- Page 1 SERVICE MANUAL REFRIGERATION © ELECTROLUX ZANUSSI Publication number EUROCOMBI ELETTRODOMESTICI S.p.A. 599 34 04-61 VIA GIARDINI CATTANEO, 3 2001-01-15 I - 33170 PORDENONE (ITALY) EN/SERVICE/AA Fax (0434) 394096 This publication updates and replaces the previous.
- Page 2 Eurocombi 2/32...
-
Page 3: Table Of Contents
CONTENTS 1. Introduction Presentation page 5/33 Eurocombi: total nofrost page 7/33 2 Characteristics Dimensions and volumes page 8/33 Characteristics page 8/33 Circuit diagram page 10/33 3 Components 3.1. Main components page 11/33 3.2. Electronic module page 13/33 3.2.1. CTB – Control board page 14/33 3.2.2. - Page 4 Eurocombi 4/32...
-
Page 5: Introduction
The temperature inside the refrigerator compartment is controlled by a flap-operated mechanical thermostat. The Eurocombi range consists of eight models, with ALFA or DELTA stylings. All models are arched doors. The differences between the various models consist in the size of the refrigerator and freezer compartments and therefore in the number of shelves and drawers. - Page 6 Markets: UK, Spain, France, Germany, Italy, Sweden, Norway, Finland, Est Europe. Brands: Zanussi, Electrolux, AEG, AME, Frigidaire, Corbero’. Eurocombi 6/32...
-
Page 7: Eurocombi: Total Nofrost
1.2. Eurocombi: total no-frost The Eurocombi is a total no-frost appliance, and as such its operation is based exclusively on the battery evaporator in the freezer compartment, which cools the air; the air is circulated by the fan. A duct embedded in foam channels the cold air into the refrigerator compartment, where the flap-operated mechanical thermostat regulates the flow of cold air and thus the temperature inside the refrigerator compartment. -
Page 8: Characteristics
2. CHARACTERISTICS 2.1. Dimensions and volumes The models in the Eurocombi range are numbered from 1 to 9 (with the exception of number 7, which has been eliminated). Model no. height* 1950 1800 1800 1800 1650 1650 1750 1950 width depth gross vol. - Page 9 -22°C -12°C -23°C -24°C -12°C Normal operating times: pre-determined** minimum maximum ** A six-hour operating cycle is performed each time the appliance is switched on. Defrosting: standard time minutes maximum time minutes temp. for end of defrosting °C Eurocombi 9/32...
-
Page 10: Circuit Diagram
1 power supply; 2 compressor; 5 fan; 9 defrosting heater; 11 drainage duct heater; 13 refrigerator light; 16 freezer switch; 26 safety switch (+55°C); 28 condenser; 41 electronic circuit board; 56 air sensor for refrigerator (optional); 57 external (in air) NTC sensor; 59 NTC sensor for evaporator. Eurocombi 10/32... -
Page 11: Components
3. Evaporator battery 4. Evaporator fan 5. Defrosting heater 6. Drainage duct heater 7. External (in air) NTC sensor 8. Heat cut-outs (+55°C), NTC sensor for evaporator 9. Power board (PWB) 10. Condenser fan 11. Condenser 12. Compressor Eurocombi 11/32... - Page 12 Eurocombi 12/32...
-
Page 13: Electronic Module
3.2. Electronic module The control system on the Eurocombi features four inputs and six outputs: inputs: • NTC sensor on evaporator; • External (in air) NTC sensor; • Refrigerator door switch (reed element with foam-embedded magnet in door) • Freezer door switch outputs: •... -
Page 14: Ctb - Control Board
NTC switches the compressor on again when the temperature falls to below 65°C, thus keeping the fans in operation. 3.2.3. Connection box The connection box is located inside the freezer compartment. The NTC sensors, heaters, evaporator fan and freezer door switch are connected to the connection box. Eurocombi 14/32... -
Page 15: Fans
As the refrigerator compartment is cooled only by the cold air ducted in by the evaporator fan, the fans switch on again after 30 minutes even if the compressor remains off. compressor fans Eurocombi 15/32... -
Page 16: Door Aperture With Compressor
If one of the doors is opened while the compressor is not in operation, during the period of 30 minutes in which the fans are switched off, the fans will switch on again for two minutes from the moment the door is closed. Thereafter, the fans switch off automatically. compressor fans doors Eurocombi 16/32... -
Page 17: Heating Elements
°C 5348±0.6 6818±0.4 8758±0.4 11337±0.4 14795±0.6 19475±0.7 25862±0.8 34666±0.9 46921±1 64161±1 88577±1 3.6. Overheating protection In case of a malfunction, two heat cut-outs fitted to the evaporator battery switch the heating elements off at a temperature of +55°C. Eurocombi 17/32... -
Page 18: Evaporator
(in air) bulb reaches the cut-in temperature, the flap opens, thus allowing cold air to enter from the freezer compartment. When the temperature in the refrigerator compartment reaches the cut-out value, the flap re-closes and prevents further air from being ducted into the refrigerator compartment. Eurocombi 18/32... -
Page 19: Operation
4 hours and an upper limit of 25 hours. In this way, the appliance adapts the duration of the normal operating cycle to the duration of the previous defrosting cycle: this is the concept of adaptivity which distinguishes the Eurocombi range of fridge-freezers. compressor... -
Page 20: Control Panel
In order to ensure that the circuit does not remain pressurized, the electronic system introduces a 5-minute delay in compressor start-up each time the appliance is switched on. If it is desired to override this delay, press the alarm buttons (b and c) simultaneously within 15 seconds after switching on the appliance. Eurocombi 20/32... -
Page 21: Door Open" Alarm
The electronic control system memorizes the time that has elapsed after selection of the “rapid freezing” function so that, in the event of a temporary power failure, the function does not restart from the beginning, but from the point at which it was interrupted. Eurocombi 21/32... -
Page 22: Ntc Sensors Failure
22 minutes failure Evaporator NTC First start 6 hours 10 min pause 22 minutes sensor + Air NTC 15 min run sensor During working latest time before latest times before 22 minutes failure failure (no adaptivity) Eurocombi 22/32... -
Page 23: Service Mode
In case of a fault in one of the sensors, the LEDs will begin to flash as follows 5 seconds after selection of service mode. 1. NTC sensor on evaporator: LEDs b and e flash 2. ambient NTC sensor: LEDs c and e flash If no faults are detected, only the ON/OFF LED (e) flashes. Eurocombi 23/32... -
Page 24: Separate Activation Of Loads
10 seconds, after pressing the “rapid freezing” button the buzzer counts the hundreds. To count the tenths and the unit of days the operation is the same. For the tenths press the “temperature” button and for the units the “door open” button. Eurocombi 24/32... -
Page 25: Demo Mode
7.3. Exiting Demo mode To exit Demo mode, it is necessary to disconnect the appliance from the power supply. Press the ON/OFF button (e) for at least 2 seconds to enter Demo mode with the appliance switched off (Demo OFF operation). Eurocombi 25/32... -
Page 26: Flap-Operated Thermostat
(warning: heat the hooks with an hairdryer in order to avoid their breakage; the hooks are not replaceable). remove the thermostat rod cover. Eurocombi 26/32... -
Page 27: Control Board (Ctb)
8.2. Control board (CTB) remove the board cover. Eurocombi 27/32... - Page 28 PCB. remove the electronic board Eurocombi 28/32...
-
Page 29: Freezer Compartment
Eurocombi 29/32... - Page 30 (1), the evaporator sensor (2), the ambient sensor (3) and the freezer compartment door switch. Eurocombi 30/32...
-
Page 31: Glass Shelves
B. 8.5. Air inlets The air inlets through which air returns to the freezer compartment are pressure-fitted. To remove them, simply lever off using a screwdriver. Eurocombi 31/32... -
Page 32: Power Board (Pwb)
(1) and remove the housing (2). Eurocombi 32/32...
