- Page 1 The model and serial numbers are located on the bottoms of the DSP master unit and amplifier. Record these numbers in the spaces provided below. Refer to these numbers whenever you call upon your Sony dealer regarding this product. Model No.
- Page 2 Warning Note on the lithium battery Do not expose the battery to excessive heat This equipment has been tested and found such as direct sunlight, fire or the like. to comply with the limits for a Class B digital device, pursuant to Part 15 of the Warning if your car’s ignition has no FCC Rules.
-
Page 3: Table Of Contents
Table of contents Introduction ............4 Getting Started . -
Page 4: Introduction
You can enjoy exciting sound from your car audio unit and iPod/iPhone via this system, which features sound settings optimized for your vehicle type by using Sony’s original digital sound technology, and powerful bass delivered by the supplied subwoofer and amplifier. -
Page 5: The System Components
The System Components This section contains explanations on the location of controls and their basic operations. DSP master unit Sound setting switches page 10 Note Set each switch according to your car • Avoid touching the top of the DSP master unit type/interior. -
Page 6: Cradle
Cradle Suction cup VOLUME (VOL) +/–* SEEK / buttons* SOURCE/OFF button Press to skip tracks. Press to turn on the power/change the source between a car audio unit and an Remote sensor iPod/iPhone. Indicator Press and hold more than two seconds You can check the status of the DSP to turn off the system. -
Page 7: Rm-X251 Card Remote Commander
LEFT/RIGHT buttons page 11 RM-X251 Card remote Press to adjust the speaker balance. commander Press and hold the CNT button () to return to the default setting. BASS (–/CNT/+) buttons page 11 Press to adjust the bass level. ... -
Page 8: Amplifier
Amplifier POWER/PROTECTOR indicator Lights up in green during operation. If the PROTECTOR turns on, the indicator will change from green to red. If the PROTECTOR turns on, refer to “Troubleshooting” (page 22). Dynamic Distortion Suppressor Conventional Amplifier Rated Power Max. -
Page 9: Subwoofer
Subwoofer... -
Page 10: Sound Settings
Compact hatchback Sound Settings Optimized sound setting based on your vehicle SW LOCATION: MID This system provides clear treble and TRUNK: N powerful bass optimized for the vehicle type VEHICLE SIZE: S by setting the DSP master unit. 18 different settings are available. -
Page 11: Setting The Sound Balance Based On Your Listening Preference
Tip for setting the SW LOCATION switch Adjusting the treble level If you are not sure about these sound settings, set the VEHICLE SIZE switch first, Press the TREBLE (–/CNT/+) button. and then set the SW LOCATION switch to Available settings are -7 to +7, in 1-step where bass sound appears to come from in increments. -
Page 12: Setting Up The Cradle
Mounting sheet Setting up the Cradle Precautions Strap • Install the cradle on a dashboard properly so that the unit will not interfere with normal driving. • Follow the instructions on this manual about dealing with the suction cup to secure the Cord clamp cradle on a dashboard. -
Page 13: Installation
Notes Notes • Choose the mounting location carefully. • After you attach the strap to the cradle, pull Practice installation before you actually mount the strap gently to make sure that the strap the sheet, if necessary. is securely attached to the cradle. •... - Page 14 Adjust the strap. Adjust the strap by using the adjuster. • The suction cup may contain tiny holes. Adjuster This can occasionally occur in the production process, and should not cause a malfunction. Turn the LOCK/RELEASE lever counterclockwise 90 degrees to secure Insert the cord the cradle on the dashboard.
-
Page 15: Arranging The Cradle Cable
Pull the tab of the cradle for a few seconds in Replace the cover on the suction cup. the direction of the arrow marked in the illustration below (), and then slowly (over 3 to 5 seconds) remove the suction cup (). -
Page 16: Attaching An Ipod/Iphone
• Remove the case or cover from the iPod/iPhone before setting it in the cradle to ensure a stable installation. • Sony cannot accept responsibility in the event that data recorded to an iPod/iPhone is lost or To release the cradle cable damaged when using an iPod/iPhone connected to the cradle. - Page 17 Press the arm down gently and set your To adjust the angle of the cradle iPod/iPhone in the cradle. You can adjust the angle of the cradle as shown in the illustration below. Do not use Press the iPod/iPhone backward until it force to adjust the angle, as a malfunction may touches to the cushion in the center of result.
-
Page 18: Playback
• When removing the iPod/iPhone, do not twist or bend the iPod/iPhone as it may result in Playback connector damage. Precautions • For safety reasons, keep your car audio unit and iPod/iPhone volume moderate so that you can still hear sounds outside your car. •... -
Page 19: Playing From A Car Audio Unit
In such a case, consult your You can play music, etc., from your car nearest Sony dealer. audio unit via this system. Press the SOURCE/OFF button on the Warning cradle or the remote commander... -
Page 20: Maintenance
Amplifier Maintenance Replacing the lithium battery of the remote commander When the battery becomes weak, the range of the remote commander becomes shorter. Replace the battery with a new CR2025 lithium battery. Use of any other battery may present a risk of fire or explosion. RM-X251 DSP master unit + side up... -
Page 21: Specifications
Amplifier Specifications AUDIO POWER SPECIFICATIONS POWER OUTPUT AND TOTAL DSP Master Unit HARMONIC DISTORTION AUDIO POWER SPECIFICATIONS AUDIO POWER SPECIFICATIONS CEA2006 Standard CEA2006 Standard Power Output: 17 Watts RMS 4 at Power Output: 300 Watts RMS 4 at 4 Ohms < 1% THD+N 4 Ohms <... -
Page 22: Troubleshooting
The / buttons on the cradle do not Should any problem persist, stop using the work. system and consult your nearest Sony dealer. The car audio unit is selected as the source. These buttons are available only when an iPod/... - Page 23 The indicator on the cradle flashes red. The POWER/PROTECTOR indicator changes The power supply from the cradle to the iPod/ from green to red. Turn off the power. The speaker outputs are iPhone is overloaded. – Remove the iPod/iPhone from the cradle, shorted.
- Page 24 • Remove any case or cover from the iPod/ iPhone. • Operate playback on the iPod/iPhone directly. Sound reduces suddenly. Temperature detection could be activated. – Be sure to place the system in a well ventilated location. – Reduce the volume. Suddenly there is no sound.
-
Page 25: Operating Instructions
Web suivant : http://esupport.sony.com http://www.sony.com/mobileAV If you have any questions/problems regarding this product, try the following: Read Troubleshooting in these Operating Instructions. Please contact (U.S.A. only); 1-800-222-7669 Call http://www.SONY.com http://www.sony.net/ ©2011 Sony Corporation Printed in Thailand... - Page 26 If you have any questions or problems concerning the system that are not covered in this manual, please consult your nearest Sony dealer. Nota Póngase en contacto con su distribuidor Sony más cercano en caso de tener cualquier consulta o problema relativos al sistema que no se hayan tratado en este manual.
- Page 27 Amplifier / Amplificador DSP Master Unit / Unidad maestra del procesador de sonido digital (DSP) Dimensions / Dimensiones Necessary item / Unit: mm (in) Unidad: mm Elemento Dimensions / Dimensiones Unit: mm (in) Necessary item / 356.8 (14 Unidad: mm necesario Elemento 210.6 (8...
- Page 28 DSP master al conectar la salida de audio del sistema de audio a la unit. In this case, please consult your nearest Sony unidad maestra del DSP. En tal caso, póngase en ...
- Page 29 Blue/White striped AMP REM Con rayas azules y blancas These terminals are for optional speakers. Not supplied. Left White Izquierdo Estos terminales se utilizan para altavoces Blanco opcionales. White/black striped No suministrado. Rayado blanco y negro Right Gray Derecho Rojo Gris Gray/black striped...
