High Definition Digital Television Recorder

Connection to a Standard-Definition television set

1. You must connect the television set to your recorder using a SCART connector (not supplied).
2. To connect other devices to the recorder (home theatre cinema...), refer to the following sections.
3. Connect the power adaptor to the power cable. Then, connect the power cable into the 12V connector
on the recorder.
4. Plug the power cord into the wall socket.

Connection to a VCR/DVD recorder

See the diagram below to connect your recorder to a VCR/DVD recorder.
Note
If your VCR/DVD recorder has more than one SCART connector, choose the
TV or EXT1 socket.
