- Page 1 Issue 1.00 Doortello Home User guide USER GUIDE Doortello Home Door phone with analogue telephone line interface and up to 6 chime bottons Page 1...
-
Page 2: Table Of Contents
Issue 1.00 Doortello Home User guide Contents Description ..............................3 Package content ............................3 Introduction ..............................3 Features ................................ 4 Security advices ............................5 Flush and wall mounted installation ......................5 Cabling of the chime buttons ........................5 Installation ..............................5 Connections .............................. -
Page 3: Description
User guide Introduction The Doortello Home is a door phone system for integration with new or existing telephone systems. The door phone has a analogue telephone line interface and can be connected to any type of transmission technology, as far as a specific adapter is available, like ISDN, VoIP, GSM, DECT and similar systems. -
Page 4: Features
Issue 1.00 Doortello Home User guide connector for expansion modules loudspeaker chime button 2 chime button 1 connections volume control Door phone DH 02. Front and rear view. Features - Up to 6 chime buttons (dry contacts) can be connected. For each button a 1 to 16 digits long telephone number (1-0,*,#, flash, pause) can be stored. -
Page 5: Security Advices
Installation Before you start with the installation please read the following indications: - The Doortello Home can, together with his modular door station program, has a IP 32 protection degree and can be installed also outside. - If you plan an installation in a rainy environment we suggest the use of a weather shelter or a surface mounting box with weather shelter (IP 33). -
Page 6: Connections
5 (P3) chime button 6 (P4) common wire for chime buttons 3 to 6 Connections Doortello Home basic bunit External power supply (A/-) The external power supply is used to power the door phone and other features. The external AC/DC power supply should be within a range of voltages between 8 and max. -
Page 7: Driver Contacts 1 And 2 (D1/D1'; D2/D2')
(read also the chapter Line impedance). Please note! The Doortello Home door phone has a „fine“ over voltage protection. This is useful only if more over voltage protection circuits are installed. If the unit is installed outside a building we suggest the installation of a over voltage protector with ground connection on the specific telephone line. -
Page 8: Automatic Heating Element
Issue 1.00 Doortello Home User guide Impedance 600 Ohm (default) Impedance Zr Jumpers for line impedance adaptation Automatic heating element If the device has an automatic integrated heating element. This is used to ensure a correct functionality with outside temperature down to - 20°C. The heating element is activated automatically at +10°C and will be deactivated at +20°C. -
Page 9: Activate The Programming Mode
Activate the programming mode If you want to program the Doortello Home you have to first activate the programming mode. Before you can program the device it has to be connected to a telephone line and to a power supply. -
Page 10: Tones During Programmation
Issue 1.00 Doortello Home User guide To terminate the programming mode dial 3. Please note! If you terminate the call hanging up the handset without dialling the digit 3 all the data inserted up to this time will be lost! -
Page 11: Chime Buttons
Issue 1.00 Doortello Home User guide Please take care that the default data load will delete all programmed telephone numbers and values. If you want to delete or change just one telephone number is the default data reload not very useful. Use instead the procedure described in the chapter Delete telephone number. -
Page 12: Delete Telephone Number
The new programmation will overwrite the existing one. Automatic call answer From factory the Doortello Home can answer the incoming calls automatically. This feature can be deactivated if needed. To deactivate the automatic call answer feature please follow this procedure:... -
Page 13: Loudspeaker Status After Line Seizure
Loudspeaker status after line seizure With the Doortello Home it is possible to define which status the loudspeaker has to have after the line seizure. You can define if it has to be on or off. Form factory the loudspeaker is always on, but you can modify this, i.e. -
Page 14: Microphone Status After Line Seizure
*#3 OK tone #23 OK tone Microphone status after line seizure With the Doortello Home it is possible to define which status the micorphone has to have after the line seizure. You can define if it has to be on or off. Form factory the microphone is always off, but can modify this. -
Page 15: Automatic Hang Up After Driver Contact Activation
User guide Automatic hang up after driver contact activation The Doortello Home will, from factory, hang up as soon as a driver contact is activated. This function can be deactivated, i.e. if you want to activate more time the driver contact during a conversation. To deactivate the automatic hang up... -
Page 16: Maximum Line Seizure Time
"7" for the driver contact 1, or modify it to another value (i.e. "701"). Maximum line seizure time The Doortello Home speakerphone has a timer to control the maximum line seizure time. This timer is activated a soon as the line is seized and will terminate the connection when the programmed time is counted down. -
Page 17: Interdigit Dial Pause
*#7 OK tone #25 OK tone Interdigit dial pause The Doortello Home will dial the programmed telephone numbers using an interdigit dial pause. This has a value of 150 ms as default. It is possible to change this value following this procedure: *#7 OK tone #3 {interdigit pause time in ms} OK tone You can use values between 100 and 999. -
Page 18: Driver Contacts Activation Time
*#7 OK tone #9100 OK tone Busy tone detection The Doortello Home door phone can detect a busy tine to terminate the call and the end of a conversation. As default the device can detect three different busy tones: standard CO busy tone 500/500, standard PBX busy tone 200/400 and... -
Page 19: Ring Back Tone Detection
3. Ring back tone detection The Doortello Home can count the numbers of rings sent to the called party by detecting the ring back tone. As default the ring back tone detected is the standard 1000 make and 4000 break tone. If needed you can change this tone... -
Page 20: Number Of Rings
Issue 1.00 Doortello Home User guide *#8 OK tone #4025 OK tone 050 OK tone 025 OK tone 400 OK tone Please note! If you want to program a ring back tone with a single make and break you have to use only the values make 1 and break 2. The values break 1 and make 2 have to have in this case a value of 000. - Page 21 Issue 1.00 Doortello Home User guide Values from 01 to 30 can be used. Example: You want to load the tone table 11 (Panasonic PBX). Input: *#8 OK tone #911 OK tone Follwing tables are available today in the system:...
- Page 22 Issue 1.00 Doortello Home User guide Busy tone 2: 16/16 Busy tone 3: 00/00 Ring back tone: 1000/4000 Table 09 CO USA, Canada, Ireland, Turkey Busy tone 1: 50/50 Busy tone 2: 25/25 Busy tone 3: 20/20 Ring back tone: 2000/4000...
-
Page 23: Call Termination
Issue 1.00 Doortello Home User guide How to use The following use description is based on the default functionality. The described procedure may change if the device has been reprogrammed. Calling a phone using a chime button Press the chime button at the doorstation. The red LED will flash and the stored number will be dialled. -
Page 24: Code Digits For The Phones
Issue 1.00 Doortello Home User guide Code digits for the phones Optical indicators s i l r i f l l a l l a Page 24... -
Page 25: Trouble Shooting
Issue 1.00 Doortello Home User guide Trouble shooting The door phone can not be programmed 1. Check if you are using the right password. 2. Check if the automatic answer feature was deactivated. In this case you have to answer the call manually at the door phone. -
Page 26: Technical Data
Issue 1.00 Doortello Home User guide Technical data External power supply: 8 to 12 Vrms (MAXIMUM), max. 150 mA Power consumption on telephone line: ca. 15 µA (standby) 18-60 mA (nominal) Optical indicators: One red LED Speakerphone: Speech driven half-duplex speakerphone, manual switching... -
Page 27: Programming Codes Overview
Issue 1.00 Doortello Home User guide Programming codes overview Following an overview of all the programming code used to configure the Doortello Business unit. In the right column (DEFAULT) you can read the information about the factory default data programmed for the related code. (T: you will hear a tone). -
Page 28: Overview Of Programmed Values
< > s l l < > Overview of programmed values Options The following options care available for the Doortello Home door phone: Expansion modules 20-6913-8200 PL 20 Spare module 20-6913-8210 PL 21 chime button module with 1 button 20-6913-8250... - Page 29 Issue 1.00 Doortello Home User guide 20-6916-7510 PL 91 aluminium wall mounting case with rain shelter and frame for 1 module 20-6916-7540 PL 92 aluminium wall mounting case with rain shelter and frame for 2 modules 20-6916-7570 PL 93 aluminium wall mounting case with rain shelter and frame for 3 modules...
- Page 30 Issue 1.00 Doortello Home User guide Page 30...
- Page 31 Issue 1.00 Doortello Home User guide This symbol indicates that this electric device has to be collected separatly and not disposed with the normal home waste. The european union has arranged a collect and recycling system where the manufacturer are responsible for the disposal of this equipment. This devices has been manufactured using high-quality and recycleable materials and components.
- Page 32 Issue 1.00 Doortello Home User guide Your dealer: Energie- und Kommunikationssysteme GmbH Lessing Str. 20, 63110 Rodgau, Deutschland Tel. +49- (0) 6106 - 6600-0 Fax +49-(0) 6106 - 6600-66 HOTLINE +49-(0)6106-646041 E-Mail: info@rocom-gmbh.de http://www.rocom-gmbh.de Page 32...
