INSTALLER/ CONSUMER
SAFETY INFORMATION
PLEASE READ THIS MANUAL
BEFORE INSTALLING AND
USING APPLIANCE
WARNING!
IF THE INFORMATION IN
THIS MANUAL IS NOT
FOLLOWED EXACTLY, A FIRE
OR EXPLOSION MAY RESULT
CAUSING PROPERTY
DAMAGE, PERSONAL INJURY
OR LOSS OF LIFE.
FOR YOUR SAFETY
Installation and service must
be performed by a qualified
installer, service agency or the
gas supplier.
WHAT TO DO IF YOU SMELL
GAS:
•
Do not try to light any
appliance.
•
Do not touch any electric
switch; do not use any phone
in your building.
•
Immediately call your gas
supplier from your neighbor's
phone. Follow the gas
suppliers instructions.
•
If you cannot reach your gas
supplier call the fire
department.
DO NOT STORE
OR USE GASOLINE OR
OTHER FLAMMABLE VAPORS
AND LIQUIDS IN THE VICINITY
OF THIS OR ANY OTHER
APPLIANCE.
INSTALLER: DO NOT DISCARD THIS MANUAL - LEAVE FOR HOMEOWNER
Freestanding
Direct Vent Fireplaces
Models: RFSDV22,
RFSDV32, RFSDV42
Homeowner's Installation and
Operating Manual
CFM Specialty Home Products
410 Admiral Blvd. • Mississauga, Ontario, Canada L5T 2N6 • 905-670-7777
www.majesticproducts.com • www.vermontcastings.com
C E RT I F I E D
10001028 7/04 Rev. 2
Advertisement
Table of Contents
Related Manuals for Vermont Castings RFSDV22
Summary of Contents for Vermont Castings RFSDV22
- Page 1 THIS MANUAL IS NOT FOLLOWED EXACTLY, A FIRE Direct Vent Fireplaces OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY Models: RFSDV22, OR LOSS OF LIFE. RFSDV32, RFSDV42 FOR YOUR SAFETY Installation and service must be performed by a qualified installer, service agency or the gas supplier.
-
Page 2: Table Of Contents
RFSDV22/32/42 Freestanding Direct Vent Fireplace Table of Contents PLEASE READ THE INSTALLATION & OPERATING INSTRUCTIONS BEFORE USING APPLIANCE. Thank you and congratulations on your purchase of a CFM Specialty Home Products fireplace IMPORTANT: Read all instructions and warnings carefully before starting installation. Failure to follow these instruc- tions may result in a possible fire hazard and will void the warranty. -
Page 3: Important Curing/Burn Information
RFSDV22/32/42 Freestanding Direct Vent Fireplace Installation and Operating Instructions This gas fireplace should be installed by a qualified installer in IMPORTANT: accordance with local building codes and with current CSA- PLEASE REVIEW THE FOLLOWING CAREFULLY B149.1 Installation codes for Gas Burning Fireplaces and Remove any plastic from trim parts before turning Equipment and CAN/CSA Z 240.4 Canada. -
Page 4: Fireplace Dimensions
RFSDV22/32/42 Freestanding Direct Vent Fireplace Fireplace Dimensions RFSDV22 RFSDV32 RFSDV42 Fig. 2 Fireplace specifications. Ref. RFSDV22 RFSDV32 RFSDV42 26" (660mm) 25" (635mm) 28¹⁄₄" (717mm) 26" (660mm) 24¹⁄₈" (613mm) 28¹⁄₄" (717mm) 15¹⁄₄" (387mm) 16" (406mm) 17⁷⁄₈" (454mm) 19¹⁄₄" (488mm) 20" (508mm) 22³⁄₄"... -
Page 5: Clearance To Combustibles
RFSDV22/32/42 Freestanding Direct Vent Fireplace High Elevations Clearance to Combustibles Input ratings are shown in BTU per hour and Adequate clearances as listed below must be are certified without deration for elevations up maintained for servicing and proper operation: to 4,500 ft. (1,370 m) above sea level. For elevations above 4,500 ft. -
Page 6: Installation Of Remote Switch For Rn/Rp Gas Valve
RFSDV22/32/42 Freestanding Direct Vent Fireplace Installation of Remote 1/2" Gas Supply Switch for RN/RP Gas Valve 1/2" x 3/8" Reducer Install on/off switch assembly on either the rear right or left side of the Fireplace. 3/8" Nipple 1. Remove the screw at the back of the cabinet top 3/8"... -
Page 7: General Venting Information - Termination Location
RFSDV22/32/42 Freestanding Direct Vent Fireplace General Venting Information - Termination Location INSIDE CORNER DETAIL Fixed Fixed Closed Closed Fixed Operable Closed VENT TERMINATION AIR SUPPLY INLET AREA WHERE TERMINAL IS NOT PERMITTED CFM145a Canadian Installations US Installations A = Clearance above grade, veranda, porch, 12”... -
Page 8: Termination Clearances
RFSDV22/32/42 Freestanding Direct Vent Fireplace Termination Clearances Termination clearances for buildings with combustible and noncombustible exteriors. Inside Corner Recessed Location Outside Corner Combustible 6"(152mm) Combustible 6"(152mm) Noncombustible 2"(50mm) Noncombustible 2"(50mm) Balcony - Balcony - with no side wall with perpendicular side wall C = Maximum depth of 48"... -
Page 9: How To Use The Vent Graph
8 9 10 11 12 13 14 15 16 17 18 19 20 and combustible materials is 1" (25mm) Horizontal Dimension on top, bottom and sides unless other- wise noted. Fig. 8 Sidewall venting graph for use with RFSDV22/32. 10001028... - Page 10 The maximum number of 90° elbows per side wall Fig. 11 Horizontal run reduction. installation is three (3). • For RFSDV22 & RFSDV32 the maximum (610cm) horizontal run off a minimum 12" (305mm) vertical rise is 3' (914mm). (Fig. 10) •...
-
Page 11: Vertical Sidewall Installation
RFSDV22/32/42 Freestanding Direct Vent Fireplace Step 3 Vertical Sidewall Installation Place fireplace into position. (Fig. 16) Measure the Step 1 vertical length (X) required form the base of the flue Locate the vent opening on the wall. It may be neces- collars to the center of the wall opening. -
Page 12: Below Grade Installations (Snorkel)
RFSDV22/32/42 Freestanding Direct Vent Fireplace Support horizontal pipes every 36" (914mm) with metal pipe straps. Check fireplace to make sure it is lev- elled and properly positioned. FP1338 Fig. 18 Measure horizontal venting length plus 2". Step 6 NOTE: If using the charcoal wall plate, Part #52202-... -
Page 13: Vertical Through-The-Roof Applications & Installation
RFSDV22/32/42 Freestanding Direct Vent Fireplace Do Not Back Fill Around Snorkel. Soil Example: Maximum horizontal length Should Not Be Less Than 4" Below elbows 10 ft. (3m) Snorkel. elbows 8.5 ft. (2.6m) elbows 7 ft. (2m) Snorkel Firestop Screws 7" Pipe 4"... - Page 14 RFSDV22/32/42 Freestanding Direct Vent Fireplace 9. Install storm collar and seal around the pipe. 10. Add additional vent lengths for proper height. (Fig. 11. Apply high temperature sealant to 4" and 7" collars of vertical vent termination and install. If there is a room above ceiling level, firestop spacer...
-
Page 15: Twist Lock Venting Components
RFSDV22/32/42 Freestanding Direct Vent Fireplace Twist Lock Venting Components Starter Kit -Model 7TDVSK - Sidewall Venting Starter Kit - Model 7TDVSKV - Vertical Venting for 7TDVSKV-A order 1/12 to 6/12 roof pitch for 7TDVSKV-B order 7/12 to 12/12 roof pitch... -
Page 16: Operating Instructions
RFSDV22/32/42 Freestanding Direct Vent Fireplace Operating Instructions Glass Information Trim Removal Only glass approved by CFM Specialty RFSDV22 Home Products may be used for replace- 1. Remove frame window brass trim by lifting up and ment. out. • The use of substitute glass will void all product 2. -
Page 17: Glass Cleaning
Also initial paint curing may deposit a slight film on the Fig. 32 RFSDV22/32 logs and burner lava rock placement. glass. It is therefore recommended that the glass be RFSDV42 (Fig. 33) -
Page 18: Ceramic Refractory
RFSDV22/32/42 Freestanding Direct Vent Fireplace FP1349 Fig. 35 Bay window ceramic refractory. Burner Lava Rock LG281 Placement Flame Adjustment (RN/RP Models) Fig. 33 RFSDV42 log and burner lava rock placement. For units equipped with Hi/Lo valves, flame adjustment Ceramic Refractory... -
Page 19: Flame Characteristics
Compare them to the Figures 39, 40 and 41. If any of the flames appear abnormal call a service person. 3/8" - 1/2" LG282 Fig. 40 Correct burner flame appearance for RFSDV22 and RFSDV32. SIT Pilot PSE Pilot F584-703 Fig. -
Page 20: Lighting Instructions
RFSDV22/32/42 Freestanding Direct Vent Fireplace Lighting And Operating Instructions FOR YOUR SAFETY READ BEFORE LIGHTING WARNING:If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This heater has a pilot which must be lit manu- instructions. -
Page 21: Troubleshooting
RFSDV22/32/42 Freestanding Direct Vent Fireplace Troubleshooting the Gas Control System SIT 630 Gas Valve NOTE: Before trouble shooting the gas control system, be sure external gas shut off is in the "On" position. WARNING: Before doing any gas control service work, remove glass front. - Page 22 RFSDV22/32/42 Freestanding Direct Vent Fireplace Troubleshooting the Gas Control System Honeywell Millivolt Valve START CHECK Gas Supply On Supply Line Hooked Up Shutoff Valve Open Lockout Has Engaged. Wait 60 Seconds And Try Again. For Spark At Electrode While Pilot Lights With Depressing Piezo 1/8"...
- Page 23 RFSDV22/32/42 Freestanding Direct Vent Fireplace Troubleshooting the Gas Control System SIT NOVA 820 Millivolt Valve NOTE: Before trouble shooting the gas control system, be sure external gas shut off is in the “On” position. WARNING: Before doing any gas control service work, remove glass front.
-
Page 24: Maintenance
RFSDV22/32/42 Freestanding Direct Vent Fireplace Maintenance Burner and Burner Compartment Visually inspect pilot. Brush or blow away any dust or lint accumulation. If pilot orifice is plugged, disassembly It is important to keep the burner and the burner may be required to remove any foreign material from compartment clean. -
Page 25: Replacement
RFSDV22/32/42 Freestanding Direct Vent Fireplace 9 a/b 3a/b 36 a/b 21a,b 8 a/b 7 a/b 25a,b 10a/b 24a,b 1028 CFM Specialty Home Products reserves the right to make changes in design, materials, specifications, prices and discontinue colors and products at any time, without notice. - Page 26 RFSDV22/32/42 Freestanding Direct Vent Fireplace RFSDV22/32/42 Series (continued) Ref.Description RFSDV22 RFSDV32 RFSDV42 Log Set Complete 10000160 10000160 10000205 Log Ember Front Log Front Left Log Front Right Log Rear Log Top Left Log Top Right Burner Lava Rock (Package) 57897...
- Page 27 RFSDV22/32/42 Freestanding Direct Vent Fireplace RFSDV22/32/42 Series (continued) Ref. Description RFSDV22 RFSDV32 RFSDV42 36b. Frame Window - Right Side – 52860 – Frame Window - Front 57244 57244 57590 Bay Window Assy. (w/glass) – – 57593 Trim Frame Window (PB)
-
Page 28: Accessories
RFSDV22/32/42 Freestanding Direct Vent Fireplace Accessories Fan Kits Stud FK24 Standard on RFSDV42 It will be easier to install the fan before connecting the gas line to the fireplace. Thermal Fan is Sensor 1. Open front access door panel by pulling forward on... -
Page 29: Mobile Home Instructions
RFSDV22/32/42 Freestanding Direct Vent Fireplace For Use in Mobile Homes - Model RFSDV32RMH This appliance may be installed as an OEM installation in a manufactured (mobile) home and must be installed in accordance with the manufacturer's instrucitons and the manufactured home construction and safety standard, Title 24 CFR, Part 3280 or Standard for Installation in Mobile Homes, CAN/CSA Z240 MH. -
Page 30: Warranty
LIMITED LIFETIME WARRANTY PRODUCT COVERED BY THIS WARRANTY All Vermont Castings gas stoves, gas inserts, and gas fireplaces, and all Majestic or Northern Flame brand gas fireplaces equipped with an Insta-Flame Ceramic Burner, or standard steel tube burner. BASIC WARRANTY parts and/or labor.
