Aastra 9133i Administrator's Manual

Sip ip phone release 1.0
Hide thumbs Also See for 9133i:
Table of Contents

Advertisement

Quick Links

See also: User Manual , Installation Manual
9133i SIP IP PHONE
Release # 1.0
ADMINISTRATOR
GUIDE

Advertisement

Table of Contents
loading

Related Manuals for Aastra 9133i

Summary of Contents for Aastra 9133i

  • Page 1 9133i SIP IP PHONE Release # 1.0 ADMINISTRATOR GUIDE...
  • Page 2 Software in object form solely with the Equipment for which the Software was intended. This Product may integrate programs, licensed to Aastra by third party Suppliers, for distribution under the terms of this agree- ment. These programs are confidential and proprietary, and are protected as such by copyright law as unpublished works and by international treaties to the fullest extent under the applicable law of the jurisdiction of the Customer.

  • Page 3: Table Of Contents

    Table of Contents Overview .......................1 General Requirements ................1 About this Guide ..................1 Methods of Installation ................2 9112i IP Phone Set up ..................2 The 9112i’s Options List ................3 9112i IP Phone Configuration ..............6 Network .......................6 TFTP Server Settings .................7 SIP settings ....................7 Setting Parameters through Configuration Files .........8 Setting Parameters –...

  • Page 4: Overview

    SIP partners who need to understand 9133i IP Phone. It also includes how to install the 9133i on a SIP details on the functioning and network. Prior knowledge of IP configuration of the 9133i IP Phone.

  • Page 5: Methods Of Installation

    Methods of Installation The firmware set up and installation for the 9133i can be done through the Options List available directly from the phone or through the Aastra 9133i Web Client web interface. When the 9133i is initialized for the first time, DHCP is enabled by default.

  • Page 6: 9112I Ip Phone Set Up

    9133i IP Phone Set up The 9133i’s Options List 1. Press the I button on the When the 9133i is first plugged in or restarted it will automatically phone to enter the options list. download any firmware updates for 2. To go to an Option, use the V the phone.
  • Page 7 5. User Name 1. DHCP This is used in the name field of This turns DHCP on or off. IP the SIP URI for the 9133i IP Phone Address, Subnet Mask and and for registering the 9133i at the Gateway options are registrar.
  • Page 8 • The USER category contains user phone. configurable sub-categories Restart and Password. This sec- • If the settings for the 9133i on the tion is accessed through the user IP PBX system had been modi- level or the administrator level fied.

  • Page 9: 9112I Ip Phone Configuration

    DHCP and The Network and SIP options uncheck to indicate that you do within the 9133i IP Phone can be not want to use DHCP. configured from the phone or from the Aastra 9133i Web Client web 4.

  • Page 10: Tftp Server Settings

    Options List. corresponding fields. 2. Select option 9. SIP Settings. TFTP Server Settings 3. Enter the administrator’s The 9133i IP Phone uses the TFTP to password. The default password download updates of the phone’s is 22222. firmware and configuration files.

  • Page 11: Setting Parameters Through Configuration Files

    Note: At this point modifications performed to the User name, Screen name, Authenti- cation name and Password affect line 1 of the 9133i only. Modifications to the other lines should be done through the <mac>.cfg file. Setting Parameters through Configuration Files The following are the parameters that can be used to configure the 9133i...

  • Page 12: Setting Parameters - Network Settings

    Description network information. The DHCP server should serve the network information that the 9133i requires. If the 9133i is unable to get any required information then it should be entered manually. Parameters affected: ip. Use “0” to disable DHCP and “1” to enable...
  • Page 13 Parameter – Configurable through the9133i’s Options default gateway List, the Aastra 9133i web client or through the configuration files Description The IP address of the network's gateway or the router IP address Format IP address Default Value 1.0.0.1 Range Not Applicable default gateway: 192.168.0.1...
  • Page 14 Parameter – tftp server Configurable through the 9133i's Options List, the Aastra 9133i web client or through the configuration files Description The TFTP server’s IP address. If DHCP is enabled and the DHCP server provides the information, this field is automatically populated.

  • Page 15: Setting Parameters - Time Server Settings

    Setting Parameters – Time Server Settings The following section contains the parameters to configure settings specific to the timeserver. Parameter – Configurable through the 9133i's Options time server disabled List or the configuration files Description This parameter enables or disables the time server.
  • Page 16 Range Not Applicable Example time server3: 192.168.0.5 Parameter – Configurable through the 9133i's Options time format List or the configuration files Description This parameter changes the time to 12 hour or 24 hour format. Use “0” for the 12 hour format and “1”...

  • Page 17: Setting Parameters - Sip Authentication

    9133i to the targeted user. This parameter’s IP address will be the address of the proxy server that the 9133i will use to send all SIP requests to Format IP address or fully qualified host name Default Value 0.0.0.0...
  • Page 18 Parameter – Configurable through the 9133i’s Options sip registrar port List, the Aastra 9133i web client or through the configuration files Description The registrar's port number Format Integer Default Value 5060 Range Not Applicable Example registrar port: 5060 Parameter –...
  • Page 19 Options List or the Aastra 9133i web client affect the first line only. Description The value for this parameter is used in the name field of the SIP URI for the 9133i phone and for registering the 9133i at the registrar. Format Text...
  • Page 20 Parameter – Configurable through the configuration files. sip lineN screen name Configurations done through the 9133i's Options List or the Aastra 9133i web client affect the first line only. Description This is used to display text on the screen of the phone.

  • Page 21: Setting Parameters - Programmable Key Settings

    There are 7 keys that can be configured. These parameters can be configured either from the Aastra.cfg, the <mac>.cfg file or the 9133i IP Phone. The most recently updated file will be used on the 9133i IP Phone when it is restarted. This is typically the <mac>.config file.

  • Page 22: Firmware Upgrade

    Firmware Upgrade From the 9133i IP Phone: 1. Press the I button to enter The 9133i IP Phone uses a TFTP server to download configuration the Options List. files and firmware. The TFTP server 2. Select 10. Phone Status. should be ready and be able to 3.
  • Page 23 4. In the TFTP server IP field enter the IP address of the computer hosting the TFTP server. 5. After entering the information into the appropriate fields click on the “Download Firmware” button. This starts the upgrade process. If the upgrade is successful you are presented the successful message. Model 9133i SIP Admin Guide...

  • Page 24: Troubleshooting

    Check that the SIP settings are firmware and the phone cannot correct in the 9133i IP Phone. If locate the application locally, this using the configuration files, this message is displayed.

  • Page 25: How To Set The 9112I Ip Phone To Factory Default

    How to set the 9133i IP Phone to factory default? From the 9133i IP Phone: 1. Press the I button to enter the Options List. 2. Select 10. Phone Status. 3. Select 5. Factory Default. 4. Enter the administrator password and press s.

  • Page 26: Appendix A: Configuring The 9112I At The Asterisk Ip Pbx

    Appendix A: Configuring the 9133i at the Asterisk IP PBX The following configuration illustrates how to create a user with an extension to make and receive calls using the Asterisk as the PBX. This configuration is defined in the “sip.conf” file present along with the other configuration files that are created when Asterisk is installed.
  • Page 27 5060 Unmonitored This completes the basic set-up for the 9133i IP Phone with 1234 extension at the Asterisk IP PBX system. Refer to Asterisk documentation for set-up on extended or advanced features such as voice mail and call forwarding, etc.

  • Page 28: Appendix B: Sample Configuration Files

    # from the TFTP server while restarting, the “aastra.cfg” file and # the “[mac].cfg” file. These two configuration files can be used to # configure all of the settings of the Aastra 9133i IP Phone with the # exception of assigning a static IP address to a phone and line # settings, which can only be set in the “<mac>.cfg”...
  • Page 29 =========================== #sip registration period: 300 # Eg. every 300 seconds, a re-register # request is sent to the SIP server. #sip rtp port: 3000 # Eg. RTP packets are sent to port 3000. #---------------------------------------------------------------------- Continued... Model 9133i SIP Admin Guide...
  • Page 30 1 = true, means the time server is disabled. #---------------------------------------------------------------------- Line Settings ============= # Lines should be set in the <mac>.cfg file since these settings # are unique to each phone. See the sample “<mac>.cfg” file for # for more information. #---------------------------------------------------------------------- Model 9133i SIP Admin Guide...
  • Page 31 # Notes: There are a maximum of 7 programmable keys that can be configured # on the 9133i IP Phone. These can be set up through either of the 2 # configuration files, depending on whether this is to be server # wide (“aastra.cfg”) or phone specific (“[mac].cfg”).
  • Page 32 “CallFwdOff” prgkey4 value: *73 prgkey5 type: speeddial prgkey5 label: “DND On” prgkey5 value: *78 prgkey6 type: speeddial prgkey6 label: “DND Off” prgkey6 value: *79 prgkey7 type: speeddial prgkey7 label: “CLIDBlock” prgkey7 value: *67 Model 9133i SIP Admin Guide...
  • Page 33 # This file contains sample configurations for the “<mac>.cfg” # file. Please rename this file with the MAC address (with the # dashes removed) of the specific 9133i device that you want to # configure, for example “00085d03059f.cfg”. # Settings that have already appeared in “aastra.cfg” will be # overridden by those in this file.
  • Page 34 #sip line1 password: # SIP Registrar request passcode. #sip line1 user name: # This parameter value is used by the 9133i # in the From header field of the outgoing # SIP packet. It may be replaced by your # registrar.
  • Page 35 # Notes: There are a maximum of 7 keys that can be configured # on the 9133i phone. These can be set up through either of the 2 # configuration files, depending on whether this is to be server # wide (“aastra.cfg”) or phone specific (“[mac].cfg”).

  • Page 36: Appendix C: Tftp Server Set-Up

    Consult PumpKIN’s documentation if you need more information on how to set-up the TFTP server. To download this software, go to www.google.com and enter the keywords “pumpkin TFTP server” You should find a link to a site where you can download the software. Model 9133i SIP Admin Guide...

  • Page 37: Limited Warranty

    Outside N orth America, contact your possession. sales representative. Note: Aastra Telecom shall not be liable for Repairs to this product may be made only by the manufacturer and its any incidental or consequential authorized agents, or by others who damages, including, but not limited are legally authorized.
