Adjusting the Screen Image

Beginning with the Main Menu shown below, use the buttons on the front
E
control panel to adjust the OnView
N
OnView controls are explained in the four steps at the top of the next page and
G
are further explained on pages 8-11.
L
S
H
Displays Main Menu; also
saves changes/exits Main
Menu.
Scrolls Up/Down
menu options
6
Adjusts selected control;
also, toggles between pair
of controls on some control
screens.
Optiquest Q110
controls which display on the screen. The
®
Main Menu with
OnView controls
Timing Mode:
1024x768 = resolution
Fh = Horizontal Frequency
(scan rate)
Fv = Vertical Frequency
(refresh rate)
Power Light
Power On/Off
Front Control Panel
