Easy-Load Desktop-Thermal Printer
GPT-4378-FLASH-70-iBT
Elektronik und
Feinwerktechnik GmbH
Modules and devices for input,
analysis, display and printing of
analog and digital data.
GeBE Document No.
SMAN-E-689-V1.1
®
Bluetooth
wireless technology
Status: 28.11.2011
Printed: 28.11.2011
German: SMAN-D-688
Article No. 13255
Operating Instructions
GeBE Contacts
Printers: GeBE Elektronik und Feinwerktechnik GmbH • Email: sales.ef@gebe.net • www.oem-printer.com
Keyboards: GeBE Computer & Peripherie GmbH • Email: sales@tastaturen.com • www.tastaturen.com
Internet Applications: www.GeBE.net
The GeBE logo is a registered trademark of GeBE Elektronik und Feinwerktechnik GmbH. All other brands named in this brochure are properties of the respective
companies. Errors and changes reserved. The technical data given are non-committal information and do not represent any assurance of certain features.
Our terms of payment and delivery apply. Copyright © 2011 GeBE Elektronik und Feinwerktechnik GmbH. All rights reserved.
GeBE Elektronik und Feinwerktechnik GmbH
Beethovenstr. 15 • 82110 Germering • Germany • www.oem-printer.com
Phone: +49 (0)89/894141-31 • Fax: +49 (0)89/8402168 • E-Mail: sales.ef@gebe.net
GeBE E + F GmbH • www.oem-printer.com • GeBE Doc. No.: SMAN-E-689-V1.1 • Thermal Printer GPT-4378-FLASH-70-iBT
Advertisement
Table of Contents
Related Manuals for GeBe GPT-4378-FLASH-70-iBT
Summary of Contents for GeBe GPT-4378-FLASH-70-iBT
-
Page 1: Bluetooth Wireless Technology
GeBE Elektronik und Feinwerktechnik GmbH Beethovenstr. 15 • 82110 Germering • Germany • www.oem-printer.com Phone: +49 (0)89/894141-31 • Fax: +49 (0)89/8402168 • E-Mail: sales.ef@gebe.net GeBE E + F GmbH • www.oem-printer.com • GeBE Doc. No.: SMAN-E-689-V1.1 • Thermal Printer GPT-4378-FLASH-70-iBT... -
Page 2: Copyrights
Our terms of payment and delivery apply. Copyright © 2011 GeBE Elektronik und Feinwerktechnik GmbH. All rights reserved. GeBE E + F GmbH • www.oem-printer.com • GeBE Doc. No.: SMAN-E-689-V1.1 • Thermal Printer GPT-4378-FLASH-70-iBT... -
Page 3: Table Of Contents
Detailed information on our warranty is part of our terms of delivery and payment, which can be seen and downloa- ded at www.oem-printer.com/lzb. GeBE E + F GmbH • www.oem-printer.com • GeBE Doc. No.: SMAN-E-689-V1.1 • Thermal Printer GPT-4378-FLASH-70-iBT... -
Page 4: Specification
® GeBE-FLASH for iOS is compatible with iPod touch (2nd generation), iPhone 3G, iPhone 3GS, iPhone 4 and iPad. GeBE E + F GmbH • www.oem-printer.com • GeBE Doc. No.: SMAN-E-689-V1.1 • Thermal Printer GPT-4378-FLASH-70-iBT... -
Page 5: Safety Instructions
Do not put heat sensitive objects close to this heat source. • Avoid constant high humidity and condensation. Protect the device from being splashed and from getting in contact with chemicals. GeBE E + F GmbH • www.oem-printer.com • GeBE Doc. No.: SMAN-E-689-V1.1 • Thermal Printer GPT-4378-FLASH-70-iBT... -
Page 6: Description
Power Functions Interfaces Options The printer GeBE FLASH® for iOS is (see Article equipped with the Controller GCT-4370 (different low) options possible) 13150 GPT-4378-FLASH-70-iBT GeBE E + F GmbH • www.oem-printer.com • GeBE Doc. No.: SMAN-E-689-V1.1 • Thermal Printer GPT-4378-FLASH-70-iBT... -
Page 7: Packing List
OEM Options on request: • Custom housing color, design foil • Program versions and special character sets • Operation with externally charged batteries or non-rechargeable batteries GeBE E + F GmbH • www.oem-printer.com • GeBE Doc. No.: SMAN-E-689-V1.1 • Thermal Printer GPT-4378-FLASH-70-iBT... -
Page 8: Connecting The Printer
The printer is switched off by holding down the "OFF/ NEXT" button for >3 seconds. It is turned on by pressing the FEED/ENTER button or by connecting the charger. GeBE E + F GmbH • www.oem-printer.com • GeBE Doc. No.: SMAN-E-689-V1.1 • Thermal Printer GPT-4378-FLASH-70-iBT... -
Page 9: Interface
The BlueRS+I complies with part 15 of the FCC rules and with RSS-210 of Industry Canada. ® The BlueRS+I has been qualified as a product in accordance with the Bluetooth Qualification Program (BQP). GeBE E + F GmbH • www.oem-printer.com • GeBE Doc. No.: SMAN-E-689-V1.1 • Thermal Printer GPT-4378-FLASH-70-iBT... -
Page 10: Maintenance
Long preservation Paper for Documents is a paper that preserves its printed image for at least 5 years or max. 25 years, if stored dark and dry. GeBE E + F GmbH • www.oem-printer.com • GeBE Doc. No.: SMAN-E-689-V1.1 • Thermal Printer GPT-4378-FLASH-70-iBT... -
Page 11: Exchanging Battery
11 Paper tear-off bar 12 Print head 13 Paper sensor Never use sharp objects for cleaning. This might cause damage to the print head. GeBE E + F GmbH • www.oem-printer.com • GeBE Doc. No.: SMAN-E-689-V1.1 • Thermal Printer GPT-4378-FLASH-70-iBT... -
Page 12: Key Functions
(default = power-off after one second) not pressed key released after < 1s in nor- call T1 mal paper mode performing 104 hex zero (termination of interrupted graphic print) GeBE E + F GmbH • www.oem-printer.com • GeBE Doc. No.: SMAN-E-689-V1.1 • Thermal Printer GPT-4378-FLASH-70-iBT... -
Page 13: Status Messages Through Leds
Vp too high "M" "m" Parity error "?" 1:31 / M green Parity or framing error / no interruption of printing GeBE E + F GmbH • www.oem-printer.com • GeBE Doc. No.: SMAN-E-689-V1.1 • Thermal Printer GPT-4378-FLASH-70-iBT... -
Page 14: Character Sets
7 x 16 IBM II 90° 16 x 11 16 x 24 14 x 22 27 11 x 22 ASCII+UTF-8 16 x 24 24 GeBE E + F GmbH • www.oem-printer.com • GeBE Doc. No.: SMAN-E-689-V1.1 • Thermal Printer GPT-4378-FLASH-70-iBT... -
Page 15: App For Ipod / Iphone / Ipad
• Change of the character height from NORMAL up to 7 times higher. g) Current software version of the App. HINT: Settings described under c) to f) are active for "Print Text" only! GeBE E + F GmbH • www.oem-printer.com • GeBE Dok.Nr.: SMAN-E-689-V1.1 Thermal Printer GPT-4378-FLASH-70-iBT... -
Page 16: Function Of App: Gebe Printer
2. Sub menu "Print Text" 4. Sub menu "Print Image" serves to edit, save and print out a text. serves to select and print out a stored image. GeBE E + F GmbH • www.oem-printer.com • GeBE Dok.Nr.: SMAN-E-689-V1.1 Thermal Printer GPT-4378-FLASH-70-iBT... - Page 17 A printer option will be activated by setting its switch to "ON" position. HINT: Some of the settings will be stored in the printer GPT-4378-FLASH-70-iBT until restart. Restart the printer by switching off/on. GeBE E + F GmbH • www.oem-printer.com • GeBE Dok.Nr.: SMAN-E-689-V1.1 Thermal Printer GPT-4378-FLASH-70-iBT...
-
Page 18: Error Detection And Recovery
Test printout: Is triggered by holding down the FEED feed key for more than 3 seconds after reactivation from po- wer OFF (switching off with the OFF/NEXT key). GeBE E + F GmbH • www.oem-printer.com • GeBE Doc. No.: SMAN-E-689-V1.1 • Thermal Printer GPT-4378-FLASH-70-iBT... -
Page 19: Ce Certification
The failure-free operation of the printer (assessment criterion A) is achieved, when all printed information remains recognizable in case of a short-time failure, and the printer, on the other hand, returns to its normal functional status afterwards. GeBE E + F GmbH • www.oem-printer.com • GeBE Doc. No.: SMAN-E-689-V1.1 • Thermal Printer GPT-4378-FLASH-70-iBT... -
Page 20: Technical Data
76.8 x 77.4 x 39.3 Weight app. 350 g incl. paper roll Housing PC-ABS, similiar RAL 9011 Norms CE: see declaration of conformity 17 Mechanical Dimensions GeBE E + F GmbH • www.oem-printer.com • GeBE Doc. No.: SMAN-E-689-V1.1 • Thermal Printer GPT-4378-FLASH-70-iBT...
