Easy-Load Desktop-Thermal Printer
GPT-4378 /-4379
GeBE-FLASH
RS232 • Infrared • USB • Bluetooth
Real Time Clock • Magnetic Card Reader
®
OPD-Menue
• Intelligent Power Management
Operating Instructions
Printers: GeBE Elektronik und Feinwerktechnik GmbH • Email: sales.ef@gebe.net • www.oem-printer.com
Keyboards: GeBE Computer & Peripherie GmbH • Email: sales@tastaturen.com • www.tastaturen.com
The GeBE logo is a registered trademark of GeBE Elektronik und Feinwerktechnik GmbH. All other brands named in this brochure are properties of the respective
companies.Errors and changes reserved. The technical data given are non-committal information and do not represent any assurance of certain features.
Our terms of payment and delivery apply. Copyright © 2011 GeBE Elektronik und Feinwerktechnik GmbH. All rights reserved.
GeBE Elektronik und Feinwerktechnik GmbH
Beethovenstr. 15 • 82110 Germering • Germany • www.oem-printer.com
Phone: +49 (0)89/894141-31 • Fax: +49 (0)89/8402168 • E-Mail: sales.ef@gebe.net
GeBE E + F GmbH • www.oem-printer.com • SMAN-E-471-V2.5 • Thermal Printer GPT-4378 /-4379
Robust Housing
Activities at GeBE
Internet Applications: www.GeBE.net
Feinwerktechnik GmbH
®
®
GeBE Document No.
SMAN-E-471-V2.5
Status: 12.08.2011
Printed: 12.08.2011
German: SMAN-D-470
Elektronik und
Modules and devices for input,
analysis, display and printing of
analog and digital data.
®
Advertisement
Table of Contents
Related Manuals for GeBe FLASH GPT-4378
Summary of Contents for GeBe FLASH GPT-4378
-
Page 1: Operating Instructions
Internet Applications: www.GeBE.net The GeBE logo is a registered trademark of GeBE Elektronik und Feinwerktechnik GmbH. All other brands named in this brochure are properties of the respective companies.Errors and changes reserved. The technical data given are non-committal information and do not represent any assurance of certain features. -
Page 2: Table Of Contents
Documents or Internet links are marked with a , referring to more detailed or additional information. GeBE E + F GmbH • www.oem-printer.com • SMAN-E-471-V2.5 • Thermal Printer GPT-4378 /-4379... -
Page 3: Safety Instructions
All parts included are listed in the chap- ter "Packing List", while the original accessories are listed in the chapter "Parts and Accessories ". GeBE E + F GmbH • www.oem-printer.com • SMAN-E-471-V2.5 • Thermal Printer GPT-4378 /-4379... -
Page 4: Description
17 Battery connector pair, 6pin 18 Magnetic card update connection, 5 pin 19 Magnet card reader *) In this document, features are specific to printer ver- sions: GPT-4378 or GPT-4379. GeBE E + F GmbH • www.oem-printer.com • SMAN-E-471-V2.5 • Thermal Printer GPT-4378 /-4379... -
Page 5: Available Printer Equipment Of The Series Gpt-437X
GPT-4378-Flash-HP - Before the initial operation, please familiarize yourself with the chapter "Safety Instructions". - The characteristics of your supply voltage must match the device characteristics. GeBE E + F GmbH • www.oem-printer.com • SMAN-E-471-V2.5 • Thermal Printer GPT-4378 /-4379... -
Page 6: Connecting The Printer
30 printer drivers. minutes and switches to preservation charge. In this case please start to charge again by reputting. GeBE E + F GmbH • www.oem-printer.com • SMAN-E-471-V2.5 • Thermal Printer GPT-4378 /-4379... -
Page 7: Interfaces
• NON parity bit • odd, even, non parity bit • 1 stop bit • 1, 2 stop bit • TX line on • TX line turned ON/OFF GeBE E + F GmbH • www.oem-printer.com • SMAN-E-471-V2.5 • Thermal Printer GPT-4378 /-4379... -
Page 8: Infrared Interfaces
IrDA: automatic setting in accordance with IrDA ; 9,600, 38,400, Interface parameters 57,600 or 115,200 Baud GeBE-IR GeBE IR-Protocol: 9,600; 38,400; 57,600; or 115,200 baud, Interface parameters 8 data bits, non parity, 1 stop bit GeBE E + F GmbH • www.oem-printer.com • SMAN-E-471-V2.5 • Thermal Printer GPT-4378 /-4379... -
Page 9: Hp Ir Interface
NEXT/OFF key. older, slower printers from being overrun with data. GeBE E + F GmbH • www.oem-printer.com • SMAN-E-471-V2.5 • Thermal Printer GPT-4378 /-4379... -
Page 10: Usb Interface
USB suspend / printer sleeping 300 µA Never activate an action in the printer driver at the end of a job. This can cause a loss of data. GeBE E + F GmbH • www.oem-printer.com • SMAN-E-471-V2.5 • Thermal Printer GPT-4378 /-4379... -
Page 11: Bluetooth® Wireless Technology
The BlueRS+I complies with part 15 of the FCC rules and with RSS-210 of Industry Canada. ® The BlueRS+I has been qualified as a product in accordance with the Bluetooth Qualification Program (BQP). GeBE E + F GmbH • www.oem-printer.com • SMAN-E-471-V2.5 • Thermal Printer GPT-4378 /-4379... -
Page 12: Operation: Inserting Paper
Long preservation Paper for Documents is a paper that preserves its printed image for at least 5 years or max. 25 years, if stored dark and dry. GeBE E + F GmbH • www.oem-printer.com • SMAN-E-471-V2.5 • Thermal Printer GPT-4378 /-4379... - Page 13 • Other stubborn debris can also be removed with a Q-tip (IPA). Never use sharp objects for cleaning. This might cause damage to the print head. GeBE E + F GmbH • www.oem-printer.com • SMAN-E-471-V2.5 • Thermal Printer GPT-4378 /-4379...
-
Page 14: Key Functions
Key FEED/ENTER Key OFF/NEXT Action pressed not pressed increasing the parameter not pressed pressed moving to the next menu item pressed pressed leaving menu and saving settings GeBE E + F GmbH • www.oem-printer.com • SMAN-E-471-V2.5 • Thermal Printer GPT-4378 /-4379... - Page 15 (Dependiong on type of printer) 48 mm, ..32 mm ? Return to default settings Press ENTER to change Press NEXT to skip Press NEXT+ENTER to save and exit GeBE E + F GmbH • www.oem-printer.com • SMAN-E-471-V2.5 • Thermal Printer GPT-4378 /-4379...
- Page 16 01 .. 07, * day to the adjusted time an alarm is called 00 .. 23, * Hour : Minute : 00 .. 59, * ON, OFF Mode: GeBE E + F GmbH • www.oem-printer.com • SMAN-E-471-V2.5 • Thermal Printer GPT-4378 /-4379...
-
Page 17: Status Messages Through Leds
Charging voltage (line) LED is on if voltage is higher than 9 - 10 V in order to signal a valid charging Charging Voltage LED on yellow voltage. GeBE E + F GmbH • www.oem-printer.com • SMAN-E-471-V2.5 • Thermal Printer GPT-4378 /-4379... -
Page 18: Batch Files
Program tinit with GE-xxxx... {Comments} Creating and Saving Logos: <ESC>s@PROG<00h><11h> A special printer driver is available for crea- <ESC>r1<28h><3Ch><01h><12h> {charging parameters} ting logos. <A9h><01h><3Ch><01h><40h> <19h><01h><85h><0Ah><8Ch> All programmed! GeBE E + F GmbH • www.oem-printer.com • SMAN-E-471-V2.5 • Thermal Printer GPT-4378 /-4379... -
Page 19: Magnetic Card Reader (Optional)
1 111100 Direction of swipe 1 011101 0 111101 0 011110 > 0 111110 ^( field) 0 011111 ? (end) 1 111111 ALPHA Character Track 1 GeBE E + F GmbH • www.oem-printer.com • SMAN-E-471-V2.5 • Thermal Printer GPT-4378 /-4379... -
Page 20: Character Sets
IBM II 9 x 22 IBM II 7 x 16 IBM II 90° 16 x 11 16 x 24 14 x 22 27 11 x 22 GeBE E + F GmbH • www.oem-printer.com • SMAN-E-471-V2.5 • Thermal Printer GPT-4378 /-4379... -
Page 21: Accessories And Spare Parts
14 Service and Maintenance Documentation about the System GPT-437x-FLASH All further documents can be found on the Internet at www.oem-printer.com/flash. The software manual SoMAN-E-485 in English bzw. 484 in German is available from GeBE via email (sales.ef@gebe.net). Service ( GeBE Technical Support) For service or questions, please contact: GeBE Elektronik und Feinwerktechnik GmbH, Beethovenstr. -
Page 22: Error Detection And Recovery
- restart printer and type in right pin code (0000). The printout stops after a short Wrong COM port settings Set virtual COM port according to installation instructions. time or is constantly repeated. GeBE E + F GmbH • www.oem-printer.com • SMAN-E-471-V2.5 • Thermal Printer GPT-4378 /-4379... -
Page 23: Ce Certification
GeBE E + F GmbH • www.oem-printer.com • SMAN-E-471-V2.5 • Thermal Printer GPT-4378 /-4379... -
Page 24: Technical Data
HP IR Protocol: app. 800 baud, only reception parameters GeBE IR Protocol: 9,600, 38,400, 57,600, or 115,200 baud, 8 data bits, non parity, 1 stop bit IrDA: automatic setting acc. to IrDA ; 9,600, 38,400, 57,600 or 115,200 baud Magnetic card reader (option)
