Summary of Contents for DVIGear DVI-3210a
-
Page 1: User Guide
User Guide DVI-D Fiber Optic Cable VGA to DVI Scaler/Converter DVI-3210a... -
Page 2: Table Of Contents
Table of Contents Section Page 1.0 Introduction ........1 2.0 Specifications . -
Page 3: Introduction
Distribution Amplifiers. Liability Statement Every effort has been made to ensure that this product is free of errors. DVIGear cannot be held liable for the use of this hardware or any direct or indirect consequential damages arising from its use. It is the responsibility of the user of the hardware to check that it is suitable for his/her requirements and that it is installed correctly. - Page 4 Long distances are possible, but special measures should be taken in order to avoid cable losses. These include using high quality (coax-type) VGA cables and premium DVI cables such as DVIGear’s Super High Resolution™ cables. Line amplifiers or repeaters may also be necessary.
-
Page 5: Specifications
SPECIFICATIONS Input Signal Specifications: Input Format Analog RGBHV, YPbPr or YCbCr RGBHV: 0.7 V p-p, 75Ω , H/V: 3 to 5 p-p TTL, Input Signal Y: 1 V p-p 75Ω, Pb/Cb, Pr/Cr: 0.7 V p-p 75Ω Output Format Single-Link DVI-I, RGB serial data bit stream, or Analog RGB,HV Output Signal DVI-A (analog) or DVI-D (digital) Input Connector Type... -
Page 6: Checking Package Contents
Note: Please retain the original packing material should the need ever arise to return the unit. If you find any items are missing, contact your reseller or DVIGear immediately. Please have the Model Number, Serial Number and Invoice Number available for reference when you call. -
Page 7: Operating The Unit
Power Adapter into an AC power receptacle. When AC power is applied in this fashion, the Power LED indicator will illuminate. OPERATING THE UNIT On-Screen Menus The DVI-3210a is controlled via three buttons with status indicated by an On-Screen Display (OSD). DVI OUTPUT 480p... - Page 8 Use the + and- buttons to adjust for least amount of noise in the picture. Input Select: The DVI-3210a will automatically detect and display the input signal format. You can also manually select the input format by selecting either the YPrPb or RGB input mode.
-
Page 9: Troubleshooting
Select to exit from the current menu page. Notes: • The default output resolution of the DVI-3210a is XGA@60 Hz. • The unit has non-volatile memory and memorizes all user settings before Power OFF and recalls those settings on next Power ON; however, changing output resolution erases all settings. -
Page 10: Limited Warranty
The liability of DVIGear with respect to any defective products will be limited to the repair or replacement of such products. In no event shall DVIGear be responsible or... - Page 11 Your Digital Connectivity Experts Toll Free 888.463.9927 DVIGear, Inc. Phone 770.421.6699 1059 Triad Court, Suite 8 Toll Free 888.463.9927 400 Meadowmont Village Circle 770.234.4207 Marietta, Georgia 30062-2258 Phone 919.969.6681 Suite 425 919.869.1310 Chapel Hill, NC 27517 www.dvigear.com www.dvigear.com DVI-3210a-UG-02 / Dec.2008...
