Daewoo DWC-1011W Service Manual page 16

No. PARTS NAME
E01 DUCT b UppER
E02 SCREW TAppING
E03 SCREW TAppING
E04 HEATER DRy
E05 pACKING THERMoSTAT
E05 SWITCH THERMoSTAT
E06 DUCT b loWER
E07 bUSHING UppER
E08 bUSHING loWER
E09 GASKET SEAl A
E10 pACKING RUbbER
E10 THERMISToR DRy
E11 NUT HEX
E12 fAN AS
E13 CoVER DUCT
E14 RING o
E15 UNIT fAN MoToR
CODE SPECIFICATIONS
361A202400 AlCoSTA
7122401411 T2S TRS 4X14 MfZN
7112401208 T1 TRS 4X12 SUS
3612801400 230V 2.1KW 25.19oHM 6.1W/SQ INColoy800 1R1A034002
3614009900 SILICON, DWD-100DR
3619046500 oN120°C off150°C 230V 15A VDE
361A202500 ALDC C-LU1011
3610703800 POM C-LU1011
3610703900 POM C-LU1011
3612325700 EpDM foAM, D=5, l=1293
3614009800 SILICON, DWD-100DR
361AAAAD00 C-LD/LU,L=200,R40=26.065K,R90=4.4278K
3616032100 M6*1.0p,CCW
3611886400 GFPP30% , C-LU1011
3611431400 GFPP30% C-LU1011
3614603400 DWD-100DR,NBR,ID=7.6,OD=13.6
36189M2Q00 24V DC 14W
14
Q'TY REMARK
1
8
1
1
1
1
1
4
4
1
1
1
1
1
1
1
1
