Personal LCD Display
Operating Instructions
US
WARNING
YOUR FAILURE TO FOLLOW THESE OPERATING INSTRUCTIONS AND THE
SUPPLIED IMPORTANT SAFEGUARDS MAY RESULT IN EYE FATIGUE, EYE
DAMAGE, OR OTHER INJURY.
CAREFULLY READ THESE OPERATING INSTRUCTIONS AND THE SUPPLIED
IMPORTANT SAFEGUARDS, AND BECOME FAMILIAR WITH ALL SAFETY
INSTRUCTIONS FOR THIS PRODUCT.
THIS PRODUCT SHOULD NOT BE USED BY CHILDREN AGE 15 OR YOUNGER.
IF YOU HAVE BEEN DIAGNOSED WITH EYE DISEASE OR EYE INJURY, CONSULT
YOUR DOCTOR BEFORE USE AND DO NOT USE WITHOUT YOUR DOCTOR'S
APPROVAL.
LDI-50B/50BE/D50B/D50BE
© 1999 by Sony Corporation
Advertisement
Table of Contents
Related Manuals for Sony LDI-50B
Summary of Contents for Sony LDI-50B
-
Page 1: Operating Instructions
THIS PRODUCT SHOULD NOT BE USED BY CHILDREN AGE 15 OR YOUNGER. IF YOU HAVE BEEN DIAGNOSED WITH EYE DISEASE OR EYE INJURY, CONSULT YOUR DOCTOR BEFORE USE AND DO NOT USE WITHOUT YOUR DOCTOR’S APPROVAL. LDI-50B/50BE/D50B/D50BE © 1999 by Sony Corporation... - Page 2 WARNING To prevent fire or shock hazard, CAUTION do not expose the unit to rain or To prevent electric shock, match wide blade of plug to wide slot, fully insert. moisture. The supplied interface cable must be used with To avoid electrical shock, do not the equipment in order to comply with the limits open the cabinet.
- Page 3 The model and serial numbers are located at the rear of the power supply box. Record these numbers in the spaces provided below. Refer to them whenever you call upon your Sony dealer regarding this product. Model No. Serial No.
- Page 4 The Personal LCD Display is a brand-new concept in visual display Congratulations on your purchase of a Sony Note on the LCD (Liquid Crystal Personal LCD Display. The Personal LCD Display) Display, using current technology in small, The LCD screen is made with high-precision lightweight visual displays, provides a television technology.
-
Page 5: Table Of Contents
Table of Contents About the Personal LCD Display ........6 Getting Started Locating the parts and controls ........7 Connecting the Personal LCD Display Connecting the video equipment ....... 8 Connecting the power source ........9 Wearing the Personal LCD Display ......10 Operations Using the Personal LCD Display ........ -
Page 6: About The Personal Lcd Display
SHUTTER switch to see the surrounding environment. Power supply box You can use Sony’s recommended optional battery pack. You can also use the house current for viewing or for charging a battery pack. To use the Glasstron, connect your video equipment to A/V IN on the power supply box. -
Page 7: Locating The Parts And Controls
Locating the parts and controls Refer to the pages indicated in parentheses ( ) for details. Display unit Strap release button (10) Earphone slide VOL (volume) button (11) control (12) Earphone (11) SHUTTER switch (13) Power supply box SEL/PUSH EXEC (PUSH DISPLAY) jog dial (14) DC IN connector (9) MENU button (14) -
Page 8: Connecting The Personal Lcd Display Connecting The Video Equipment
Connecting the Personal LCD Display Connecting the video equipment Connect a VCR, laser disc player, DVD player, or camcorder to the power supply box using a commercially available audio/video cables as shown below. VCR, laser disc player, DVD player, camcorder, etc. to audio/video outputs (phono jack) Power supply box... -
Page 9: Connecting The Power Source
Notes • The audio and video signals may not be carried to • When you connect the Personal LCD Display to the Personal LCD Display depending on the video the audio output jacks (phono jacks) of your video source. In this case, contact an authorized service equipment, connect the Personal LCD Display to center. -
Page 10: Wearing The Personal Lcd Display
Wearing the Personal LCD Display WARNING • Failure to properly fit the product each time may result in eye fatigue, eye damage, or loss of visual functions and may result in accident or injury. • This product should not be used by children age 15 or younger. The eyes of children are still developing and may be adversely affected by using this product, and it may cause eye fatigue, eye damage, or loss of visual functions. - Page 11 Adjust the angle of the display unit. While holding the front pad against Front pad your forehead, adjust the angle of the display unit using the two hinges. Move the display unit close to your eyes at a slight downward angle. If you wear glasses, move the display unit as close to °...
-
Page 12: Using The Personal Lcd Display
Using the Personal LCD Display Before you start… Be sure to follow the procedures in “Connecting the Personal LCD Display” (page 8) and “Wearing the Personal LCD Display” (page 10). Turn on the Personal LCD Display using the POWER ON/OFF switch. -
Page 13: Viewing The Surrounding Environment (See-Through)
Viewing the surrounding environment (See-through) While you are wearing the Personal LCD Display, you can view the surrounding environment through the screen by opening the shutter in the display unit. Turn the SHUTTER switch to OPEN. CLOSE OPEN SHUTTER Display unit The picture The area becomes... -
Page 14: Adjusting The Sound And Picture
Adjusting the sound and picture You can adjust the following items using the menu display. BRIGHTNESS: Adjusts the picture brightness. HUE (NTSC mode only): Adjusts the hue, if the picture looks too reddish or greenish. COLOR: Adjusts the color intensity. MEGA BASS: Creates a deep, powerful sound by emphasizing the bass sound. - Page 15 BRIGHTNESS COLOR Turn the jog dial to adjust Turn the jog dial to adjust the brightness, then press the color intensity, then the jog dial. press the jog dial. BRIGHTNESS COLOR EXEC EXEC darker brighter less more HUE (NTSC mode only) MEGA BASS Turn the jog dial to adjust Turn the jog dial to set to...
- Page 16 Adjusting the sound and picture (continued) AVLS (Auto Volume Limiter Resetting the adjustment System) to the factory preset Turn the jog dial to set to level ON, then press the jog dial. Turn the jog dial to select RESET in the menu, then press the jog dial.
-
Page 17: Using The Optional Battery Pack
LITHIUM ION BATTERY. DISPOSE OF PROPERLY. You can return your unwanted lithium ion batteries to your nearest Sony Service Center or Factory Service Center. NOTE: In some areas the disposal of lithium ion batteries in household or business trash may be prohibited. - Page 18 Using the optional battery pack (continued) Battery life (fully charged battery) Charging time NP-F550 Approx. 2 hours 20 minutes Approx. 8 hours NP-F750 Approx. 4 hours 40 minutes Approx. 16 hours NP-F950 Approx. 6 hours Approx. 24 hours * The battery life and charging time may change depending on the conditions of use. * You can also use a battery pack such as the NP-F530/F730/F930 (not supplied) with the Personal LCD Display.
-
Page 19: Precautions
Precautions Installation • Operate the product only with the supplied • To prevent internal heat build-up, do not AC power adapter. If you use a different block the ventilation openings. AC power adapter, it may cause a • Avoid operating the product at temperatures malfunction. - Page 20 Precautions (continued) Others • Upon completion of any service or repairs to the product, ask the service technician to • Unplug the product from the wall outlet and perform routine safety checks (as specified by refer servicing to qualified service personnel the manufacturer) to determine that the under the following conditions: product is in safe operating condition, and to...
-
Page 21: Troubleshooting
Troubleshooting If you have any questions or problems not listed below, contact an authorized service center. Symptom Cause Remedy The playback picture does Connections are incorrect. Connect the equipment correctly not appear. (pages 8 and 9). The picture is dark or You are not wearing the Personal Put on the Personal LCD Display dim. -
Page 22: Index
Audio output S, T, U, V Stereo minijack See-through 13 Stereo earphones 11 Design and specifications are subject to change Surround 14, 15 without notice. W, X, Y, Z Wearing the Personal LCD Display 10, 11 Sony Corporation Printed in Japan...
