- Page 1 MODEL N° 65027 OWNER’S MANUAL Keep this Identification Number in case you must contact our Customer Service Department.
-
Page 2: Safety Information
SAFETY INFORMATION SAfETy ALERT SyMbOLS AND SIGNAL WORDS The safety information in this manual is denoted by the safety alert symbol: The level of risk is indicated by the following signal words: SIGNAL WORDS Warning Hazards or unsafe practices which COULD result in severe personal injury or death if the warning is ignored. - Page 3 BEFORE BEGINNING ASSEMBLY Keep the hardware bags and their contents separate. If any parts are missing, call our Customer Service Department Test fit all Bolts by inserting them into their respective holes. If necessary, carefully scrape away any excess powder coating buildup from inside the holes. Do not scrape away all of the powder coating.
- Page 4 ASSEMBLY GUIDES Refer to the following areas throughout the instructions to assist in the assembly process: TOOLS AND HARDWARE REQUIRED FOR THIS PAGE This area is located at the top, left-hand corner of the page and indicates which tools and hardware are needed to complete the assembly steps on a page.
-
Page 5: Table Of Contents
PARTS LIST Item Description Right Handle Bar Left Handle Bar Roll Bar Connection Sleeve Axle Wheel HARDWARE LIST Item Description Axle / Frame Hardware (1049675) Cotter Key 5/16” Nylock Nut 5/16” U-Bolt Axle End Plug Handles-to-Tub Assembly Hardware (1047564) 5/16” x 3” Round Phillips Head Screw 5/16”... -
Page 6: Tub
PARTS IDENTIFIER Parts shown at 10% of Actual Size AMu (x2) Wheel ARb (x1) ARE (x2) Roll Bar ” ARG (x1) Axle 19” ARf (x2) Connection Sleeve ARC (x1) ARD (x1) Right Handle Bar Left Handle Bar... - Page 7 HARDWARE IDENTIFIER AxLE/fRAME ASSEMbLy HARDWARE [bHS] (Hardware shown at actual size) ARJ (x2) 5/16” U-Bolt ARH (x4) AAO (x4) Cotter Key 5/16” Nylock Nut ARI (x2) Axle End Plug HANDLES-TO-Tub ASSEMbLy HARDWARE [bHT] (Hardware shown at actual size) AVf (x2) 5/16”...
-
Page 8: Wheel
AxLE fRAME ASSEMbLy HARDWARE REQUIRED AxLE/fRAME ASSEMbLy HARDWARE [bHS] (Actual Size) ARJ (x2) ARH (x4) 5/16” U-Bolt Cotter Key AAO (x4) 5/16” Nylock Nut ARI (x2) Axle End Plug PARTS REQUIRED Parts shown at 10% of Actual Size ” ARG (x1) Axle ARE (x2) Roll Bar... - Page 9 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 1/2” ARJ (x2) AAO (x4) Slide the two (2) Roll bars (ARE) over the two (2) Connection Sleeves (ARf) as shown. Ensure the holes line up. Ensure the Axle (ARG) is centered, and connect it to the Roll Bar Assembly using two (2) 5/16” u-bolts (ARJ) and four (4) 5/16”...
- Page 10 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE ARH (x2) Insert a Cotter Key (ARH) into the second hole from each end of the Axle (ARG) as shown.
- Page 11 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE NO HARDWARE REQuIRED fOR THIS STEP Slide one (1) Wheel (AMu) over each end of the Axle (ARG) until they butt up against the Cotter Keys (ARH). Note: Assemble the Wheels onto the Axle with the valve stems facing away from the Tub (ARB).
- Page 12 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE ARH (x2) ARI (x2) Secure the Wheels (AMu) to the Axle (ARG) by inserting a Cotter Key (ARH) through each hole at the ends of the Axle as shown. Insert one Axle End Plug (ARI) into each end of the Axle.
-
Page 13: Handles-To-Tub Assembly Hardware
HANDLES-TO-Tub ASSEMbLy HARDWARE REQUIRED HANDLES-TO-Tub ASSEMbLy HARDWARE [bHT] (Actual Size) AAN (x2) AbD (x2) AVf (x2) 5/16” Flat Washer 5/16” Cap Nut 5/16” x 3” Round Phillips Head Screw AVG (x2) 5/16” Custom Plastic Spacer PARTS REQUIRED Parts shown at 10% of Actual Size ARb (x1) ARC (x1) ARD (x1) - Page 14 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE NO HARDWARE REQuIRED fOR THIS STEP Turn the Tub (ARb) upside down and lay the Left & Right Handle bars (ARD & ARC) over the bottom of the Tub so the holes in the Handle Bars align with the holes on the bottom of each side of the Tub.
- Page 15 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE AVf (x2) 1/2” AVG (x2) AAN (x2) AbD (x2) Secure the Left & Right Handle bars (ARD & ARC) to the back of the Tub (ARb) using two (2) 5/16” x 3” Round Phillips Head Screws (AVf), two (2) 5/16”...
-
Page 16: Tub-To-Frame Assembly Hardware
Tub-TO-fRAME ASSEMbLy HARDWARE REQUIRED Tub-TO-fRAME ASSEMbLy HARDWARE [bHu] (Actual Size) AVH (x6) AbD (x6) AAO (x6) 5/16” x 2” Round Phillips Head Screw 5/16” Nylock Nut 5/16” Flat Washer PARTS REQUIRED Tub/HANDLES ASSEMbLy fRAME/WHEEL ASSEMbLy TOOLS REQUIRED Phillips Screwdriver 1/2” Wrench Safety Glasses... - Page 17 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE NO HARDWARE REQuIRED fOR THIS STEP Carefully turn the Tub (ARb) over and place it onto the Roll Bar/Wheel Assembly. Align the holes as shown.
- Page 18 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE AVH (x6) 1/2” AbD (x6) AAO (x6) Secure the Handles to the upper back of the Tub (ARb) using six (6) 5/16” x 2” Round Phillips Head Screws (AVH), six (6) 5/16” Flat Washers (ABD), and six (6) 5/16” Nylock Nuts (AAO). WARNING Do not overtighten the Cap Nut.
- Page 19 buILD WALL ExTENSIONS ADD EXTENSIONS Standard 1” x 2” (about 3/4” x 1 1/2”) boards can be inserted into the four slots on the sides of the Tub to extend the walls of the Wheelbarrow and hold a higher stack of debris. WARNING Do not exceed 550 lb., or more than you can carry.
-
Page 20: Warranty Information
Lifetime Products, Inc. reserves the right to make substitutions to warranty claims if parts are unavailable or obsolete. 1. Lifetime wheelbarrows are warranted to the original purchaser to be free from defects in material and workmanship for a period of two years from the date of original retail purchase. The word “defects” is defined as imperfections that impair the use of the product.
