  • Page 1 ™ Carpetwin 14 / 18 OPERATOR MANUAL AND PARTS LIST OPERATOR MANUAL AND PARTS LIST OPERATOR MANUAL AND PARTS LIST OPERATOR MANUAL AND PARTS LIST OPERATOR MANUAL AND PARTS LIST Advance MODELS 56704200, 56704201 5/99 revised 11/02 Form Number 56041453...

  • Page 2: Table Of Contents

    Important Safety Instructions ..............2 Grounding Instructions ................5 Introduction ................... 7 Parts and Service .................. 7 Nameplate ..................... 7 Unpacking the Machine ................ 7 Know Your Machine ................7 Set-Up and Assembly ................7 Operating the Machine ................8 Using the Wand ..................

  • Page 3: Important Safety Instructions

    No changes or modifications of the mechanical, electrical or thermal safety devices should be made. When repairing or replacing the cord, the same type of cord as originally supplied with the machine must be used. This cord can be supplied by ADVANCE. SAVE THESE INSTRUCTIONS...
  • Page 4 Ne pas aspirer de liquides inflammables ou combustibles, telle l’essence, et ne pas utiliser à proximité. Eviter d’aspirer des objets durs ou pointus. Ne pas modifier les systèmes électriques, mécaniques ou thermiques. Remplacer le cable far un cable identique fourni far Advance. CONSERVER CES INSTRUCTIONS 3 - FORM NO. 56041453 / CARPETWIN 14 / 18...

  • Page 5: Instrucciones Importantes De Seguridad

    Cuando repare o sustituya el cable de conexión eléctrica, utilice el mismo tipo de cable suministrado originalmente con la máquina. Este cable le puede ser suministrado por ADVANCE. NO PIERDA ESTAS INSTRUCCIONES FORM NO. 56041453 / CARPETWIN 14 / 18 - 4...

  • Page 6: Grounding Instructions

    GROUNDING INSTRUCTIONS This appliance must be grounded. If it should electrically malfunction, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. This appliance is equipped with a cord having an equipment-grounding conductor and grounding plug. The plug must be plugged into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances.
  • Page 7 INTRUCCIONES PARA HACER LA TOMA A TIERRA Este aparato deberá ser conectado a tierra. En caso de malfuncionamiento o de desperfectos, la toma a tierra proporciona una vía de menor resistencia de la corriente eléctrica para reducir el riesgo de choques eléctricos. Esta unidad viene equipada con un cordón con conductores para toma a tierra y con un enchufe con toma a tierra.

  • Page 8: Introduction

    A-KNOW YOUR MACHINE As you read this manual, you will occasionally run across a bold number This manual will help you get the most from your Advance Carpetwin. in parentheses - example: (2). These numbers refer to an item shown Read it thoroughly before operating the machine.

  • Page 9: Operating The Machine

    VACUUM MOTOR BRUSHES To release the Power Cord (12) from the Cord Hooks (2), press the Have your Advance Dealer check the carbon motor brushes once a year Handle Lock Button (4) in while pushing down on the Handle (1) and or after 500 operating hours.

  • Page 10: Cleaning The Vacuum Inlet Filter

    CLEANING THE VACUUM INLET FILTER CHANGING THE BRUSH The vacuum inlet filter catches any dirt spilled from the bag, before it can Lay the machine over onto its left side. enter the vacuum motor. The filter is located just below the bag. Clean Slide the side cover (item #46 / page 13) off of the brush housing.
  • Page 11 NOTES FORM NO. 56041453 / CARPETWIN 14 / 18 - 10...

  • Page 12: Bag Housing Parts List

    11 - FORM NO. 56041453 / CARPETWIN 14 / 18...
  • Page 13 BAG HOUSING Item Ref. No. Description Item Ref. No. Description 56704205 Bag Housing Cover 56704212 Bag Door Latch (w/spring) 56646851 Grill Complete 56704222 Filter Holder 56703712 Grill Filter Holder 56646888 Exhaust Filter (pkg of 5) 56703714 Scented Pad (pkg of 10) 56704223 Exhaust Filter Cover 56703713...

  • Page 14: Brush Housing Parts List

    11 14 13 - FORM NO. 56041453 / CARPETWIN 14 / 18...
  • Page 15 BRUSH HOUSING - 14 / 18 Item Ref. No. Description Item Ref. No. Description 56704203 Brush Housing Assembly, 14" 56703853 Pulley Nut 56704204 Brush Housing Assembly, 18" 56704042 Circuit Board 56704227 Body Main Brush Head, 14" 56704155 Channel Cover 56704228 Body Main Brush Head, 18"...

  • Page 16: Wiring Diagram

    120Vac Brush Motor Motor WIRING DIAGRAM Item Ref. No. Description 56703708 Main Switch 56704159 Vacuum Sensor 56646877 Indicator Light 56704237 Vacuum Motor (56704168 used prior to SN1498331 on 14” & SN1499231 on 18”) 56704238 Carbon Brush for 56704237 & 56704168 TSBUS2002-829 56703738 Brush Motor Switch 56704042...
  • Page 17 Buyer. Authorized Nilfisk-Advance Service Centers can assist owners in the proper handling of any warranty question or claim. In the event that you want to contact Nilfisk-Advance directly, please write to the Customer Service Department at Nilfisk-Advance, Inc., 14600 21st Avenue North, Plymouth, Minnesota 55447-3408.
