Digital Clamp Meter
(TRMS)
Model : 2727
Instruction Manual
1
1.2 Electrical Specifications
AC CURRENT (True RMS)
Range
Accuracy
40A
50/60Hz ± (2%rdg+4dgt)
40-500Hz ± (3.5%rdg+5dgt)
400A/600A (2727)
40 - 500Hz ± (3.5%rdg+5dgt) for 1 min.
AC VOLTS (True RMS) (50 Hz - 500Hz)
Range
Resolution
Accuracy
Input lmpedance
Overload protection
DC VOLTS
Range
Resolution
Accuracy
Input lmpedance
Overload protection
RESISTANCE
Range
Resolution
Accuracy
Open circuit voltage
Overload protection
3
®
Overload
Protection
1000A
ac max.
400V,750V
100mV
± (2.9%rdg+4dgts)
10MV
1000V DC or 750V AC rms
1000V
1V
± (1.5%rdg+1dgt)
10MV
1000V DC or 750V AC rms
400V, 400KV
100mV
± (1.5%rdg+3dgt)
0.6V DC (3.0V DC on 400V
range) 500V DC or AC rms
1. SPECIFICATIONS
1.1 General Specifications
Display
: 3 ¾ digit liquid crystal display
(LCD) with a maximum reading
of 3999.
Polarity
: Automatic, positive implied,
negative polarity indication.
Overrange
: (OL) or (-OL) is displayed.
Zero
: Automatic.
Low battery indication
: "(+ -)" is displayed when the
battery voltage drops below the
operating level.
Measurement rate
: 2.5 times per second, nominal.
Operating Environment
: 0
humidity.
Storage Temperature
: -20
battery removed from meter.
Accuracy
: Stated accuracy at 27
<75% relative humidity.
Power
: Single standard 9 Volt battery
EVEREADY TYPE 216 or
Equivalent.
Battery life
: 200 hours typical with
carbon-zinc.
Dimension
2727 : 192mm(H)x82mm(W)x33mm(D).
Weight
2727 : 270grams approx.
Accessories
: One "K" type thermocouple,
one pair of test leads 9V battery
(installed), instruction manual.
Maximum Jaw Opening
: 2727 : 30mm.
DIODE TEST
Test Current
Accuracy
Open circuit volts
Overload protection
FREQUENCY (Autoranging)
Ranges
Accuracy
Sensitivity
Overload Protection
TEMPERATURE
Ranges
Resolution
Accuracy
CONTINUITY
Audible indication
Overload protection
0
0
C to 50
C at < 70% relative
0
0
C to 60
C, 0 to 80% R.H. with
0
0
C ± 5
C,
1.0mA ± 0.6mA
± (3%rdg + 3dgt)
3.0V DC typical
500V DC or AC rms
4kHz - 40kHz
± (1%rdg+2dgt)
100V rms min
500V DC or AC rms (50Hz-1KHz)
- 20
0
C ~ 750
0
C
0
1
C
± (2.0% rdg + 3 dgts ) on
0
0
-20
C ~ 500
C
± (3.0% rdg + 2 dgts ) on
500
0
C ~ 750
0
C
less than 100V
500V DC or AC rms
2
4
