- Page 1 User Guide AV-PC to HDMI Converter / Scaler DVI-3531a...
-
Page 2: Table Of Contents
TABLE OF CONTENTS SECTION PAGE PRODUCT SAFETY ........1 PRODUCT LIABILITY STATEMENT. -
Page 3: Product Safety
Every effort has been made to ensure that this product is free of defects. DVIGear cannot be held liable for the use of this product or for any direct or indirect consequential damages arising from its use. It is the responsibility of the users of this product to check that it is suitable for their requirements and that it is installed correctly. -
Page 4: Introduction
INTRODUCTION The model DVI-3531a is a versatile Converter / Scaler that provides selection of three input signal formats: Component Video, Analog RGB and HDMI (or DVI). Each input format supports its own stereo audio connection. The selected input signal is converted to a digital HDMI signal with embedded audio. -
Page 5: Specifications
SPECIFICATIONS Performance Format Compliance HDMI v1.2, HDCP v1.1, and DVI v1.0 Video Input Formats Component Video: YPbPr / YCbCr; HDMI: RGB; HD15: RGB,H,V Maximum Pixel Clock Frequency 165 MHz Maximum Video Bit Rate 1.65 Gbps (single-link) Supported Color Depth 8-bit Analog Stereo Audio: 20KΩ... - Page 6 Specifications are subject to change without notice. Supported Input Formats and Resolutions The DVI-3531a accepts digital HDMI or DVI (using an adapter cable), as well as analog RGB and analog Component Video via separate input connections. Each input format supports its own dedicated stereo audio connection. The...
-
Page 7: Package Contents
Note: Please retain the original packing material in case you need to return the unit. If you find any items are missing, contact your reseller or DVIGear immediately. Please have the Model Number, Serial Number, and Invoice Number available for reference when you call. -
Page 8: Connecting The Hardware
CONNECTING THE HARDWARE Please study the following front panel and back panel drawings in order to become familiar with connector locations and control functions: 1 Component Video Input: supports YPbPr and YCbCr formats 2 Stereo Audio Input: associated with the Component Video Input 3 Infrared Receiver 4 Status LEDs: indicates selected source type 5 MENU / ENTER: press to access OSD Menus;... - Page 9 Converter / Scaler and the source and destination devices. Cable selection is especially important for long HDMI and DVI cables due to the high bit rates of these digital signals. For best results use DVIGear’s Super High Resolution™ (SHR™) HDMI and DVI cables.
-
Page 10: Operating The Unit
OPERATING THE UNIT The DVI-3531a can be operated either from the front panel controls or via the supplied IR Remote Control unit. Since IR is the control method preferred by most users, please take a moment to familiarize yourself with the location and function of the control buttons on the IR Remote Control unit. - Page 11 Menu Structure The OSD Menu structure is as follows: Secondary High Level Adjustment Level Picture Mode VIDEO User / Standard / Movie / Vivid (HDMI In and 0-100 Relative Contrast Adjustment Contrast Component In) 0-100 Relative Brightness Adjustment Brightness 0-100 Relative Hue Adjustment 0-100 Relative Saturation Adjustment Saturation 0-100 Relative Sharpness Adjustment...
- Page 12 The selection of the Video Menu or PC Menu is made automatically based on the selected input signal. The Video Menu offers additional functions, including Picture Mode, Scale and NR (Noise Reduction). The Picture Mode Function has four settings: User, Standard, Movie and Vivid. When the Picture Mode is set to Standard, Movie or Vivid, the Brightness, Contrast, Hue, Saturation and Sharpness adjustments are set to fixed values in order to optimize the appearance of the image.
-
Page 13: Troubleshooting
Press the EXIT key to escape from the OSD menus. TROUBLESHOOTING In the event that the DVI-3531a Converter / Scaler does not appear to be functioning properly, make certain that the source and all other devices connected to the unit are functioning correctly by connecting each source device directly to a compatible display using a short cable. -
Page 14: Limited Warranty
In no event shall DVIGear be responsible or liable for any damage arising from the use of such defective products, including but not limited to loss of use, revenue or profit, whether such damages are direct, indirect, consequential or otherwise and whether such damages are incurred by the reseller, end user, or any third party. - Page 15 Your Digital Connectivity Experts Toll Free 888.463.9927 DVIGear, Inc. Phone 770.421.6699 1059 Triad Court, Suite 8 770.234.4207 Marietta, Georgia 30062-2258 www.dvigear.com DVI-3531a-UG-03 / March.2017...
