REACTOR
SPEAKERS
RE-FR4020, RE-FR52520, RE-FR6530, RE-FR6930
Speaker Parameters
Max Power Rating
RMS Power Rating
Frequency Response
Impedance
Sensitivity
Mounting Depth
Mounting Diameter
Installation Guidelines
1) Ensure there is adequate clearance and depth for the speaker to be mounted
2) Use the supplied template to mark out and cut the correct diameter hole
3) Drill four holes for the mounting screws
4) Insert the speaker and grille frame and affix with the screws provided
Warning: Do not drill mounting holes with speaker in place as this could allow drill shavings to damage the voice
coil and void your warranty.
RE-FR4020
RE-FR52520
130 Watts
150 Watts
55 Watts
65 Watts
75Hz - 20kHz
65Hz - 22kHz
4 Ohms
4 Ohms
86 dB
88 dB
54mm (2-1/8")
56.5mm (2-1/4")
101mm
118.5mm
(4")
(4-11/16")
RE-FR6530
RE-FR6930
220 Watts
275 Watts
100 Watts
110 Watts
60Hz - 22kHz
55Hz - 22kHz
4 Ohms
4 Ohms
89 dB
90 dB
65mm (2-9/16")
85mm (3-3/8")
131mm
155 x 224mm
(5-3/16")
(6-1/8 x 8-7/8")
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Fusion RE-FR4020
Summary of Contents for Fusion RE-FR4020
- Page 1 REACTOR SPEAKERS RE-FR4020, RE-FR52520, RE-FR6530, RE-FR6930 Speaker Parameters RE-FR4020 RE-FR52520 RE-FR6530 RE-FR6930 Max Power Rating 130 Watts 150 Watts 220 Watts 275 Watts RMS Power Rating 55 Watts 65 Watts 100 Watts 110 Watts Frequency Response 75Hz - 20kHz 65Hz - 22kHz...
- Page 2 Ensure the audio system is turned off before making any connections to the amplifier, speakers or source unit. Failure to do so could result in permanent damage to the audio system. When wiring the speakers ensure that the wire is protected from sharp objects and always use rubber grommets when wiring through metal panels.
