WET & DRY

VACUUM CLEANER

STOCK No.59311
PART No.WDV8
• INSTRUCTIONS •
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY TO ENSURE THE
SAFE AND EFFECTIVE USE OF THIS TOOL.
02/2000

GENERAL INFORMATION

This manual has been compiled by Draper Tools and is an integrated part of the power tool equipment, which
should be kept with the machine. This manual describes the purpose for which this tool has been designed and
contains all the necessary information to ensure its correct and safe use.We recommend that this manual is read
before any operation of the machine, before performing any kind of adjustment to the machine, and prior to any
maintenance tasks. By following all the general safety instructions contained in this manual, it will ensure both
machine and operator safety, together with longer life of the tool itself.
All photographs and drawings in this manual are supplied by Draper Tools to help illustrate the operation of the
machine. Whilst every effort has been made to ensure accuracy of information contained in this manual, the Draper
Tool policy of continuous improvement determines the right to make modifications without prior warning.
