Accessories - Pfaff Coverlock 3.0 Owner's Manual

28. Moveable upper cutter
29. Stitch nger lever
30. Stationary lower cutter
31. Chainstitch/Coverstitch looper
32. Lower looper
33. Upper looper
34. 2-thread converter
35. Upper looper clutch
36. Chain/coverstitch thread guide

Accessories

Accessories are contained in the accessory box.
1. Accessory box
2. Screwdriver
3. Knife blade (for the movable upper cutter)
4. Thread unreeling discs (5)
5. Thread spool nets (5)
6. Oiler
7. Allen key
8. Tweezers
9. Coverstitch table B (for Cover/chainstitch)
10. Cone holders (5)
11. Dust cover
12. Lint brush
13. Waste tray
14. Needle threader
15. Extension table including four legs and push pin (not
pictured).
Assemble the extension table and legs according to the
illustrations provided with the table. The push pin is
used in the small holes in the table to hold your fabric
in place when sewing circles (see page 31).
16. Needle pack (not pictured) system ELx705 including
three needles, size #14/90 and two needles, size
#12/80. Two needles, size #14/90, are in the machine
on delivery.
31 33
29 30 32
28
1
2 3 4
10
9
13
34
36 35
5 6 7 8
11
12
14
Introduction 5
