DVIGear DVI-3551a User Manual

Video-pc to hdmi converter / scaler
Hide thumbs
Table of Contents

Advertisement

Quick Links

User Guide
Video-PC to HDMI Converter / Scaler
DVI-3551a

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DVI-3551a and is the answer not in the manual?

Questions and answers

Related Manuals for DVIGear DVI-3551a

Summary of Contents for DVIGear DVI-3551a

  • Page 1 User Guide Video-PC to HDMI Converter / Scaler DVI-3551a...

  • Page 2: Table Of Contents

    Table of ConTenTS SeCTIon PaGe ProDUCT SafeTy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 ProDUCT lIabIlITy .

  • Page 3: Product Safety

    Every effort has been made to ensure that this product is free of defects. DVIGear cannot be held liable for the use of this product or for any direct or indirect consequential damages arising from its use. It is the responsibility of the users of this product to check that it is suitable for their requirements and that it is installed correctly.

  • Page 4: Introduction

    PC and HDTV output resolutions up to 1920x1200 and 1080p/60. Our professional digital distribution products have been serving the industry for over ten (10) years. DVIGear offers a full line of high quality Digital Matrix Routers, Switchers, Splitters, Video Scalers, Up/Down/Cross Converters, Format Converters, Analog-Digital Converters, as well as a wide range of long reach Digital Cables, Extenders, and Optical Transmission systems.

  • Page 5: Specifications

    2 .0 SPeCIfICaTIonS Input Connections HDMI or DVI 1x HDMI female connector, DVI using DVI-8511b Adapter (not included) Analog RGB 1x HD15-pin VGA female connector Analog Component Video 3x RCA female connectors S-Video 1x 4-pin Mini-DIN female connector Composite Video 1x RCA female connector Digital Audio (S/PDIF) 1x RCA female connector...
  • Page 6 2 .1 Supported Input formats and resolutions The DVI-3551a accepts HDMI, DVI, Analog RGB, Analog Component Video, S-Video (Y/C), and Composite Video inputs via rear-panel connectors. The resolutions and formats supported by these inputs are as follows: Vertical rate Scan...
  • Page 7 2 .2 Supported output formats and resolutions The DVI-3551a has a single HDMI output. An internal scaling engine provides user selection of a wide range of output resolutions as listed below: Vertical rate Scan Signal output resolution / format (Hz)

  • Page 8: Package Contents

    Note: Please retain the original packing material should the need ever arise to return the unit. If you find any items are missing, contact your reseller or DVIGear immediately. Please have the Model Number, Serial Number, and Invoice Number available for reference when you call.
  • Page 9 14 S-Video Input (4-pin mini-DIN) 15 +5 VDC Input (connects to external AC Power Adapter) Connect the supplied AC Power Adapter to the DVI-3551a. Use only the furnished power adapter to avoid the possibility of equipment damage. Next, connect the appropriate cables to the Input(s) and Output and power ON the source and destination devices.

  • Page 10: Operating The Unit

    Note: Proper operation of this product depends on the use of the high quality cables. DVIGear’s Super High Resolution (SHR™) cables provide low loss, low jitter, high bandwidth signal handling and are recommended for use with this product.
  • Page 11 5 .1 Manual Control Referring to the front panel image on page 6, the Power and Input selection switches have LEDs above them to indicate that the power is “ON” and/or an Input selection has been made. Simply press the Power switch and then press the appropriate input selection push button.
  • Page 12 Navigate to the specific parameter you wish to adjust and then press the ENTER push button to make the selection. Use the Decrease (-) and Increase (+) push buttons to select a different value for the parameter (e.g., change output resolution or change brightness).
  • Page 13 5 .3 rS-232 Protocol The DVI-3551a is equipped with a RS-232 serial control port. The connection between the DVI-3551a and PC host controller should be made with an RS-232 modem cable. Pin-out of rS-232 Modem Cable...
  • Page 14 5 .4 rS-232 Set Commands: Command Code response Description S POWER 0 > POWER OFF POWER OFF S POWER 1 > POWER ON POWER ON S SOURCE 0 > SOURCE CV CV INPUT S SOURCE 1 > SOURCE SV SV INPUT S SOURCE 2 >...
  • Page 15 5 .4 rS-232 Set Commands: (continued) Command Code response Description S SIZE 0 > SIZE FULL SCALER FULL OUTPUT S SIZE 1 > SIZE OVERSCAN SCALER OVERSCAN OUTPUT S SIZE 2 > SIZE UNDERSCAN SCALER UNDERSCAN OUTPUT S SIZE 3 >...
  • Page 16 5 .5 rS-232 Status Commands: Command Code response Description R POWER > POWER ON SHOW POWER STATUS R SOURCE > SOURCE CV~HDMI SHOW SOURCE STATUS R OUTPUT > OUTPUT NATIVE~SXGA+ SHOW OUTPUT STATUS R SIZE > SIZE FULL~PANSCAN SHOW SIZE STATUS R PICTUREMODE >...

  • Page 17: Troubleshooting

    Should the problem persist after trying the above suggestions, please contact your dealer for additional assistance. Should the dealer’s technical personnel be unable to assist you, please contact DVIGear via telephone at 1.888.463.9927 (Toll-Free for United States and Canada), or 1.770.421.6699. You may contact DVIGear by e-mail at support@dvigear.com.

  • Page 18: Limited Warranty

    The liability of DVIGear with respect to any defective products will be limited to the repair or replacement of such products. In no event shall DVIGear be responsible or...
  • Page 19 Your Digital Connectivity Experts Toll Free 888.463.9927 DVIGear, Inc. Phone 770.421.6699 1059 Triad Court, Suite 8 770.234.4207 Marietta, Georgia 30062-2258 www.dvigear.com DVI-3551a-UG-02 / April.2012...
