PQS-202 Mk II User Manual
This product complies with European Union EMC Directive
(89/336/EEC) and the Low Voltage Directive (73/23/EC)
© German Physiks 2007, 2008
Revision d
th
Released 26
August, 2008
We reserve the right to change the information contained in this manual without notice. For the
latest version please see our web site at www.german-physiks.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for German Physiks PQS-202 Mk II
Summary of Contents for German Physiks PQS-202 Mk II
- Page 1 PQS-202 Mk II User Manual This product complies with European Union EMC Directive (89/336/EEC) and the Low Voltage Directive (73/23/EC) © German Physiks 2007, 2008 Revision d Released 26 August, 2008 We reserve the right to change the information contained in this manual without notice. For the...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. INTRODUCTION ..........................3 2. UNPACKING YOUR LOUDSPEAKERS ....................3 3. PRINCIPLE FEATURES OF THE PQS-202 Mk II ................4 4. LOUDSPEAKER PLACEMENT AND SET-UP ..................5 Adjusting the Spikes.........................5 Listening Room Layout ........................7 Loudspeaker Placement ........................7 Distance from the Front Wall ......................7 Distance from the Side Wall .......................7... -
Page 3: Introduction
Thank you for selecting the German Physiks PQS-202 Mk II loudspeakers for your audio system. The PQS-202 Mk II is a 3 way design based on our PQS-201 loudspeaker. It is designed for use in high-end 2-channel systems and also as the front loudspeakers in high quality home theatre systems. It may be positioned directly against the front wall to minimise its intrusion into the listening room. -
Page 4: Principle Features Of The Pqs-202 Mk Ii
The use of any other packing may result in the loudspeakers sustaining damage in transit. Such damage is not covered by the warranty. Should you require replacement packing, please contact your German Physiks dealer, the national distributor or the factory directly. 3. PRINCIPLE FEATURES OF THE PQS-202 Mk II Top plate Input terminals &... -
Page 5: Loudspeaker Placement And Set-Up
The base of the PQS-202 Mk II is fitted with four spikes. These are double ended as shown in figure 4 and are locked in position with a nut. You will need an open ended 10mm spanner to adjust them - figure 5. - Page 6 The round ends of the spikes should be used when the loudspeakers are to be placed on a hard floor such as tile or wood and the pointed ends should be used when the loudspeakers are to be placed on a carpeted floor.
-
Page 7: Listening Room Layout
Listening Room Layout The following points will help you optimise your listening room layout. 1. The left and right sides of the room should be symmetrical. If the room is asymmetrical, this will degrade the quality of the stereo image. This is because most of the sound energy that you hear is reflected before it reaches your ears. - Page 8 Minimum: against wall Optimum: 1 metre/3.3 feet or more Distance = “d” Minimum: Minimum: 1 metre/3.3 feet 1 metre/3.3 feet Listening Position Do not have the listening position closer than 1.2m from the rear wall Figure 6. Listening Room Arrangement...
-
Page 9: Connecting Your Loudspeakers
An amplifier capable of delivering at least 100W into 4 ohms should be used for each loudspeaker. The PQS-202 Mk II is a 3 way design with separate input terminals for the low frequency and high frequency sections of the crossover. These drive the woofer/sub woofer and DDD driver respectively. -
Page 10: Single Wire Connection
Single Wire Connection This uses one cable to connect each loudspeaker to the power amplifier. The two red terminals and the two black terminals on the crossover panel should be linked together. The loudspeaker will be shipped with high quality links in this position. Connect the loudspeaker cable to the woofer input terminals taking care to ensure that the woofer positive terminal is connected to the power amplifier positive output terminal and the woofer negative terminal is connected to the power amplifier negative output terminal. -
Page 11: Loudspeaker Cables
Remove the DDD Driver Cover 7. LOUDSPEAKER BREAK IN Like all audiophile equipment, German Physiks loudspeakers require a break in period from new before they reach their optimum level of performance. Initially the sound may seem harsh. Please do not be concerned. The sound will become more relaxed and smooth as the break in progresses. The music used for the break in should be dynamic in order to properly exercise all the components of the loudspeakers. -
Page 12: Care Of Your Loudspeakers
German Physiks to decide the best way to affect a repair. If they are unable to assist you, please contact German Physiks by phone on + 49 61 09 50 29 823, by fax on + 49 61 09 50 29 826, or by email at service@german-physiks.com. -
Page 13: How To Contact Us
German Physiks dealer or the factory. For items returned to the factory under warranty during the first year, German Physiks will pay for the shipping charges both ways. A shipping company approved by German Physiks must be used and the items will be returned to the customer using the same carrier, or an equivalent service. -
Page 14: Pqs-202 Mk Ii Specifications
12. PQS-202 Mk II SPECIFICATIONS Version With DDD Titanium Driver With DDD Carbon Driver Impedance 3 ohms 3 ohms Frequency Response 35 - 21,500Hz 35 - 24,000Hz Power Handling Nominal 300W 300W Short term 600W 600W Amplification required Minimum 100W/4 ohms Crossover frequency 120Hz &... -
Page 15: Warranty Registration
7 days of purchase and return it by post together with a copy of the receipt of purchase to: DDD-Manufactur GmbH Gutenbergstraße 4 D-63477 Maintal GERMANY Name Address Country Zip/Post Code Model PQS-202 Mk II DDD Type Titanium / Carbon. Delete as necessary Serial Number See label under speaker Finish Date of Purchase Where...
