JBL S-Center Studio Series Technical Manual

Technical Manual
S-Center
Studio Series
ACOUSTIC & ELECTRICAL SPECIFICATIONS:
• Nominal Impedance
• Max Amp Power
• Frequency Response
• Sensitivity
• Crossover Frequency

SYSTEM COMPONENTS:

• Enclosure w/ network
• Grille
• Low Frequency Transducer (2) 5
DC Resistance
• Mid Frequency Transducer
DC Resistance
• HIgh Frequency Transducer 1" (25mm) Titanium dome
DC Resistance
• Crossover Network
PACKAGING
End Foam
WP0368
JBL Consumer Products, Inc. 250 Crossways Park Dr., Woodbury, New York 11797
8 ohms
150 watts
80 Hz - 20 kHz (-3dB)
91 dB (1 watt @ 1 meter)
800 Hz, 3200 Hz
S-CENTER (XY05009)
X05246
1/4" (133mm) PolyPlas
Shielded (SS-W5.25SS)
9.4 ohms ±10%
4" (101mm) PolyPlas ™
Shielded (SS-M4SS))
3.9 ohms ±10%
Shielded (40DT25BC-DT01)
3.3 ohms ±10%
See above Enclosure w/ network
Owner's Manual
AI0398
Warranty Card
AT0341
Survey Card
AI0193-01
OWNER'S
Instruction Sheet for Feet
MANUAL
AI0408
Rubber feet (set of 8)
WI0758-01B
Plastic Bag
Outer Carton
WB1973
AURAL SWEEP TEST SPECIFICATIONS:
• A. System Aural Sweep Test 6.0V Input 80 Hz to 20 kHz
• B. L.F. Aural Sweep Test
• C. M.F. Aural Sweep Test
• D. H.F. Aural Sweep Test
PHYSICAL SPECIFICATIONS:
• Enclosure dimensions:
• Weight
™ cone
WARRANTY:
• Refer to Warranty Statement packed with each product.
cone

WIRING DIAGRAM

Driver
Mid.Frequency
SS-M4SS
Driver
Low Frequency
SS-W5.25SS
+
INPUT
6.0V Input 80 Hz to 1 kHz
4.0V Input 500 Hz to 4 kHz
2.83V Input 3 kHz to 20 kHz
7 " x 20
7/8
200mm x 521mm x 229mm
15 lbs. /6.8kg Each
Driver
High Frequency
40DT25BC-DT01
YELLOW
BLACK
WHITE
BLACK
GREEN
BLACK
GREEN
BLACK
S-Center SCHEMATIC
L1
2.0mh
C2
0.01µF
100V
C3, 20µF
L2
±5% 100V
0.5mH
C4
0.01µF
C6
100V
0.01µF
100V
C7, 6.2µF
R1, 0.39 ohm, 5W
100V
C8 R2
20 ohm
0.01mF
100V 5W
" x 9" (H x W x D)
1/2
Crossover Network
S-Center (XY05009)
GREEN
+
250
C1
L.F.
60µF
100V
205
BLACK
110
BLACK
C5 14µF
MID.F.
100V
+
205
WHITE
110
BLACK
L3
H.F.
0.2mh
+
205
YELLOW
10-99
