Napoleon BGD36CFNTR Installation And Operating Instructions Manual
Natural and propane gas model vented fireplace heaters
Hide thumbs
Also See for BGD36CFNTR:
- Installation and operating instructions manual (136 pages) ,
- Installation and operation manual (120 pages) ,
- Installation and operating instructions manual (68 pages)
Table of Contents
Advertisement
Quick Links
INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.
CERTIFIED UNDER CANADIAN AND AMERICAN NATIONAL STANDARDS: CSA 2.33, ANSI Z21.88 FOR VENTED GAS FIREPLACE HEATERS.
BGD36CFNTR,
BGD36CFGN &
GD36MN
NATURAL GAS MODEL
BGD36CFPTR,
BGD36CFGP &
GD36MP
PROPANE GAS MODEL
CERTIFIED FOR CANADA AND UNITED STATES USING ANSI/CSA METHODS.
SAFETY INFORMATION
WARNING
!
If the information in these instructions are
not followed exactly, a fi re or explosion
may result causing property damage,
personal injury or loss of life.
- Do not store or use gasoline or other fl ammable
vapors and liquids in the vicinity of this or any
other appliance.
- WHAT TO DO IF YOU SMELL GAS:
•
Do not try to light any appliance.
•
Do not touch any electrical switch; do not use
any phone in your building.
•
Immediately call your gas supplier from a
neighbour's phone. Follow the gas supplier's
instructions.
•
If you cannot reach your gas supplier, call the
fi re department.
- Installation and service must be performed by a
qualifi ed installer, service agency or the supplier.
Phone (705)721-1212 • Fax (705)722-6031 • www.napoleonfi replaces.com • ask@napoleonproducts.com
$10.00
OPERATING INSTRUCTIONS
Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON, L4M 4Y8 Canada /
103 Miller Drive, Crittenden, Kentucky, USA, 41030
INSTALLATION AND
B G
D 3
6 C
F N
T R
I L L
U S
T R
A T
E D
1.2A
W415-0899 / 06.01.10
1
Advertisement
Table of Contents
Related Manuals for Napoleon BGD36CFNTR
Summary of Contents for Napoleon BGD36CFNTR
-
Page 1: Safety Information
INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE. CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE. INSTALLATION AND OPERATING INSTRUCTIONS CERTIFIED UNDER CANADIAN AND AMERICAN NATIONAL STANDARDS: CSA 2.33, ANSI Z21.88 FOR VENTED GAS FIREPLACE HEATERS. BGD36CFNTR, BGD36CFGN & GD36MN NATURAL GAS MODEL BGD36CFPTR, BGD36CFGP &... -
Page 2: Table Of Contents
TABLE OF CONTENTS INSTALLATION OVERVIEW INTRODUCTION DIMENSIONS 2.1.1 BGD36CF / BGD36CFG 2.1.2 GD36M GENERAL INSTRUCTIONS GENERAL INFORMATION RATING PLATE INFORMATION VENTING VENTING LENGTHS AND COMPONENTS TYPICAL VENT INSTALLATIONS SPECIAL VENT INSTALLATIONS 3.3.1 PERISCOPE TERMINATION 3.3.2 CORNER TERMINATION MINIMUM AIR TERMINAL LOCATION CLEARANCES VENT APPLICATION FLOW CHART DEFINITIONS ELBOW VENT LENGTH VALUES... -
Page 3: Installation Overview
14.0 MAINTENANCE 14.1 BULB REPLACEMENT BGD36CFG / GD36M 14.2 LENS ASSEMBLY REPLACEMENT BGD36CFG / GD36M 14.3 DOOR GLASS REPLACEMENT 14.4 CARE OF GLASS 15.0 REPLACEMENTS 16.0 TROUBLE SHOOTING 16.1 BGD36CF 16.2 BGD36CFG / GD36M 17.0 WARRANTY 18.0 SERVICE HISTORY 1.0 INSTALLATION OVERVIEW See the sections “MINIMUM ENCLOSURE CLEARANCES”... -
Page 4: Introduction
2.0 INTRODUCTION WARNING • THIS APPLIANCE IS HOT WHEN OPERATED AND CAN CAUSE SEVERE BURNS IF CONTACTED. • Do not operate appliance before reading and understanding operating instructions. Failure to operate appliance according to operating instructions could cause fi re or injury. •... -
Page 5: Dimensions
DIMENSIONS 2.1.1 BGD36CF / BGD36CFG 5” ” 27” 38 ½” 38 ½” 4" DIA. 33” 34” 7" DIA. 17” 24 ¼” 15” 8” ” 40” 3” ELECTRICAL INLET INLET ” LEFT SIDE 2.1.2 GD36M 5” 38 ½” 27” 33” 4" DIA. 34”... - Page 6 THIS GAS APPLIANCE SHOULD BE INSTALLED AND SERVICED BY A QUALIFIED INSTALLER to conform with local codes. Installation practices vary from region to region and it is important to know the specifi cs that apply to your area, for example in Massachusetts State: •...
-
Page 7: General Information
GENERAL INFORMATION FOR YOUR SATISFACTION, THIS APPLIANCE HAS BEEN TEST-FIRED TO ASSURE ITS OPERATION AND QUALITY! APPLIANCE Altitude (FT) 0-4,500 0-4500 Max. Input (BTU/HR) 17,000 17,000 Max. Output Steady State (BTU/HR) 10,900 10,900 Effi ciency (w/the fan on) A.F.U.E. (Annual Fuel Utilization Effi ciency) Min. -
Page 8: Venting
3.0 VENTING WARNING RISK OF FIRE, MAINTAIN SPECIFIED AIR SPACE CLEARANCES TO VENT PIPE AND APPLIANCE. IF VENTING IS INCLUDED WITH SPACERS THE VENT SYSTEM MUST BE SUPPORTED EVERY 3 FEET FOR BOTH VERTICAL AND HORIZONTAL RUNS. USE SUPPORTS OR EQUIVALENT NON-COMBUSTIBLE STRAPPING TO MAINTAIN THE REQUIRED CLEARANCE FROM COMBUSTIBLES. -
Page 9: Typical Vent Installations
For optimum flame appearance and appliance performance, keep the vent length and number of elbows to a minimum. The air terminal must remain unobstructed at all times. Examine the air terminal at least once a year to verify that it is unobstructed and undamaged. Rigid and fl... - Page 10 16" MINIMUM 40 FT MAXIMUM 3 FT MINIMUM 24" MAXIMUM 10" MINIMUM 42 3/8" MINIMUM PLUS RISE* 34" 34" TOP VENT * See "VENTING" section. W415-0899 / 06.01.10...
-
Page 11: Special Vent Installations
SPECIAL VENT INSTALLATIONS 3.3.1 PERISCOPE TERMINATION Use the periscope kit to locate the air termination above grade. The periscope must be installed so that when fi nal grading is completed, the bottom air slot is located a minimum 12” above grade. The maximum allowable vent length is 10’. -
Page 12: Minimum Air Terminal Location Clearances
MINIMUM AIR TERMINAL LOCATION CLEARANCES COVERED BALCONY APPLICATIONS = 3 feet = 2 x ACTUAL feet INSTALLATIONS CANADA U.S.A. 12” 12” Clearance above grade, veranda porch, deck or balcony. 12” 9” Clearance to windows or doors that open. Δ Δ 12”... -
Page 13: Vent Application Flow Chart
VENT APPLICATION FLOW CHART TOP EXIT Horizontal Termination Vertical Termination Vertical rise is equal Vertical rise is equal Vertical rise is less Vertical rise is less to or greater than to or greater than than horizontal run than horizontal run the horizontal run the horizontal run Horizontal run +... -
Page 14: Elbow Vent Length Values
ELBOW VENT LENGTH VALUES FEET INCHES 1° 0.03 15° 0.45 30° 11.0 45° 1.35 16.0 90°* 32.0 * The fi rst 90° offset has a zero value and is shown in the formula as - 90° 15.1 TOP EXIT HORIZONTAL TERMINATION ) <... - Page 15 ) > (V Simple venting configuration See graph to determine the required vertical rise V for the required horizontal run H (only one 90° elbow) 147” REQUIRED VERTICAL RISE IN INCHES V 57” 10” 2’ 12.5’ 19.5’ HORIZONTAL VENT RUN PLUS OFFSET IN FEET H The shaded area within the lines represents acceptable values for H and V For vent configurations requiring more than one 90°...
-
Page 16: Rear Exit Horizontal Termination
REAR EXIT HORIZONTAL TERMINATION ) < (V Simple venting configuration See graph to determine the required vertical rise V for the required (only two 90° elbows) horizontal run H 38.3 REQUIRED VERTICAL RISE IN FEET V 12.5 17.5 HORIZONTAL VENT RUN PLUS OFFSET IN FEET H The shaded area within the lines represents acceptable values for H and H For vent configurations requiring more than two 90°... - Page 17 ) > (V Simple venting configuration See graph to determine the required vertical rise V for the (only two 90° elbows) required horizontal run H REQUIRED VERTICAL RISE IN INCHES V 12.5 17.5 19.25 HORIZONTAL VENT RUN PLUS OFFSET IN FEET H The shaded area within the lines represents acceptable values for H and H...
-
Page 18: Top Or Rear Exit Vertical Termination
3.10 TOP OR REAR EXIT VERTICAL TERMINATION ) < (V See graph to determine the required vertical rise V for the Simple venting configurations. required horizontal run H REQUIRED VERTICAL RISE IN FEET V HORIZONTAL VENT RUN PLUS OFFSET IN FEET H The shaded area within the lines represents acceptable values for H and H... - Page 19 ) > (V See graph to determine the required vertical rise V for the Simple venting configurations. required horizontal run H REQUIRED VERTICAL RISE IN FEET V HORIZONTAL VENT RUN PLUS OFFSET IN FEET H The shaded area within the lines represents acceptable values for H and H For vent configurations requiring more than two 90°...
-
Page 20: Pre-Installation Preparation
Example 8: = 1.5 FT = 5 FT = 1.5 + 1 + 5 = 6.5 FT = 1 FT = 1 FT = 10.75 FT = 1 + 1 + 10.75 = 12.75 FT = .03 (four 90° elbows + one 45° elbow - 90°) 90°... -
Page 21: Door Operation
DOOR OPERATION To access the lower door latch, open the Valve Access Door as illustrated. Release the top and bottom door latches, located at the right side of the door. REAR EXIT WARNING FAILURE TO INSTALL THE CAP WILL CAUSE THE APPLIANCE TO FUNCTION IMPROPERLY AND CAN CAUSE INJURY OR PROPERTY DAMAGE. -
Page 22: Installation
5.0 INSTALLATION WARNING FOR SAFE AND PROPER OPERATION OF THE APPLIANCE, FOLLOW THE VENTING INSTRUCTIONS EXACTLY. ALL INNER EXHAUST AND OUTER INTAKE VENT PIPE JOINTS MAY BE SEALED USING EITHER RED RTV HIGH TEMP SILICONE SEALANT W573-0002 (NOT SUPPLIED) OR BLACK HIGH TEMP MILL PAC W573-0007 (NOT SUPPLIED) WITH THE EXCEPTION OF THE APPLIANCE EXHAUST FLUE COLLAR WHICH MUST BE SEALED USING MILL PAC. -
Page 23: Horizontal Installation
HORIZONTAL INSTALLATION WARNING THE FIRESTOP ASSEMBLY MUST BE INSTALLED WITH THE VENT SHIELD TO THE TOP. TERMINALS MUST NOT BE RECESSED INTO A WALL OR SIDING MORE THAN THE DEPTH OF THE RETURN FLANGE OF THE MOUNTING PLATE. This application occurs when venting through an exterior wall. Having determined the correct height for the air terminal VENT location, cut and frame a hole in the exterior wall as... -
Page 24: Using Flexible Vent Components
USING FLEXIBLE VENT COMPONENTS WARNING DO NOT ALLOW THE INNER FLEX PIPE TO BUNCH UP ON HORIZONTAL OR VERTICAL RUNS AND ELBOWS. KEEP IT PULLED TIGHT. SPACERS ARE ATTACHED TO THE INNER FLEX PIPE AT PREDETERMINED INTERVALS TO MAINTAIN AN EVEN AIR GAP TO THE OUTER FLEX PIPE. -
Page 25: Vertical Air Terminal Installation
5.4.2 VERTICAL AIR TERMINAL INSTALLATION WARNING MAINTAIN A MINIMUM 2” SPACE BETWEEN THE AIR INLET BASE AND THE STORM COLLAR. Fasten the roof support to the roof using the screws provided. The roof support is optional. In this case the venting is to be adequately supported using either an alternate method suitable to the authority having jurisdiction or the optional roof support. -
Page 26: Appliance Vent Connection
5.4.3 APPLIANCE VENT CONNECTION Install the inner fl ex pipe to the appliance. Secure with 3 screws #8 X 1/2” and fl at washers. Seal the joint and screw holes using the high SELF temperature sealant W573-0007 (not supplied). DRILLING SCREWS Install the outer fl... -
Page 27: Extended Horizontal And Corner Terminal Installation
5.5.2 EXTENDED HORIZONTAL AND CORNER TERMINAL INSTALLATION A 45° corner installation can have 0” rise between the appliance combustion AIR TERMINAL air collar and the air terminal. In this case, vent lengths must be kept to a TELESCOPIC SLEEVE maximum of 24”. For longer vent lengths, a minimum vertical rise of 24” is required. -
Page 28: Vertical Air Terminal Installation
5.5.3 VERTICAL AIR TERMINAL INSTALLATION NOTE: Before attaching elbows to the collars on the back of the appliance, 1 1/2” will need to be trimmed off the 4” collar. REAR VENT APPLICATION: Attach 4” and 7” elbows to the appliance. Secure with 3 screws and seal the joints and screw heads using high temperature sealant. -
Page 29: Mobile Home Installation
MOBILE HOME INSTALLATION This appliance is certifi ed to be installed as an OEM (Original Equipment Manufacturer) installation in a manufactured home or mobile home and must be installed in accordance with the manufacturer’s instructions and the Manufactured Home Construction and Safety Standard, Title 24 CFR, Part 3280, in the United States or the Mobile Home Standard, CAN/CSA Z240 MH Series, in Canada. -
Page 30: Optional Wall Switch Excluding Bgd36Cfg & Gd36M
Installation and servicing to be done by a qualifi ed installer. Do not use open fl ame. • Move the appliance into position and secure. 5.7.1 • If equipped with a fl ex connector the appliance is designed to accept a 1/2” gas supply. Without the 5.7.2 connector it is designed to accept a 3/8”... -
Page 31: Framing
6.0 FRAMING WARNING RISK OF FIRE! IN ORDER TO AVOID THE POSSIBILITY OF EXPOSED INSULATION OR VAPOUR BARRIER COMING IN CONTACT WITH THE APPLIANCE BODY, IT IS RECOMMENDED THAT THE WALLS OF THE APPLI- ANCE ENCLOSURE BE “FINISHED” (IE: DRYWALL / SHEETROCK), AS YOU WOULD FINISH ANY OTHER OUTSIDE WALL OF A HOME. -
Page 32: Installing Stand-Offs
Minimum clearance to combustible construction from appliance and vent surfaces: Non-combustible Framing: - 0" to stand-offs if using optional clean face surround. Combustible Framing: Sides, back and bottom of appliance - 0" to rear. - 3 1/2" to stand-offs if using optional clean face surround. Combustible Finishing: Sides, bottom and top - 0"... -
Page 33: Minimum Framing Dimensions
MINIMUM FRAMING DIMENSIONS WARNING FOR TOP EXIT APPLICATIONS: DO NOT BUILD INTO THIS AREA. IT MUST BE LEFT CLEAR TO PROVIDE ADEQUATE CLEARANCE FOR THE VENT. IN THIS 14" WIDE AREA CENTRED ALONG THE FRONT OF THE APPLIANCE, NO COMBUSTIBLES ARE ALLOWED. 49”... -
Page 34: Steel Header Installation For Clean Face Surround And Stylo Glass Facia
" INSIDE CHASE " " 6" OUTSIDE " CHASE " 12” TO COMBUSTIBLE MANTLE IMPORTANT: Encroaching in this area with fi nishing material will interfere with the opening of the door. THIS AREA MUST REMAIN EXPOSED TO ALLOW FOR PROPER DOOR OPERATION. -
Page 35: Minimum Enclosure Clearances
MINIMUM ENCLOSURE CLEARANCES WARNING ENSURE CLEARANCES TO COMBUSTIBLES ARE MAINTAINED WHEN BUILDING A MANTEL OR SHELVES ABOVE THE APPLIANCE. ELEVATED TEMPERATURES CAN CAUSE MELTING, DEFORMATION, DISCOLOURATION OR PREMATURE FAILURE OF T.V. OR OTHER ELECTRONIC COMPONENTS. 6.3.1 REAR VENT ENCLOSURE NON-COMBUSTIBLE COMBUSTIBLE TOP OF COMBUSTIBLE... -
Page 36: Top Vent Enclosure
6.3.2 TOP VENT ENCLOSURE NON-COMBUSTIBLE COMBUSTIBLE SHELF 2” 0” IF NON-COMBUSTIBLE COMBUSTIBLE FINISHING IS USED SUCH MATERIAL 2” AS BRICK AND STONE 1 1/2” 15” 1” *6 1/2” MIN 49” NON- COMBUSTIBLE MATERIAL STEEL 43” HEADER MINIMUM REQUIRED PLUS RISE** IF USING OPTIONAL * If this appliance is installed... -
Page 37: Enclosure Installation With Clean Face Surround Or Stylo Glass Facia (Gd36M)
6.3.4 ENCLOSURE INSTALLATION WITH CLEAN FACE SURROUND OR STYLO GLASS FACIA (GD36M) CEMENT BOARD PANEL (SUPPLIED) STEEL HEADER (SUPPLIED) *6 1/2” 34” STYLO GLASS FACIA STEEL HEADER COMBUSTIBLE NON-COMBUSTIBLE *6 1/2” 0” IF NON-COMBUSTIBLE FINISHING IS USED SUCH AS BRICK AND STONE 2”... -
Page 38: Clean Face Surround Framing And Finishing Excluding Gd36M
CLEAN FACE SURROUND FRAMING AND FINISHING EXCLUDING GD36M CONCAVE WAVE CONVEX S36CCN (BROWN) S36WN (BROWN) S36CVN (BROWN) S36CCP (PEWTER) S36WP (PEWTER) S36CVP (PEWTER) Installation requires a minimum of 6 1/2" non-combustible facing material at the top of the appliance. Refer to illustrations above (depending on your installation) to ensure your appliance has been installed with the proper requirements for this kit. -
Page 39: Hearth Installation
6.4.2 HEARTH INSTALLATION When installing to a hearth the appliance riser must create a minimum clearance of 3 3/8" PLUS the height of the hearth from the fi nished fl oor to the bottom of the appliance. COMBUSTIBLE STEEL STEEL MATERIAL HEADER HEADER... -
Page 40: Finishing
7.0 FINISHING DOOR INSTALLATION & REMOVAL WARNING GLASS MAY BE HOT, DO NOT TOUCH GLASS UNTIL COOLED. THE DOOR LATCHES ARE PART OF A SAFETY SYSTEM AND MUST BE PROPERLY ENGAGED. DO NOT OPERATE THE APPLIANCE WITH LATCHES DISENGAGED. FACING AND/OR FINISHING MATERIALS MUST NOT INTERFERE WITH AIR FLOW THROUGH AIR OPENINGS, LOUVRES OPENINGS, OPERATION OF LOUVRES OR DOORS OR ACCESS FOR SERVICE. -
Page 41: Clean Face Trim Kit Installation Excluding Gd36M
CLEAN FACE TRIM KIT INSTALLATION EXCLUDING GD36M The “wave” clean face surround kit is shown in all illustrations. From the rear side of the clean face front, insert the weld studs on the top window plate assembly upward through the holes on the underside of the top section of the clean face front. Using a socket wrench, secure using the nuts and washers provided. -
Page 42: Bgd36Cf Finishing
8.0 BGD36CF FINISHING LOG PLACEMENT WARNING FAILURE TO POSITION THE LOGS IN ACCORDANCE WITH THESE DIAGRAMS OR FAILURE TO USE ONLY LOGS SPECIFICALLY APPROVED WITH THIS APPLIANCE MAY RESULT IN PROPERTY DAMAGE OR PERSONAL INJURY. LOGS MUST BE PLACED IN THEIR EXACT LOCATION IN THE APPLIANCE. DO NOT MODIFY THE PROPER LOG POSITIONS, SINCE APPLIANCE MAY NOT FUNCTION PROPERLY AND DELAYED IGNITION MAY OCCUR. -
Page 43: Glowing Embers
GLOWING EMBERS Tear the embers into pieces and place along the front row of ports covering all of the burner area in front of the small logs. Care should be taken to shred the embers into thin, small irregular pieces as only the exposed edges of the fi... -
Page 44: Bgd36Cfg / Gd36M Finishing
9.0 BGD36CFG / GD36M FINISHING GLASS BURNER INSTALLATION WARNING CLEAN THE GLASS MEDIA PRIOR TO INSTALLATION. BEFORE APPLYING THE CLEANED GLASS, ENSURE THAT IT IS DRY. DO NOT CHANGE OR SUBSTITUTE THE GLASS MEDIA MATERIAL PROVIDED WITH THIS APPLIANCE. IF REPLACING, USE ONLY THE REPLACEMENT GLASS MEDIA AVAILABLE FROM YOUR AUTHORIZED DEALER / DISTRIBUTOR. -
Page 45: Gd36M Glass Front Installation / Removal
GD36M GLASS FRONT INSTALLATION / REMOVAL BRACKET FLAT PLASTIC WASHER PLASTIC SHOULDER WASHER THREADED 9.2.1 NOTE: Ensure threaded rod is completely threaded into the cap. Place plastic shoulder washer GLASS over threaded rod. FACIA Run the rod through the hole in 9.2.2 the glass facia (silk screen side FRONT... -
Page 46: Top Prp Panel Installation Gd36M
TOP PRP PANEL INSTALLATION GD36M TOP DEFLECTOR TOP PORCELAIN PANEL SIDE SIDE PORCELAIN PORCELAIN BACK PANEL PANEL PORCELAIN PANEL Place the top porcelain panel behind the back and side porcelain panels as illustrated. 9.3.1 W415-0899 / 06.01.10... -
Page 47: Optional Blower Installation
10.0 OPTIONAL BLOWER INSTALLATION WARNING RISK OF FIRE AND ELECTRICAL SHOCK. TURN OFF THE GAS AND ELECTRICAL POWER BEFORE SERVICING THIS APPLIANCE. USE ONLY WOLF STEEL APPROVED OPTIONAL ACCESSORIES AND REPLACEMENT PARTS WITH THIS APPLIANCE. USING NON-LISTED ACCESSORIES (BLOWERS, DOORS, LOUVRES, TRIMS, GAS COMPONENTS, VENTING COMPONENTS, ETC.) COULD RESULT IN A SAFETY HAZARD AND WILL VOID THE WARRANTY AND CERTIFICATION. -
Page 48: Wiring Diagram
11.0 WIRING DIAGRAM WARNING DO NOT USE THIS APPLIANCE IF ANY PART HAS BEEN UNDER WATER. CALL A QUALIFIED SERVICE TECHNICIAN IMMEDIATELY TO HAVE THE APPLIANCE INSPECTED FOR DAMAGE TO THE ELECTRICAL CIRCUIT. RISK OF ELECTRICAL SHOCK OR EXPLOSION. DO NOT WIRE 110V TO THE VALVE OR TO THE APPLIANCE WALL SWITCH. -
Page 49: Bgd36Cfg / Gd36M Light Switch
11.2 BGD36CFG / GD36M LIGHT SWITCH A wall switch must be installed in a convenient location for the light operation. The recommended maximum lead length depends on wire size: WIRE SIZE MAX. LENGTH 14 gauge 100 feet 16 gauge 60 feet 18 gauge 40 feet A 20’... -
Page 50: Receptacle Wiring Diagram
11.3 RECEPTACLE WIRING DIAGRAM W415-0899 / 06.01.10... -
Page 51: Operation
12.0 OPERATION 12.1 BGD36CF WARNING IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. ALWAYS LIGHT THE PILOT WHETHER FOR THE FIRST TIME OR IF THE GAS SUPPLY HAS RUN OUT WITH THE GLASS DOOR OPENED OR REMOVED. -
Page 52: Bgd36Cfg / Gd36M
12.2 BGD36CFG / GD36M WARNING IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. ALWAYS LIGHT THE PILOT WHETHER FOR THE FIRST TIME OR IF THE GAS SUPPLY HAS RUN OUT WITH THE GLASS DOOR OPENED OR REMOVED. -
Page 53: Adjustments
13.0 ADJUSTMENTS 13.1 PILOT BURNER ADJUSTMENT Adjust the pilot screw to provide properly sized fl ame. Turn in a clockwise PILOT direction to reduce the gas fl ow. BURNER THERMOPILE Inlet pressure can be checked by turning screw (A) counter- THERMOCOUPLE clockwise until loosened and then placing pressure gauge tubing over the test point. -
Page 54: Bgd36Cfg / Gd36M Venturi Adjustment
13.2.2 BGD36CFG / GD36M VENTURI ADJUSTMENT WARNING CARBON CAN BE DISTRIBUTED IN SURROUNDING LIVING AREA IF THE AIR SHUTTER IS IMPROPERLY ADJUSTED. THE FRONT OF THE APPLIANCE BECOMES VERY HOT DURING OPERATION. LET THE APPLIANCE COOL COMPLETELY BEFORE CONDUCTING SERVICE. This appliance has an air shutter that has been factory set open according to the chart below: Closing the air shutter will cause a more yellow fl... -
Page 55: Bgd36Cf Flame Characteristics
13.4 BGD36CF FLAME CHARACTERISTICS It’s important to periodically perform a visual check of the pilot and 3/8” - 1/2” burner fl ames. Compare them to the illustrations provided. If any fl ames appear abnormal call a service person. FLAME MUST ENVELOPE UPPER 3/8"... -
Page 56: Maintenance
14.0 MAINTENANCE MAINTENANCE MAINTENANCE WARNING MAINTENANCE TURN OFF THE GAS AND ELECTRICAL POWER BEFORE SERVICING THE APPLIANCE. APPLIANCE MAY BE HOT, DO NOT SERVICE UNTIL APPLIANCE HAS COOLED. DO NOT USE ABRASIVE CLEANERS. CAUTION: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. -
Page 57: Lens Assembly Replacement Bgd36Cfg / Gd36M
14.2 LENS ASSEMBLY REPLACEMENT BGD36CFG / GD36M WARNING THE FRONT OF THE APPLIANCE BECOMES VERY HOT DURING OPERATION. LET THE APPLIANCE COOL COMPLETELY BEFORE CONDUCTING SERVICE. 14.2.1 Remove the glass and glass ember tray. 14.2.2 Remove the burner base from the fi rebox. 14.2.3 Compress the retainer fi... -
Page 58: Care Of Glass
14.4 CARE OF GLASS WARNING DO NOT CLEAN GLASS WHEN HOT! DO NOT USE ABRASIVE CLEANERS TO CLEAN GLASS. HOT GLASS WILL Buff lightly with a clean dry soft cloth. Clean both sides CAUSE BURNS. of the glass after the fi rst 10 hours of operation with a DO NOT TOUCH GLASS recommended fi... -
Page 59: Replacements
15.0 REPLACEMENTS WARNING FAILURE TO POSITION THE PARTS IN ACCORDANCE WITH THIS MANUAL OR FAILURE TO USE ONLY PARTS SPECIFICALLY APPROVED WITH THIS APPLIANCE MAY RESULT IN PROPERTY DAMAGE OR PERSONAL INJURY. ** THIS IS A FAST ACTING THERMOCOUPLE. IT IS AN INTEGRAL SAFETY COMPONENT. REPLACE ONLY WITH A FAST ACTING THERMOCOUPLE SUPPLIED BY WOLF STEEL LTD. - Page 60 COMPONENTS REF NO. BGD36CF BGD36CFG GD36M DESCRIPTION W300-0102 W300-0135 GLASS EMBERS W010-1835 W010-1835 GLASS EMBER TRAY W387-0011 W387-0012 HIGH TEMPERATURE LIGHT ASSEMBLY W387-0009 (5W) W387-0013 (10W) HALOGEN BULB W010-2370 FLUSH GLASS FRONT ASSEMBLY W300-0130 STYLO GLASS FACIA W190-0015 W190-0015 CONTROLE MODULE W190-0021 W190-0021 CONTROL RELAY...
- Page 61 ACCESSORIES REF NO. BGD36CF BGD36CFG GD36M DESCRIPTION W175-0001 W175-0001 W175-0001 4" COUPLER W175-0013 W175-0013 W175-0013 7" COUPLER W500-0103 W500-0103 W500-0103 TERMINAL EXTENSION PLATE GD-301 GD-301 GD-301 HEAT GUARD W010-0370 W010-0370 W010-0370 WALL SUPPORT ASSEMBLY W175-0053 W175-0053 W175-0053 DURA-VENT ZERO CLEARANCE ADAPTOR VS47KT VS47KT VS47KT...
- Page 62 W415-0899 / 06.01.10...
-
Page 63: Trouble Shooting
16.0 TROUBLE SHOOTING 16.1 BGD36CF WARNING ALWAYS LIGHT THE PILOT WHETHER FOR THE FIRST TIME OR IF THE GAS SUPPLY HAS RAN OUT, WITH THE GLASS DOOR OPEN OR REMOVED. TURN OFF THE GAS AND ELECTRICAL POWER BEFORE SERVICING THE APPLIANCE. APPLIANCE MAY BE HOT, DO NOT SERVICE UNTIL APPLIANCE HAS COOLED. - Page 64 SYMPTOM PROBLEM TEST SOLUTION Pilot will not light. No spark at pilot burner. Check if pilot can be lit by a match. Check that the wire is connected to the push button igniter. Check if the push button igniter needs tightening. Replace the wire if the wire insulation is broken or frayed.
-
Page 65: Bgd36Cfg / Gd36M
16.2 BGD36CFG / GD36M WARNING ALWAYS LIGHT THE PILOT WHETHER FOR THE FIRST TIME OR IF THE GAS SUPPLY HAS RAN OUT, WITH THE GLASS DOOR OPEN OR REMOVED. TURN OFF THE GAS AND ELECTRICAL POWER BEFORE SERVICING THE APPLIANCE. APPLIANCE MAY BE HOT, DO NOT SERVICE UNTIL APPLIANCE HAS COOLED. - Page 66 SYMPTOM PROBLEM TEST SOLUTION Continues to Short or loose Verify all connections. Verify the connections from the pilot spark and pilot connection in sensor assembly are tight; also verify these connections are not lights, but main rod. grounding out to any metal. burner will not Poor fl...
-
Page 67: Warranty
17.0 WARRANTY NAPOLEON® products are manufactured under the strict Standard of the world recognized ISO 9001 : 2008 Quality Assurance Certifi cate. NAPOLEON® products are designed with superior components and materials assembled by trained craftsmen who take great pride in their work. The burner and valve assembly are leak and test-fi red at a quality test station. -
Page 68: Service History
18.0 SERVICE HISTORY 43.1 W415-0899 / 06.01.10...
