- Page 1 Model DV110 User Guide DVD / Tuner CLASS 1 LASER PRODUCT KLASSE 1 LASER PRODUKT I.H.T. IEC 825...
- Page 2 Le spese ed i rischi di trasporto sono a carico del cliente. GARANTIE La casa costruttrice declina ogni responsabilità per danni diretti o indiretti Pour des informations sur la garantie, contacter le distributeur local Marantz. provocati dalla inosservanza delle prescrizioni di installazione, uso e CONSERVER L'ATTESTATION D'ACHAT manutenzione dettagliate nel presente manuale o per guasti dovuti ad uso L'attestation d'achat est la preuve permanente d'un achat de valeur.
- Page 3 The DV110 is in conformity with the EMC directive and low-voltage directive. Français Le DV110 est conforme à la directive EMC et à la directive sur les basses tensions. Deutsch Das Modell DV110 entspricht den EMC-Richtlinien und den Richtlinien für Niederspannungsgeräte.
- Page 4 English Español To ventilate the unit, do not install the unit in a rack or bookshelf, Para ventilar la unidad no la instale en una estantería ni and note the followings. estante para libros, y tenga en cuenta lo siguiente: - Do not touch the top of the enclosure during operation.
- Page 5 STANDBY OPEN DV110 TUNER REPEAT RANDOM ANGLE S.TITLE AUDIO DISPLAY STANDBY OPEN MENU MENU TUNER MENU SETUP /MODE ENTER ENTER MULTI JOG PUSH ENTER /MEMO ZOOM RETURN MODE SLOW MEMO 11 12 13 14 15 PROGRESSIVE NEWS/TA TIMER CLEAR PROGRAM...
-
Page 6: Table Of Contents
INITIALIZE (RESET ALL) ........32 CONNECTIONS ........... 9 TROUBLE SHOOTING ........33 PRECAUTIONS CONCERNING CONNECTIONS ....9 MAINTENANCE ..........33 CONNECTING THE MARANTZ EQUIPMENT (PS110, DR110, MD110) ............9 CONNECTING OTHER AUDIO EQUIPMENT ....10 BASIC OPERATIONS ........11 PREPARATION ..............11 PLAYING A DISC ............... -
Page 7: Foreword
EQUIPMENT MAINS WORKING SETTING Your Marantz product has been prepared to comply with the household power and safety requirements that exist in your area. DV110 can be powered by 230 V AC only. -
Page 8: About Discs
Regional restriction codes are built in to DV110 player and DVD Audio CD (CD-DA) discs for each sales region. If the regional code of the DV110 player does not match one of the regional codes of the DVD disc, playback is not possible. -
Page 9: About Video Cds
Unlike conventional turntables for playing analog discs, the The Video-CD with PBC (Play Back Control : Menu playback DV110 reads the information recorded on the disc from function) function. You can choose or search a section to play underneath without contacting it using a beam of laser light. -
Page 10: Remote Control Unit
!2 ZOOM button REMOTE CONTROL UNIT • Press this button to enlarge picture. (This function may be disabled depending on discs.) STANDBY button !3 , / . (Slow) buttons • Press to switch the power ON, and press again to switch it OFF. -
Page 11: Operation Of Remote Control Unit
The distance between the transmitter of the remote control unit @4 ENTER button and the IR SENSOR of the DV110 should be less than about 5 • Press this button to decide an item selected with the cursor. meters. If the transmitter is pointed to a direction other than the •... -
Page 12: Main Unit
⁄2 5 / MEMO button MAIN UNIT • Press this button to fast rewind the disc while playing. • Also this button is used for preset memory. FRONT PANEL Note: 5 button is unavailable for MP3. STANDBY button ⁄3 Infrared sensor •... -
Page 13: Rear Panel
D System selector switch • This switch selects the system operation mode. • Set to EXT position when DV110 is being used in combination with a AV amplifier (PS110), CDR (DR110) or MD (MD110). • If your component is not capable of system connection, set this switch to INT position. -
Page 14: Connections
• Be sure to make a distinction between the left (white) and right (red) audio cable plugs when connecting them. • When connecting this unit to other audio equipment, read the operation manual for that equipment carefully for details on how to make the correct connections. CONNECTING THE MARANTZ EQUIPMENT (PS110, DR110, MD110) AM loop antenna FM external antenna... -
Page 15: Connecting Other Audio Equipment
AM loop antenna FM external antenna FM feeder antenna VIDEO IEC type converter plug (attached) VIDEO VIDEO EUROCONNECTOR • When using the FM antenna attach to this apparatus. DV110 White Black Amplifier ANALOG IN LEFT RIGHT RIGHT LEFT CD-Recorder ANALOG DIGITAL OPT OUT DIGITAL COAX. -
Page 16: Basic Operations
BASIC OPERATIONS For operations for specific disc types, the disc type marks ( ) are shown beside the operations. DVD VCD If no mark is shown, the operation is for all disc types. Note: If the player is in the tuner mode, press 9, 2 or ENTER button @4 / , to turn into the DVD mode. -
Page 17: To Pause Playing
Deactivate Resume Function TO PAUSE PLAYING • After stopping playback (Resume status displayed), 1. Press the ; button @3 / v. press 9 button o/x again to deactivate the resume To resume playing, press the 2 button @2 / v. function. -
Page 18: Direct Search
DIRECT SEARCH DVD MENU Most of DVD discs have their own menu screen (DVD menu). In Using the numeric buttons this menu, you can choose a chapter, audio language, subtitle, In playback and stop modes, you can choose a chapter(track) etc. -
Page 19: Playing Mp3
PLAYING MP3 SWITCHING INFORMATION ON FL DISPLAY If discs in MP3 format is loaded, menu screen is displayed on Information on the FL Display, such as time clock or remaining time, can be changed by pressing DISPLAY button !9 on the TV automatically. -
Page 20: Various Playing Functions
VARIOUS PLAYING FUNCTIONS • For VCD, Audio CD and MP3 discs, currently played track is repeated. SLOW PLAY 1. While playing, Press , button or . button !3 on the remote for slow backward play or slow forward play. • Press . button !3 for slow forward. •... -
Page 21: A-B Repeat Play
A-B REPEAT PLAY RANDOM PLAY You can play a specific part (between A and B) in a chapter(track) All tracks will be played in random sequence. repeatedly. 1. In stop mode, press the RANDOM button !8 then press the Caution 2 button @2 / v. -
Page 22: Ams (Auto Music Scan) Playing
AMS (AUTO MUSIC SCAN) PLAYING • For MP3 discs, a folder, all files in a folder is played in This function plays just the first ten seconds of each track. random sequence. When the desired track is found, press the AMS button on the remote control again to begin playing that track. -
Page 23: Changing Angles
3. Repeat step 2 for the next track, and so on to program up to ZOOM FUNCTION 30 tracks. When playing a wide aspect picture in letter box format on a • If the number of programmed tracks exceeds 30, the normal aspect (4:3) TV, the center part of the picture can be display below will be shown. -
Page 24: Tuner Operation
TUNER OPERATION PRESET MEMORY OPERATION The DV110 can store up to total 30 stations selected in the FM TO LISTEN TO THE RADIO and AM bands. This player can receive FM and AM radio broadcast. Manual preset memory 1. If TUNER button w/n is pressed, the player turns into tuner 1. -
Page 25: Selecting Preset Channel
Auto preset memory SELECTING PRESET CHANNEL This allows a band to be scanned automatically, a station with 1. Press TUNER button w/n to select a radio band you want. good reception to be found and to be stored in the preset 2. -
Page 26: Reception Of Rds Broadcasting
7. The auto search will stop at a station with the specified PTY. RECEPTION OF RDS BROADCASTING The DV110 provides the following functions for use with the RDS (Radio Data System). PTY (Program TYpe) AUTO SEEK This unit automatically searches for stations transmitting any of 30 different programme types. - Page 27 EON (ENHANCED OTHER NETWORK) SEEK 7-1. To set EON SEEK on the present station. The EON gives information from an other network of RDS. Turn the MULTI JOG dial ⁄4 to select a following information; Information, such as TA (Traffic Announcement), PTY, etc., can NEWS, TA, NEWS/TA or OFF.
-
Page 28: Setup Menu Operation
SETUP MENU OPERATION LANGUAGE SETUP You can set up settings for the player and for TV monitor by Audio language setup your preference from. To set the audio language to play. 1. Press 9 button o/x to stop the player. CONTENTS OF SETUP MENU 2. - Page 29 DVD menu language setup If “Others” is selected for the language setup, Most of DVD discs have their own menu screen. This is too set Note: the DVD menu language to display. This setting is effective only when any of the languages in 1.
-
Page 30: Video Setup
How it is displayed VIDEO SETUP • When your TV is 4:3 screen. Set picture aspect ratio. This menu is to set picture aspect ratio to fit into your TV. Picture in 16:9 aspect ratio 1. Press 9 button o/x to stop the player. Player’s setting How it looks 2. - Page 31 SCART video setup Still-picture display setup 1. Press 9 button o/x to stop the player. To set how still-picture is displayed while pausing. 1. Press 9 button o/x to stop the player. 2. Press SETUP button !0 to display the main menu. 3.
-
Page 32: Audio Setup
Dynamic range compression setup AUDIO SETUP For discs recorded in Dolby Digital format, audio dynamic range (the range between the smallest and the biggest sound) Setting Dolby Digital signal output. compression ratio can be changed depending on volume level. To set how Dolby Digital signal (digital audio) is output depending If the compression is set On, you can hear small sound much on your digital equipment. -
Page 33: Ratings Setup
Parental lock level setup RATINGS SETUP If a disc has parental lock level, the disc is played with restriction based on parental lock level and disc contents. You Set password for parental lock can set the player not to play what you do not want to show to You need to enter password to play discs under parental lock or children. -
Page 34: Others Setup
Default setup OTHERS SETUP If this default setup is set, all the settings made in the setup menu EXCEPT the parental lock level and the password are Screensaver setup reset to the default. 1. Press 9 button o/x to stop the player. 1. -
Page 35: Language Code List
LANGUAGE CODE LIST Language name Language name Language name Input code Input code Input code Japanese (ja) Gujarati (gu) Rhaeto-Romance (rm) 1001 0721 1813 English (en) Hausa (ha) Kirundi (rn) 0514 0801 1814 French (fr) 0618 Hindi (hi) 0809 Romanian (ro) 1815 German (de) 0405... -
Page 36: Using The Timer Functions
7. Press the ENTER button @4 to enter the selection. USING THE TIMER FUNCTIONS Or push the ENTER button ,. This unit enables a time to be set and for a disc to be played at The time set on the display now flashes. (Second setting) this setting. -
Page 37: Setting And Clearing Timer Playback
4. Set the playback ON minute using the Cursor ( 1 / 2 ) SETTING AND CLEARING TIMER PLAYBACK buttons !1 on the remote control or the Cursor ( 1 / 2 ) 1. Press the TIMER button @9 on the remote control twice. buttons . -
Page 38: Trouble Shooting
If the corrosive effect. problem is not solved even after carrying out the following checks, consult your dealer or nearest Marantz sales office or service center. The power does not come on. • Plug in the power plug to the socket completely. -
Page 40: Specifications
