  • Page 1 Super Audio CD & DVD Audio/Video Changer DPC-8.5 Instruction Manual...

  • Page 2: Important Safety Instructions

    WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR MOISTURE. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING QUALIFIED PERSONNEL.

  • Page 3: Precautions

    Precautions DANGER: VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN AND INTERLOCK FAILED OR DEFEATED. DO NOT STARE INTO BEAM. CAUTION: THIS PRODUCT UTILIZES A LASER. USE OF CON- TROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECI- FIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
  • Page 4 Precautions— Continued 1. Region Numbers The DVD standard uses region numbers to control how discs can be played around the world, the world being divided into six regions. This unit will only play DVD discs that match its region number, which can be found on its rear panel (e.g., 2.

  • Page 5: Table Of Contents

    Keep this manual for future reference. Important Safety Instructions... 2 Precautions ... 3 Introduction... 7 Before Using the DPC-8.5 ... 13 Getting to Know the DPC-8.5... 14 Connecting the DPC-8.5... 20 Turning On the DPC-8.5 & First Time Setup ... 27 Basic Playback...
  • Page 6 Terminology ... 11 Before Using the DPC-8.5... 13 Installing the Remote’s Batteries ... 13 Using the Remote Controller... 13 Getting to Know the DPC-8.5 ... 14 Front Panel ... 14 Display ... 15 Rear Panel ... 16 Remote Controller ... 18 Connecting the DPC-8.5 ...

  • Page 7: Introduction

    To use , in addition to an connection, you must make an analog audio connection (RCA) between the DVD player and your Integra AV receiver. Power cord Shape may vary depending on the area which it was pur- chased. (Remote...

  • Page 8: Dpc-8.5 Features

    • Dynamic Range Control setting • Adjustable display brightnes • IR in/out * In catalogs and on packaging, the letter added to the end of the product name indicates the color of the DPC-8.5. Spec- ifications and operation are the same regardless of color.

  • Page 9: Disc Notes

    • Don’t use discs that have residue from adhesive tape, rental discs with peeling labels, or discs with custom- made labels or stickers. Doing so may damage the DPC-8.5 and you may not be able to remove the disc properly. DVD Region Numbers The DPC-8.5 supports only Region 1 DVD-Video...

  • Page 10: Disc Content Organization

    Stereo area Track 2 Track 3 • The DPC-8.5 supports up to 999 folders and up to 672 files per folder. • If you try to play an incompatible file, the message “This format cannot be played” appears on the display.

  • Page 11: Terminology

    Introduction —Continued Handling Discs • Never touch the underside of a disc. Always hold discs by the edge, as shown. Underside • Never attach adhesive tape or sticky labels to discs. Cleaning Discs • For best results, keep your discs clean. Fingerprints and dust can affect the sound or picture quality and should be removed as follows.
  • Page 12 Introduction —Continued ■ DVD-RW (DVD rewritable): A type of DVD disc that can be recorded over and over again. Can be used for DVD-Video or DVD-Audio. ■ DVD-Video: The format for storing MPEG2 video on DVD, with interactive menus, multiple soundtracks, subtitles, camera angles, and so on.

  • Page 13: Before Using The Dpc-8.5

    • Flat batteries should be removed as soon as possible to prevent possible leakage and corrosion. Using the Remote Controller To use the remote controller, point it at the DPC-8.5’s remote control sensor, as shown below. Remote control sensor DPC-8.5 30˚...

  • Page 14: Getting To Know The Dpc-8.5

    Standby For detailed information, refer to the pages in parenthesis. Standby/On button (27) This button is used to set the DPC-8.5 to On or Standby. Don’t turn on the DPC-8.5 until you’ve completed and double checked all of your connections (page 20).

  • Page 15: Display

    Getting to Know the DPC-8.5 —Continued Display CHAIN M CD DVD ALL MEMORY RANDOM DISC TITLE GROUP CHP TRACK For detailed information, refer to the pages in parenthesis. DISC indicator (30) The number of the currently selected disc appears here.

  • Page 16: Rear Panel

    PL) & DTS ( The Dolby Digital indicator ( a Dolby Digital soundtrack is selected. The Dolby Pro Logic ( DPC-8.5’s Dolby Pro Logic decoder is on. The DTS indicator appears when a DTS soundtrack is selected. DISC indicators 1–6 (29) These indicators show how many discs are loaded.
  • Page 17 IR receiver, which can be used to pickup signals from the remote controller when the DPC-8.5 is located in another room, installed in a rack, or is out of range of the remote controller The IR OUT connector can be used to connect a...

  • Page 18: Remote Controller

    For detailed information, refer to the pages in parenthesis. Standby button (27) This button is used to set the DPC-8.5 to Standby. On button (27) This button is used to turn on the DPC-8.5. Don’t turn on the DPC-8.5 until you’ve completed and double checked all of your connections (page 20).
  • Page 19 Getting to Know the DPC-8.5 —Continued Display button (48) This button is used to display information about the current disc, title, chapter, group, or track, including the elapsed time, remaining time, total time, and so Clear button (33, 36, 46) This button is used to cancel functions and to clear entered numbers.

  • Page 20: Connecting The Dpc-8.5

    Connecting the DPC-8.5 This chapter explains how to connect the DPC-8.5 to your other AV components. Before Making Any Connections • Read the manuals supplied with your AV components. • Don’t connect the power cord until you’ve completed all audio and video connections.

  • Page 21: Connecting Your Tv Or Projector

    S-Video offers better picture quality than composite video, so if your TV supports it, use the supplied S-Video cable to connect one of the DPC-8.5’s S VIDEO OUTPUTs to an S-Video input on your TV. Failing that, use the supplied composite video cable to connect one of the DPC-8.5’s VIDEO OUTPUTs to a composite video...
  • Page 22 (supplied) (red) (white) (yellow) Notes • Before making any connections, turn off the DPC-8.5 and your TV and disconnect their power cords from the wall outlets. • Refer to the connection information supplied with your TV. • Connect the DPC-8.5’s video outputs directly to your TV.

  • Page 23: Connecting An Av Receiver

    Connecting the DPC-8.5 —Continued Connecting an AV Receiver This section shows how to connect the DPC-8.5 to an AV receiver for Dolby Digital, DTS, DVD-Audio, and SACD playback. Digital Audio Connection (Dolby Digital & DTS) To fully enjoy the Dolby Digital and DTS soundtracks available on most DVD-Video discs, you need to connect one of the DPC-8.5’s digital audio outputs (OPTICAL or...

  • Page 24: Connecting A Stereo Amp

    Connecting the DPC-8.5 —Continued Connecting a Stereo Amp This section explains how to connect the DPC-8.5 to a stereo amp or receiver for sound quality better than that possible with most TV’s built-in speakers. This is great for listening to your CDs and MP3s, and DVDs and VCDs will sound better too.

  • Page 25: Controlling Components That Are Out Of Range

    Controlling the DPC-8.5 When It’s Out of Range If the DPC-8.5 is located in another room, installed in a cabinet, or is out of range of its remote controller, you can use a commercially available IR receiver to pick up the remote controller signals and feed them to the DPC-8.5, as shown below.

  • Page 26: Connecting The Power Cord

    • Do not use a power cord other than the one supplied with the DPC-8.5, which is designed exclusively for use with the DPC-8.5 and should not be used with any other component. • Never disconnect the power cord from the DPC-8.5 while the other end is still plugged into a wall outlet.

  • Page 27: Turning On The Dpc-8.5 & First Time Setup

    Angle Subtitle Play Pause Down Here you need to make a few settings to get the DPC-8.5 up and running. You can change these settings later (see page 52). Use the Up and Down [ ]/[ ] but- tons to select a TV shape, and Remote controller then press [Enter].
  • Page 28 Turning On the DPC-8.5 & First Time Setup —Continued On the Analog Audio Out menu, use the Up and Down [ Remote controller buttons to select 2 Channel or Multi Channel (default), and then press [Enter]. Enter Choose 2 Channel if you’re connecting the FRONT AUDIO OUTs to a stereo amp.

  • Page 29: Basic Playback

    If a bay is found to have no disc, the corresponding indicator disappears. • To open the disc tray and turn on the DPC-8.5 at the same time, press the Open/Close [ disc tray will take slightly longer to open.) •...

  • Page 30: Loading Discs During Playback

    Press the Open/Close [ button. The disc tray opens. The disc that’s currently playing Remote controller remains inside the DPC-8.5 and its disc Open/ bay is empty and won’t come to the Close front. To remove this disc, you must...

  • Page 31: Starting, Pausing & Stopping Playback

    • The type of disc currently selected is shown on the dis- play: DVD, DVD-AUDIO, SACD, VCD, or CD (see page 15). • You can select discs while the DPC-8.5 is stopped or during playback. • You can use the [Disc Skip] button to skip the current disc and start the next disc.

  • Page 32: Navigating Disc Menus

    Basic Playback —Continued Standby/On Standby Standby Open/ Close Search Last M Memory Chain Mode Repeat Random Display Clear Menu Top Menu Top Menu Enter Enter Return Setup Return Audio Angle Subtitle Audio Stop Play Pause Down Disc 1 Disc 2 Disc 3 Step/Slow Disc 4...

  • Page 33: Selecting Titles & Chapters By Number

    Basic Playback —Continued Standby/On Standby Standby Open/ Close Search Last M Memory Chain Mode Search Repeat Number buttons Random Display Clear Clear Top Menu Menu Enter Enter Return Setup Audio Angle Subtitle Stop Play Pause Down Down Step/Slow Disc 1 Disc 2 Disc 3 Disc 4...

  • Page 34: Using The Disc Navigator

    Basic Playback —Continued Standby/On Standby Standby Open/ Close Search Last M Memory Chain Mode Memory Repeat Random Display Clear Top Menu Top Menu Menu Enter Enter Return Setup Return Audio Angle Subtitle Stop Play Pause Down Down Disc 1 Disc 2 Disc 3 Step/Slow Disc 4...

  • Page 35: Memory Playback In The Disc Navigator

    Basic Playback —Continued Press the Stop [ ] button to stop playback. Remote controller Stop Notes: • If the selected JPEG file’s resolution is 640 x 480 pix- els, a thumbnail-size preview will be shown. If the res- olution exceeds 640 x 480, a preview will only be shown if the file contains thumbnail image data.

  • Page 36: Selecting Tracks By Number

    Basic Playback —Continued Standby/On Standby Standby Open/ Close Last M Memory Chain Mode Search Search Repeat Number buttons Random Display Clear Top Menu Menu Enter Return Setup Audio Angle Subtitle Stop Play Pause Down Step/Slow Disc 1 Disc 2 Disc 3 Disc 4 Disc 5 Disc 6 Disc Skip Progressive...

  • Page 37: Fast Forward & Reverse

    • Prolonged display of the same picture or menu may cause irreparable damage to your TV screen called screen burn-in . To prevent this, don’t display the same frame for too long. The DPC-8.5 features a screen saver to protect your TV from the effects of burn-in (page 63).

  • Page 38: Slow-Motion Playback

    Remote controller Dimmer Notes: • When the display brightness on another Integra AV component that’s connected via “disc tray light off” option might not work. • Even with the “disc tray light off” option selected, the disc tray light will come on when the disc tray is opened.

  • Page 39: Using Jpeg Cds

    Dimmer RC- 543DV Using JPEG CDs JPEG The DPC-8.5 supports JPEG CDs, so you can view your photos on TV either individually or as a slideshow. Load and select a JPEG CD. Depending on the type of JPEG disc, either the first nine pictures appear in thumbnail-size or the Disc Navigator appears.

  • Page 40: Using Chain Mode

    Menu Notes: • If the folder containing the JPEG images also contains some MP3 tracks, the DPC-8.5 will play those tracks while showing the slideshow. • If the selected JPEG file’s resolution is 640 x 480 pix- els or less, a thumbnail-size preview is shown. If the resolution exceeds 640 x 480, a preview will only be shown if the file contains thumbnail data.

  • Page 41: Advanced Playback

    Advanced Playback Repeat Standby/On Standby Standby Open/ Close Last M Memory Chain Mode Search Search Repeat Repeat Number buttons Random Display Clear Top Menu Menu Enter Return Setup Audio Angle Subtitle Play Stop Play Pause Down Disc 1 Disc 2 Disc 3 Step/Slow Disc 4...

  • Page 42: A-B Repeat Playback

    Advanced Playback —Continued Press the Play [ ] button to start repeat playback. Remote controller Play To cancel repeat playback, use the [Repeat] button to select Off. Remote controller If you’re using the Repeat function with Repeat the Disc Navigator (MP3/JPEG), the Repeat function is off when the MODE: field is blank.

  • Page 43: Random Playback

    Advanced Playback —Continued Random Playback DVD-A DVD-V SACD With the Random function you can enjoy a random selection of discs, titles, chapters, groups, tracks, or folders. Select a disc. See page 30. Press the [Random] button repeatedly to select a random Remote controller option.

  • Page 44: Memory Playback

    Advanced Playback —Continued Standby Open/ Close Search Last M Memory Chain Mode Repeat Number buttons Random Display Clear Menu Top Menu Enter Enter Return Setup Audio Angle Subtitle Angle Stop Play Pause Down Disc 1 Disc 2 Disc 3 Step/Slow Memory Playback DVD-A SACD...
  • Page 45 Advanced Playback —Continued To stop playback, press the Stop [ ] button. Remote controller Stop Inserting New Items into the Memory List Press the [Memory] button. The Memory Play Setup window Remote controller appears onscreen. Memory Use the Left or Right [ button to move the cursor from Remote controller the top row.

  • Page 46: Selecting Camera Angles

    [Memory] Memory button. Notes: • The playlist is deleted when the DPC-8.5 is set to Standby. • To use this function with a VCD that supports PBC, you must first turn off PBC (see page 64). • With some discs you won’t be able to make a playlist.

  • Page 47: Selecting Languages & Audio Formats

    With progressive scanning you can enjoy better picture quality. To use progressive scanning, your TV or projec- tor must support it and be connected to one of the DPC-8.5’s component video outputs (see page 21). Press the [Progressive] button. Progressive scanning is enabled and the...

  • Page 48: Using Last Memory

    Last M To stop playback, press the Stop [ ] button once or twice. At this point you may choose to play another disc, or to turn off the DPC-8.5. Remote controller Stop To resume playback, select the disc and press the Play [ ] button.
  • Page 49 As above plus number of audio channels. Current/total track number, elapsed disc time, remaining disc time, total disc time. Title, artist name, album name. DPC-8.5 Display Elapsed title time Remaining title time Elapsed chapter time Elapsed title time DPC-8.5 Display...
  • Page 50 Disc Navigator Current/total track number, elapsed track time, current/total folder number, file name, etc. Title, artist name, album name, year, genre, comment. Disc Navigator DPC-8.5 Display Elapsed track time Remaining track time Elapsed disc time Remaining disc time Elapsed track time DPC-8.5 Display...

  • Page 51: Turning Off The Video Circuits

    You can turn off all of the internal video circuitry, elimi- nating the possibility of interference, for a pure-audio experience when playing audio-only discs. Press the DPC-8.5’s [Video Cir- cuit Off] button. The internal video circuitry is turned off, the [Video Circuit Off] button indi- cator lights up, and the V.OFF indicator...

  • Page 52: Configuring The Dpc-8.5

    Configuring the DPC-8.5 This chapter explains the various settings on the onscreen setup menus. Settings are arranged into six groups: Picture, Audio, Language, Display, Operation, and Initial Setup . The following table lists all of the settings, with a brief descrip- tion and page number where you can find full details.
  • Page 53 Turns PBC (Playback Control) for VCDs on and off. Determines what’s played on DVD-Audio discs with DVD-Video content. Sets the Auto power off function. This is the menu that appears automatically the very first time the DPC-8.5 is turned on. Page #...

  • Page 54: Using The Onscreen Setup Menus

    Disc 1 Using the Onscreen Setup Menus This section explains how to use the onscreen setup menus. Turn on the DPC-8.5 and your TV. On your TV, select the video input to which the DPC-8.5 is connected. Press the [Setup] button.

  • Page 55: Interlaced Setting

    Configuring the DPC-8.5 —Continued Random Display Clear Top Menu Menu Enter Enter Return Setup Setup Audio Angle Subtitle Stop Play Pause Down Disc 3 Step/Slow Disc 1 Disc 2 Interlaced Setting With this setting you can adjust various picture parame- ters for interlaced scanning.

  • Page 56: Progressive Setting

    Audio Menu Digital Out/Digital1 (OPTICAL) With these settings you can determine how the DPC-8.5 outputs digital audio from its OPTICAL DIGITAL AUDIO OUTPUT. The options you choose will depend on the type of component that you connect.
  • Page 57 ■ Digital Out With this setting you can turn the OPTICAL DIGITAL AUDIO OUTPUT on or off. Depending on how you con- nect the DPC-8.5 to your other components, this can be useful in certain situations. On (default) OPTICAL DIGITAL AUDIO OUTPUT is on.

  • Page 58: Analog Audio Out

    • Speaker Setting • Speaker Distance • Test Tone ■ Dolby Pro Logic Setting This setting determines how the DPC-8.5’s built-in Dolby Pro Logic decoder works with 2-channel material. Auto (default) The Dolby Pro Logic decoder automatically detects and decodes only Dolby Surround material.

  • Page 59: Setting The Speaker Distances

    Configuring the DPC-8.5 —Continued Use the Up and Down [ buttons to select Front Speaker, Remote controller press the [Enter] button, use the Left and Right [ select an option, and then press [Enter] again. Enter When setting the Speaker Setting, for...
  • Page 60 Configuring the DPC-8.5 —Continued When you’ve finished, press the [Setup] button to exit setup, or Remote controller press the Left [ Setup edly to go back to the main setup menu. Note: • The Speaker Distance settings have no effect on SACD (multichannel area and 2-channel area) and 196 kHz/176.4 kHz DVD-Audio.

  • Page 61: Sacd Audio Setup

    Configuring the DPC-8.5 —Continued Use the Left and Right [ buttons to set the delay time. Remote controller Memory Range Enter 0–100 ms When you’ve finished, press the [Setup] button. Remote controller The settings are stored. Setup Notes: • This setting affects only the analog multichannel out- put.

  • Page 62: Language Menu

    Configuring the DPC-8.5 —Continued Language Menu On-Screen Language With this setting you can select a language for the onscreen setup menus and messages. English (default): English Français: French Español: Spanish Deutsch: German Italiano: Italian Japanese Disc Menu Language DVD-V With this setting you can specify your preferred lan- guage for DVD menus.

  • Page 63: Display Menu

    Configuring the DPC-8.5 —Continued Display Menu On-Screen Display With this setting you can turn on or off onscreen mes- sages, such as “Play,” “Stop,” and “Resume.” Off: Onscreen messages off. On (default): Onscreen messages on. On-Screen Display Color With this setting you can set the color and theme for the Disc Navigator.

  • Page 64: Title/Group Stop

    Stop [ ] button four times. • When using a disc that supports parental control, depending on the DPC-8.5’s operating status, some- times you may not be able to remove the disc simply by pressing the [Open/Close] button. In this case,...

  • Page 65: Initial Setup Menu

    Configuring the DPC-8.5 —Continued Initial Setup Menu This menu appears automatically the very first time you turn on the DPC-8.5. See “First Time Setup” on page 27 for more information. Selecting Other Languages This section explains how to select other languages for disc menus, audio, and subtitles.

  • Page 66: Troubleshooting

    Remedy Connect the power cord to a suitable wall outlet (page 26). Turn off the DPC-8.5, wait five seconds, then try turning it on again. If that fails, disconnect the power cord from the wall outlet, wait five sec- onds, reconnect it, then try turning it on again.
  • Page 67 ■ Restoring the Default Settings To reset the DPC-8.5 to its factory defaults, turn it on and, while holding down the Stop [ ] button, press the [Standby/ On] button. “Initialize” appears on the display. When the reset is complete, “Complete” is displayed, and the DPC-8.5 enters Standby mode.

  • Page 68: Specifications

    Dimensions (W x H x D) Weight Operation Condition Temperature Disc Compatibility Specifications and features subject to change without notice. Integra Division of ONKYO U.S.A. CORPORATION 18 park Way, Upper Saddle River, N.J. 07458, U.S.A. Tel: 201-785-2600 Fax: 201-785-2650 http://www.integrahometheater.com Integra Division of ONKYO CORPORATION Sales &...
