  • Page 1 MODEL N° 80193 OWNER’S MANUAL Keep this Identification Number in case you must contact our Customer Service Department.

  • Page 2: Safety Instructions

    REGISTER YOUR PRODUCT ONLINE AT WWW.LIFETIME.COM At Lifetime, we are committed to providing innovative and quality products. While registering, you will have the opportunity to give us your feedback. Your input is valuable to us. directly. LIFETIME’S PROMISE TO YOU: Maintaining your privacy is our long-standing policy at Lifetime.

  • Page 3: Before Beginning Assembly

    BEFORE BEGINNING ASSEMBLY Keep the hardware bags and their contents separate. If any parts are missing, call our Customer Service Department. *TWO ADULTS RECOMMENDED TO COMPLETE ASSEMBLY* TOOLS REQUIRED FOR THIS ASSEMBLY Safety Glasses 7/16” Wrench 1/2” Wrench Rubber Mallet (1 pair for each person)

  • Page 4: Assembly Guide

    ASSEMBLY GUIDE Refer to the following areas throughout the instructions to assist in the assembly process: This area is located at the top, left-hand TOOLS AND HARDWARE REQUIRED FOR THIS PAGE corner of the page and indicates which tools and hardware are needed to complete the assembly steps on a page.

  • Page 5: Parts List

    PARTS LIST Item Description Item Description DAZ 80193 Table Cart Hardware Bag 1/4” x 1” Button-Head Screw 1/4” Nylock Nut 1/4” Standard Washer Cart Handle Front Table Support 3/16” Allen Wrench Rear Table Support End Cap PARTS IDENTIFIER PART ILLUSTRATIONS...

  • Page 6: Hardware Identifier

    Cart Handle Rear Castor DAX (x1) DAL (x1) Front Table Support Rear Table Support Front Castor HARDWARE IDENTIFIER 80193 TABLE CART HARDWARE BAG [DAZ] DAA (x6) DAC (x8) DAB (x18) 1/4” x 1” Button-Head Screw DAD (x16) DAE (x4) DAH (x4) DBA (x6) 5/16”...
  • Page 7 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 5/32” DAC (x4) Connect a Short Horizontal Support (DAT) and Cart Handle (DAU) to the Left and Right Rear Vertical Supports (DAV and DAW) as shown using the required hardware. Do not completely tighten Screws.
  • Page 8 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 3/16” Connect the second Short Horizontal Support (DAT) to the Left and Right Front Vertical Supports (DAO and DAN) as shown using the required hardware. Do not completely tighten Nuts until instructed. Note the positions of the holes.
  • Page 9 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 3/16” 1/2” DAB (x8) DAG (x10) Connect the Front and Rear Assemblies to the Left and Right Side Horizontal Supports (DAR and DAS) using the required hardware. Completely tighten these Nuts only after visually aligning the four holes indicated below. These four holes go toward the rear.
  • Page 10 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 5/32” Lay the Assembly on its side and connect the two Center Vertical Supports (DAQ) Supports using the required hardware. Do not completely tighten Nuts until instructed.
  • Page 11 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 5/32” DAC (x4) DBA (x4) DAH (x4) DAE (x4) Horizontal Support Tubes (DAP) hardware. Do not completely tighten Nuts until instructed. Note: You will need to gently pull out on the Left and Right Front Vertical Supports to insert the Horizontal Support Tubes (DAP).
  • Page 12 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 3/16” Carefully turn the Frame upside down. Slide a Center Table Support (DAI) up into place as shown. Secure the Center Table Support to the Frame using the required hardware. Do not completely tighten Nuts until instructed. Note: For 5’...
  • Page 13 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 3/16” Slide the second Center Table Support (DAI) up into place as shown. Secure the Center Table Support to the Frame using the required hardware. Do not completely tighten Nuts until instructed. Note: For 5’ round tables, attach the Center Table Supports using these holes.
  • Page 14 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 3/16” DAB (x4) DAG (x4) Slide the Front Table Support (DAL) up into place as shown. Secure the Front Table Support to the Frame using the required hardware. Do not completely tighten Nuts until instructed.
  • Page 15 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 3/16” 1/2” 7/16” DAB (x4) DAG (x4) Slide the Rear Table Support (DAX) up into place as shown. Secure the Rear Table Support to the Frame using the required hardware. Completely tighten all hardware.
  • Page 16 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 5/32” DAD (x16) Connect the Front and Rear Castors (DAK and DAJ) to the frame as shown using the required hardware. Completely tighten 1.10 these Screws. Turn the Table Cart right side up, and insert the four (4) End Caps (DBB) 1.11 as shown.

  • Page 17: Cleaning And Care

    CLEANING & CARE Congratulations on your Lifetime ® product purchase. By following the instructions below, your new Lifetime product should provide you with years of service and enjoyment. Cleaning and Care Clean with a non-abrasive cleaning solution and soft bristled brush. Abrasive cleaning materials may scratch the powder coating and are not recommended.
  • Page 18 5. This warranty is in lieu of all other warranties expressed or implied, including warranties of merchantability ® or fi tness for use to the extent permitted by Federal and state law. Neither Lifetime Products, Inc. nor any representative assumes any other liability in connection with this product. This warranty gives you specifi c legal rights, and you may also have other rights which vary from state to state.
