SERVICE MANUAL
3
2006
MA255
KD-SH1000J,KD-SH1000E,
KD-SH1000EX,KD-SH1000EY,
KD-SH1000EU,KD-SH1000U,
KD-SH1000UN,KD-SH1000UT,
Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)
1
PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
2
SPECIFIC SERVICE INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
3
DISASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8
4
ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-23
5
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-27
CD RECEIVER
KD-SH1000UH

TABLE OF CONTENTS

COPYRIGHT © 2006 Victor Company of Japan, Limited
No.MA255
2006/3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KD-SH1000J and is the answer not in the manual?

Questions and answers

Related Manuals for JVC KD-SH1000J

Summary of Contents for JVC KD-SH1000J

  • Page 1: Table Of Contents

    SERVICE MANUAL CD RECEIVER MA255 2006 KD-SH1000J,KD-SH1000E, KD-SH1000EX,KD-SH1000EY, KD-SH1000EU,KD-SH1000U, KD-SH1000UN,KD-SH1000UT, KD-SH1000UH Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade) TABLE OF CONTENTS PRECAUTIONS ............... 1-4 SPECIFIC SERVICE INSTRUCTIONS .
  • Page 2 SPECIFICATION AUDIO AMPLIFIER SECTION 20 W RMS × 4 Channels at 4 Ω and [< or =] 1% THD+N Power Output (for J) 80 dBA (reference: 1 W into 4 Ω) Signal to Noise Ratio(for J) Maximum Power Output Front/Rear 50 W per channel 19 W per channel into 4 Ω, 40 Hz to 20 000 Hz at no more than Continuous Power Output (RMS)
  • Page 3 CD PLAYER SECTION Type Compact disc player Signal Detection System Non-contact optical pickup (semiconductor laser) Number of Channels 2 channels (stereo) Frequency Response 5 Hz to 20 000 Hz Dynamic Range 98 dB Signal-to-Noise Ratio 102 dB Wow and Flutter Less than measurable limit Bit Rate 32 kbps - 320 kbps...

  • Page 4: Precautions

    SECTION 1 PRECAUTIONS Safety Precautions Burrs formed during molding may be left over on some parts of the chassis. Therefore, pay attention to such burrs in the case of preforming repair of this system. Please use enough caution not to see the beam directly or touch it in case of an adjustment or operation check.
  • Page 5 Preventing static electricity Electrostatic discharge (ESD), which occurs when static electricity stored in the body, fabric, etc. is discharged, can destroy the laser diode in the traverse unit (optical pickup). Take care to prevent this when performing repairs. 1.2.1 Grounding to prevent damage by static electricity Static electricity in the work area can destroy the optical pickup (laser diode) in devices such as laser products.
  • Page 6 Important for laser products 5.CAUTION : If safety switches malfunction, the laser is able 1.CLASS 1 LASER PRODUCT to function. 2.DANGER : Invisible laser radiation when open and inter 6.CAUTION : Use of controls, adjustments or performance of lock failed or defeated. Avoid direct exposure to beam. procedures other than those specified here in may result in 3.CAUTION : There are no serviceable parts inside the hazardous radiation exposure.

  • Page 7: Specific Service Instructions

    SECTION 2 SPECIFIC SERVICE INSTRUCTIONS This service manual does not describe SPECIFIC SERVICE INSTRUCTIONS. (No.MA255)1-7...

  • Page 8: Disassembly

    SECTION 3 DISASSEMBLY Main body section 3.1.1 Removing the front panel assembly (See Fig.1) (1) Push the detach button in the lower right part of the front Front panel assembly panel assembly. (2) Remove the front panel assembly. Detach button Fig.1 3.1.2 Removing the heat sink (See Fig.2)
  • Page 9 3.1.3 Removing the top chassis assembly (See Fig.3 to 6) • Prior to performing the following procedures, remove the heat Bottom chassis assembly sink. Reference: Remove the front panel assembly as required. (1) From the bottom side of the main body, remove the two screws C attaching the top chassis assembly to the bottom chassis assembly.
  • Page 10 3.1.4 Removing the front chassis assembly (See Fig 7, 8) • Prior performing the following procedure, remove the front Top chassis assembly panel assembly, heat sink and top chassis assembly. (1) From the both sides of the top chassis assembly, remove the two screws F attaching the front chassis assembly.
  • Page 11 3.1.6 Removing the main board (See Fig.10, 11) • Prior to performing the following procedures, remove the front Rear bracket panel assembly, heat sink and top chassis assembly. (1) From the rear side of the bottom chassis assembly, remove the two screws H attaching the rear bracket to the bottom chassis assembly.
  • Page 12 3.1.8 Removing the front door mechanism assembly (See Fig.13) • Prior to perform the following procedures, remove the front Front door mechanism assembly panel assembly, heat sink, top chassis assembly and main Bottom chassis board. (1) From the top side of the bottom chassis assembly, remove the one screw N attaching the FPC guide to the bottom chassis.
  • Page 13 CD mechanism assembly section • Remove the CD mechanism assembly from the main body. (See "3.1.5 Removing the CD mechanism assembly".) 3.2.1 Removing the mechanism control board (See Fig.1) (1) From the bottom side of the CD mechanism assembly, sol- CD mechanism assembly der the short sections on the flexible wire.
  • Page 14 3.2.2 Removing the top cover (See Fig.2) (1) From the back side of the CD mechanism assembly, re- move the two screws B attaching the top cover. (2) Take out the top cover in an upward direction. Reference: When attaching the top cover, set the sections c of the top cov- er under the bending sections d of the chassis base 2.
  • Page 15 3.2.4 Removing the clamper unit (See Figs.5 and 6) • Remove the mechanism control board, top cover and mecha- Clamper unit 2 nism section. (1) From the bottom side of the mechanism section, remove the clamper 2 spring. (See Fig.5.) (2) Release section e of the clamper spring from the bending section of the CD chassis assembly.
  • Page 16 Clamper 2 spring CD chassis assembly Clamper unit 2 Fig.7 Notch Clamper unit 2 Fig.8 Clamper unit 2 Clamper spring Fig.9 1-16 (No.MA255)
  • Page 17 3.2.6 Removing the front unit (See Figs10 to 12) • Remove the mechanism control board, top cover and mecha- nism section. Flexible wire (1) From the bottom side of the mechanism section, remove the double-stick tape fixing the flexible wire. (See Fig.10.) (2) From the top side of the mechanism section, remove the screw D attaching the front unit 2.

  • Page 18: Cd Chassis Assembly Fig

    3.2.7 Removing the loading arm assembly (See Figs.13 and 14) • Remove the mechanism control board, top cover, mechanism Loading arm assembly section and front unit 2. (1) From top side of the mechanism section, move the loading arm assembly in the direction of the arrow. (See Fig.13.) (2) Release the projections from the right and left joints (m, n) of the CD chassis assembly.

  • Page 19: No.ma255)1

    3.2.8 Removing the rod (L), rod (R) and roller assembly (See Figs.15 and 16) • Remove the mechanism control board, top cover, mechanism Collar Collar section, front unit and loading arm assembly. (1) From the bottom side of the loading arm assembly, release the rod (L) and (R) from the joints r.
  • Page 20 3.2.9 Removing the CD pickup (See Figs.17 to 19) • Remove the mechanism control board. CD mechanism assembly (1) From the bottom side of the CD mechanism assembly, turn the feed gear in the direction of the arrow to move the CD pickup assembly outwards.

  • Page 21: Clamper Unit

    3.2.10 Removing the spindle motor (See Fig.20) • Remove the mechanism control board, top cover, mechanism T. table assembly section and clamper unit. (1) From the top side of the mechanism section, remove the T.table assembly and washer from the spindle motor. Washer (2) Remove the two screws H attaching the spindle motor.
  • Page 22 3.2.12 Removing the SW board and rest SW board (See Fig.23) • Remove the mechanism control board. CD mechanism assembly (1) From the bottom side of the CD mechanism assembly, re- move the screw L attaching the SW board. (2) Remove the screw M attaching the rest SW board. SW board Rest SW board Fig.23...

  • Page 23: Adjustment

    (3) Digital tester Output Level Line out 2.5V (Vol. MAX) (4) Tracking offset meter (5) Test Disc JVC :CTS-1000 Dummy load (6) Extension cable for check Exclusive dummy load should be used for AM,and FM. For FM EXTDV001-20P × 1...

  • Page 24: No.ma255)1

    Service mode 4.2.1 Service mode setting (1) Push POWER button (Power ON) (2) Set to service mode By pushing and holding "DISP" button and "BAND" button sequentially. (3) Select the menu with " " or " " button and decide it with "ENTER" button. (4) When the "BACK"...
  • Page 25 Adj Now CD Data Read Adj Int Others OK : Function Adj Now FEB ** FEO ** TEB ** RFG ** FGA ** TEO ** TGA ** *Adj Now The auto adjustment Value of servo at now Adj Int FEB ** FEO ** TEB ** RFG ** FGA ** TEO ** TGA **...
  • Page 26 DSP Tuner S Mode V=R*** SPI=**** PI=**** **.** SM=**% PTY=** NO PS MP=**% TP/TA=*/* Adj=**% MS/DI=*/* BW=* IF Count :****** **,**,** **,**,** AF **.** MF **.* PI =**** SM=**% SM=**% MP=**% MP=**% A,J=**% A,J=**% ** ** ** ** ** ** ** ** ** ** ** ** ** ** ** ** ** ** ** ** DSP Tuner Adjust...

  • Page 27: Troubleshooting

    SECTION 5 TROUBLESHOOTING Feed section Is 4V present at both Check the feed motor. sides of the feed motor? Check the connections Is the voltage output at between the feed motor pin 4 and pin 5 of IC681? and IC681. Is the power supply Is the voltage input at pin present at pin 3, pin 12...
  • Page 28 Spindle section Does the RF signal appear Is the RF waveform at Is the disk rotated? at pin 83 of IC541? pin 83 of IC541 distorted? Is the voltage output at Check the spindle motor Check the circuits in Proceed to the Tracking pin 6 and pin 7 of IC681? and its wiring.
  • Page 29 Signal processing section Is the sound output from Normal both channels (L, R)? Is the audio signal (including sampling Is the audio signal output No sound from either Is 9V present at pin 24 output components) at pin 18 and pin 19 of channel.
  • Page 30 16PIN CORD DIAGRAM (for northern america) Black WH/BK Green GN/BK VI/BK GY/BK Violet Gray Blue White Yellow BL/WH Brown Orange OR/WH MEMORY OR/WH ILLUMINATION CONTROL GN/BK VI/BK WH/BK GY/BK REMOTE BL/WH TEL MUTING Rear Right ACC Line Front Right Telephone Muting Ground Front Left MEMORY Memory Backup Battery+...
  • Page 31 16P CORD DIAGRAM (for asia) Black Green GN/BK WH/BK VI/BK GY/BK Violet Gray Blue WH White Yellow BL/WH OR/WH Brown Orange MEMORY Choking Coil OR/WH ILLUMINATION CONTROL WH/BK GY/BK GN/BK VI/BK BL/WH REMOTE TEL MUTING Rear Right Auto Antenna Front Right Line Illuminations...
  • Page 32 5.10 16 PIN CORD DIAGRAM (for europe) WH/BK GN/BK VI/BK GY/BK Black Green Violet Blue Gray BL/WH White Yellow OR/WH Orange Brown VI/BK GY/BK MEMORY OR/WH WH/BK BL/WH REMOTE GN/BK VI/BK GY/BK BL/WH OR/WH WH/BK GN/BK Rear Right Auto Antenna Front Right Line...
  • Page 33 (No.MA255)1-33...
  • Page 34 Victor Company of Japan, Limited Mobile Entertainment Business Group Mobile Entertainment Category 10-1,1chome,Ohwatari-machi,Maebashi-city,Gumma-ken, 371-8543,Japan (No.MA255) Printed in Japan...
  • Page 35 SCHEMATIC DIAGRAMS CD RECEIVER KD-SH1000J,KD-SH1000E,KD-SH1000EX KD-SH1000EY,KD-SH1000EU,KD-SH1000U KD-SH1000UN,KD-SH1000UT,KD-SH1000UH CD-ROM No.SML200603 Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade) Contents Block diagram Standard schematic diagrams Printed circuit boards 2-15 to 17 No.MA255SCH COPYRIGHT 2006 Victor Company of Japan, Limited.

  • Page 36: Safety Precaution

    Safety precaution Burrs formed during molding may be left over on some parts of the chassis. Therefore, pay attention to such burrs in the case of preforming repair of this system. Please use enough caution not to see the beam directly or touch it in case of an adjustment or operation check.
  • Page 37 < M E M O >...

  • Page 38: Block Diagram

    Block diagram CD servo control section AD0 to AD11 I00 to I03 MP3STB, MP3RST CDSCK IC653 IC652 CAS, RAS EROMCK, EROMD I CDLRCK OE, WE DRAM MP3/WMA MODESW, ERR/DECEND CDDATA BSGATE IC430 LRCKIB BSBCK LRCK BCKIB X430 CLOCK BSDATA DATA SDI1 SBDATA BSLRCK...
  • Page 39 BZ841,Q841 BUZZER MUTING-CONT Q892,Q893 BUZZER TELMUTE-IN BUSIO, BUSSO, BUS-I/O /BUS-I/O, BUSINT, BUSSCK JBUS-SI/SO CH-L IC801 JBUS-SCK CH-R CD CHANGER JVC BUS CONTROL CODE1 to CODE3 DISPCE, DISPSCK KEYDATA, DISPDATA REMOCON PANEL PM+/- OUT1 RST-101E, PS2 IC961,Q961 MOTOR PMKICK OUT2 IC945...
  • Page 40 Standard schematic diagrams CN721 CN291 Main section QGA2006C1-04 QGB2027M5-20S C147 C146 100P 100P C964 C963 R148 0.01 C148 0.22 0.01 C966 C149 C965 0.01 D149 UDZW11B-X C967 0.01 CN962 QGA2001C1-04 IC961 BA6956AN CODE3 CODE2 CODE1 0.047 C961 C962 100/10 CN961 QGA2501C1-02 Q841 R959...
  • Page 41 R322 R321 LO-FL KTD1304-X KTD1304-X J321 LO-RL Q321 Q341 QNN0748-001 LO-FR R342 R341 R151 LO-RR A-GND OUT-SUBW R332 KTD1304-X R331 R152 Q151 R351 R352 R153 Q351 Q331 KTD1304-X KTD1304-X D321 MC2836-X IN-RR R323 2.2k IN-FR R343 2.2k IN-FL R333 2.2k IN-RL 1B-X R353...
  • Page 42 DSP section C246 ADSP-3.3V REAR-DATA ADATA3 R864 DIRNLRCLK DIRNBCK IC231 DSPB56374AEC C235 DIRN-SUBW R865 ADSP-3.3V PC_8 ADSP-1.25V R231 PC_9 ADSP-GND R232 R233 R234 C236 ADSP-REQ R235 XTAL ADSP-CS R236 ADSP-SCK R237 ADSP-DO R238 ADSP-DI R239 ADSP-RST SP-SCK SP-CS SP-SO SP-SI R862 IC254 MM3141YN-X...
  • Page 43 C246 R261 R259 NQL093K-1R8X L257 DAC-MLCK R257 R255 C268 R266 2.2M IC266 AK4385ET-X C266 X255 L245 C256 PC_8 C255 NQL093K-1R8X R267 220/6.3 PC_9 C267 R245 100p REAR-OUT C245 DAC-PON R268 R-LCH+ DAC-CSN R269 R-LCH- DAC-CCLK R270 R-RCH+ XTAL DAC-CDTI R271 R-RCH- R243 C244...
  • Page 44 Tuner section AF-SAMPLE1 AF-HOLD1 IC15 SAF7730HV/N224A 0.022 10/6.3 10/6.3 10/6.3 10/6.3 QAM0556-001 NAX0749-001X 0.01 4.7/6.3 470p 180p 0.022 0.01 QAU0444-001 0.047 220/6.3 AM-ANT FM-ANT 4.7/6.3 0.0022 220/6.3 390p 4.7/6.3 10/10 0.001 0.001 0.033 AGC-MSB AGC-LSB 0.001 IF-1P 47/6.3 6.8k CLEAN-1.8V IF-1N 0.001 NQR0129-003X...
  • Page 45 REAR-DATA ADATA3 DIRNLRCK DIRNBCK DIRN-SUBW A-GND LINE.IN-L LINE.IN-GND 10/6.3 LINE.IN-R USB-DATA USB-LRCK CH-L USB-BCLK CH-R 10/6.3 100p 100p DSP-INIT-FIN IC141 RDS-CLK NJM4565E-X RDS-DATA RESET-7730 100p TUNER-SCL TUNER-SDA 100p CDDATA CDLRCK 100p CDSCK 470p 0.022 0.01 C141 .047 220/6.3 C143 2.2/50 R145 220/6.3 0.0033...
  • Page 46 CD servo control section C603 100/6.3 C604 Q601 0.01 2SB1132/QR/-W C637 0.047 PVREF C636 0.047 R643 3.3k C632 470p C631 470p C649 0.0056 L622 C612 0.01 C678 470p C677 470p R604 C613 L623 0.01 R603 R602 R601 R615 IC601 PVREF TC94A15FG BUS0 BUS1...
  • Page 47 L431 Q430 L432 R435 2SB624/4/-X L430 R415 C417 C419 4.7/6.3 C415 4.7/6.3 150p R411 R413 8.2k R439 Q431 UN2211-X R431 CD.L-CH 2.2M CD.R-CH C420 C418 R412 C416 R414 X430 L402 8.2k 4.7/6.3 150p 4.7/6.3 NAX0375-001X R416 Q401 ON5V Q402 2SA1037AK/R/-X UN2211-X R402 2.2k...
  • Page 48 LCD / Key control section CN602 VFD1 QLF0164-001 K6301 NQR0007-002X SIG2 CLKG2 X6011 NAX0841-001X NRZ0065-330X NRZ0065-330X NRZ0065-330X IC601 MN103SB9NEG V-CLK V-LAT C6015 V-GCP C6014 V-BK NRZ0065-330X CLKG1 RA608 R6069 SIG1 K6302 NQR0007-002X L6301 K6304 C6016 0.01 0.01 RA609 C6305 C6306 NQR0007-002X R6047 NRZ0065-330X...
  • Page 49 EN601 QSW1025-001 R6151 R6152 R6153 R6154 R6155 2SA1530A/QR/-X Q6151 IC606 R6156 GP1UX511RK D6161 MC2838-X R6165 R6161 R6162 R6163 R6164 R6082 R6166 R6081 Q6161 2SA1530A/QR/-X C6020 0.001 CN601 NNZ0162-001X C6015 C6014 C6025 0.001 R6069 ACC5V KEYDA C6016 0.001 REMC SBRST DISPCK DISPDA DISPCE R6078...
  • Page 50 USB section C401 C403 C402 IC401 TCC760 XA12 USB-MCLK XA11 R418 XA10 L402 C406 0.47 C407 C408 C420 R411 C409 1.5K C410 C411 330P C422 R445 4.7/6.3 C412 C419 R446 XD15 4.7K R407 XD14 XD13 R413 XD12 XD11 C413 XD10 R414 C414 C451...
  • Page 51 C401 UART-RX UART-TX DETACH DIRN-1.8V DIRN-3.3V USB-DATA USB-LRCK USB-BCLK IC442 K4S161622H-UC60 R442 IC441 SA04D70TFI021A C449 C442 C448 XA16 0.1/16 10/6.3 10/6.3 XA15 XD15 R447 XA14 XD14 C431 XA13 C436 XA12 XD13 XD15 XA11 XD12 C443 C446 XA10 0.1/16 0.1/16 C420 XD14 XD11 XD10...
  • Page 52 Printed circuit boards Main board Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade) Forward side D901 C729 D729 C172 C901 C171 C293 D307 C175 D306 CN901 J321 C292 D308 C291 C856 C294 C851 D305 R856 R851...
  • Page 53 Reverse side CN702 C901 D901 CN901 J321 CN291 C817 C988 R981 J801 C304 C314 R201 R206 D331 C991 IC15 R177 L221 L222 R208 C312 C224 C222 C223 C309 R207 IC191 R166 R176 R165 Q301 IC201 C307 IC141 D309 R264 R301 R214 R302 C216...
  • Page 54 CD servo control board Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade) Forward side R572 C649 R635 C637 C599 C629 C615 IC601 R611 C647 C607 C608 IC502 R609 C635 C605 C627 R629 C602 R632 C621 R559...
  • Page 55 < M E M O >...
  • Page 56 Victor Company of Japan, Limited Mobile Entertainment Business Group Mobile Entertainment Category 10-1,1chome,Ohwatari-machi,Maebashi-city,Gumma-ken,371-8543,Japan Printed in Japan (No.MA255SCH)

  • Page 57: Parts List

    PARTS LIST KD-SH1000J,KD-SH1000E,KD-SH1000EX KD-SH1000EY,KD-SH1000EU,KD-SH1000U KD-SH1000UN,KD-SH1000UT,KD-SH1000UH * All printed circuit boards and its assemblies are not available as service parts. - Contents - 3- 2 Exploded view of general assembly and parts list (Block No.M1) 3- 6 CD mechanism assembly and parts list (Block No.MB) 3- 9 Electrical parts list (Block No.01~03)
  • Page 58 Exploded view of general assembly and parts list Block No. UT only Switch board...
  • Page 59 E,EX,EY,EU Main board...
  • Page 60 General Assembly Block No. [M][1][M][M] Symbol No. Part No. Part Name Description Local  GE20156-001A GEAR BKT UNIT FSYH4036-100 SHEET GE30968-002A LEVER BKT UNIT GE30964-003A LOWER LEVER ASS QYWDL215025 SLIT WASHER 5mm/2.1mm x 0.25mm(x2) GE10111-001A TOP CHASSIS GE40135-001A EARTH PLATE GE40259-001A MECHA HEAT SINK LV43854-003A...
  • Page 61  Symbol No. Part No. Part Name Description Local LV36398-001A CAUTION LABEL QLF0164-001 QAL0846-001 FFC CABLE QNZ0856-001 FRONT CONNECTOR QAM0237-001 CAR CABLE E,EX,EY,EU QAM0858-001 LINE IN CABLE VYTA500-001 PIN CAP (x2) QJJ010-040904-E SIN CR C-C WIR QMFZ039-150-T FUSE  GE32166-001A REAR BRACKET QYSDSF2606ZA TAP SCREW...
  • Page 62 CD mechanism assembly and parts list Block No. Grease FMU-JC3-2D = JVS-1003 = MOBIL-1 = JVG-31N = JC-803B The upper surface of chassis turntable rubber rubber 61 38 11.10mm 0.10mm 82 82 Inside 1.2 0.1mm After set pick up apply grease The parts without symbol number are not service.
  • Page 63 CD mechanism Block No. [M][B][M][M] Symbol No. Part No. Part Name Description Local  VKZ4539-056 MINI SCREW (x5) LV10857-002A CHASSIS FRAME 2 LV30225-0J6A SPACER (x2) LV35272-001A DAMPER(F) (x2) LV35273-001A DAMPER(R) QYSPSTU2045MA TAP SCREW M2 x 4.5mm(x3) LV43039-001A DAMPER SP.(R) LV43849-001A DAMPER SP(F2) (x2) LV43041-001A...
  • Page 64  Symbol No. Part No. Part Name Description Local LV43011-001A THRUST SPRING QYSPSFT2040ZA TAP SCREW M2 x 4mm LV21604-004A L.S.HOLDER 1 VKZ4539-056 MINI SCREW (x2) LV34582-002A L.S.HOLDER 2 VKZ4539-056 MINI SCREW (x2) LV34581-002A SUB GUIDE VKZ4539-056 MINI SCREW (x3) LV34915-001A SW LEVER LV43898-001A S.L.SPRING...

  • Page 65: Electrical Parts List

    Electrical parts list Main board  Symbol No. Part No. Part Name Description Local Block No. [0][1] D149 UDZW11B-X Z DIODE  Symbol No. Part No. Part Name Description Local D161 CRS03-W SB DIODE D281 RB051L-40-X SB DIODE D303 CRS03-W SB DIODE IC15 SAF7730HV/N224A...
  • Page 66  Symbol No. Part No. Part Name Description Local  Symbol No. Part No. Part Name Description Local NCB31CK-473X C CAPACITOR 0.047uF 16V K C213 NDC31HJ-101X C CAPACITOR 100pF 50V J NCB31HK-103X C CAPACITOR 0.01uF 50V K C214 NDC31HJ-331X C CAPACITOR 330pF 50V J NCB31EK-223X C CAPACITOR...
  • Page 67  Symbol No. Part No. Part Name Description Local  Symbol No. Part No. Part Name Description Local C412 NCB31CK-104X C CAPACITOR 0.1uF 16V K C915 NCB31HK-104X C CAPACITOR 0.1uF 50V K C413 NCB31CK-104X C CAPACITOR 0.1uF 16V K C917 NEAF1CM-106X E CAPACITOR 10uF 16V M...
  • Page 68  Symbol No. Part No. Part Name Description Local  Symbol No. Part No. Part Name Description Local NRSA63J-470X MG RESISTOR 47Ω 1/16W J R239 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J NRSA63J-470X MG RESISTOR 47Ω 1/16W J R240 NRSA63J-0R0X MG RESISTOR 0Ω...
  • Page 69  Symbol No. Part No. Part Name Description Local  Symbol No. Part No. Part Name Description Local R419 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R755 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R421 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R756 NRSA63J-0R0X MG RESISTOR 0Ω...
  • Page 70  Symbol No. Part No. Part Name Description Local  Symbol No. Part No. Part Name Description Local R912 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J QZW0010-001 STYLE PIN Ω U,UN, TH945 NAD0031-005X N THERMISTOR R913 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J UT,UH ...
  • Page 71  Symbol No. Part No. Part Name Description Local  Symbol No. Part No. Part Name Description Local C6306 NCZ1070-103X C CAPACITOR 0.01uF R6161 NRSA63J-301X MG RESISTOR 300Ω 1/16W J C6307 NCB31HK-104X C CAPACITOR 0.1uF 50V K R6162 NRSA63J-271X MG RESISTOR 270Ω...
  • Page 72  Symbol No. Part No. Part Name Description Local  Symbol No. Part No. Part Name Description Local S6154 NSW0246-001X TACK SW C608 NCB31CK-104X C CAPACITOR 0.1uF 16V K S6155 NSW0246-001X TACK SW C610 NCB31CK-104X C CAPACITOR 0.1uF 16V K S6156 NSW0246-001X TACK SW...
  • Page 73  Symbol No. Part No. Part Name Description Local  Symbol No. Part No. Part Name Description Local R438 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R584 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R439 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R585 NRSA63J-101X MG RESISTOR 100Ω...
  • Page 74  Symbol No. Part No. Part Name Description Local R908 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J R909 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J L432 NQL093K-1R8X COIL 1.8uH K L501 NQL114K-470X COIL 47uH K L502 NQL114K-470X COIL 47uH K L621 NQL114K-470X COIL 47uH K L622...
  • Page 75 <MEMO> 3-19...
  • Page 76 Packing materials and accessories parts list Block No. No additional / supplemental order of WARRANTY CARDs are available A1A2 A3 A1A2 A24 A25 U only KD-SH1000E,EX,EY,EU KD-SH1000U,UN,UT,UH KD-SH1000J KIT: A5 A6 A7 A8 A9 KD-SH1000E,EX,EY,EU,U 3-20...
  • Page 77 Packing and Accessories Block No. [M][3][M][M] Symbol No. Part No. Part Name Description Local  GET0364-001A INST BOOK ENG FRE SPA GET0366-002A INST BOOK SPA GRE POR GET0366-003A INST BOOK ENG FRE EX,EU GET0366-007A INST BOOK POL CZE HUN GET0365-001A INST BOOK ENG THA U,UH...
