PQS-402 User Manual
This product complies with European Union EMC Directive
(89/336/EEC) and the Low Voltage Directive (73/23/EC)
© German Physiks 2007
Revision o
Released 20th October 2007
We reserve the right to change the information contained in this manual without notice. For the
latest version please see our web site at www.german-physiks.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PQS 402 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for German Physiks PQS 402

Summary of Contents for German Physiks PQS 402

  • Page 1 PQS-402 User Manual This product complies with European Union EMC Directive (89/336/EEC) and the Low Voltage Directive (73/23/EC) © German Physiks 2007 Revision o Released 20th October 2007 We reserve the right to change the information contained in this manual without notice. For the...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. INTRODUCTION ..........................3 2. UNPACKING YOUR LOUDSPEAKERS ..................3 3. ASSEMBLING YOUR LOUD SPEAKERS ..................5 Introduction ..........................5 Assembly Procedure ......................... 6 4. CONNECTING YOUR LOUDSPEAKERS ..................10 High Frequency Level Control ....................10 Low Frequency Level Control ....................10 Input Terminal Connections ......................

  • Page 3: Introduction

    1. INTRODUCTION Thank you for selecting the German Physiks PQS 402 for your audio system. It uses an array of two DDD drivers to cover all frequencies above 220Hz. The low frequencies are handled by a system using two 10 inch drivers combined with four 8 inch passive radiators. The Loreley is entirely handmade and is built and tested by highly skilled technicians at our factory in Germany.
  • Page 4 5.. Top Plate 4. Upper Module 6. DDD Tower 3. Distance Frame 2. Lower Module 1. Bottom Plate Figure 1. PQS-402 Major Components...

  • Page 5: Assembling Your Loud Speakers

    These tasks will be carried out by the supplying dealer who has received detailed training from German Physiks engineers. Many of the component parts are very heavy and personal injury could result if they are inappropriately lifted.

  • Page 6: Assembly Procedure

    Assembly Procedure 1. Place the left loudspeaker bottom plate on the floor in the position where the speaker is to be sited. Ensure that it is sitting squarely on all 5 support points and that it is level. 2. Identify the left lower module. This has the input terminals and level selectors on its rear face.
  • Page 7 Figure 5. Fitting Upper Module and Connection Cables 4. The next operation must be carried out by two people. You will need 8 of the black inter-cabinet connecting cables ready to hand. Identify the left loudspeaker upper module. Place this on top of the distance frame and ensure that it is properly seated.
  • Page 8 Figure 6. Top Plate Cable Connection 5. Identify the left loudspeaker top plate and fit one black and one red cable to each pair of sockets as shown in figure 6. Figure 7. Top Plate Adjusting Screws The top plate has 3 screws, marked X in figure 7, which will be used by the dealer to adjust the module stack for any variation in verticality.
  • Page 9 Figure 8. Fitting the DDD Tower and Top Plate 6. Identify the DDD tower. Referring to figure 8, carefully fit the base of the DDD tower, Y, over the locating disc on the bottom plate and ensure that it is sitting squarely. Take great care not to damage the front of the lower bass module with the DDD tower, as there is very little clearance between where the DDD tower fits and the bass module.

  • Page 10: Connecting Your Loudspeakers

    4. CONNECTING YOUR LOUDSPEAKERS The German Physiks PQS-402 is a 2 way loudspeaker with separate input terminals for the low frequency and high frequency sections of the crossover. These drive the woofers and DDD drivers respectively and are labeled as such. Provision is also made to allow the output level of the low frequency and high frequency cross overs to be adjusted.

  • Page 11: Input Terminal Connections

    5. LOUDSPEAKER BREAK IN Like all audiophile equipment, German Physiks loudspeakers require a break in period from new before they reach their optimum level of performance. The music used for the break in should be dynamic in order to properly exercise all the components of the loudspeaker.

  • Page 12: Loudspeaker Placement And Set-Up

    Before the loudspeakers can be set up, the break in procedure in section 5 must be completed. The German Physiks PQS-402 is an extremely high performance loudspeaker and optimum performance will only be achieved when set up by a trained technician. For this reason the supplying audio dealer will carry out the set-up for the customer.
  • Page 13 We do not recommend placing the loudspeakers closer than 1m from the side walls, as the early reflections will degrade the stereo image. Positioning the speakers too close to the side walls will also lead to an uneven bass response. Aim to find the position that provides the best defined and most realistic stereo image when you are seated at the listening position.

  • Page 14: Care Of Your Loudspeakers

    German Physiks to decide the best way to affect a repair. If they unable to assist you, please contact German Physiks by phone on + 49 61 09 50 29 823, by fax on + 49 61 09 50 29 826, or by email at service@german-physiks.com.

  • Page 15: How To Contact Us

    German Physiks dealer or the factory. For items returned to the factory under warranty during the first year, German Physiks will pay for the shipping charges both ways. A shipping company approved by German Physiks must be used and the items will be returned to the customer using the same carrier, or an equivalent service.

  • Page 16: Pqs-402 Specifications

    11. PQS-402 SPECIFICATIONS Version With Titanium DDD Drivers With Carbon DDD Drivers Impedance 2.2 ohms at 1,200 Hz 2.2 ohms at 1,200 Hz Frequency Response 25 – 21,500 Hz 25 – 24,000 Hz Power Handling Nominal 450W 450W Short term 750W 750W DDD Section: Minimum 140 watts into 4 ohms...

  • Page 17: Warranty Registration

    7 days of purchase and return it by post together with a copy of the receipt of purchase to: DDD-Manufactur GmbH Gutenbergstraße 4 D-63477 Maintal GERMANY Name Address Country Zip/Post Code Speaker Model German Physiks PQS 402 DDD Type Titanium/Carbon Delete as necessary Serial Number Finish Date of Purchase Where Purchased...
