Summary of Contents for Team Losi 22SCT

  • Page 2: Table Of Contents

    Contents ....................3 Limited Warranty ..................10 FCC Information ..................11 Tools Included ..................3 Needed to Complete.................3 IC Information ..................11 Spektrum DX2L Transmitter ..............4 Compliance Information for the European Union ........12 Installing the Battery ................5 Appendix ....................43 Replacement Parts ..................45 Control Test ....................6 Driving Precautions ..................6...

  • Page 3: Contents

    1/10-Scale Ready To Compete 22SCT • Spektrum DX2L 2.4GHz DSM Radio System (SPMR2400) ™ ® • Spektrum SR3520 DSM2 3-Channel Micro Race Receiver (SPMSR3520) ® • Dynamite Platinum Sensored Brushless ESC, 13.5T Limit (DYNP1001) ® • Dynamite Platinum 17.5T Sensored Brushless Motor (DYNP1017) •...

  • Page 4: Spektrum Dx2L Transmitter

    SPektrum dx2l trAnSmitter 1. Steering Wheel controls direction (left/right) of the model 2. Throttle Trigger controls speed and direction (forward/brake/reverse) of the model 3. R.O.S.S. Button used with vehicles featuring the R.O.S.S. Remote Start System 4. Antenna transmits the signal to the model TH LIMIT 5.

  • Page 5: Installing The Battery

    ADJuSTING THE STEERING TRIM ADJuSTING THE THROTTlE TRIM The steering trim dial is used to adjust the steering trim when The throttle trim dial adjusts the throttle trim when the throttle the wheel is centered. Rotating the dial changes the steering trigger is at neutral (center).

  • Page 6: Control Test

    control teSt fORWARD BRAkE/REvERSE Perform a control test with the vehicle wheels off of the ground. If the tires rotate after the vehicle is powered-on, adjust the “TH. Trim” knob located to the lower left of the steering wheel until they stop. To make the wheels move forward, pull the trigger.

  • Page 7: Recalibrating And Adjusting The Esc (Dynp1001)

    recAlibrAting And AdjuSting the eSc (dynP1001) 4. The red LED flashes when you enter a menu. The number of flashes corresponds to the current selection. 5. Quickly press the Setup button to change the menu option. 6. After you select a menu option, press and hold the Setup button to confirm the selection.

  • Page 8: Changing Between Blinky And Timing Modes

    OpTIMIzED pERfORMANCE fOR DIRT CONDITIONS 4. Use the 2.5mm Hex Wrench (“L” shaped) to loosen the 2 screws securing The 22SCT has been tested and developed to optimize the performance the motor 1 turn each, then slide the motor away from the spur gear.

  • Page 9: Troubleshooting Guide

    To change to the Timing Mode 15° Motor Timing 1. Remove the body from the vehicle. 2. Use the 2mm Hex Wrench (“L” shaped) to loosen the 3 motor end plate screws 2 turns each. 3. Rotate the motor end plate clockwise until the line on the end plate is matched to the 2nd line on the “-”...

  • Page 10: Limited Warranty

    limited WArrAnty WArrAnty ServiceS WHAT THIS WARRANTY COvERS QuESTIONS, ASSISTANCE, AND REpAIRS Horizon Hobby, Inc. (“Horizon”) warrants to the original purchaser that the Your local hobby store and/or place of purchase cannot provide warranty product purchased (the "Product") will be free from defects in materials support or service.

  • Page 11: Fcc Information

    2.400 GHz to 2.4835 GHz frequency range. ANTENNA SEpARATION DISTANCE When operating your Spektrum transmitter, please be sure to maintain a separation distance of at least 5 cm between your body (excluding fingers, hands, wrists, ankles and feet) and the antenna to meet RF exposure safety requirements as determined by FCC regulations.

  • Page 12: Compliance Information For The European Union

    This product must not be disposed of with other waste. Instead, it is the user’s responsibility to dispose of their waste equipment by handing it over to Product(s): TLR 22SCT RTC (includes Spektrum DX2L Transmitter a designated collections point for the recycling of waste electrical and electronic with Spektrum SR3520 Receiver) equipment.
