
Page 243 DO-IT-YOURSELF MAINTENANCE G200E01O-AAT FUSE FUSE PROTECTED COMPONENTS Inner Panel RATING Cigarette lighter & Power outlet Audio, Power outside mirror Digital clock, Rear power outlet Cruise control Head lamp relay Seat warmer Rear wiper motor control Rear window defogger, Power outside mirror A/C control, Sunroof controller, Electrical chrome mirror (Not used) Room lamp, Door warning switch, Door lamp, Manual A/C control, Homelink controller...
Page 244: Emission Control Systems
EMISSION CONTROL SYSTEMS Emission Control System ..........7-2 EGR System ..............7-3 Catalytic Converter ............7-3 smhma-7.p65 7/28/04, 5:51 PM...
Page 245 H010C01S-AAT up during ordinary driving, the PCSV opens to tained by an authorized Hyundai dealer in ac- 2. Evaporative Emission Control (Includ- introduce evaporated fuel to the engine. cordance with the maintenance schedule in this ing ORVR: Onboard Refueling Vapor manual.
Page 246 Avoid driving with a very low fuel level. H020A01O Running out of gasoline may cause the All Hyundai vehicles are equipped with a mono- engine to misfire and result in damage to lith type three-way catalytic converter to re- the catalytic converter.
Page 247 EMISSION CONTROL SYSTEMS WARNING: o Do not stop your Hyundai over any com- bustible material such as grass, paper, leaves or rags. These materials might contact the hot catalytic converter and a fire might result. smhma-7.p65 7/28/04, 5:51 PM...
Page 248 Tire Traction ..............8-10 When to Replace Tires ..........8-10 Tire Maintenance ............8-11 Spare Tire and Tools ........... 8-11 Warranties for Your Hyundai Vehicle ......8-12 Consumer Information ..........8-12 Reporting Safety Defects ..........8-15 Binding Arbitration of Warranty Claims ....... 8-15 smhma-8.p65...
Page 249: Engine Number
I020A02A-AAT I010A01O-AAT I010B01A-AAT TIRE INFORMATION 2.7 V6 The tires supplied on your new Hyundai are chosen to provide the best perfor- mance for normal driving. If you ever have questions about your tire warranty and where to obtain ser- vice, see the tire manufacture's booklet included with your vehicle's Owner's Manual Literature Kit.
Page 250: Recommended Inflation Pressures
CONSUMER INFORMATION, REPORTING SAFETY DEFECTS & BINDING ARBITRATION OF WARRANTY CLAIMS I030A01JM-AAT RECOMMENDED INFLATION PRES- SURES WARNING: o Lower-than-recommended tire pressures cause uneven tread wear, poor handling, poor fuel economy or tire failure. o Higher-than-recommended tire pressures can cause poor han- dling, uneven tread wear or tire failure.
Page 251: Tire Sidewall Labeling
CONSUMER INFORMATION, REPORTING SAFETY DEFECTS & BINDING ARBITRATION OF WARRANTY CLAIMS at them. Radial tires may look properly I030B01O-AAT o Check the pressure of your spare TIRE SIDEWALL LABELING inflated even when they're underinflated. tire each time you check the pres- Check the tire's inflation pressure when sure of other tires.
Page 252: Index
CONSUMER INFORMATION, REPORTING SAFETY DEFECTS & BINDING ARBITRATION OF WARRANTY CLAIMS 1. Manufacturer or Brand name o T: Speed Rating. The speed rating o Four numbers represent the week o Manufacturer or Brand name is denotes the speed at which a tire is and year the tire was built.
Page 253: Tire Terminology And Definitions
CONSUMER INFORMATION, REPORTING SAFETY DEFECTS & BINDING ARBITRATION OF WARRANTY CLAIMS 6. Maximum load rating I030D01JM-AAT Cold Tire Pressure: The amount of air TIRE TERMINOLOGY AND DEFINI- This number indicates the maximum pressure in a tire, measured in pounds TIONS load in kilograms and pounds that per square inch (psi) or kilopascals Air Pressure: The amount of air inside...
Page 254 CONSUMER INFORMATION, REPORTING SAFETY DEFECTS & BINDING ARBITRATION OF WARRANTY CLAIMS Intended Outboard Sidewall: The side Occupant Distribution: Designated Sidewall: The portion of a tire between of an asymmetrical tire, that must al- seating positions. the tread and the bead. ways face outward when mounted on a Outward Facing Sidewall: The side of Speed Rating: An alphanumeric code...
Page 255: Snow Tires
I040A01O-AAT ALL SEASON TIRES SNOW TIRES of designated seating positions multi- Hyundai specifies all season tires on If you equip your car with snow tires, plied by 150 lbs. (68 kg) plus the rated some models to provide good perfor-...
Page 256: Tire Chains
Use the SAE "S" class or wire & Hyundai dealer so the cause may be Whenever a tire is dismounted for re- plastic chains.
Page 257: Tire Traction
Wear indicator ply tires, they must be installed in sets of four. HSM5013 o Wheels that do not meet Hyundai's The original tires on your car have tread dimensional specifications may wear indicators. The tread wear indica- fit poorly and result in damage to tors appear when the tread depth is 0.06...
Page 258: Tire Maintenance
D060B01O life. Additionally, a tire shoud always be ure or rollover and serious injury. Your Hyundai is delivered with the fol- rebalanced if it is removed from the When replacing the tires, be sure lowing: wheel.
Page 259: Warranties For Your Hyundai Vehicle
This consumer information has been prepared Warranty. in accordance with regulations issued by the A Hyundai Shop Manual is available from your o New vehicle 120 Months/100,000 Miles Lim- National Highway Traffic Safety Administration authorized Hyundai dealer. It's written for pro- ited Powertrain Warranty (original owner of the U.S.
Page 260 CONSUMER INFORMATION, REPORTING SAFETY DEFECTS & BINDING ARBITRATION OF WARRANTY CLAIMS I130B04A-AAT Traction AA, A, B, C - The traction Temperature A, B, C - The tempera- Tire Quality Grading grades, from highest to lowest, are AA, ture grades are A (the highest), B, and Department of Transportation quality A, B, and C.
Page 261 CONSUMER INFORMATION, REPORTING SAFETY DEFECTS & BINDING ARBITRATION OF WARRANTY CLAIMS I130D03A-AAT Southern Region: Alabama, Arkansas, Florida, Hyundai motor vehicles are designed and manu- Georgia, Louisiana, Mississippi, North Caro- factured to meet or exceed all applicable safety lina, South Carolina, Oklahoma, Tennessee, WARNING: standards.
Page 262: Reporting Safety Defects
All other arbitration costs shall be borne Motor America, Attn: Consumer Af- of Transportation, Washington. D.C. 20590. by Hyundai Motor America. You are not You can also obtain other information about fairs, 10550 Talbert Avenue, P.O. Box responsible to pay any of the costs motor vehicle safety from the Hotline.
Page 263: Vehicle Specifications
VEHICLE SPECIFICATIONS Measurement ..............9-2 Engine ................9-3 Lubrication Chart ............9-4 smhma-9.p65 7/28/04, 5:53 PM...
Page 264 VEHICLE SPECIFICATIONS J010A02O-AAT J030A02O-AAT MEASUREMENT TIRE in. (mm) psi (kpa) Overall length 177.1 (4500) Tire Size Tire pressure Overall width 71.5 (1820) Standard 225/70 R16 30 (207) Overall height 65.2(1655)/67.3(1710)* Full Size Spare 65.9(1675)/68.1(1730)* Wheel base 103.1 (2620) J040A04O-AAT ELECTRICAL Front Wheel tread 60.6 (1540)
Page 265 VEHICLE SPECIFICATIONS ENGINE J070A03O-AAT SPECIFICATIONS ITEMS 2.7 V6 3.5 V6 Engine Type 6-Cyl., V-type DOHC 6-Cyl., V-type DOHC Bore x Stroke in. (mm) 3.41 x 2.95 (86.7 x 75) 3.66 x 3.38 (93 x 85.8) Displacement cu.in. (cc) 162.1 (2,656) 213.4 (3,497) Firing order 1 - 2 - 3 - 4 - 5 - 6...
Page 266 SAE 50W-20, 5W-30 ILSAC GF-3 or ABOVE SAE 10W-30 [ABOVE 0°F (-18°C)] Transaxle HYUNDAI GENUINE ATF SP III, DIAMOND ATF SP III, SK ATF SP III or other brands approved by Hyundai Motor Co., Coolant Ethylene glycol base for aluminum radiator...
Page 267 VEHICLE SPECIFICATIONS J080A05O-AAT Quantity (US. QTS) (lmp.qts, liter) ITEM 2.7 V6 3.5 V6 Drain & refill; Engine Drain & refill; Without oil filter : 4.44 (3.7, 4.2) Without oil filter : 4.23 (3.52, 4) With oil filter : 4.76 (3.96, 4.5) With oil filter : 4.54 (3.78, 4.3) 8.98 (7.48, 8.5) Transaxle...
Page 268 INDEX smhma-10.p65 7/29/04, 1:43 PM...
Page 269 Brake traction control system (BTCS) ........2-13 Corrosion protection Checking the brakes ..............6-15 Cleaning the interior ............... 4-5 Fluid ....................6-15 Protecting your Hyundai from corrosion ........4-2 Pedal clearance ................6-28 Washing and waxing ..............4-3 Pedal free-play ................6-18 Cruise Control ................... 1-89 Practices ..................
Page 270 INDEX Defrosting / Defogging ..............1-101 Fan Speed Control ................1-93 Door Floor Mat Anchor ................1-86 Central door locks ................1-7 Fog Light Door locks ..................1-4 Front ..................... 1-62 Front door edge warning light ............1-88 Front Seats Locking, unlocking front door with a key ........
Page 271 INDEX Heating and Ventilation Air flow control ................1-94 Light Bulbs Replacement ..............6-25 Air intake control switch ............... 1-93 Limited-Slip Differential ..............2-19 Bi-level heating ................1-98 Luggage Compartment Light ............1-81 Defrosting / Defogging .............. 1-101 Luggage Net ..................1-82 Fan speed control (Blower control) ..........
Page 272 INDEX Steering Wheel Tilt Lever ..............1-87 Rear Seat Stereo Sound System ..............1-108 Adjusting seatback angle ............. 1-17 Sunroof ....................1-69 Folding rear seatback and seat cushion ........1-17 Sun Visor ................... 1-86 Rear Window Defroster Switch ............1-62 Reporting Safety Defects ..............
Page 273 INDEX Transaxle Automatic ................2-6, 2-19 Automatic transaxle fluid checking ..........6-13 Trip Computer ................... 1-55 Vehicle Identification Number ............. 8-2 Vehicle Load Limit ................2-37 Vehicle Specifications Engine ..................... 9-3 Lubrication chart ................9-4 Measurement ................. 9-2 Warning and Indicator Lights ............1-48 Windows Power ...................
Page 274 2005 smhma-11.p65 7/29/04, 8:12 AM...
Page 275 “N” (Neutral) position. Then check the UNLEADED gasoline only level of fluid on the dipstick. Use only HYUNDAI GENUINE ATF SP III, Pump Octane Rating of 87 (Research Octane Number 91) or higher. DIAMOND ATF SP III, SK ATF SP III or other brands approved by Hyundai Motor Co.,...

Hyundai Santa Fe Owner's Manual

Features of Your Hyundai

Driving Your Hyundai

What to Do in an Emergency

Corrosion Prevention & Appearance Care

Vehicle Maintenance Requirements

Do-It-Yourself Maintenance

Consumer Information, Reporting Safety Defects & Binding Arbitration of Warranty Claims

Quick Links

Chapters

Related Manuals for Hyundai Santa Fe

Summary of Contents for Hyundai Santa Fe

Table of Contents
