Advanced Setup

This is normally done by the installer at initial installation.
Enter advanced setup by sliding the Program Switch to
SET. When the clock is flashing, press the NEXT button for
5 seconds. Do not release the button until this screen
appears.
Press NEXT
to advance
NEXT
Press NEXT
to advance
NEXT
Press NEXT
to advance
NEXT
Press NEXT
to advance
NEXT
Continued
S1-THEC11P5S
Use these buttons to
adjust the deadband
from 1 to 6 degrees.
Use these buttons to
adjust the Cycles Per Hour
from 2 to 6.
d=no limit (zoning)
d1=d+no compressor
lockout (page 18).
Select backlight operation
when a button is pressed:
OFF: Never turns on.
2,4,6 or 8: Seconds back-
light will be on.
ON: Always on.*
Use these buttons to select
thermostat operation in
degrees C or F.
* ON is only available if the thermostat
is system powered.
Page 17
