- Page 1 User’s Guide Guide de l’utilisateur Bedienungsanleitung Manual de instrucciones...
- Page 2 User’s Guide 17 (16.0" Viewable Diagonal) Flat Square Color Monitor with Plug & Play...
-
Page 3: For Your Records
VESA. Energy Star is a trademark of the U.S. Environmental Protection Agency (EPA). Disclaimer: ViewSonic Corporation shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from furnishing this material, or the performance or use of this product. -
Page 4: Safety Guidelines
If you lose the fuse cover, the plug must not be used until a replacement cover is obtained. A replacement fuse cover can be purchased from your local ViewSonic dealer. IF THE FITTED MOULDED PLUG IS UNSUITABLE FOR THE SOCKET OUTLET IN YOUR HOME, THEN THE FUSE SHOULD BE REMOVED AND THE PLUG CUT OFF AND DISPOSED OF SAFELY. -
Page 5: Fcc Information
This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications. CE Certification This device complies with the requirements of the EEC directive 89/336/EEC with regard to "Electromagnetic compatibility." Optiquest Q71... -
Page 6: Table Of Contents
..........31 Contents Optiquest Q71... - Page 7 Contents Optiquest Q71...
-
Page 8: Getting Started
Getting Started Package Contents Congratulations on your purchase of an Optiquest Q71 high performance color monitor. Your Optiquest Q71 package includes the following: Optiquest Q71 monitor Attached video cable with 15 pin high density (HD) mini D-sub connector Power cord User’s guide... -
Page 9: Quick Installation
Macintosh users, see Chapter 4 for Is your computer an a telephone number in your area to get a free ViewSonic ® Macintosh ® ® or compatible? adapter (part No. VMA-1). -
Page 10: Monitor Stand Removal
Press the locations shown in the drawing to release the lock tab. 3. After the lock tab is released, pull the monitor stand up at an angle. 4. Remove the stand and store in the monitor's shipping carton. Optiquest Q71 Getting Started... -
Page 11: Features
This product is Energy Star compliant. All plastic parts are recyclable. All materials are strictly selected for ease of maintenance, inspection, and disposal. Our shipping cartons are made of recyclable material. Getting Started Optiquest Q71... - Page 12 PC and ® Macintosh ® Macintosh computers require ViewSonic Macintosh adapters. Contact your local dealer or ViewSonic for your free adapter. See Chapter 4 on Troubleshooting for a telephone number in your area. Optiquest Q71 Getting Started...
- Page 13 Getting Started Optiquest Q71...
-
Page 14: Operation
OPERATION This section shows how to adjust the monitor using the buttons Optiquest Q71 ® and the OnView control menu (pages 10-14). To adjust the monitor, follow the instructions on page 10. Power Degausses Power automatically LED. when turning on the power. - Page 15 ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ width. 6500 Exit User- defined 71Hz 57khz color temperatures. 5000 Color Temperatures Contrast Rotate Brightness Black lines = inactive The monitor's horizontal and Pink lines = active (ready to adjust) vertical frequencies. Optiquest Q71 Operation...
-
Page 16: Horizontal Size
This control curves the screen's vertical edges to the left or right. Press the + or - button to adjust. - Curves the screen's vertical edges to the left. + Curves the screen's vertical edges to the right. Optiquest Q71 Operation... - Page 17 + or - button. Press the select button again until R, G, and B are deselected. All the bars in the center will be black when deselected. Select another icon to adjust or exit the control menu. Optiquest Q71 Operation...
- Page 18 A small adjustment screen appears as shown below. 66 66 Press the + or - button to adjust. The adjustment screen automatically disappears after 20 seconds. Or press the brightness button to exit the screen. Optiquest Q71 Operation...
- Page 19 This control saves adjustments and exits the control menu. Exit is available twice for your convenience when moving around the menu. Shortcut: From anywhere in the control menu, press either the contrast or the brightness button twice to exit. Optiquest Q71 Operation...
- Page 20 Timing Chart The Optiquest Q71 digital monitor can run at an extensive range of resolutions and refresh rates. Certain standard resolutions are factory preset. There are also 10 timings which are user definable. For example, if your video card is set up to run 1024 pixels x 768 lines at an 80 Hz refresh rate, once you have adjusted the screen size and position to your preferences, the monitor will save this information to memory.
-
Page 21: Timings
• The factory preset timing is registered when the difference between the user definable timing and the factory preset timing is smaller than the allowable deviation; also, the polarity of their synchronizing signals must be the same. Optiquest Q71 Operation... -
Page 22: Plug And Play
Some older computer systems are not compatible with the DDC standard. If your monitor is displaying a monochrome image or the wrong resolution, call ViewSonic’s customer support for a non-DDC adapter. If you upgrade to a DDC compatible system later and want to use Plug & Play, just remove the adapter. -
Page 23: Ddc Diagnostic Utility
The Optiquest Q71 uses DDC (Display Data Channel) protocol to communicate with your computer's video card. The software diskette or CD ROM included in the Optiquest Q71 package has a utility file called DDCTEST.EXE. This utility is useful for troubleshooting if DDC-related ®... -
Page 24: Power Management System
The monitor automatically goes through the Power Management System steps when it is idle. To conserve energy, we recommend turning the monitor off at the power switch when it will not be used for long periods of time. Optiquest Q71 Operation... - Page 25 Optiquest Q71 Operation...
-
Page 26: Technical Data
0.30mm (max) at center 0.40mm (max) at corner ® ® *Macintosh computers require ViewSonic Macintosh adapters. Contact your local dealer or ViewSonic for your free adapter. See Chapter 4 on troubleshooting for a telephone number in your area. Continued... Optiquest Q71 Technical Data... - Page 27 <30W Suspend yellow <8W yellow <8W Other Features Compatible with the display data channel standards DDC1 and DDC2B All products and trademarks are brand names of their respective companies. Specifications are subject to change without notice. Optiquest Q71 Technical Data...
-
Page 28: Dimensions
Screen 408mm (16.0") (diagonal viewable) Side View 462mm Depth 462mm (18.2") Height 424mm (16.7") (with base) Tilt Base 312mm (12.3") 15˚ Tilt Tilt down down 5˚ 312mm 411mm Rotation Top View 90˚ Swivel Angle left right Optiquest Q71 Technical Data... - Page 29 Optiquest Q71 Technical Data...
-
Page 30: Troubleshooting
Troubleshooting If your Optiquest Q71 monitor is not performing properly, use this troubleshooting chart for quick solutions to common problems. If the problem persists, call your monitor dealer. For further support or to order your free ® Macintosh adapter, call ViewSonic... - Page 31 Electric power wiring nearby? Your office may have electric power wiring behind the wall. Move the monitor. Image is distorted Is the earth’s magnetic field Face monitor east for interfering with display? best image quality. Optiquest Q71 Troubleshooting...
-
Page 32: Care And Safety Tips
Never remove the rear cover. The display unit contains high-voltage parts. You may suffer electric shock if you touch these parts. Call your dealer or ® ViewSonic Customer Support. Optiquest Q71 Care and Safety Tips... -
Page 33: Care Of Your Monitor
If the plastic is very dirty, use a neutral, non-abrasive detergent. Do not use alcohol or ammonia based solutions. Avoid spilling liquid on the monitor. Always handle your monitor with care when moving it. Optiquest Q71 Care and Safety Tips... -
Page 34: Warranty
How long the warranty is effective: The OPTIQUEST Q71 color monitor, including the display tube, is warranted for three (3) years for all parts and one (1) year for all labor from the date of the first consumer purchase. - Page 35 Care and Safety Tips Optiquest Q71...
-
Page 36: Index
10, 11 Warranty, 29 IBM (PC), 7, 21 Weight, 22 Installation, 3-5 Width (monitor dimensions), 22, 23 Macintosh, 4, 7, 21, 25 Width (screen size), 10, 11 Maintenance, 27, 28 Monitor Stand Removal, 5 Monitor Controls, 9-14 Optiquest Q71 Index... - Page 37 NOTES Optiquest Q71 Index...
- Page 38 ® Optiquest ® A ViewSonic Company 20480 Business Parkway Walnut, CA 91789 Tel (909) 869-7976 Tel (800) 688-6688 Fax (909) 468-1202 V70124001...
