Learn Mode - SureFlap MICROCHIP CAT FLAP User Manual

6. Learn Mode

TM
To start operation, first SureFlap needs to learn the unique ID code of your
cat's microchip. This process is only required once for each cat, as the code is
permanently stored even if batteries are removed. Follow the simple step-by-
step guide below to carry out this process:
1) Initially the unit will be locked and no cat will be allowed to enter the
house. Make sure the manual lock is set to position 1, allowing the
door to open freely. See figure 21.
2) Remove the battery cover. Press the memory button for around 1
second and release. See figure 22.
3) The latch will open, allowing a cat to pass through the flap in either
direction. A further indication that the unit is in learn mode is the
indicator lamp which will flash every second. See figure 23.
4) The next cat to pass through the flap from either direction will be
remembered if they have a microchip implant.
5) Once a cat has been successfully learnt, the flap reverts back to
normal operation. The indicator lamp stops flashing and the latch
will close a couple of seconds after they have passed through the
flap.
For multiple cats, repeat the process until all cats have been learnt. Up to 32
different cats may be held in memory at once. Replace the battery cover after
all cats have been learnt.
This method of learning is particularly convenient for uncooperative cats!
Rather than having to find your cat and pass them through the flap, you can
simply set to learn mode and leave until he next decides to go through of his
own free will.
To cancel learn mode (e.g. after pressing the memory button accidentally)
simply press the memory button again for around 1 second and the unit will
revert back to normal operation.
In order to learn a cat, it is important that they pass through the flap.
There is a sensor that detects the cat's presence in the tunnel that
needs to be triggered and no amount of waving your cat in front of
the flap will have an effect.
Page 12
Manual lock set to
position 1 (open
both ways)
Figure 21
Figure 22
Latch opens
Figure 23
Page 13
Latch closed
Press memory
button once
Indicator lamp
flashes every
second
