CLEANING AND MAINTENANCE

Connections
Connections on pressure washer hoses; gun and spray wand should be cleaned regularly
and lubricated with non-water soluble grease.
Spray Tips Only
Clogging of the spray tips causes the pump
pressure to be too high and cleaning is
immediately required. You can clean the
spray tips by carefully inserting the needle,
or a thin, sharp instrument (i.e. paperclip)
into the tip to rid it of deposits.
Water Filter Screen
The pressure washer is equipped with a
water inlet screen to protect the pump.
of water to the pressure washer will be
restricted and the pump may be damaged.
1. To clean inner water screen, push the
connector inside and and remove the
filter screen from the water inlet.
2. Rinse screen until it is free of debris
and blockage.
3. Replace screen immediately to prevent
any foreign matter from entering the
pump.
13

TROUBLESHOOTING

Disconnect the machine from the power source before making any repairs.
Symptom Cause
Motor will not start. On/Off switch is in the
"OFF" (O) position.
GFCI is not plugged in.
Extension cord is too long.
Extension cord is not
proper gauge.
Extension cord is damaged.
Electrical outlet does not
supply adequate power.
Tripped pressure washer
thermal protector.
Unit does not reach Diameter of garden hose is
high pressure. too small.
Water supply is restricted.
Not enough water supply.
Water inlet filter is clogged.
Power nozzle is in low-
pressure position.
Pump is sucking air.
Output pressure varies high Not enough inlet water supply. Turn water on fully. Check
and low.
Pump is sucking air.
Water inlet filter is clogged.
Solution
Turn switch to the "ON"
( | ) position.
Plug in GFCI.
Replace extension cord
with either a 25' (7 .6 m)
14AWG cord or a 50' (15 m)
14AWG cord.
Try a different outlet.
Allow to cool, and restart unit.
Replace with a 1" (25 mm) or
5/8" (16 mm) garden hose.
Check garden hose for
kinks, leaks and blockage.
Open water source fully.
Remove filter and rinse in
warm water.
Turn power nozzle to high-
pressure position.
Check that hoses and
fittings are airtight. Turn
"OFF" machine, and purge
pump by squeezing trigger
water emerges through
the nozzle.
garden hose for kinks, leaks
or blockage.
Check that hoses and
fittings are airtight. Turn
"OFF" machine, and purge
pump by squeezing trigger
water emerges through
the nozzle.
Remove filter and rinse
with warm water.
