- Page 1 15’’ LCD TV Model: 15/4, 15/6 USER GUIDE...
- Page 3 WARNINGS Thank you for purchasing this television. For your safety, please take time to read these instructions carefully in order to familiarise yourself with the operation of the appliance and the important safety information. We strongly recommend that this product is installed by a competent person. If in doubt, refer to the retailer or the manufacturer helpline.
- Page 4 WARNINGS Screen Burn A characteristic of Plasma and LCD TV Panels is that displaying the same image for a long time may cause a permanent after-image to remain on the screen. This is called screen burn. Most pictures shown on your TV will be constantly moving and fill the screen.
-
Page 5: Table Of Contents
Frequently Asked Questions ..................Technical Specification ....................Warranty - Helpline Information ..................Index ..........................25 If you experience any problems with this Television, Please contact the helpline. Customer Support/Technical Helpline Sky Media UK LTD 0870 242 6292 Telephone: service.uk@umc-slovakia.sk Email:... -
Page 6: What Is Included In The Box With The Tv
GETTING STARTED - INCLUDED ACCESSORIES Accessories Included with this TV are the following accessories: 1x - User Guide Book 1x - Remote control NICAM MENU MENU BACK AV/TV SUBT INFO TEXT HOLD PGDN PGUP INDEX SIZE REVEAL SUBPAGE GREEN YELLOW CYAN SLEEP LAST P- MODE... -
Page 7: Tuning Into Digital / Freeview Tv Stations
GETTING STARTED - INITIAL SET UP IMPORTANT - AFTER TUNING DO NOT PRESS ANY BUTTONS FOR 20 SECONDS SO THE CHANNEL INFORMATION CAN BE STORED. If you do not have Digital TV (Freeview) in your area TUNING IN DIGITAL TV or wish to tune in via the analogue signal please follow the below. -
Page 8: Tv & Remote Control Buttons
15 SUBT To display subtitles of favorite program 16 INFO To display system information 27 LAST 28 SLEEP Applies sleep timer 29 P-MODE To adjust the picture mode of the TV TOP PANEL BUTTONS 15/4 INPUT MENU VOL- VOL+ PRO- PRO+ POWER... -
Page 9: Connecting Power Supply
TV BUTTONS & CONNECTIONS FRONT PANEL BUTTONS 15/6 REAR CONNECTIONS 15/4 POWER DC 12V Power input VGA input SCART input SCART S-VIDEO S-Terminal Video input VIDEO AUDIO Audio input for Video and S-Video PC Audio input PC-AUDIO Earphone output H.PHONE... -
Page 10: Rear Connections
CONNECTIONS & SELECTING SOURCE REAR CONNECTIONS Selecting Input Source To switch between the different connections is very easy. 1) Press [TV/AV] - The following will appear 2) Press [\/] or [/\] to select the input you S-VIDEO require. SCART 3) Press [OK] PC-RGB... -
Page 11: Adjusting The Picture Settings
DVB-T MODE MENU OPERATION PICTURE SETTINGS Adjusting Colour Lets you adjust the brightness, contrast Increase or decrease the Red, Green & Blue which colour and sharpness to enhance make up the picture the viewing experience. 1) Press [MENU] to enter menu Adjusting Brightness 2) Press [\/] 3 times to select Colour Increase or decrease the brightness... -
Page 12: Adjusting The Sound Settings
DVB-T MODE MENU OPERATION SOUND SETTINGS Lets you adjust the balance and audio presets to enhance the viewing experience. Adjusting Balance To switch the sound between the left and right speakers 1) Press [MENU] to enter menu 2) Press [>] to go to Sound menu 3) Press [\/] twice to select Balance 4) Then press [>] or [<] to increase or decrease the balance... -
Page 13: Adjusting The General Settings
DVB-T MODE MENU OPERATION GENERAL SETTINGS Adjusting Input Source You may wish to change the input which is being used Adjusting Blue Screen Changes the background when there is no 1) Press [MENU] to enter menu input between clear and a blue 2) Press [>] twice to go to General menu background 3) Press [\/] 3 times to select Input Source... -
Page 14: Adding / Deleting / Naming For Digital Channels
DVB-T CHANNEL SETTINGS MENU Within Digital (DVB-T) mode there is also Create/Edit Favourite List a channel settings menu. This is provided so you can search for new channels, 1) Press [DVB MENU] create favourite lists and apply a pin code 2) Press [\/] to select favourite list to limit access. -
Page 15: Reinstalling Digital Tv / Radio Stations
DVB-T CHANNEL SETTINGS & ADJUSTING THE PICTURE FORMAT / SIZE Picture Size / Format System Settings 1) Press [DVB MENU] Your television has been factory set to show the correct picture format depending on the signal being 2) Press [\/] 3 times to select System received by the broadcast TV station. -
Page 16: Using Electronic Programme Guide (Epg)
ELECTRONIC PROGRAM GUIDE (EPG) The Electronic Program Guide is available in DVB-T mode. It is a 7 day TV guide and provides information about forthcomming programs (where supported by the broadcasted channel). You can view the start and end time of all programs and on all channels for the next 7 days. -
Page 17: Tuning Analogue Tv
TV MODE MENU OPERATION TUNING SETTINGS Skip If there is a channel that you do not wish Tuning Program to view you can add ‘Skip’ to that channel. You may wish to do some additional When you press P+ or P- it will skip past tuning. -
Page 18: Naming Channels
TV MODE MENU OPERATION Program Edit / Changing Channel Auto Search Position Scan for all channels based on the current You can change the channel position to settings suit your requirements. 1) Press [MENU] to enter menu 1) Press [MENU] to enter menu 2) Press [>] twice to go to Tuning menu 2) Press [>] twice to go to Tuning menu 3) Press [\/] twice to select Auto Search... -
Page 19: Using Teletext
TV MODE TELETEXT OPERATION Teletext is a service offered by some broadcasters which is provided with the video and audio signals. Teletext Operation 1) Press [TEXT], after a few seconds teletext page 100 should appear. Here is an example of BBC1 2) You can now navigate to the page you require in a number of ways: a) Press the page you require using... -
Page 20: Installing To Use On A Windows Xp Pc
CONNECTING TO A PC - WINDOWS XP 4) Left mouse click on Settings, this screen will IMPORTANT— Before connecting to appear. Check the Screen Resolution is set a PC you must ensure that the settings to 1024 by 768 pixels, if it is not change to this. of the PCs output are correct for the new LCD Monitor. -
Page 21: Pc Picture Settings
PC MODE MENU OPERATION (VGA) Within PC mode there is an additional Adjusting Colour Settings menu. This can be operated in the Choose between 9300k, 6500k or User following way. 1) Press [MENU] to enter menu PC SETTINGS 2) Press [\/] 3 times to select colour settings 3) Then press [<] or [>] to switch between Adjusting Brightness 9300k, 6500k or USER. -
Page 22: Wall Mounting
WALL MOUNTING IMPORTANT— BEFORE 15/4 Instructions DRILLING ANY HOLES IN THE To remove the stand WALL ENSURE YOU ARE NOT DRILLING WHERE THERE 1) Remove the two highlighted COULD BE ANY ELECTRIC WIRES, WATER OR GAS PIPES THIS TV REQUIRES A VESA... -
Page 23: Using With Sky Digital (B Sky B)
Connecting via RF Ensure the Sky signal is switched on, www.umc-slovakia.sk before you start the below. email - service.uk@umc-slovakia.sk 1) Connect the RF cable from the RF output socket of the sky/cable box to the ‘RF IN’ of the TV. -
Page 24: Frequently Asked Questions
1) Ensure that the RF cable is connected to DVB RF In Question: I have a 15/4 and I am trying 2) Check you are in an area that can to tilt the TV on the stand. How do I do this? receive Freeview. -
Page 25: Technical Specification
TECHNICAL SPECIFICATIONS 15/4 Type Horizontal frequency: 20-70KHz PC-RGB Vertical frequency: 60Hz 75 ohm Antenna / PAL-SECAM Input signal 1 AV/Composite RCA, 1 S-Video Video 1 SCART Audio 1 pair 3.5mm Phone Jack for PC, 1 pair RCA for AV/S 3,5” jack audio in... -
Page 26: Warranty - Helpline Information
OF REPAIR / SERVICE, YOU WILL NEED TO PACKAGE THE ITEM ADEQUATELY IN ORDER THAT IT CAN BE COLLECTED / REPAIRED OR REPLACED AND RETURNED. Sky Media UK Telephone 0870 242 6292. Email service.uk@umc-slovakia.sk You can find contact details, latest support information on any of our web sites. www.skymediauk.co.uk or www.umc-slovakia.sk... -
Page 27: Index
INDEX PC Settings for using this TV Audio Presets Auto Search - TV mode Pin Code Balance Remote buttons Block channels - DVB mode Reset Settings Blue Screen Search for new channels - DVB mode Brightness Sharpness Skip channel - TV mode Channel naming/re-name - TV mode 15 Sky Digital Use Channel Order - DVB mode... - Page 28 M15/MAN/0001 M15/4/6 - Version 1 Manual...
