Manufacturers Guarantee IMPORTANT GUARANTEE INFORMATION IMPORTANT GUARANTEE INFORMATION Congratulations on purchasing this television. We hope you have many years of trouble free enjoyment from your purchase. Your product is covered under the manufacturers guarantee for 12 months from date of purchase.
IMPORTANT SAFETY INSTRUCTIONS Please read these instructions. All the safety and operating instructions should be read before the appliance is operated. Warnings • To reduce the risk of fi re, electric shock or damage to the television, do not expose it to dust, rain or moisture, or place any objects fi...
Page 5
IMPORTANT SAFETY INSTRUCTIONS Please read these instructions. All the safety and operating instructions should be read before the appliance is operated. Important Information Regarding Use of Video Games, Computers, Captions or Other Fixed Image Displays The extended use of fi xed image program material can cause a permanent “shadow image” on the LCD panel.
Page 6
Helpline No UK. 0871 2000 463 ROI. 01443 3940 Web Support: www.skymediauk.co.uk...
1 x RF Cable 1 x Stand Installation Pack for 1 x Stand Installation Pack for 32-188G-GB-5B-TCU-UK 39-210G-GB-5B-FTCU-UK Please save your packaging as you will need this in the event of warranty/service repair or support. We are unable to carry out warranty/service if you are unable to package it correctly. The safest way to package your item in the event of warranty/service repair is in it’s original box/packaging.
Attaching the stand ATTACHING THE STAND IMPORTANT: 32/188G-GB-5B-TCU-UK The following instructions are for the model only. For the assembly you will need a screwdriver. Place the TV body on a fl at surface with the panel facing downwards to avoid damage.
Attaching the stand ATTACHING THE STAND IMPORTANT: 39/210G-GB-5B-FTCU-UK The following instructions are for the model only. For the assembly you will need a screwdriver. Place the TV body on a fl at surface with the panel facing downwards to avoid damage. 4 x B 2 x A 2 x A...
Detaching the stand and wall mounting DETACHING THE STAND Detaching the Stand Detaching the Stand For 32-188G-GB-5B-TCU-UK only For 39-210G-GB-5B-FTCU-UK only 5 x M(4x12) 4 x B 2 x A 2 x A 4 x B M (4x16) M (4x20)
Getting Started - Initial Set Up GETTING STARTED - INITIAL SET UP 1) Using the RF cable supplied, connect the TV 2) Connect the power cable to the Electrical to the TV Aerial wall socket (Fig A) outlet (Fig B) Fig B Fig A 3) Switch on the television using the...
TV Buttons and Source Menu TV BUTTONS & SOURCE MENU Volume up and menu right Volume down and menu left Programme/Channel up and menu up Programme/Channel down and menu down Displays Menu/OSD Displays the input source menu Standby Power On/Off Choosing Mode Input/Source To switch between the different input/ connections.
Remote Control REMOTE CONTROL STANDBY - Switch on TV when in standby or vice versa MUTE - Mute the sound or vice versa TV/RADIO - Switch to Freeview and switch between TV and radio in Freeview mode TV GUIDE - Opens the 7 Day TV Guide (Freeview mode) ATV - Switch to analogue TV source USB - Switch to USB Source S.MODE - Scrolls through sound mode options...
Page 15
Connections HDMI 1 HDMI input HDMI 2 HDMI input SCART SCART input VGA(PC) Audio In 3.5mm PC audio input VGA(PC) VGA-PC input RF IN RF / TV Aerial Input COAX Audio Out Digital Coax output USB input HDMI 3 HDMI input CI CARD IN Common Interface Card Input VIDEO...
Connections CONNECTIONS Connecting a Camcorder, Camera or Games Console Source should be set to Video Camera or Camcorder Yellow Video White Audio In L/R Connecting a High Defi nition (HD) Device Option 1 - via HDMI to HDMI cable A HDMI cable can output both video and audio and enables you to enjoy digital-quality video and audio with minimal loss of quality.
TV Menu Operation CHANNEL MENU To access this menu, press [MENU] button on the remote control. To enter a menu press [OK] If you wish to make changes to any of the default settings, use the scroll buttons. To confi rm any settings press [OK] button.
TV Menu Operation PICTURE MENU To access this menu, press [MENU] button on the remote control. To enter a menu press [OK] If you wish to make changes to any of the default settings, use the scroll buttons. To confi rm any settings press [OK] button. To exit this menu at anytime, press [EXIT] button.
TV Menu Operation SOUND MENU To access this menu, press [MENU] button on the remote control. To enter a menu press [OK] If you wish to make changes to any of the default settings, use the scroll buttons. To confi rm any settings press [OK] button.
TV Menu Operation TIME MENU To access this menu, press [MENU] button on the remote control. To enter a menu press [OK] If you wish to make changes to any of the default settings, use the scroll buttons. To confi rm any settings press [OK] button.
TV Menu Operation FEATURE MENU To access this menu, press [MENU] button on the remote control. To enter a menu press [OK] If you wish to make changes to any of the default settings, use the scroll buttons. To confi rm any settings press [OK] button.
TV Menu Operation SETUP MENU To access this menu, press [MENU] button on the remote control. To enter a menu press [OK] If you wish to make changes to any of the default settings, use the scroll buttons. To confi rm any settings press [OK] button.
PC Operation USING THE TELEVISION AS A COMPUTER MONITOR IMPORTANT – Before connecting the computer to the television you must ensure the computer settings are correct for the television. You MUST do this using your old monitor. How to set up for Windows XP & Windows Vista (connecting via VGA cable to the TV) 1) Switch on your computer 2) When fi...
Page 24
PC Operation PC SETTINGS To access this menu, press [MENU] button on the remote control. To enter a menu press [OK] If you wish to make changes to any of the default settings, use the scroll buttons. To confi rm any settings press [OK] button.
7 Day TV Guide 7 DAY TV GUIDE TV Guide is available in Digital TV mode. It provides information about forthcoming programmes (where supported by the freeview channel). You can view the start and end time of all programmes and on all channels for the next 7 days and set reminders.
USB Mode / Media Player USB MODE / MEDIA PLAYER USB mode offers playback of various different types of content that you have saved on your USB Memory Stick. On switching to USB source the above menu screen will appear. The content will be divided into Photo, Music, Movie and Text based on fi...
General Information USING YOUR TV WITH A SKY DIGITAL SET TOP BOX Option 1) Connecting your TV to your Sky box (when both the TV and Sky Box are located in the same room) Depending on your Sky Box & TV model, connect either by SCART or HDMI cable (available separately) If connecting by SCART, select the ‘Input source’...
General Information FREQUENTLY ASKED QUESTIONS General I would like to have louder Subject to the TV model and connections, it is possible to connect the TV sound by connecting to an external amplifi er or surround sound (subject to connections/inputs additional speakers on the device) as follows:- 1) Connect a COAX cable* from the TV’s COAX output to your amplifi...
TECHNICAL SPECIFICATION Model 32/188G-GB-5B-TCU-UK 39/210G-GB-5B-FTCU-UK Screen size (diagonal) 32”/ 81cm 39”/ 99CM Resolution 1366 x 768 1920 x 1080 PC RGB 75 ohm Antenna / PAL-SECAM Video Inputs 1 x SCART, 1 x Video, 1 x Component (YPbPr - 1080p),...
General Information INDEX Attaching the stand ............9-10 System Lock ..............21 Aspect Ratio ..............22 Technical Specifi cations ..........29 Auto Confi guration of screen (PC) ........ 24 Treble ................19 Auto Tuning ..............17 TV buttons ..............13 Auto Volume Level ............
Page 31
Helpline No UK. 0871 2000 463 ROI. 01443 3940 Web Support: www.skymediauk.co.uk...
Page 32
Helpline No UK. 0871 2000 463 ROI. 01443 3940 Web Support: www.skymediauk.co.uk...
