Summary of Contents for Zanussi ZHC 925
- Page 1 INSTRUCTION BOOKLET COOKER HOOD ZHC 925...
- Page 2 If you require guidance in the use of the appliance or require further information on Zanussi Products, please contact our Customer Care Department. For general enquiries concerning your Zanussi appliance or for further information, visit our website at http:\\www.zanussi.co.uk...
-
Page 3: Important Safety Information
It is dangerous to alter the specifications or modify inexperienced persons may cause injury or more this product in any way. serious malfunction. Refer to your local Zanussi Service Force Centre. Always insist on genuine spare • When installed between adjoining wall cabinets the parts. -
Page 4: Your Appliance
YOUR APPLIANCE OPERATING INSTRUCTIONS This cooker hood is designed to extract unpleasant odours from the kitchen, it will not extract steam. Cooker Hood Controls The cooker hood functions are controlled by five push button switches located centrally in the T1 T2 T3 T4 T5 control fascia. - Page 5 To Operate Select the required fan speed and light if required. The appliance can be installed to recirculate or extract contaminated air. The cooker hood is more effective when used in the extraction mode. Recirculation The cooker hood is supplied specified for use in the recirculation mode with the charcoal filter fitted.
-
Page 6: Maintenance And Cleaning
MAINTENANCE AND CLEANING Before carrying out any maintenance or cleaning isolate the cooker hood from the mains supply. The cooker hood must be kept clean, as a build up of grease or fat can be a fire hazard. External Cleaning Wipe the cooker hood frequently with warm soapy water using a mild detergent. -
Page 7: Charcoal Filters
Charcoal Filters In the recirculation mode the charcoal filters absorb smells and unwanted odours. The charcoal filters cannot be cleaned or regenerated, and must be replaced when the Instensive speed LED T5 starts to flash, or at least once every 3 months. Attention: If, when used in the recirculation mode both the T2 and T4 LED indicator lights begin to flash simultaneously this indicates the... -
Page 8: Something Not Working
If you require an engineer or wish to purchase spare For general assistance with your appliance or for parts contact your local Service Force Centre by information on Zanussi products please contact our telephoning: Customer Care Department. Customer Care Department,... -
Page 9: Guarantee Conditions
GUARANTEE CONDITIONS We, Zanussi, undertake that if within twenty four months of the date of the purchase this Zanussi built-in product or any part thereof is proved to be defective by reason only of faulty workmanship or materials, the company will, at our option repair or replace the same FREE OF ANY CHARGE for labour, materials or carriage on condition that: •... -
Page 10: Installation Instructions
INSTALLATION INSTRUCTIONS It is dangerous to alter the specifications or attempt to modify this product in any way. Technical information DIMENSIONS HEIGHT OF CANOPY: 71.5mm HEIGHT OF CHIMNEY:(UPPER SECTION) 215mm (LOWER SECTION) 728.5mm WIDTH OF CANOPY: 898mm DEPTH OF CANOPY: 485mm ELECTRICAL SUPPLY VOLTAGE:... -
Page 11: Installing The Cooker Hood
INSTALLING THE COOKER HOOD Fig. 5 Please ensure that when the appliance is The manufacturer disclaims any responsibility for installed it is easily accessible to an damage due to incorrect installation of the cooker engineer in the event of a breakdown. hood or if the hood is not installed in compliance with relevant regulations controlling this type of installation. -
Page 12: Clearance Heights
Clearance Heights The cooker hood is designed to be fitted over a cooking appliance at the clearance heights stated, providing the maximum output of the appliance beneath does not exceed the maximums quoted in the Technical Specifications. If the output of the appliance below the cooker hood exceeds the maximum outputs quoted, please refer to the cooker manufacturer’s installation instructions. -
Page 13: Fitting The Wall Brackets
Fitting the Wall Brackets Draw a vertical line on the wall, from the centre of the cooking appliance up to the ceiling, using a spirit level and marker pen. This is to ensure the correct vertical alignment of the appliance. Fixing the first wall brackets No 2 Draw a horizontal line through the vertical approximately 1 or 2mm from the ceiling or from... -
Page 14: Fitting The Canopy Hood
Fitting the Canopy Hood Before starting to fix the canopy it will be necessary to adjust the support brackets S1 by turning the screws clockwise until the limit of the thread is reached as illustrated in Fig. 8. Hook the canopy onto the two 4.2x44.4mm screws1 fitted as described above and illustraed in Fig. - Page 15 Note: The two venting grilles must not be fitted into the lower chimney (I) until the chimney has been installed. Extraction The charcoal filter is not required in this mode and should be removed. Ducting The ducting used must be 150mm (6ins), or 125mm (5ins) in diameter.
-
Page 16: Fitting The Chimney Stack
Fitting the Chimney Stack The chimney consists of two sections. The upper chimney measures 215mm and the lower chimney (with the holes for recirculation on either side) measures 728.5mm. To fit the upper section (S) first expand the chimney slightly to allow it to be fitted over the brackets 2, and then secure the chimney stack to brackets using the four self tapping screws provided as illustrated... - Page 20 © Electrolux Household Appliances Limited 2001 4329620 03 - 010910...
