SpeakerCraft EazyR-2 Owner's Manual Addendum

OWNER'S MANUAL
ADDENDUM
EazyR-2
EZ Learning Remote Control

INTRODUCTION

This addendum should only be read
after you become familiar with the
basic programming functions of the
EazyR-2 remote in the main owner' s
manual. This assumes you are then
familiar with the basic setup proce-
dure for entering Library Codes and
the procedure for learning IR codes.
IR LIBRARIES & OVERLAYS
We have included special IR code
libraries and overlays for the
SoundSource and Eazy6 in our new
EazyR-2 remote.
The EazyR-2 comes with both sets of
codes installed in its library. The AMP
Source button is the button that you
would normally use for either the
SoundSource or the Eazy6.
The factory default under the AMP
button is the SoundSource Code Set
(# 0839), which can be changed to
the Eazy6 Code Set (# 1114). More
on how to accomplish this later.
Three overlays for the lower 12 buttons
are included: 1 for the SoundSource, 1
for the Eazy6, and a blank overlay. (See
Figure 1)
Figure 1
SoundSource Overlay
Eazy6 Overlay
Blank Overlay
LOCKING/UNLOCKING
IR LIBRARIES
The EazyR-2 remote comes fac-
tory defaulted (and locked) to the
SoundSource Code Set under the
AMP button. All other sources are
available for use with any of the
installed IR libraries or the IR codes
can be individually learned.
A Source button (i.e., AUX, CBL,
VCR, TV, SAT, CD, AMP, or TNR)
and its associated library can be
Locked or Unlocked for Code Set
changes as follows:
Press a Source button -> then SETUP
-> then 9 - 8 - 2.
This is a toggle function so it will alter-
nate from Locked to Unlocked each
time you go through the SETUP ->
then 9 - 8 - 2 sequence. The LED will
blink twice when locked and 4 times
when unlocked.
For example: If you want to unlock
the fixed, factory default for the AMP
button, which is the SoundSource,
you would:
Press the AMP button -> then
SETUP -> then 9 - 8 - 2. The LED
should blink 4 times indicating that
it is unlocked and can then be pro-
grammed with any other Library
Code Set. Follow the setup procedure
in the main owner' s manual.
To change it to the default Eazy6
Code Set however, additional steps
are required after the unlock steps
above.
