ESP0027
Z100 / Z300
Z500
Z700
OWNER'S MANUAL
PLEASE CAREFULLY READ THIS ENTIRE MANUAL BEFORE
OPERATING YOUR NEW ELLIPTICAL!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EL155 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ESPRIT EL155

  • Page 1 ESP0027 Z100 / Z300 Z500 Z700 OWNER’S MANUAL PLEASE CAREFULLY READ THIS ENTIRE MANUAL BEFORE OPERATING YOUR NEW ELLIPTICAL!
  • Page 2: Table Of Contents

    Table of Contents Product Registration…………………………………………………………………………..2 Important Safety Instructions………………………………………………………………… Important Electrical Information……………………………………………………………… Important Operation Instructions…………………………………………………………….. Assembly Instructions…………………………………………………………………………. Features……………………………………………………………………………………….. Operation of Your New Elliptical…………………………………………………………….. Maintenance……………………...…………………………………………………………… Parts List and Explode Drawing.…………………………………………………………… Manufacturer’s Limited Warranty……………………………………………………………. EL155 Elliptical...
  • Page 3: Product Registration

    We appreciate your support and we will always remember that you are the reason that we are in business. Yours in Health, BOYLES FITNESS Equipment Pty Ltd. Name of Dealer______________________________________ Purchase Date_______________________________________ EL155/ESP0027_Ver.B EL155 Elliptical...
  • Page 4: Important Safety Instructions

    Wear proper shoes. High heels, dress shoes, sandals or bare feet are not suitable for use on ■ your elliptical. Quality athletic shoes are recommended to avoid leg fatigue. SAVE THESE INSTRUCTIONS - THINK SAFETY! EL155 Elliptical...
  • Page 5: Important Electrical Information

    Do not use excessive pressure on console control keys. They are precision set to properly function with little finger pressure. Pushing harder is not going to make the unit go faster or slower. If you feel the buttons are not functioning properly with normal pressure, contact your dealer. EL155 Elliptical...
  • Page 6: Assembly Instructions

    Assembly Instructions EL155 ) ASSEMBLY PACK CHECK LIST Step 1 #112. 3/8" × 23 × 1.5T Ø #104. 8.5× 26 × 2.0T #102. 3/8" × 25 × 2T Curved Washer (2pcs) Flat Washer (2pcs) Flat Washer (4pcs) #110. 3/8" × 2T #84.
  • Page 7 #75. 5/16" × 1-1/4" Phillips Head Screw (4pcs) Hex Head Bolt (2pcs) Hex Head Bolt (2pcs) #91. 5/16" × 7T #105. 5/16" × 20 ×1.5T Ø #104. 8.5× 26 × 2.0T Nyloc Nut (2pcs) Flat Washer (2pcs) Flat Washer (2pcs) EL155 Elliptical...
  • Page 8 #76. 5/16" × 1-3/4" Sheet Metal Screw (6pcs) Hex Head Bolt (6pcs) Tools #116. 12 mm Wrench (1pcs) #115. 13&14 mm Wrench (1pcs) #118. Combination M5 Allen Wrench #117. M6 Allen Wrench (1pcs) & Phillips Head Screw Driver (1pcs) EL155 Elliptical...
  • Page 9 2pcs of M5 × 10m/m Phillips Head Screws (84) by using Combination M5 Allen Wrench & Phillips Head Screw Driver (118). Secure the Middle Stabilizer Cover (71) on the Rear Rail Assembly with 1pc of M5 × 15m/m Phillips Head Screw (82) by using Combination M5 Allen Wrench & Phillips Head Screw Driver (118). EL155 Elliptical...
  • Page 10 3. Install the two Slide Wheel Covers (65) respectively upon the left Slide Wheel and right Slide Wheel, and secure with 4pcs of M5 × 15m/m Phillips Head Screws (82) by using Combination M5 Allen Wrench & Phillips Head Screw Driver (118). EL155 Elliptical...
  • Page 11 3. Put one of two Connecting Arm Covers (L) (66) and one of two Connecting Arm Covers (R) (67) together on each side of Rod End Bearing, and secure them with 4pcs of M5 × 15m/m Phillips Head Screws (82) by using Combination M5 Allen Wrench & Phillips Head Screw Driver (118). EL155 Elliptical...
  • Page 12 2. Put the Front Handle Bar Cover (L) (69) and the Rear Handle Bar Cover (L) (69~1) together on the left Handle Bar and secure with 3pcs of Ø3.5 × 12m/m Sheet Metal Screws (87) by using Combination M5 Allen Wrench & Phillips Head Screw Driver (118). Repeat the same procedure for the right side. EL155 Elliptical...
  • Page 13: Features

    This eases the over stressing of the ankles, knees and hips. Transportation elliptical is equipped with two transport wheels, which are engaged when the rear of the Elliptical is lifted. POWER CONNECTOR LOCATED ON FRONT, LEFT HAND SIDE OF UNIT. EL155 Elliptical...
  • Page 14: Operation Of Your New Elliptical

    Operation of Your Elliptical Getting familiar with the control panel EL155 Console ■ Key Functions: ENTER: 1. Press this button to confirm the setting value of Year- Month- Date- Hour-Minute and alarm. 2. Press this button to select functions of Distance, Time, Calories, T.H.R, Gender, Age,...
  • Page 15 Target Heart Rate program, Heart Rate Control and 4 users programs to choose for training. Each program has 16 columns of loading bars and 8 bars in each column. Each column represents 1 minute work out (without the change of time value) and each bar represents 2 levels loading. EL155 Elliptical...
  • Page 16: Operation Instructions

    User can set the target value from 10 to 9990 then the monitor will count down form the setting value. Once reach the setting value, the monitor will alarm then stop. If user would like to continue exercise, press Start key then the value will count up from 0.0. EL155 Elliptical...
  • Page 17 Type 5 is Ultra body fate type (40% ~50%) BMI: Body Mass Index Calculate from your personal data to show the value from 1.0 ~ 99.99. Body Fat%: Calculate from your personal data to show the value from 5 ~ 50%. EL155 Elliptical...
  • Page 18 LCD display. After that the result will show out on the LCD from F1.0 to F6.0, the increment is 0.1. F1.0 means the best, and F6.0 means the worst. Press any key to return to the main display. EL155 Elliptical...
  • Page 19: Maintenance

    Motor test (continually runs the tensioning gear motor) v. Manual (Allows stepping of the gear motor) vi. Key tone (Turn on or off the beep when a key is pressed) d. Security (Allows you to lock the keypad so no unauthorized use is allowed) EL155 Elliptical...
  • Page 20: Parts List And Explode Drawing

    ESP0027 –EL155 Parts List DESCRIPTION O'TY Main Frame Rear Rail Assembly Crank Arm Assembly Bushing Housing, Pedal Arm Pedal Arm (L) Pedal Arm (R) Connecting Arm (L) Connecting Arm (R) Lower Handle Bar (L) Lower Handle Bar (R) Console Mast...
  • Page 21 Ø17_C Ring 5/16" × 7T_Nyloc Nut M8 × 7T_Nyloc Nut M8 × 9T_Nyloc Nut 1/4"_Nyloc Nut 3/8" × 11T_Nyloc Nut 3/8"_Cap Nut 3/8" -UNF26 × 4T_Nut 3/8”-UNF26 × 9T_Nut 3/8" × 7T_Nut 3/8" × 19 × 1.5T_Flat Washer EL155 Elliptical...
  • Page 22 7 × 7 × 25L_Woodruff Key 13.14m/m_Wrench 12_Wrench M6_Allen Wrench Combination M5 Allen Wrench & Phillips Head Screw Driver Ø5/16" × 16 × 1T_Flat Washer Ø5 × 16 × 1.5T_Flat Washer M6 × 15m/m_Phillips Head Screw 2000m/m_Adaptor Power Cord EL155 Elliptical...
  • Page 23 ESP0027 – EL155 Explode Drawing EL155 Elliptical...
  • Page 24: Manufacturer's Limited Warranty

    1 Year Brake Lifetime BOYLES FITNESS warrants its ESP0027 EL155 Elliptical to be free from defects in material and workmanship under normal use and service conditions. Evidence of unfair usage or incorrect adjustment by the owner will void this promise.
  • Page 25: Warranty Information

    Law. If the warranty periods offered in the two documents are different then the greater of the two shall be honoured. This EL155 Elliptical is warranted to be free from defects in material and workmanship under normal use and service conditions for a period of 6 months from the date of purchase of this article.
  • Page 26 Contact details and hours of operation. 07 3272 7010 Freecall 9:00am – 4:30pm Monday to Friday (excluding Public Holidays) 9:00am – 3:00pm Saturday This product is warranted by Boyles Fitness Equipment Pty Ltd 130 Carrolls Road, Menangle NSW 2568 Phone 02 4636 6680 EL155 Elliptical...
