UNICOM MicroGST/5 User Manual

5 and 8 port 10/100/1000base-t gigabit ethernet switches
Hide thumbs Also See for MicroGST/5:

Advertisement

Quick Links

Download this manual
908 Canada Court
City of Industry, CA 91748 U.S.A.
Phone: 626.964.7873 or 800.346.6668 Fax: 626.964.7880
www.unicomlink.com
e-mail: info@unicomlink.com
©UNICOM 2005. UNICOM and "A Network Systems Solution" are trademarks of UNICOM Electric, Inc.
All rights reserved. Specifications subject to change without notice.
Rev: 01.05
MicroGST/5
5 and 8 Port 10/100/1000Base-T

Gigabit Ethernet Switches

GEP-32005T
5 Port Switch
GEP-32008T
8 Port Switch
U
SER'S
8
and
M
ANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the MicroGST/5 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for UNICOM MicroGST/5

Summary of Contents for UNICOM MicroGST/5

  • Page 1: Gigabit Ethernet Switches

    City of Industry, CA 91748 U.S.A. Phone: 626.964.7873 or 800.346.6668 Fax: 626.964.7880 SER’S ANUAL www.unicomlink.com e-mail: info@unicomlink.com ©UNICOM 2005. UNICOM and “A Network Systems Solution” are trademarks of UNICOM Electric, Inc. All rights reserved. Specifications subject to change without notice. Rev: 01.05...

  • Page 2: Table Of Contents

    Content 1. Introduction ............... 1 2.Hardware Description..........3 3. Installation ..............6 4. Network Application ..........7 5. Technical Specification..........8...

  • Page 4: Introduction

    Unicom's 5 and 8 Port Desktop Gigabit Ethernet Switches are an ideal solution for solving traffic congestion at the core of the network. They offer Auto-Negotiation 10/100/1000Base-T Gigabit Ethernet ports that can significantly improve your network backbone performance.

  • Page 5: Package Contents

    N-Way Auto-Negotiation ν Back pressure half duplex ν Flow control full duplex ν True non-blocking switching ν Store-and-Forward architecture support ν Package Contents 5 or 8 Port Desktop Gigabit Ethernet Switch ν Power Adapter ν Four Rubber Feet ν User Manual ν...

  • Page 6: Hardware Description

    2.Hardware Description This Section describes the hardware of the MicroGST/5 and 8 switches. The physical dimensions of each switch are 165 x 100 x 32.5 mm (L x W x H) Front and Rear Panel The Front Panel of the MicroGST/5 and 8 switches consists of a power LED indicator for the unit and LED indicators (100/1000, Link/Activity, Full duplex/Collision) for each Gigabit port.

  • Page 7: Led Indicators

    Figure 2-2. The Rear Panel of the MicroGST/5 and 8 switches LED Indicators The LED Indicators gives real-time monitoring of system operating status. There are three LED indicators (100/1000, LNK/ACT, FDX/COL) for each The following table provides Gigabit port and one Power LED for the unit. descriptions of each LED status.
  • Page 8 Status Description Green Power On Power Power is not connected Green Port is operating at 1000Mbps speed. 100/1000 Orange Port is operating at 100Mbps speed. No device attached or in 10Mbps mode Green Port is connecting with the device. LNK/ACT Blinking Port is receiving or transmitting data.

  • Page 9: Installation

    3. Installation Set the Switch on a sufficiently large flat space with a power outlet nearby. The surface should be clean, smooth, level, and sturdy. Ensure there is enough clearance around the Switch to allow air circulation and the attachment of the power cord and cables.

  • Page 10: Network Application

    4. Network Application This section provides a sample of network topology in which the MicroGST/5 and 8 switches are used. In general, the MicroGST switches are designed as high-bandwidth backbone switches. You can use the MicroGST switches to connect servers, switches, workstations, and PCs to each other by connecting these devices directly to the Switch.

  • Page 11: Technical Specification

    5. Technical Specification The following table provides the technical specifications of the MicroGST/5 and 8 switches. IEEE 802.3 10Base-T Ethernet, IEEE 802.3u 100Base-TX Fast Ethernet Standard IEEE 802.3ab Gigabit Ethernet IEEE802.3x Flow Control and Back-pressure Protocol CSMA/CD Technology Store-and-Forward switching architecture 14,880 pps for 10Mbps Transfer Rate 148,800 pps for 100Mbps...
  • Page 12 Per port: 100/1000, Link/Activity, Full duplex/ Collision Per unit: Power Power Supply External power DC 12V/1.3A Power 5 port: 7.5 Watt (maximum) Consumption 8 port: 13.2Watt(maximum) Operation 0˚ to 45˚ C (32˚ to 113˚F) Temperature Operation 10% to 90% (Non-condensing) Humidity 165 x 100 x 32.5 mm (L x W x H) Dimension...
